Saivod TTC-84 User manual

partn erof
th e
en
pt
es
Instruction Manual
Manual de Instruções
Manual de instrucciones
TTC-84
TTC-84A+
TTC-84 N

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual will help you use the product in a fast and safe way.
 Read the manual before installing and operating the product.
 Make sure you read the safety instructions.
 Keep the manual in an easily accessible place as you may need it later.
 Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
3
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ...................................4
For products with a water dispenser;.8
Child safety........................................9
Compliance with WEEE Directive and
Disposing of the Waste Product: .......9
Package information..........................9
HC warning .......................................9
Things to be done for energy saving 10
3 Installation 11
Points to be paid attention to when the
relocation of the refrigerator .............11
Before you start the refrigerator,.......11
Disposing of the packaging .............12
Disposing of your old refrigerator .....12
Placing and Installation ....................12
Adjusting the legs ............................13
Reversing the doors ........................14
4 Preparation 15
5 Using your cooler/
freezer 16
Setting the operating temperature ...16
LED indicators and control panel .....16
6 Maintenance and
cleaning 20
Protection of plastic surfaces ..........20
7 Troubleshooting 21
CONTENTS

EN
4
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your refrigerator
1. Reflectors
2. Top tri m
3. Indicator lights
4. Thermostat knob
5. Ice bank
6. Fast-freeze compartment
7. Frozen-food compartments
8. Adjustable front feet
1
5
7
7
6
8
42
3

EN
5
2Safety and Environment Instructions
This section provides the safety
instructions necessary to prevent the
risk of injury and material damage.
Failure to observe these instructions will
invalidate all types of product warranty.
Intended use
A
WARNING:
Keep ventilation openings,
in the appliance enclosure or
in the built-instructure, clear
of obstruction.
A
WARNING:
Do not use mechanical
devices or other
means to accelerate the
defrostingprocess, other than
those recommended by the
manufacturer.
A
WARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments of the
appliance, unless they are of
the type recommended by
the manufacturer.
A
WARNING:
Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
This appliance is intended to be used
in household and similar applications
such as
– staff kitchen areas in shops, offices
and other working environments;
– farm houses and by clients in hotels,
motels and other residential type
environments;
–bedand breakfasttypeenvironments;
– catering and similar non-retail
applications.
General Safety
 This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person
responsible for their safety. Children
should not be allowed to play with this
device.
 In case of malfunction, unplug the
device.
 After unplugging, wait at least 5
minutes before plugging in again.
 Unplug the product when not in use.
 Do not touch the plug with wet
hands! Do not pull the cable to plug
off, always hold the plug.
 Do not plug in the refrigerator if the
socket is loose.
 Unplug the product during installation,
maintenance, cleaning and repair.
 If the product will not be used for a
while, unplug the product and remove
any food inside.
 Do not use the product when the
compartment with circuit cards
located on the upper back part of the
product (electrical card box cover) (1)
is open.

EN
6
1
1
 Do not use steam or steamed
cleaning materials for cleaning the
refrigerator and melting the ice inside.
Steam may contact the electrified
areas and cause short circuit or
electric shock!
 Do not wash the product by spraying
or pouring water on it! Danger of
electric shock!
 In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorized service
before doing anything.
 Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
 If the product has LED type lighting,
contact the authorized service for
replacing or in case of any problem.
 Do not touch frozen food with wet
hands! It may adhere to your hands!
 Do not place liquids in bottles and
cans into the freezer compartment.
They may burst out!
 Place liquids in upright position after
tightly closing the lid.
 Do not spray flammable substances
near the product, as it may burn or
explode.
 Do not keep flammable materials and
products with flammable gas (sprays,
etc.) in the refrigerator.
 Do not place containers holding
liquids on top of the product.
Splashing water on an electrified part
may cause electric shock and risk of
fire.
 Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product,
do not pull by holding the door
handle. The handle may come off.
 Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
 Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the product
to fall down and cause damage to the
parts.
 Take care not to trap the power cable.
 When positioning the appliance,
ensure the supply cord is not trapped
or damaged.
 Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the appliance.
 Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.

EN
7
 To avoid contamination of food,
please respect the following
instructions:
 – Opening the door for long periods
can cause a significant increase of the
temperature in the compartments of
the appliance.
 – Clean regularly surfaces that can
come in contact with food and
accessible drainage systems.
 – Clean water tanks if they have not
been used for 48 h; flush the water
system connected to a water supply if
water has not been drawn for 5 days.
 – Store raw meat and fish in suitable
containers in the refrigerator, so that
it is not in contact with or drip onto
other food.
 – Two-star frozen-food compartments
are suitable for storing pre-frozen
food, storing or making icecream and
making ice cubes.
 – One-, two- and three-star
compartments are not suitable for the
freezing of fresh food.
 – If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the door
open to prevent mould developing
within the appliance.
1.1.1 HC Warning
If the product comprises a cooling
system using R600a gas, take care
to avoid damaging the cooling system
and its pipe while using and moving the
product. This gas is flammable. If the
cooling system is damaged, keep the
product away from sources of fire and
ventilate the room immediately.
C
The label on the inner left
side indicates the type of gas
used in the product.
1.1.2 For Models with
Water Dispenser
 Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar). If
your water pressure exceeds 80
psi (5.5 bar), use a pressure limiting
valve in your mains system. If you
do not know how to check your
water pressure, ask for the help of a
professional plumber.
 If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in
your installation. Consult Professional
plumbers if you are not sure that there
is no water hammer effect in your
installation.
 Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and 100°F
(38°C) maximum.
 Use drinking water only.
Intended Use
 This product is designed for home
use. It is not intended for commercial
use.
 The product should be used to store
food and beverages only.
 Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.

EN
8
 The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
 Original spare parts will be provided
for 10 years, following the product
purchasing date.
Child Safety
 Keep packaging materials out of
children’s reach.
 Do not allow the children to play with
the product.
 If the product’s door comprises a
lock, keep the key out of children’s
reach.
Compliance with WEEE
Directive and Disposing of
the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU). This
product bears a classification symbol
for waste electrical and electronic
equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Do not dispose of the
waste product with normal
domestic and other wastes at the end
of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn about
these collection centers.
Compliance with RoHS
Directive
 This product complies with EU
WEEE Directive (2011/65/EU). It does
not contain harmful and prohibited
materials specified in the Directive.
Package Information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.

EN
9
3Installation
2. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3. Connect the plug of the refrigerator to
the wall socket. When the fridge door
is opened, fridge internal lamp will turn
on.
BIn case the information which are
given in the user manual are not taken
into account, manufacturer will not
assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes
and the transportation rules on the
package should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
refrigerator,
Check the following before you start
to use your refrigerator:
1. Attach 2 plastic wedges as illustrated
below. Plastic wedges are intended
to keep the distance which will ensure
the air circulation between your
refrigerator and the wall. (The picture
is drawn up as a representation and it
is not identical with your product.)
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
5. Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
6. Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
1
2
3
3
3
1

EN
10
Important:
The connection must be in compliance
with national regulations.
 The power plug must be easily
accessible after installation.
 Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
 The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
 Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
 You may consult your authorized
dealer or waste collection center of
your municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the doors
of your refrigerator and pass it sideways
through the door.
1. Install your refrigerator to a place that
allows ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do not
place your product on the materials
such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.

EN
11
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction
of black arrow and raised when you
turn in the opposite direction. Taking
help from someone to slightly lift the
refrigerator will facilitate this process.

EN
12
1
60°
10
6







Reversing the doors
Proceed in numerical order

EN
13
4Preparation
 Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
 The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating
your refrigerator under cooler
conditions is not recommended with
regard to its efficiency.
 Please make sure that the interior of
your refrigerator is cleaned thoroughly.
 If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
 When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
 The door should not be opened
frequently.
 It must be operated empty without
any food in it.
 Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
 Original packaging and foam
materials should be kept for future
transportations or moving.
 Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. Functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy under
these circumstances.

EN
14
5Using your cooler/
freezer
Setting the operating
temperature
21 3
LED indicators and control
panel
There are two coloured indicator lights
located on the front of the appliance
which shows the operating mode of
the freezer.
Green Indicator (1):
Illuminates when the appliance is
connected to the mains and will glow as
long as electricity is available. The green
light will not glow if the thermostat is
set to ‘0’ position. The green indicator
does not give any indication of the
temperature inside the freezer.
Red Indicator (2) Illuminates:
a) If the pre-set temperature can not
be maintained.
b) If excessive amounts of fresh food
are placed inside.
c) If the appliance door is left open
accidentally.
Thermostat knob (3)
Thermostat knob is located on the
indicator light set.
The operating temperature is regulated
by the temperature control.

EN
15
Warm Cold
1 = Lowest cooling setting (Warmest
setting)
4 = Highest cooling setting (Coldest
setting)
(Or)
Min. = Lowest cooling setting
(Warmest setting)
Max. = Highest cooling setting
(Coldest setting)
Please choose the setting according
to the desired temperature.
The interior temperature also depends
on ambient temperature, the frequency
with which the door is opened and the
amount of food kept inside.
Frequently opening the door causes
the interior temperature to rise.
For this reason, it is recommended
to close the door again as soon as
possible after use.
The normal storage temperature of
your appliance should be -18 °C (0 °F).
If the thermostat knob is turned counter
clockwise from position 1, the appliance
will be switched off and “click” sound
will be heard. Lower temperatures can
be obtained by adjusting the thermostat
knob towards Position 4.
We recommend checking the
temperature with a thermometer to
ensure that the storage compartments
are kept to the desired temperature.
Remember at take the reading
immediately since the thermometer
temperature will rise very rapidly after
you remove it from the freezer.
Freezing food
The freezing area is marked with
symbol on the door liner.
You can use the appliance for freezing
fresh food as well as for storing pre-
frozen food.
Please refer to the recommendations
given on the packaging of your food.
AAttention
Do not freeze fizzy drinks, as the bottle
may burst when the liquid in it is frozen.
Be careful with frozen products such
as coloured ice-cubes.
Do not exceed the freezing capacity
of your appliance in 24 hours. See the
rating label.
In order to maintain the quality of the
food, the freezing must be effected as
rapidly as possible.
Thus, the freezing capacity will not be
exceeded, and the temperature inside
the freezer will not rise.

EN
16
1-
4-
-2
-3
AAttention
Keep the already deep-frozen food
always separated with freshly placed
food.
When deep-freezing hot food, the
cooling compressor will work until the
food is completely frozen. This can
temporarily cause excessive cooling of
the refrigeration compartment.
If you find the freezer door difficult
to open just after you have closed it,
don’t worry. This is due to the pressure
difference which will equalize and allow
the door to open normally after a few
minutes.
You will hear a vacuum sound just after
closing the door. This is quite normal.
Making ice cubes
Fill the ice-cube tray 3/4 full with water
and place it in the freezer.
As soon as the water has turned into
ice, you can take out the ice cubes.
Never use sharp objects such as
knives or forks to remove the ice cubes.
There is a risk of injury!
Let the ice cubes slightly thaw instead,
or put the bottom of the tray in hot
water for a short moment.
Defrosting of the appliance
Excessive build-up of ice will affect the
freezing performance of your appliance.
It is therefore recommended that you
defrost your appliance at least twice
a year, or whenever the ice build-up
exceeds 7 mm.
Defrost your appliance when there is
only little or no food in it.
Take out the deep-frozen food from
the drawers. Wrap the deep-frozen
food in several layers of paper, or a
blanket, and keep it in a cold place.
Unplug the appliance or switch off the
circuit breaker to start the defrosting
process.
Take out the accessories (like shelf,
drawer etc.) from the appliance and
use a suitable container to collect the
thawing water.

EN
17
Use a sponge or a soft cloth to remove
thawing water if necessary
Keep the door open during defrosting.
For quicker defrosting, place
containers with warm water inside the
appliance.
Never use electrical devices,
defrosting sprays or pointed or sharp-
edged objects such as knives or forks
to remove the ice.
After the defrosting is done, clean the
inside.
Reconnect the appliance to the mains.
Place the frozen food into the drawers
and slide the drawers into the freezer.
Check regularly to see if the drain pipe
is clogged or not and clear it with the
stick in the hole when necessary.

EN
18
6Maintenance and cleaning
ANever use gasoline, benzene or similar
substances for cleaning purposes.
BWe recommend that you unplug the
appliance before cleaning.
BNever use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
CUse lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
CUse a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
BMake sure that no water enters the
lamp housing and other electrical
items.
BIf your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
CCheck door seals regularly to ensure
they are clean and free from food
particles.
ATo remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
ANever use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
Protection of plastic
surfaces
CDo not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the plastic
surfaces of your refrigerator. In case of
spilling or smearing oil on the plastic
surfaces, clean and rinse the relevant
part of the surface at once with warm
water.

EN
19
7Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
 The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
 The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
 Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10 °C.
 Door has been opened frequently. >>>Do not open and close the door of
refrigerator frequently.
 Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
 Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
 Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
 Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
 Compressor is not running
 Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
 The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
 The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit
into the socket.
 Temperature settings are not made correctly. >>>Select the suitable temperature
value.
 There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
The operation noise increases when the refrigerator is running.
 The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.

EN
20
The refrigerator is running frequently or for a long time.
 New product may be wider than the previous one. Larger refrigerators operate for
a longer period of time.
 The room temperature may be high. >>>It is normal that the product operates for
longer periods in hot ambient.
 The refrigerator might be plugged in recently or might be loaded with food.
>>>When the refrigerator is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature. This is normal.
 Large amounts of hot food might be put in the refrigerator recently. >>>Do not
put hot food into the refrigerator.
 Doors might be opened frequently or left ajar for a long time. >>>The warm
air that has entered into the refrigerator causes the refrigerator to run for longer
periods. Do not open the doors frequently.
 Freezer or fridge compartment door might be left ajar. >>>Check if the doors are
closed completely.
 The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator
temperature to a warmer degree and wait until the temperature is achieved.
 Door seal of the fridge or freezer may be soiled, worn out, broken or not
properly seated. >>>Clean or replace the seal. Damaged/broken seal causes
the refrigerator to run for a longer period of time in order to maintain the current
temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
 The freezer temperature is adjusted to a very low value. >>>Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
 The fridge temperature is adjusted to a very low value. >>>Adjust the fridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
 The fridge temperature is adjusted to a very high value. >>>Adjust the fridge
temperature to a lower value and check.
