Sailwin SW-A6V6BW Operator's manual

DMX CHANNEL
Core APP Batery it has 6 and 10 DMX channel mode.
User can choose mode by menu, chnd and choose 6/10 DMX channel
mode
Power supply: AC110V-250V
Frequency: 50-60Hz
Power consumption: 108W
Light source: 4pcs 18W high brightness 6 in 1 leds
Lamp life: 6-10 ten thousand hrs
LED angle: 15/25/40 degree
Color: 16.7 million kinds of color change
Control channels: 6/10 CH
Control mode: DMX512, master/slave, auto, sound
active, infrared control, phone App
Automatic model (by function button) : color
change, color strobe, color dimmer, color gradual
change/color jump change
Operation menu: 4 digit digital LED display
Packing size: 138*145*184mm
N.W: 3.2kg
G.W: 3.5kg
Warranty:1 Year
SAILWIN V4 APP BATTERY
WIRELESS LED PAR CAN
4*18W 6IN1 RGBAW UV APP
BATTERY POWERD & WIRELESS
USER INSTRUCTION MANUAL
Introduction
The led powerizer is a battery powered & wireless
dmx intelligent led panta color RGBAW fixture. This
fixture can operate in wireless DMX, DMX, stand alone,
sound active, master/salve and strobe function. it has
very good emitting listing wash effect. Widely uses for
the stages, ideal led stage, event, and lighting effect
Product Description
MENU MAP
Thank you for purchasing the APP Core by
our company. Every product has been well
tested and has shipped in perfect operating
condition. When receiving our products
carefully check the shipping cartoon for
damage that may have happen during
transport. In case of the damage inspect
the fixture for the damages or missing
accessories necessary to operate. If parts
are missing or fixture has been damage
please report this by Product.
Caution
Do not attempt any repairs yourself. Doing so will
void your manufactures warranty. In the unlike event
your unit may require service please contact us
Warning
To prevent or reduce the risk of the electrical shock or
fire, do not expose this unit to any moisture. Please
read this manual carefully to familiarize yourself with
basic operations of this unit
Safety precautions
1. Do not expose this unit to , wet moisture,
explosive
2. Before plugging the power be sure local power
outlets matches with the required voltage of the
unit
3. Do not remove the cover under the circumstance
in case you are not qualified to do so
4. Never connect the power when cover is removed
5. Never use this unit if it becomes damage
6. Never connect this unit to any if dimmer and / or
power pack
7. If the unit will not be used for the long time ,
disconnect it from the power supply
8. Always mount this unit safe and stable and make
sure the area will have proper ventilation. Take
care this unit will not mounted in are close to
heat sources such as lighting fixtures, amplifiers
heat registers, stoves and radiators
9. Always contact us in case you have any doubts
General Instruction
Crux is a battery powered and wireless Dmx
intelligent RGBAW UV color light. User can control
the light by using wireless Dmx transmitter or run
at master and salve mode. Fixture it has 12 static
color, user can set lights at static color mode
without using the Dmx controller.
Set Up
Crux in had used switching voltage power supply, User can
use directly plug in any voltage from 90V-240V when charging
or operating at charging mode. Battery it can be fully charged
after 3-4 hours of charging, user can also operate the light
while charging the battery. When User ready to operate the
light or use in event or any places first user need to turn on the
power switch. After on the Power switch user can start to set
up light at wireless Dmx mode, wire Dmx mode, master and
salve. Sound active mode, static color mode, auto mode, strobe,
fade or test mode. There is 2 thing must be remember by user
1. Operate light at Dmx Mode: Always set the fixture from
menu at “Sl1 or Sl2” mode, process; Press menu then press
up/down key until appear “Slnd” press enter at “Slnd” choose
Sl1 or Sl2 and press Enter, after some second light will be stay
at “stby” means at standby mode to catch dmx signal, no
matter its cable or wireless Dmx.
Note: when operate light at wireless Mode, make sure that
signal switch is on, fixture its not too far from the wireless DMX
Transmitter, after on the signal switch wireless indicator bulb
should show red color, once fixture start to receive the signal
this indicator bulb it will show blipping green color led, some
time if wireless signal indicator bulb show other color then
continually press black button below the led indicator bulb until
it shows red color. Some manufactures wireless transmitter it
has different led bulb color signal, make sure with supplier
which is color indicate the transmitting signal and set same
color at fixture’s wireless signal indictor by pressing the black
button(id code selector) of fixture, once both color are same
wireless signal led it will start to blip green color, remember
green color means its receiving signal from master unit or dmx
controller.
1. Operate light without using Dmx controller or built in color or
effects or strobe or fade or static color, sound active or master
and slave: Always set the fixture from Menu at “Nast” mode,
then user can go inside the “Shnd” and choose any built in
effects such as sound active, static color, strobe, fade, Process;
Press menu then press up/down key until appear “Slnd” press
enter at “Slnd” choose “nast” and press Enter then Press Up
button choose “Shnd” then press enter, now user can choose
any type of effect mode, soun for sound active mode, colo for
static color mode, StCo for strobe and Fade for built in effect
types.
Examples:
1. Set light at sound active and stay at sound active mode
Press Menu then press up/down button until appear slnd, press
enter at slnd, find nast by pressing up/down button then press
enter, Press up button Shnd will appear at display then press
enter now you can see soun at display then press enter, after
some second of pressing enter light it will start to work at
sound active mode.
If you wish connect other light also at same mode without
setting or salve mode, then Press Menu, find slnd and press
enter then choose sl1 or sl2 then press enter. Follow same
process at all light you want to work at same mode, after some
seconds light it will start to work same function as first light
You can connect the lights by Dmx cable or also can connect
wirelessly. When connect wireless make sure signal switch it’s
on. This is function of master and salve .(App #. 1)
2. Set and stay at static color: Press Menu- Up/down button
Slnd-enter- press up button- Shnd- Press enter- up button-
colo- press enter- choose any color number from 1-12 and
press enter after some seconds your choose color it will start.
For link fixtures follow App #. 1.
3. Make own custom color and display: Press menu, slnd-
Press enter choose Nast- enter, press up button, find nanu put
the value 1-255 on RGBAW each color and press up/down
button find- shnd press enter- choose colo press enter and
choose Co11 and press enter, after some second light it will
start to project custom made color as per value of color you put.
APP Guideline
After Sale Service:
www.sailwinlight.com
Email:info@sailwinlight.com
