Salter Brecknell PR-3000 Series User manual


Pallet Jack Digital Scale

Version 1.2
February 13, 2004
Contents subject to change without notice.
Salter Brecknell Weighing Products
1000 Armstrong Drive
Fairmont, MN 56031
Tel [phone]
Tel [phone]
Fax [phone]
E-mail: [e-mail]
Web: www.salterbrecknell.com.

2
TABLE OF CONTENTS
Page
Chapter 1: Introduction to the PALLET RUNNER 3000 Pallet Jack Scale..................................... 4
Chapter 2: Getting Started.............................................................................................................. 5
Chapter 3: Operation ...................................................................................................................... 6
3.1 Display .......................................................................................................................... 6
3.1.1 Liquid Crystal Display (LCD)............................................................................ 6
3.2 Keyboard....................................................................................................................... 7
3.2.1 Function Keys .................................................................................................. 7
3.3 General Scale Operation .............................................................................................. 7
3.3.1 Weighing an Item............................................................................................. 7
3.3.2 Taring an Item.................................................................................................. 7,8
Chapter 4: Advanced Features and Operation............................................................................... 9
4.1 Piece Counting.............................................................................................................. 9
Chapter 5: Scale Configuration....................................................................................................... 10
5.1 Scale Configuration Overview....................................................................................... 10,11
5.2 User (“A”) Menu ............................................................................................................ 12
5.2.1 Entering the User Menu................................................................................... 10
5.2.2 Navigating in the User Menu............................................................................ 10
5.2.3 Notes on the User Menu.................................................................................. 11
5.2.4 Exiting the User Menu...................................................................................... 11
5.3 Factory Setup (“F”) Menu.............................................................................................. 13,14,15
Chapter 6: Scale Calibration........................................................................................................... 16
6.1 Scale Calibration Overview........................................................................................... 16
6.2 Zero Calibration (F16)................................................................................................... 16
6.3 Span Calibration (F17).................................................................................................. 16

3
Appendix A: Specifications................................................................................................................ 18
Appendix B: Serial Port Information .................................................................................................. 18
Appendix C: Error Messages............................................................................................................. 19
C.1 Error Messages............................................................................................................. 19
C.1.1 Operator Errors................................................................................................ 19
Appendix D: Notes on Rechargeable Battery.................................................................................... 20
D.1 Overview ....................................................................................................................... 20
D.2 When to charge the internal battery.............................................................................. 20
D.3 How to charge the internal battery................................................................................ 20
D.4 How long to charge the internal battery ........................................................................ 20
LIST OF FIGURES
1-1 PALLET RUNNER 3000 Front Panel ..................................................................................... 4
3-1 PALLET RUNNER 3000 Display Detail .................................................................................. 6
3-2 Function Keys Layout ............................................................................................................. 7
5-1 PALLET RUNNER 3000 Main Circuit Board Overview .......................................................... 10
5-2 User Menu Key Assignments ................................................................................................. 11
5-3 User Menu Chart .................................................................................................................... 12
6-1 Calibration Mode Key Assignments........................................................................................ 16
LIST OF TABLES
1-1 PALLET RUNNER 3000 Information...................................................................................... 4
3-1 PALLET RUNNER 3000 Annunciator Definitions................................................................... 6
5-1 User Menu Chart .................................................................................................................... 12,13,14,15

4
CHAPTER 1: INTRODUCTION TO THE PALLET RUNNER 3000 PALLET JACK SCALE
The PALLET RUNNER 3000 Series Scale is a general purpose, industrial grade pallet weighing
scale. Featuring complete portability utilizing 2-6 Volt internal batteries, push button tare, and an
easy to use piece-counting function.
The display type, enclosure type and scale capacity information can be found in Table 1-1.
All PALLET RUNNER 3000 model scales are factory tested and calibrated prior to delivery.
Therefore calibration is not required after unpacking the scale. A small amount of preparation is
necessary before the scale can be used. You will find this information in Chapter 2. Please read
these instructions carefully and completely, prior to using the scale.
Prior to using the scale, please read this user’s guide carefully and completely. Store the manual
in a safe and convenient place so it will be available if you have questions concerning the
operation of the scale.
MODEL DISPLAY TYPE ENCLOSURE TYPE CAPACITY /
GRADUATION
PALLET RUNNER
3000 LCD (liquid crystal display), 0.8” tall Carbon Steel NEMA 12 rated 3000 x 1 lb
TABLE 1-1: PALLET RUNNER 3000 Information
MODEL
PR-3000



ZERO
UNITS TARE PRINTOFF
ON
NET
GROSS
SET
G N
oz
lb
%
O
kg
pcs
P T

5
CHAPTER 2: GETTING STARTED
After unpacking the scale, a small amount of preparation is required before the scale can be
used. All PALLET RUNNER 3000 models are factory tested and calibrated prior to delivery.
1. Remove all packaging from scale.
2. Position the scale on a firm, flat surface.
3. Lower the forks by squeezing the hand control upwards. The hand control is located
at the top of the swivel handle.
4. Turn the scale’s power ON to begin use. (If the display is not at a zero weight reading,
press the Zero key).
5. Slide the Pallet Runner forks under any standard pallet. (For optimum weighing
accuracy, the forks must be at least ¾ of their length under the pallet to be weighed).
6. Engage the lift mechanism by lowering the hand control. It may be necessary to hit
the release button before doing so.
7. Lift the pallet by cranking the handle in an UP/DOWN direction a minimum of 3
complete cycles. Now view the display for the weight value.
NOTE: Your PALLET RUNNER 3000 will automatically shut off after five minutes of non-
use. To change this setting, see Chapter 5.
For best results, be sure to follow these general guidelines:
•If using the AC adapter, do not share an AC outlet with electrical noise producing
equipment, such as refrigeration units. This includes products with electrical motors
and/or relays.
•Do not place the scale in an area with changing ambient temperature and/or high
humidity.
•Do not place the scale in an area with vibrating equipment.
•You may obtain a weight reading while moving, however for the best accuracy a
static weighment is advised.

6
CHAPTER 3: OPERATION
3.1 DISPLAY
The PALLET RUNNER 3000 utilizes a 6 digit LCD (Liquid Crystal Display) to display the
weight and system information Table 3-1 summarizes the display
annunciators.
3.1.1 LIQUID CRYSTAL DISPLAY (LCD)
Figure 3-1 shows the display detail of the PALLET RUNNER 3000 LCD.
oz
lb
pcs
%
kg
G N
O
PT
FIGURE 3-1: PALLET RUNNER 3000 LCD Detail
LCD
Annunciator
MEANING
0
Better known as the “Center of Zero” annunciator, this light is active
whenever the displayed weight is within ± 0.25 divisions of true zero.
N
Indicates that the scale is displaying net weight.
G
Indicates that the scale is displaying gross weight.
T
Indicates that a tare weight has been established in the system.
lb, kg, pcs
Indicates the unit of the displayed weight. .
This light is on whenever the scale is stable.
Indicates that the battery voltage is too low for normal operation. Use the AC
adapter to re-charge the battery.
TABLE 3-1: PALLET RUNNER 3000 Annunciator Definitions

7
3.2 KEYBOARD
The keyboard is composed of five function keys. Refer to Figure 3-2 for the overall layout
and key locations.
ZERO
UNITS TARE PRINT
NET
GROSS
OFF
ON
FIGURE 3-2: Function Keys Layout
3.2.1 FUNCTION KEYS
Units – This key toggles the scale among the available weight units. Available weight
units as shipped from the factory include lb, kg and pieces.
Zero/OFF – When held for three seconds, powers the scale OFF. Otherwise, this key
sets the scale to display zero provided the following conditions are met:
1. The scale is displaying Gross weight.
2. The scale is not in motion.
3. The scale is not in overload (see Appendix C for error codes).
Net/Gross - This key toggles the scale between Gross weight and Net weight only if a
Tare has been established.
Tare - This key is used to establish a Tare provided the following conditions are met:
1. The scale is not at or below Gross zero.
2. The scale is not in motion.
3. The scale is not in overload (see Appendix C for error codes).
ON/Print – This key is used to turn the scale ON. (The Print function is not available
on this model).
3.3 GENERAL SCALE OPERATION
3.3.1 WEIGHING AN ITEM
1. Select the desired weighing unit by pressing the UNITS key until that unit is
indicated on the display.
2. If necessary, press the ZERO key to obtain a weight reading of zero.
3. Raise the object to be weighed off the floor and allow the weight indication to
stabilize. If the item weight exceeds the scale’s weight capacity, it displays
“”.
4. Read the weight shown on the display.
3.3.2 TARING AN ITEM
To weigh an item in a container or on a pallet, the weight of that container or pallet
must first be subtracted from the overall weight to obtain an accurate weight reading.
This is known as taring.
1. Select the desired weighing unit by pressing the UNITS key until that unit is
indicated on the display.
2. If necessary, press the ZERO key to obtain a weight reading of zero.

8
3. Raise the empty container or pallet off the floor and allow the weight indication to
stabilize.
4. Press the TARE key. The display shows zero weight and turns the NET
annunciator on.
5. Place the material to be weighed on the container or pallet, raise it off the floor
and allow the weight indication to stabilize.
6. Read the weight shown on the display.
7. You may toggle between the gross weight and the net weight by pressing the
NET/GROSS key.

9
CHAPTER 4: ADVANCED FEATURES AND OPERATION
4.1 PIECE COUNTING
This mode is used to indicate the number of pieces of an item you have placed on the
scale’s forks and is accessed by pressing the UNITS key. To ensure accuracy, the
parts you are counting must be consistent in weight.
The scale uses the sampling method to determine the average piece weight (APW) of
the items you wish to count. When sampling items, always count the parts in your
hand and place them on the scale all at once. If the APW of the items is too light or
the total weight of the sample is too light, accuracy cannot be guaranteed. You will get
an error message, but piece counting will still be allowed.
1. Press the UNITS key until “PCS” is indicated on the display. If a previous sample
has not been taken, the scale will display “10 0”. If a previous sample has been
taken, the scale will display the current number of pieces on the platform.
2. If the items you will be counting require a container or pallet, you must first tare
the container or pallet off by pressing the TARE key.
3. If the screen does not show “10 0”, press the TARE key once. The scale is
prompting you to place ten identical items on the scale’s forks.
NOTE: If you wish to change the sample number, simply press the NET/GROSS
key repeatedly until the desired sample number appears. Available choices are 5,
10, 25, 50 and 100.
4. Place the sample items on the scale’s forks all at once and allow the weight
indication to stabilize. Once this is done, the zero indicated after the sample
number will change to a “–“. For example, “10 –“.
5. Press the NET/GROSS key to take the sample. If the sample size is large
enough, the scale now displays the number of pieces on the forks. If it does not,
the scale briefly displays “Add” and automatically increments the sample size.
Repeat Step #4 with the new sample size.
NOTE: If the scale continues to display “Add” even after sampling 100 pieces, the
unit weight of the items you wish to count is too light for your scale to process
accurately.
6. To exit the piece count mode, press the UNITS key. The APW will remain in
scale memory until you repeat Steps # 2 or #3.

10
CHAPTER 5: SCALE CONFIGURATION
5.1 SCALE CONFIGURATION OVERVIEW
The scale contains two main setup menus: The User (“A”) menu - which configures the
serial communication port and enables some user options - and the Factory Setup (“F”)
menu.
5.2 USER (“A” & “F”) MENUS
5.2.1 ENTERING THE USER MENU “A” AND “F”
1. Power off the indicator by pressing and holding the down ZERO/OFF key for 3
seconds.
2. Remove the top digital display cover and find the black switch. The switch is
located on top of the silver canned A/D converter. (Refer to Figure 5.1 for switch
location)
3. Place the switch in the down position as shown at right.
4. Power on the indicator by pressing the ON key. The indicator shows ” F 1” to
indicate that you are in Setup Menu mode.
CANNED A/D
CONVERTER
SETUP
SWITCH
Figure 5-1: PALLET RUNNER 3000 Main Circuit Board Overview
5.2.2 NAVIGATING IN THE A & F USER MENUS
Use the directional keys shown in Figure 5-2 to move around in the A and F User
Menus.
1. To move to the selection level, press the ZERO/OFF (down) key once. The
current saved selection is shown.
2. To view the available selections for A and F menus, use the TARE (left) or
ON/PRINT (right) key to move through the selection field.
3. To save a new selection, press the NET/GROSS (Save) key .To exit without
saving, press the UNITS (up) key to return to the A OR F heading.

11
USER MODE KEY FUNCTIONS
NET TARE
UNITS
SAVE
PRINT
ZERO
OFF GROSS
ON
Figure 5-2: User Menu Key Assignments
A15
Auto Power Off
Off 3 5 10 20 30
Figure 5-3: User Menu Chart
5.2.3 NOTES ON THE USER MENU
1.Detailed descriptions of the user menu parameters can be found in Table 5-1. Factory-set
defaults are shown in bold with a checkmark (√).
5.2.4 EXITING THE USER MENU
1. Power off the indicator by pressing and holding the down ZERO/OFF key for 3 seconds.
2. Move the Setup/Calibration Switch back to its original position.
3. Power on the indicator by pressing the ON/PRINT key. The display will go through a digit
check, then settle into Normal Operating mode. All front panel keys will now return to their
normal mode of operation.

12
5.3 FACTORY SETUP (“A”) MENU Table 5-1: User Menu Chart
NAME/CODE DESCRIPTION CODE/VALUE
A1
Baud Rate Selects the baud rate for the data transmission through both
serial ports (COM! And COM2) 1200 2400√
4800 9600
A2
Data Bits and Parity Selects the number of data bits and parity of serial
transmission.
"8n" = 8 data bits with no parity bit and one stop bit
"7O" = 7 data bits with odd parity bit and one stop bit
"7E" = 7 data bits with even parity bit and one stop bit
"7n" = 7 data bits with no parity bit and two stop bits
8n√
√√
√
7O
7E
7n
A3
COM1 Mode Selects the mode of the COM1 serial port: Refer to appendix
B for more information
“0” = Full duplex
“1” = Print ticket mode
0√
1
A4
ID No. Enable Allows the ID number to be disabled in the Print Ticket mode.
Valid only when A3 is set to “1”.
"0" = Disable the ID No. "1" = Enable the ID No.
0√
√√
√
1
A5
ID No. Entry Actuates the function that allows entry of a new ID number.
Valid only when A3 is set to “1”. Pressing the ZERO key to
scroll down one level begins the sequence.
0 – 199999
123456√
√√
√
A6
No. of line feeds Actuates the function that allows entry of the desired number
of line feeds to be printed in the Print Ticket Mode. Valid only
when A3 is set to “1”. Pressing the ZERO key to scroll down
one level begins the sequence.
0-99
5√
√√
√
A7
Handshaking Enable Enables hardware handshaking for Print Ticket Mode. Valid
only when A3 is set to “1”.
“0” = Disable “1” Enable
0√
1
A14
Display Check Actuates the function that illuminates all digit segments,
decimal points, and LCD annunciators in a test sequence. Press ZERO to begin
A15
Auto off Enables the selection of time in minutes before power down
when no activity has occurred. Pressing the ZERO key to
scroll down one level begins the sequence.
OFF√3, 5, 10, 20,30
A16
Mode of serial transmisson Allows selection of continuous serial transmission or demand
transmission. “C = continuous
“D” = demand
A1 Baud
Rate
A2
Bits
A3 COM1
mode
A7
Handshaking
A14 Display
Check
A 15 Auto off
A16 Serial
Mode
A6 No.
line
feeds
A5 ID no.
entry
A4 ID no.
enable
8 N 7 N7 O 7 E
1200 12001200 1200
10 Press ZERO
to begin
1
0 Press zero
1200 12001200 1200 12001200
10
10 Press ZERO
to begin

13
NAME/CODE DESCRIPTION CODE/VALUE
F1
Graduations Specifies number of full-scale graduations. Value should be
consistent with legal requirements and environmental limits on the
useful system resolution.
500 1,000
1,500 2,000
2,500 3,000
4,000 5,000
6,000 8,000
10,000√
√√
√12,000
20,000 30,000
40,000 50,000
F2
Span Gain Span Gain is related to A/D integration time. The larger the span
gain, the higher the internal resolution, but the slower the update
speed. Note that the scale must be re-calibrated whenever this
parameter is altered. See Appendix C for more information.
25 50
75 100√
√√
√
150 200
F3
Zero Track
Band
Selects the range within which the scale will automatically zero. Note
that the scale must be in standstill to automatically zero. Selections
are in Display Divisions.
0d
0.5d√
√√
√
1d
3d
5d
F4
Zero Range Selects the range within which the scale may be zeroed. Note that
the indicator must be in standstill to zero the scale. 100%√
√√
√
1.9%
F5
Motion Band Sets the level at which motion is detected by comparing the present
display update with the previous one. If motion is not detected for
two seconds or more, scale is in standstill and can process a Print or
Zero command. Maximum value varies depending on local
regulations.
1d√
√√
√
3d
5d
10d
F6
Digital Filter Averages weight readings to produce higher stability. The higher the
filter number, the greater the stability but the slower the response
time. Choose 8 or 12 unless a very fast response is needed. Use the
“Auto” setting to automatically determine the filter length as you are
weighing.
1 2
4 8
12 16
24
F7
Overload Limit Selects the desired formula which determines the point at which the
indicator shows overload. All selections are based on the primary
unit selected in F8.
"FS" = Full scale in primary units.
FS
FS + 2%√
√√
√
FS + 1d
FS + 9d
F8
Calib. Unit Selects the primary base unit to be used in the calibration process.
Also the default unit for normal operation.
"1" = primary unit is lb. "2" = primary unit is in kg.
1√
√√
√
2

14
NAME/CODE DESCRIPTION CODE/VALUE
F9
Display
Divisions
Determines the desired weight increments. Value should be
consistent with legal requirements. 1√
√√
√
2
5
F10
Decimal Pt. Determines location of the decimal point. 0√
√√
√0.0
0.00 0.000
0.0000 00
F11
Custom Unit
Multiplier
Actuates the function that allows you to enter a multiplier for the
custom unit. Scrolling down with the ZERO key one level begins the
procedure.
Press ZERO key
to begin sequence
1√
√√
√
F12
Custom Unit
Enable
Used to enable or disable the custom unit whenever the UNITS key
is pressed. This feature must be disabled for commercial
applications.
"0" = Disable custom unit "1" = Enable custom unit
0
1√
√√
√
F13
Piece Count
Enable
Used to enable or disable the piece count feature. This feature must
be disabled for commercial applications.
"0" = Disable piece count "1" = Enable piece count
0√
√√
√
1
F14
lb/kg
Conversion
Enable
Used to enable or disable the lb to kg conversion whenever the
UNITS key is pressed.
"0" = Disable conversion "1" = Enable conversion
0
1√
√√
√
F16
Zero
Calibration
Places indicator into the zero calibration routine. Scrolling down with
the ZERO key one level begins the procedure. Press ZERO key
to begin sequence
F17
Span
Calibration
Places indicator into the span calibration routine. Scrolling down with
the ZERO key one level begins the procedure. Press ZERO key
to begin sequence
F18
View Calibra-
tion
Actuates the function that allows you to view both the zero and span
calibration value. The values displayed in this function are valid only
after Calibration (F16 & F17) has been successfully completed.
Scrolling down with the ZERO key one level begins the procedure.
Press ZERO key
to begin sequence
F19
Key-in Zero Allows you to key-in known zero calibration value in case of memory
loss in the field. Scrolling down with the ZERO key one level begins
the procedure.
Press ZERO key
to begin sequence
F20
Key-in Span Allows you to key-in a known span calibration value in case of mem-
ory loss in the field. Scrolling down with the ZERO key one level
begins the procedure.
Press ZERO key
to begin sequence
F21
Factory Reset This sub-menu will reset all parameters in the “F” and “A” menu to
the default settings. USE WITH CAUTION! Password = 38181 Press the ZERO
key twice to
execute.

15

16
CHAPTER 6: SCALE CALIBRATION
6.1 SCALE CALIBRATION OVERVIEW
The PALLET RUNNER 3000 scale may be calibrated with any precision test weight
between 30 pounds and 3000 pounds. The recommended test weight is 2000 pounds, but
in general the larger the test weight, the more accurate the scale will be.
Before you can calibrate the scale, you must enter the Setup Menu. See Section 5.2.1 for
instructions on how to do this.
6.2 ZERO CALIBRATION (F16)
1. While in the Setup mode, scroll to "F 16", then scroll down once using the ZERO/OFF
key to enter zero calibration menu. The display will momentarily show "C 0" followed by
a value. This value is the internal A/D count and can prove useful when trying to
troubleshoot setup problems.
2. After making sure that there are no test weights on the platform, press the ZERO/OFF
key again to zero out the displayed value.
3. Press the NET/GROSS key to save the zero point value. The display will show "EndC0"
momentarily, then revert back up to F16. At this time, proceed to the F17 span
calibration to complete indicator calibration.
6.3 SPAN CALIBRATION (F17)
1. While in the Setup mode, scroll to "F 17", then scroll down once using the ZERO/OFF
key to enter span calibration menu.
2. The display will momentarily show "C 1" for the span calibration, followed by a value
with one flashing digit. Place the test weight on the weighing mechanism.
3. Use the four directional keys (shown in Figure 6-1 below) to adjust the displayed value
to the actual test weight value. Increase the flashing digit by pressing the UNITS key.
Decrease the flashing digit by pressing the ZERO/OFF key. Pressing the ON/PRINT
key or the TARE key will change the position of the flashing digit.
SETUP MODE KEY FUNCTIONS
ZERO GROSS
NET TARE PRINT
SET
UNITS OFF
ON
Figure 6-1: Setup Menu Key Assignments
4. After setting the exact value, press the NET/GROSS key to save the value.
5. If the calibration was successful, the display will show " EndC1 " momentarily, then revert
back up to F17.

17
6. If the calibration was not successful, one of the error messages below will appear. Take
the indicated action to correct the problem, then perform a new calibration.
" Err0 " - The calibration test weight or the adjusted keyed-in weight is larger than the full
capacity of the scale. Change the calibration test weight or check the input data.
" Err1 " - The calibration test weight or the adjusted keyed-in weight is smaller than 1% of
the full capacity of the scale. Change the calibration test weight or check the input data.
" Err2 " – The calibration test weight does not match the keyed-in weight. This could also
be due to an internal fault and/or damaged load cell. Or you could have simply forgotten
to place the test weight on the scale before pressing the NET/GROSS key.

18
APPENDIX A: SPECIFICATIONS
CONSTRUCTION:
Pallet Jack: High Tensile Steel
Indicator: A-36 Carbon Steel
DISPLAY:
6 digit, 7-segment LCD
KEYPAD:
5-key Tactile Keypad
OVER CAPACITY ANNUNCIATION:
103% of Full Scale Capacity
OPERATING TEMPERATURE RANGE:
14 ° F to 104 ° F
(-10°C to 40°C)
POWER SOURCE:
2 internal 6V lead acid batteries
AC Adapter, 12VDC, 800 mA (Also acts
as charger)
CHARGER: See “Power Source” above
Charge Period: See Appendix D
WEIGHT:
Net Weight: 300 lb (136kg)
Shipping Weight: 330 lb (150 kg)
DIMENSIONS:
Forks: 42” x 27” x 3”
APPENDIX B: SERIAL PORT INFORMATION
APPENDIX B is not applicable to this scale product.

19
APPENDIX C: DISPLAYED
ERROR CODES
CODE MODE MEANING / POSSIBLE SOLUTION

Normal Operating
Mode Gross Overload. A weight greater than the rated capacity has been applied to the scale. Remove the weight from the platter or try re-
calibrating the scale. Otherwise, check for a bad load cell connection or
possible load cell damage due to overloading.
Err 0
Span Calibration
Mode (F17) Keyed-in weight value is less than 1% of full-scale capacity. Use a larger test weight or check keyed-in value.
Err 1
Span Calibration
Mode (F17) Keyed-in weight value is larger than full-scale capacity. Use a smaller test weight or check keyed-in value.
Err 2
Span Calibration
Mode (F17) There is not enough load cell signal to produce the internal counts necessary to properly calibrate the scale. First check all load
connections. Use F16 mode to view internal counts. See Appendix C for
more information.
Err 3
All Modes Non-volatile memory read error. One or more setup parameters have
been lost.
Err 4
All Modes Non-volatile memory write error. Indicator needs service.
Err 7
Initialization No reading from the ADC. Could indicate a damaged load cell.
Err 9
Normal Operating
Mode Span calibration value has been lost. Re-calibrate the scale.
Err 10
Initialization or Setting
Code Entry Indicator cannot read serial number. Indicator must be returned for service.
Err 11
Initialization Serial number mismatch. Re-enter setting code from product ID tag.
Err 12
Initialization or Setting
Code Entry Invalid setting code. Re-enter proper setting code from product ID tag.
Err 13
Setting Code Entry Non-volatile memory is in write-protect mode. Toggle position of
Setup/Calibration Switch (See Chapter 5).
Note: Contact Service Department at Transcell for instructions on how to re-enter setting code.

20
APPENDIX D: NOTES ON RECHARAGEABLE BATTERY
D.1 OVERVIEW
Your scale contains two internal lead-acid rechargeable batteries connected in parallel.
Before using the scale for the first time, please charge the battery overnight.
The scale’s battery should operate for about 40 hours if left on continuously. Therefore,
greater usage times can be achieved by selecting an appropriate Auto Power Off Period
under A15 of the User Menu.
The battery can be charged while ON or OFF and the scale can be operated while it’s
charging.
D.2 WHEN TO CHARGE THE INTERNAL BATTERY
1. The best time to charge the sealed lead-acid type battery is any time the scale is not in
use. You do not have to wait for the Low Battery Indication – in fact it’s best you don’t.
Charging the battery when the scale is not in use keeps the battery “fresh” and is the
recommended way to manage your scale’s battery.
2. When the battery needs to be charged, the Low Battery Indicator will appear in the
upper left-hand corner of the display. The scale may be used for an additional 15 to 30
minutes without damage to the internal battery. If the scale is used for more than 30
minutes after a low battery indication, permanent damage may occur to the
battery and/or the battery may not accept a charge.
NOTE: When a low battery indication occurs, the scale automatically shuts off after 5
minutes of idle use.
D.3 HOW TO CHARGE THE INTERNAL BATTERY
1. Connect the charger (AC Adapter 12 VDC, 800mA) to the scale, and then plug the
charger into an AC outlet. Make sure that the AC voltage appearing at the wall
outlet matches the input voltage marked on the AC adapter.
2. After the charging period expires, unplug the charger from the AC outlet, then from the
scale. The scale is now ready for use under its own battery power.
NOTE: The charger may be left connected to the scale indefinitely without damage to
the internal battery.
D.4 HOW LONG TO CHARGE THE INTERNAL BATTERY
In general, the battery should be allowed to charge a minimum of 1.5 hours for every hour
of use.
If you discharge the battery below 50% and do not allow the proper time for charging, you
may notice a decline in the usage period. This is due to the battery’s reluctance to accept a
charge.
