9*18W 6in1 RGBAW+UV BATTERY
POWERED LED PAR LIGHT
User Manual

www.sailwinlight.com
[email protected]
2
SAFETY INSTRUCTION
Caution
Do not attempt any repairs yourself. Doing so will void your manufactures warranty. In the
unlike event your unit may require service please contact us.
Warning
To prevent or reduce the risk of the electrical shock or fire, do not expose this unit to any
moisture. Please read this manual carefully to familiarize yourself with basic operations of this
unit
Safety precautions
1.Do not expose this unit to , wet moisture, explosive
2.Before plugging the power be sure local power outlets matches with the required voltage of
the unit
3.Do not remove the cover under the circumstance in case you are not qualified to do so
4.Never connect the power when cover is removed
5.Never use this unit if it becomes damage
6.Never connect this unit to any if dimmer and / or power pack
7.If the unit will not be used for the long time , disconnect it from the power supply
8.Always mount this unit safe and stable and make sure the area will have proper ventilation.
Take care this unit will not mounted in are close to heat sources such as lighting fixtures,
amplifiers heat registers, stoves and radiators
9.Always contact us in case you have any doubts
General Instruction
This is a battery powered and wireless Dmx intelligent RGBAW UV color light. User can
control the light by using wireless Dmx transmitter or run at master and salve mode. Fixture it
has 32 static color, user can set lights at static color mode without using the Dmx controller

www.sailwinlight.com
[email protected]
3
FEATURE & INSTRUCTION
Light source
Led
LED quantity
9pcs x 18W LED
Color
RGBWA+UV 6in1
Voltage
AC110V-250V 50-60Hz
Power consumption
162W
Housing
Aluminum Alloy
IP Rate
IP 20
LED angle
25/40 degree
Display
4 digit digital LED display
Battery capacity
13200MAH
Charging Time
5 hours
Control channel
7/12 CH
Control mode
DMX512, infrared control, 2.4G, Sound mode,
Master/slave, Auto run, Infrared control
Light body size
24*13*25CM
Packing size
1PC/CTN 4.5KG, 4pcs/CTN 18KG
N.W
4KG
G.W
4.5KG
Length 24.CM
Width 13 CM
Height 25 CM

www.sailwinlight.com
[email protected]
4
MAIN MENU
1. Operate light with touch or encoder button
• Top Left Sets your Fixtures Address
• Top Center Displays your Fixures Modes of operation
• Top Right Displays Test Mode
• Bottom Left Displays options for Display, (i.e. Screen Rotation)
• Bottom Center displays Advanced option for Fixture.
• Bottom Left diplays current mode, DMX address, Fixture Information.
2. Parameter value setting
Press MENU to navagate menu
• press <UP> or <DOWN> to scroll to correct setting. Touch <Enter> to enter sub
menu.
• Set and save value. Touch <ENTER> submenu.
3. Sub-Menu
• Select desired sub menu from main menu to enter corresponding sub menu shown
below. There is a of total 15 menu programs, includes class of parameter and
status:
• Addr - Select DMX address
• Chnd - Select DMX Channels 7/12
• Slnd - Select Enable Slave, Master,Sync or IR mode
• Shnd
• Select color presets
• Fade speed
• Flas speed
• Auto speed
• Soun - Select sensitivity
• Cust - Set values for up to 5 custom Color
• Dinn - Dimmer
MENU
UP
DOWN
ENTER

www.sailwinlight.com
[email protected]
5
• Blnd - Black out
• LED - Turn off LED display
• Disp - Invert Dispaly
• Test - Test Mode
• Fhrs - Fixture Hours
• Ver - Firmware Version
• Rest - Rest all values to Factory Settings
Mark:
A. One key operate function, choose POWER in the display show, choose “ON” and the light
can be ON/FF when press the menufor a while.
B. Hide the current adjust function, press ENTER for 5 second in A001 menu into the current
adjust function, UP DOWN to change the data, press ENTER to change each color.
C. This version can be worked in 2 kinds of protocol - DMX and RDM
DMX Channel
7 CH mode
Channel
Value
Description
CH 1
0
No action
1 - 255
Red dimmer
CH 2
0
No action
1 - 255
Green dimmer
CH 3
0
No action
1 - 255
Blue dimmer
CH 4
0
No action
1 - 255
Amber dimmer
CH 5
0
No action
1 - 255
White dimmer
CH 6
0
No action
1 - 255
UV dimmer
CH 7
0
No action
1 - 255
Strobe speed (0 - 99)

www.sailwinlight.com
[email protected]
6
12CH mode
Channel
Value
Description
CH 1
0
No action
1 - 255
Red dimmer
CH 2
0
No action
1 - 255
Green dimmer
CH 3
0
No action
1 - 255
Blue dimmer
CH 4
0
No action
1 - 255
Amber dimmer
CH 5
0
No action
1 - 255
White dimmer
CH 6
0
No action
1 - 255
UV dimmer
CH 7
0 - 7
No action
8 - 15
Color 1
16 - 23
Color 2
24 - 30
Color 3
31 - 38
Color 4
39 - 46
Color 5
47 - 54
Color 6
55 - 61
Color 7
62 - 69
Color 8
70 - 77
Color 9
78 - 85
Color 10
86 - 92
Color 11
93 - 100
Color 12
101 - 108
Color 13
109 - 116
Color 14

www.sailwinlight.com
[email protected]
7
117 - 123
Color 15
124 - 131
Color 16
132 - 139
Color 17
140 - 147
Color 18
148 - 154
Color 19
155 - 162
Color 20
163 - 170
Color 21
171 - 178
Color 22
179 - 185
Color 23
186 - 193
Color 24
194 - 201
Color 25
202 - 209
Color 26
210 - 216
Color 27
217 - 224
Color 28
225 - 232
Color 29
233 - 240
Color 30
241 - 247
Color 31
248 - 255
Color 32
CH 8
0 -255
Dimmer
CH 9
Strobe
0 - 7
OFF
16 - 131
ON
132 - 139
Strobe - slow-fast
140 - 181
ON
182 - 189
Pulse - fast close & slow open
190 - 231
ON
232 - 239
Pulse - slow close & fast open
240 - 247
ON
248 - 255
Random strobe

www.sailwinlight.com
[email protected]
8
CH 10
0 - 255
RGBAWUV slow to fast ramdom color change
CH 11
0 - 255
Auto color change slow to fast without strobe
CH 12
0 - 255
Auto color change with strobe along with sound
Wireless Remote Control:
1. ON: Turn on
2. OFF: Turn off
3. Fash: Strobe
4. Soun: Sound mode
5. Auto: Auto run mode
6. Cust: Customized color
7. Colo: Change color
8. Fade: Color fade change
9. Low: Change to low speed
10. Med: Change to middle speed
11. High: Change to high speed
12. Red: Red color
13. Gren: Green color
14. Blue: Blue color
15. Aber: Amber color
16. Whit: White color
17. UV: UV color
