Sailwin SW-MBSW350 User manual

1
350W Moving Head Beam Light
User Manual
Please read over this manual before operation the light

2
Specifications:
Used voltage：AC110V-240V，50/60Hz
Light source：350W
Color temperature revise：6700K
Linear dimming：mechanical linear dimming0~100
Fixed color：13color + white light（half color effect is available）
Fixed gobo ：13fixed gobo + white light
Prism：8prims，48prism，double prism superposition，bilateral rotation
Color chips：1colorful chip
pulverization：one independent frost effect，facula soft and natural
Electrical motor：three-phase machine，silence and high speed main board
Channel control：16/20channel
Size：32*22*58
N .W：14.8kg

3
Menu construction
Interface---Manual operation
----Setting ----running mode
----DMX address
----channel mode
----X inversion
----Y inversion
----XY interchange
---- XY encoder
----DMX signal
----power on light
----color ring linear
variation
----reset default setting
--system --software version
--restoration adjust
--sensor monitor
--system error
--permission setting
--DMX monitor
--Chinese-English shift
--screen rotate

4
Manual control
This interface is use to control the light ，in the same time enter the mainframe
condition（do not accept DMX signal，send the DMX signal from trunk to the
slave machine）。
Manual menu set the standard 16 channel mode or 20 channel mode according to the
setup menu，corresponding dispaly 16 channel and 20 channel。
Option
Illustration
1CH. Color dish
0~25
5
press“confirm”key to enter redact status。This
moment pitch on hundreds place，press“up”
“down”key to change the channels。Press
“confirm”key again to choose decade redact。
Press “confirm ”again to choose the unit
redact。Press again and exit the redact.
……
0~25
5
14CH.frost/colorful lens
0~25
5
15CH. restoration
Press“confirm”key then see confirm dialog
box ，press “confirm ”key again ，enter
restoration interface ，all the electrical
machinery restoration
16CH.lamp control
open
close
17CH. Pan/Tilt speed
0~25
5
Show by “extension CH20” channel mode
18CH. Color ring speed
0~25
5
Show by “extension CH20” channel mode
19CH.
dimmer-prism-pulverization-spe
ed
0~25
5
Show by “extension CH20” channel mode
20CH. Pattern dish speed
0~25
5
Show by “extension CH20” channel mode
Setting

5
Option
Illustrate
Operation mode
DMX
Slave condition：receive DMX signal from controller or
main engine
Self
working1
Main engine condition ：self working and send DMX
signal to slave engine
Self
working2
random
Voice
control
DMX address
1~512
press“confirm”key to enter redact condition。press
“confirm ”key to enter redact status。This moment
pitch on hundreds place，press“up”“down”key to
change the channels 。Press “confirm ”key again to
choose decade redact。Press“confirm”again to choose
the unit redact。Press again and exit the redact.
Channel mode
Norm 16CH
Norm 16 channel mode，17~2 0channel invalid
Extension
20CH
Extension 20 channel mode，Number17~20 to control
speed
X inversion
close
open
Y inversion
close
open
XY exchange
close
open
Exchange Pan/Tilt channel（including fine tuning）
XY encoder
open
use encoder to judge step out and self-correcting the
setting
close
Do not use encoder to correct the setting
DMX signal
keep
Running as virgin state
reset
Electrical return，stop running
Screen saver
open
Free 30 seconds and close backlight

6
close
Backlight keep lighting
Open and light
bulb
close
Restoration after power on ，bulb not working （use
menu or controller to light the bulb）
open
Bulb light after on power ，and wait for the bulb
successful light then restoration
Color ring linear
variation
open
Color ring linear variation
close
Color ring nonlinear variation，half color change
Reset to default
setting
Press“confirm”key and see the confirm dialog box，
press“confirm”key again and reset to default setting
System information
Set a password on“permission setting”to prevent non-pro people to operate。Default
password is“up down up down”。Press“confirm”key to check the password。
Option
Illustration
Software version
Present software version
Restoration
adjusting
Pan adjustment
After enter sub-interface ，the restoration
location of Pan/Tilt etc is adjustable ，to
remedy the error of hardware cause by
installation，adjustment range -128~+127，
+0means no adjustment。
Tilt adjustment
Color adjusting
Gobo adjusting
Dimmer adjustment
Aiming adjustment
Sensor monitor
RT monitor the condition of all kinds of
optoelectronic switch, hoare and etc
System error
System error info cue
Permission
setting
Permission duration
0-9999Hs，there will be an alarm when the
lifespan of bulb is over
User password
Can modify the default password "1010",
that is, "up and down"
Administrators
password

7
DMX monitor
RT monitor the signal of controller
False information
Illustration
Fail to reset the
electric motor，gorge
error
Driver board no reply。The telecommunication line that connect
dispaly and gorge line broken，or the driver board broken。
Pan rest failure
Pan optoelectronic or Pan electric motor broken
Tilt rest failure
Tilt optoelectronic or Tilt electric motor broken
Pan Hall error"
Pan hall broken
Tilt Hall error
Tilt hall broken
Color dish rest failure
Hall of color dish or electric motor of color dish broken
Gobo dish rest failure
Hall of gobo dish or electric motor of gobo dish broken
Dimmer rest failure
Hall of dimming or electric of dimming broken
Prism dimmer rest
failure
Prism dimming hall or electric motor of prism dimming broken
Fail to control the
bulb
Light bulb or fail to light bulb，light on machine or bulb broken
Bulb used for a long
time, change a bulb
pls!
The accumulated brightening time exceeds the maximum
brightening time set in the “Advanced” menu, prompting the user
to change the gun in time. After changing the bubble, clear the
lighting time in the “Advanced” menu, and the lighting time will
be re-timed.
DMX channel
Channel
Channel mode
16
20
1
Color wheel
Color wheel
2
Change light/strobe
Change light/strobe

8
3
dimming
dimming
4
Gobo dish
Gobo dish
5
Prism 1
Prism 1
6
Prism rotation 1
Prism rotation 1
7
Prism 2
Prism 2
8
Prism rotation2
Prism rotation2
9
Zoom
Zoom
10
X
X
11
X fine dimming
X fine dimming
12
Y
Y
13
Y fine dimming
Y fine dimming
14
frost/colorful lens
frost/colorful lens
15
reset
reset
16
Lamp control
Lamp control
17
XY speed
18
Color ring speed
19
Dimmer, prism, frost speed
20
Gobo dish speed
COLOUR WHEEL - channel 1

9
BIT
EFFECT
Remarks
255
FAST
ROTATION(forward)
……
……
200
SLOW
ROTATION(forward)
199
SLOW
ROTATION(forward)
……
……
140
FAST ROTATION(reverse)
135
CTB 8000 + WHITE
In order to facilitate
memory, the color value
is always a multiple of 5.
Linear change:
The color ratio can be
adjusted, for example,
when the value is 5, the
white 50% dark red is
50%, if the value is 4, the
white 60% dark red 40%;
if the value is 6, the white
40% dark red 60%.
Nonlinear variation:
The color is adjusted in
130
CTB 8000
125
CTO 190 + CTB 8000
120
CTO 190
115
CTO 260 + CTO 190
110
CTO 260
105
CYAN + CTO 260
100
CYAN
95
MAGENTA + CYAN
90
MAGENTA
85
YELLOW + MAGENTA
80
YELLOW
75
PINK + YELLOW
70
PINK
65
LAVENDER + PINK
60
LAVENDER
55
LIGHT GREEN +
LAVENDER
50
LIGHT GREEN
45
GREEN + LIGHT GREEN

10
units of color.
The “Linear” and
“Nonlinear” selections of
the patches can be made
through the setup menu.
40
GREEN
35
AQUAMARINE + GREEN
30
AQUAMARINE
25
ORANGE +
AQUAMARINE
20
ORANGE
15
RED + ORANGE
10
RED
5
WHITE + RED
0
WHITE
STOP/STOBE - channel 2
BIT
EFFECT
Remark
252-255
OPEN
Controlled by dimming
channel
239-251
RANDOM FAST
STROBE
226-238
RANDOM MEDIUM
STROBE
213-225
RANDOM SLOW
STROBE
208-212
OPEN
Controlled by dimming
channel
207
FAST PULSATION
……
……
108
SLOW PULSATION
104-107
OPEN
Controlled by dimming
channel
103
FAST STROBE
……
……
4
SLOW STROBE

11
0-3
CLOSED
DIMMER - channel 3
BIT
EFFECT
255
Brightness 100%
……
……
0
Brightness 0%
STATIC GOBO CHANGE - channel 4
BIT
EFFECT
255
FAST ROTATION
……
……
201
SLOW ROTATION
200
SLOW ROTATION
……
……
141
FAST ROTATION
140
GOBO 13 SHAKE, FAST SPEED

12
……
……
136
GOBO 13 SHAKE, SLOW SPEED
135
GOBO 12 SHAKE, FAST SPEED
……
……
131
GOBO 12 SHAKE, SLOW SPEED
……
……
84
GOBO 2 SHAKE, FAST SPEED
……
……
80
GOBO 2 SHAKE, SLOW SPEED
79
GOBO 1 SHAKE, FAST SPEED
……
……
75
GOBO 1 SHAKE, SLOW SPEED
74
WHITE SHAKE, FAST SPEED
……
……
70
WHITE SHAKE, SLOW SPEED
65
GOBO 13
60
GOBO 12
55
GOBO 11
50
GOBO 10
45
GOBO 9
40
GOBO 8
35
GOBO 7
30
GOBO 6
25
GOBO 5
20
GOBO 4
15
GOBO 3
10
GOBO 2
5
GOBO 1
0
WHITE

13
PRISM INSERTION 1- channel 5
BIT
EFFECT
128-255
PRISM INSERTED
0-127
PRISM EXCLUDED
PRISM ROTATION 1- channel 6
BIT
EFFECT
255
FAST ROTATION
……
……
193
SLOW ROTATION
191-192
STOP
190
SLOW ROTATION
……
……
128
FAST ROTATION
0-127
POSITION
PRISM INSERTION2 - channel 7
BIT
EFFECT
128-255
PRISM INSERTED
0-127
PRISM EXCLUDED
PRISM ROTATION2 - channel 8
BIT
EFFECT
255
FAST ROTATION
……
……
193
SLOW ROTATION
191-192
STOP
190
SLOW ROTATION
……
……

14
128
FAST ROTATION
0-127
POSITION
FOCUS - channel 9
BIT
EFFECT
255
100%
Zoom 100%
……
……
0
0%
Zoom 0%
PAN - channel 10

PAN FINE - channel 11

TILT - channel 12
TILT FINE - channel 13
FROST /COILURFUL MIRROR- channel 14
RESET - channel 15
BIT
EFFECT
Remark
128-255
COMPLETE
RESET
Reset is activated passing through the unused range and
staying 5 seconds.
77-127
PAN/TILT
RESET
26-76
EFFECTS
RESET
0-25
UNUSED
BIT
EFFECT
192-255
FROST INSERTED
128-191
COILURFUL MIRROR INSERTED
0-127
FROST /COILURFUL MIRROR EXCLUDED

15
RANGE
LAMP CONTROL- channel 16
TIMING CHANNELS
BIT
EFFECT
Remark
101-255
LAMP ON
Lamp switch passing through the unused range and
staying 5 seconds.
10-100
LAMP OFF
0-9
UNUSED
RANGE
Timing Channel
Channel function
Remark
17
Pan-Tilt time
Pan-Tilt-(Pan fine-Tilt
fine)
255 SLOW SPEED
…… ……
0 FAST SPEED
18
Color time
Color wheel
19
Beam time
Dimmer-Prism -Frost
20
Gobo time
Static Gobo
