Sagem MY200C User manual

ENGLISH
252852454_LU_my200C_en.book Page 1 Jeudi, 21. décembre 2006 2:24 14

252852454_LU_my200C_en.book Page 2 Jeudi, 21. décembre 2006 2:24 14

3
You have just purchased a SAGEM mobile phone, and we
congratulate you on your choice.
Your phone can be used internationally in the various dual band
networks (GSM 900 MHz and DCS 1800 MHz) depending on the
roaming arrangements with your operator.
This phone is approved to meet European standards.
We recommend that you read this handbook carefully before using
your phone efficiently and in the best conditions.
WARNING
Depending on the configuration of the networks and the associated
subscriber cards, some functions may not be available.
SAGEM is a trademark of Sagem Communication SAFRAN Group.
AT® is a registered trademark of Hayes Microcomputer Products Inc.
Hayes® is a registered trademark of Hayes Microcomputer Products Inc.
T9 ® Text Input is a registered trademark of ©Tegic Communications
Inc.
T9 is protected by one or more of the following US patents:
5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other
patents are being applied for worldwide.
252852454_LU_my200C_en.book Page 3 Jeudi, 21. décembre 2006 2:24 14

4 Contents
Contents
Menus ..................................................................................... 7
Your phone package - Accessories..................................... 8
Description............................................................................. 9
Principles of navigation...................................................... 12
Home page ........................................................................... 13
Activating your phone......................................................... 14
Information on the SIM card.....................................................14
Installing the SIM card and installing the battery .....................15
Charging the battery ................................................................16
Do NOT obstruct the antenna with your fingers.......................18
Getting started .........................................................................18
PIN Number .............................................................................18
Setting time and date ...............................................................19
Network....................................................................................20
First call....................................................................................20
Receiving a call........................................................................21
Switching off.............................................................................21
Phonebook........................................................................... 22
Using the phonebook ...............................................................22
Phonebook menu.....................................................................23
Call groups...............................................................................24
Messages ............................................................................. 25
Composing messages .............................................................25
Receiving messages................................................................28
Inbox ........................................................................................28
Drafts .......................................................................................29
Options.....................................................................................29
Memory ....................................................................................29
Games .................................................................................. 30
252852454_LU_my200C_en.book Page 4 Jeudi, 21. décembre 2006 2:24 14

Contents 5
Sounds..................................................................................31
Volume and ring tone............................................................... 31
Vibrate ..................................................................................... 31
Silent mode.............................................................................. 31
Beeps ...................................................................................... 32
Background..........................................................................33
Colours .................................................................................... 33
Wallpapers............................................................................... 33
Screensavers........................................................................... 34
Greeting message ................................................................... 34
Settings.................................................................................35
Date / Time .............................................................................. 35
My objects................................................................................ 35
Languages............................................................................... 36
Networks.................................................................................. 36
Contrast ................................................................................... 36
Energy saving.......................................................................... 36
Leds......................................................................................... 37
Short cuts ................................................................................ 37
Active flap ................................................................................ 37
Calls ......................................................................................38
Forward calls ........................................................................... 38
View last calls .......................................................................... 38
Counters .................................................................................. 38
Display numbers ...................................................................... 39
Call waiting .............................................................................. 39
Automatic redial....................................................................... 39
Blacklist.................................................................................... 40
Answer phone number............................................................. 40
Local info ................................................................................. 40
Security.................................................................................41
PIN number.............................................................................. 41
PIN number 2........................................................................... 41
Phone code ............................................................................. 42
252852454_LU_my200C_en.book Page 5 Jeudi, 21. décembre 2006 2:24 14

6 Contents
Confidentiality ..........................................................................42
Operator code ..........................................................................42
Call barring...............................................................................43
Fixed dialling ............................................................................43
Cost..........................................................................................44
Accessories ......................................................................... 45
Calendar ..................................................................................45
Calculator.................................................................................45
Converter .................................................................................46
Alarm........................................................................................46
Timer........................................................................................47
Data .........................................................................................47
Services................................................................................ 48
Technical features............................................................... 49
Conformance Document..................................................... 50
Care and safety information............................................... 51
SAR..........................................................................................51
Advice for limiting exposure to radiofrequency (RF) fields.......52
Safety.......................................................................................52
Environment.............................................................................54
Warranty............................................................................... 55
End User Licence Agreement (EULA), for the software .. 60
Troubleshooting .................................................................. 67
Customer care ..................................................................... 71
Index ..................................................................................... 72
252852454_LU_my200C_en.book Page 6 Jeudi, 21. décembre 2006 2:24 14

Menus 7
Menus
Phonebook
Phonebook menu
Messages
Compose
Inbox
Drafts
Options
Memory
Games
Sounds
Ring tones
Vibrate
Silent mode
Beeps
Background
Colours
Wallpapers
Screensavers
Greeting msg
Settings
Date/Time
My objects
Languages
Networks
Contrast
Energy saving
Leds
Short cuts
Active flip
Calls
Calls forwarded
View last calls
Counters
Display numbers
Call waiting
Auto redial
Blacklist
Answ. phone nb.
Local info.
Security
PIN number
PIN number 2
Phone code
Confidentiality
Operator
Call barring
Fixed dialling
Cost (depending on
model)
Accessories
Calendar
Calculator
Converter
Alarm
Timer
Data
Services
252852454_LU_my200C_en.book Page 7 Jeudi, 21. décembre 2006 2:24 14

8 Your phone package - Accessories
Your phone package - Accessories
When you open the box, check that all the items are present:
1 - Phone
2 - Mains charger
3 - Battery
4 - User manual
Accessories
We advise you the use of SAGEM brand accessories for an optimal
operating of your phone and of your accessories. You can also find
(as an option) or order the following accessories:
-Pedestrian kit
-Extra battery
-Extra charger
-USB cable (with associated drivers) to connect your phone to a
PC
-Cigar lighter adapter
For more information: www.planetsagem.com.
252852454_LU_my200C_en.book Page 8 Jeudi, 21. décembre 2006 2:24 14

Description 9
Description
252852454_LU_my200C_en.book Page 9 Jeudi, 21. décembre 2006 2:24 14

10 Description
Programmable keys and Shortcut keys
Short press : Switch on
Hold down: Switch off
In a call context: Rejects a call - hangs up
In menus: Return to home page.
Short
press: Activate/Deactivate hands-free mode
(
WARNING: in this mode do not bring the phone up to
your ear)
In call context: Call - receiving a call
Left programmable key:
In home page: Access to certain functions (shortcuts)
In menus: Access to the selection shown on screen in the
tab (*)
During a call: Reduces the volume
Right programmable key:
In home page: Access to certain functions (shortcuts)
In menus: Access to the selection shown on screen in the
tab (*)
During a call: Increases the volume
Central key:
In menus: Validation
In home page: Access to menus
S Up key: Previous choice / increase value / top
T Down key: Down choice / reduce value / down
W Left key: Up input field / move left
X Right key: Down input field / move right
252852454_LU_my200C_en.book Page 10 Jeudi, 21. décembre 2006 2:24 14

Description 11
∗ Key :
When composing a message:
Short press : upper case/lower case
In call reception mode: Short press stops ring tone
Hold down: In home page: Silent mode
Hold down:
# Key: Zoom mode (see Messages menu)
When composing a message:
Short press: access to the symbol table
(*) In this manual, when a function is chosen by pressing on this
key, square brackets are used (e.g.: [ Save ]).
252852454_LU_my200C_en.book Page 11 Jeudi, 21. décembre 2006 2:24 14

12 Principles of navigation
Principles of navigation
These basic principles bring a great deal of intuitiveness to your
phone
Accept by pressing the left programmable key .
Cancel by pressing the right programmable key .
The tabs on the sides at the bottom of the screen refer to the
Programmable keys .
In the menus a title bar indicates the down higher level.
The
S T W X arrows are used to navigate from a menu to the
other (or from one a sub-menu to the other).
The
left programmable key is used to go from a menu to a
sub-menu.
The
right programmable key is used to go from a sub-menu to
a menu.
The first menu level can be identified by a large animated icon in the
centre of the screen.
The key (press briefly) is used to return to the home page (current
function is abandoned).
252852454_LU_my200C_en.book Page 12 Jeudi, 21. décembre 2006 2:24 14

Home page 13
Home page
The home page contains the following
1 - The title bar icons:
Battery
Calls forwarded
Call (establishing the call)
Call (hands free)
SMS (reception of an SMS)
Silent mode
Message in answer phonebox
Home zone
HPLMN / roaming
Signal strength level (5 bars).
2 - Date and time, in digital or analogue mode
3 - Network provider
4 - Tab centred on down line:
the main "menu" tab shows that the menu can be accessed via the
down / up T S keys. The following information may also be
displayed: "1 message received"; or "1 call". They can be deleted by
pressing the key briefly.
252852454_LU_my200C_en.book Page 13 Jeudi, 21. décembre 2006 2:24 14

14 Activating your phone
Activating your phone
Information on the SIM card
To use your phone, you have a smart card called a
SIM card. It contains all the information needed by
the network as well as other information unique to you
and that you can modify:
-Secret codes (PIN(s): Personal Identification Numbers), these
codes allow you to restrict access to your SIM card.
-Phonebook,
-Messages,
-How special services work.
WARNING
This card must be handled and stored with care to avoid
damaging it by scraping or bending it. If you should lose your
SIM card, contact your operator or your SMC (Services
Marketing Company) immediately.
Comment : do not leave your SIM card within the reach of
young children.
252852454_LU_my200C_en.book Page 14 Jeudi, 21. décembre 2006 2:24 14

Activating your phone 15
Installing the SIM card and installing the
battery
Switch off your phone and disconnect the
charger.
The SIM card is inserted beneath the
phone’s battery.
Slide the SIM card, with cut corner as
shown on the phone, into the card
holder with fold face down.
Place the battery by first inserting the
upper section into the opening.
Replace the back cover, making it
slide.
1
2
3
1
2
3
252852454_LU_my200C_en.book Page 15 Jeudi, 21. décembre 2006 2:24 14

16 Activating your phone
Charging the battery
Your phone is powered by a rechargeable
battery. A new battery must be charged for at
least 4 hours before being used for the first
time. It reaches its optimum capacity after a
few cycles of use.
When your battery has been discharged, the
phone displays the state (empty battery icon
flashes). In this case recharge your battery
for at least 15 minutes before making any more calls so as to avoid
being cut off mid-call.
To recharge the battery
Connect the charger to a mains socket.
Plug the end of the cable into the connector at the base of the phone.
The phone starts to charge up. Charging stops by itself. Disconnect
the cable.
252852454_LU_my200C_en.book Page 16 Jeudi, 21. décembre 2006 2:24 14

Activating your phone 17
It is possible that the battery may heat up slightly during charging;
this phenomenon is normal.
WARNING
There is danger of explosion if the battery is placed in an
incorrectly way or if it is exposed to fire.
Do not short circuit it.
The battery does not have any part that you can change.
Do not try to open the battery casing.
Use only the appropriate chargers and batteries as shown in the
phone manufacturer's catalogue.
The use of other types of chargers or batteries may be
dangerous or invalidate the warranty.
Used batteries must be disposed of in the appropriate places.
We advise you to take the battery out if you plan not to use the
phone for extended periods.
You are strongly advised not to connect your phone to the
charger if it doesn’t contain a battery.
The charger is a safety step-down transformer, it is forbidden to
modify, alter or replace it by another component (power supply
plug, etc).
If the battery has entirely discharged, the phone cannot start.
Plug the phone to the charger. The phone will switch on after a
few minutes of charge. You can use the phone again when the
Start option is displayed on the screen.
252852454_LU_my200C_en.book Page 17 Jeudi, 21. décembre 2006 2:24 14

18 Activating your phone
Do NOT obstruct the antenna with your
fingers
The antenna is integrated in your phone, under the back cover at the
top.
Avoid putting your fingers on this area when the phone is switched
ON.
If your fingers obstruct the antenna, the phone may have to operate
with a higher power level than usual; decreasing its efficiency
quickly. It could also affect the quality of your communications.
Getting started
You are now ready to use your phone for the first time.
Switch on the phone by pressing the key. A short display appears.
PIN Number
This is your SIM's secret code.
If access to the SIM card is protected, the phone prompts you to
enter the PIN number:
Enter the code between 4 and 8 digits given to you when the SIM
card was issued. These digits do not appear on the screen for
security reasons.
Press the
left programmable key to accept.
252852454_LU_my200C_en.book Page 18 Jeudi, 21. décembre 2006 2:24 14

Activating your phone 19
If your phone indicates that the SIM is missing, press the key to
switch off your phone and check that the SIM card is correctly
installed.
Setting time and date
When you use your phone for the first time, you need to set the date
and time.
In due course, when the battery is completely discharged, or if it has
been removed, you will be prompted systematically to confirm date
and time.
Setting the date
Set the date by entering it directly in numerical form or by using the
down / up T S keys to decrease or increase the default values.
Use the
right key X (or left key W ) to access the next (or last) data
input field.
Once the date is correct, press the
left programmable key to
accept .
Setting the time
Same procedure as for setting the date.
WARNING
If a wrong PIN number is entered three times in succession,
your SIM card is blocked. You must then:
-Enter the PUK (Personal Unblocking Key) code provided by
your operator, and accept.
-Enter your PIN number and accept.
-Enter your PIN number again and accept.
After 5 or 10 failed attempts (depending on the type of SIM
card), the SIM card is definitely locked. You must then contact
your operator or your SMC to obtain a new card.
252852454_LU_my200C_en.book Page 19 Jeudi, 21. décembre 2006 2:24 14

20 Activating your phone
Network
From now on the phone hunts for a network on which it can make
calls. If it finds one, it displays the name of the network on the screen.
You are then ready to send or receive a call.
First call
Dial the number of your caller.
Press the key.
During the call, the call in progress icon flashes on screen and tones
may indicate the establishment of the call.
Once communication has been established, the call icon stops
flashing.
You can adjust the sound level (volume) using the
left and right
programmable keys .
At the end of the conversation press the key to hang up.
If the network icon appears, calls are possible on your
operator's network.
If the letter
R and a network name are displayed, calls are
possible on the network of a different operator.
If the letter
E is displayed without any network name, only the
emergency services are accessible (ambulance, police, fire
brigade).
If the network icon flashes, the phone is in permanent search
mode. There is no network available. The signal strength
indicator received allows you to display the quality of reception.
If it indicates less than three bars, search for better reception in
order to call in good conditions.
252852454_LU_my200C_en.book Page 20 Jeudi, 21. décembre 2006 2:24 14
