Salton WC-2050 User manual

®
Dual Zone
Wine Cellar
Instruction Booklet
Model: WC-2050
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 1

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
1. Read all instructions. Use this appliance only as described in this manual.
Other uses not recommended may cause fire, electric shock or personal injury.
2. To protect against electrical hazards, DO NOT immerse cord, plugs, or the
appliance in water or other liquid.
3. This unit is designed to be freestanding only. DO NOT recess into cabinets.
Follow the instructions in the “Installation” section.
4. It is recommended that a separate circuit, serving only this unit be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
5. Unplug from outlet when not in use, before moving, servicing or cleaning.
6. To unplug from the outlet, grip the plug and pull it from the wall outlet.
Never pull by the cord.
7. DO NOT operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return appliance
to SWG Canada for examination, repair or adjustment. See “Warranty” section.
8. The use of attachments not recommended by the manufacturer may
be hazardous.
9. Close supervision is necessary when any appliance is used by or near children.
10. DO NOT operate the appliance in the presence of explosives and/or
flammable fumes.
11. DO NOT place the appliance or any of its parts near an open flame, cooking
or other heating appliance.
12. Place the unit on a dry level surface. Follow the instructions in the
“Installation” section.
13. DO NOT place heavy objects on top of the unit.
14. Empty contents before moving the unit.
15. Never clean appliance parts with flammable fluids. DO NOT store or use
gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
16. CAUTION: Risk of child entrapment:
Before disposing take off the doors. Leave the shelves so children may not
easily climb inside. Never allow children to operate, play with or crawl
inside the Wine Cellar.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
2
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 2

GROUNDED PLUG
To reduce the risk of electric shock this appliance has a grounded plug (2 blades
and 1 pin). If the plug does not fit fully into the electrical outlet contact a qualified
electrician. DO NOT modify the plug in any way or use an adaptor.
INTRODUCTION
Your new Wine Cellar has no compressor and as such is environmentally
friendly, needing no special disposal precautions other than those listed in
the “Important Safeguards” section of this manual.
Cooling is done using thermoelectric circuits. This uses the ambient air around
the unit which is cooled when drawn in. The warm air is exhausted through
the vents. Thermoelectric wine cellars create less noise and vibration than
compressor units. The minimized vibration will prevent bubbles from forming
in stored wine, which helps to maintain its quality. These units offer a high
level of reliability, lower maintenance, more accurate temperature control
and an environmentally friendly operation since no CFC’s or HCFC type
refrigerants are used in the cooling process.
DESCRIPTION OF PARTS
1. Electronic Control Panel
a) Temperature ‘Up’ ()
b) Temperature ‘Down’ ()
c) Digital Display – Upper Zone
d) Digital Display – Lower Zone
e) Upper or Lower Zone Selection
f) Interior Light On/Off Switch
2. Wine Racks
3. Four Leveling Legs
4. Double Panel Glass Door
5. Ventilation Spacer (Not shown)
3
1e
1d
1c
1a 1b 1f
3
4
5
1
2
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 3

BEFORE FIRST USE
1. Remove all packaging including labels. If there is any glue residue rub a
small amount of liquid dish soap with your fingers then wipe with warm
water. Dry.
NOTE: DO NOT use any sharp instruments, rubbing alcohol, flammable
fluids or abrasive cleaners to remove tape or glue.
2. Clean the Wine Cellar, following the instructions in the “Care and
Cleaning” section.
INSTALLATION
1. The unit is designed to be free standing only, it should not be recessed
or built-in.
2. To ensure that your Wine Cellar works at the maximum efficiency,
follow the recommended clearances below:
- sides 2” (5 cm)
- top 4” (10 cm)
- back 2” (5 cm) or use the ventilation spacer
3. Place the Wine Cellar on a flat level surface that is strong enough
to support it when fully loaded.
4. DO NOT place next to any appliance that emits large amount of heat,
such as a dishwasher, microwave, oven, toaster, etc. or in direct sunlight.
Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption.
Install the Leveling Legs
1. Turn the Wine Cellar on its back and install the Leveling Legs by turning
clockwise into the preset screw holes.
NOTE: The leg that stands on the hinge is the shorter leg.
2. Place the Wine Cellar into its final position.
3. Turn the legs counterclockwise to raise the Wine Cellar or clockwise
to lower the Wine Cellar.
NOTE: To help with door closure, position legs with a 1/8" (3 mm) tilt
to the back.
4
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 4

Install the Ventilation Spacer
To ensure good ventilation, install
the provided ventilation spacer on
the rear of the unit as shown
in Illustration 1.
Install the Wall Bracket
Always avoid having bottles in the upper zone and none in the lower zone
to ensure stability. To avoid a hazard due to instability of the appliance, attach
to the wall using the enclosed Wall Bracket.
1. Fix the Wall Bracket on the appropriate location of the wall with the screw
provided. The bracket should be placed approximately 40” (101 cm) from
the floor surface.
2. Lift the unit and fit the end of the Wall Bracket into the slot located on the
back-cover of the Wine Cellar. The unit is now secured and ready to use.
HOW TO USE
1. Plug the Wine Cellar in 120 volt A.C. wall outlet.
2. The temperature is factory set at 10°C (50°F) and will be displayed in
the Fahrenheit scale. To switch the Display between Fahrenheit and Celsius
scales, depress the and arrows simultaneously for approximately
5 seconds.
3. The temperature range in the upper zone is 4 - 22°C (39-72°F). The
temperature range in the lower zone is 7 - 22°C (44.5 - 72°F). To lower the
temperature press the Temperature ‘Down’ arrow () or to raise the
temperature press the Temperature ‘Up’ arrow (). Each time you press
the ‘Up’ or ‘Down’ arrow the temperature will change by 1 degree within
the temperature range of 4 - 22°C (39 - 72°F). The Wine Cellar will work
towards the temperature that has been set and the Temperature Display
will change.
5
Ill. 1
Ventilation
Spacer
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 5

NOTE: Thermoelectric Wine Cellars work with the ambient temperature.
Please note the temperature differences below:
Unloaded: Maximum difference with ambient temperature is 18ºC
Loaded: Maximum difference with ambient temperature is 15ºC
CARE AND CLEANING
1. Always unplug the Wine Cellar and remove Wine Racks before cleaning.
2. Wash the interior with a warm water and baking soda solution 2 tbsp.
(30 ml) of baking soda to 1 quart (litre) of water.
3. Wash the wine racks, gasket and the exterior of the unit with water
and a mild detergent.
4. Wring excess water out of the sponge or cloth before cleaning the area
around the control or any other electrical parts.
5. Dry all parts thoroughly with a clean, dry cloth, before plugging the unit
back into the electrical outlet.
NOTE:
• Never use abrasive products (scouring pads, powders). They may
permanently damage the surface finish of the Wine Cellar.
• Never use gasoline, benzene, paint thinner or any other chemicals
to clean this unit.
Power Failure
Most power failures are corrected within a few hours and should not affect
the temperature of your appliance if you minimize the number of times
the door is opened.
NOTE: If the unit is unplugged, has lost power, or is turned off; you must wait
3 to 5 minutes before restarting the unit. If you attempt to restart before this
time delay, damage may occur and or the appliance may not start.
6
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 6

Vacations
•Short vacations: Leave the appliance operating during vacations of less
than 3-4 weeks.
•Long vacations: If the appliance will not be used for over one month,
remove all items and unplug the power cord. Clean and dry the interior
thoroughly. To prevent odor and mold growth, leave the door open slightly:
blocking it open if necessary.
Moving your Wine Cellar
• Remove all contents and store properly.
• Securely tape down all loose items inside your appliance.
• Screw in the leveling feet.
• Tape the doors shut.
• Be sure the appliance stays secure in the upright position during
transportation. Also protect the outside of appliance with a blanket,
or similar item.
7
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 7

TROUBLESHOOTING
8
PROBLEM POSSIBLE CAUSE
Appliance does not operate. • Not plugged in.
• The circuit breaker tripped or there is a blown
Appliance is not cold enough. • Check the temperature control setting.
• The door is opened too often.
• The door is not closed completely.
• The door gasket does not seal properly.
Appliance too cold. • Check temperature setting.
• The room temperature is too cold.
Turns on and off frequently. • The room temperature is hotter than normal.
• The door is opened too often.
• The door is not closed completely.
• The temperature control is not set correctly.
Vibrations. • Check to assure that the appliance is level.
(See “Installation” section).
Condensation on front of door. • Room environment is too humid.
Moisture on exterior of appliance. • Normal during periods of high humidity – wipe dry.
The door will not close properly. • The appliance is not level.
(See “Installation” section).
• The gasket is dirty.
• The shelves are out of position.
Ice formation on the inner rear wall. • The door gasket does not seal properly.
• The door is opened too often or for too long.
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 8

9
Because of potential safety hazards under certain conditions, it is strongly
recommended that you do not use an extension cord with this appliance. However,
if you must use an extension cord it is absolutely necessary that it be a CSA-Listed,
3-wire grounding type appliance extension cord having a grounding type plug and
outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.
LIMITED WARRANTY
SWG Canada warrants that this appliance shall be free from defects in material
and workmanship for a period of one year from the date of purchase. During this
‘in-warranty’ period, defective products will be repaired or replaced at the discretion of
the retailer and/or SWG Canada. A defective product should be returned to the original
place of purchase within the retailer’s stipulated return/exchange period*. If you do not
wish or are unable to have a defective product replaced under warranty by the retailer,
SWG Canada will repair or replace the defective product without charge. You may
contact us for assistance by mail, e-mail, fax or telephone as listed below.
This warranty covers normal domestic usage and does not cover damage which occurs
in shipment or failure which results from alteration, accident, misuse, abuse, glass
breakage, neglect, commercial use or improper maintenance.
To ensure prompt ‘in-warranty’ service be sure you have an original proof of purchase.
You may be asked to return the product to us along with a description of the defect and
your address, zip/postal code.
For repairs not covered by the warranty, please contact us for assistance.
®
SWG CANADA
Division of Salton Appliances (1985) Corp.
Customer Service Department
81A Brunswick
Dollard-des-Ormeaux
Quebec, Canada H9B 2J5
Website: www.salton.com
E-mail: [email protected]
Fax: [phone]
Tel: [phone]
* Return/exchange policies at each retailer vary and may differ from the SWG Canada 1 year limited warranty
period.
Booklet WC-2035_ENG.qxd 8/7/08 10:58 AM Page 9
