Saluki STB8827 Series User manual

OOPPEERRAATTIIOONNMMAANNUUAAL
STB8827 Series
PPPrrreeeccciiisssiiiooonnnLLLCCCRRRMMMeeettteeerrr
Saluki Technology Inc.

STB8827Series Operation Manual Contents
II
Contents
Chapter 1 Out of Box Audit .................................................................... 1
1.1 To Inspect the package ........................................................... 1
1.2 Power connection................................................................... 1
1.3 Fuse .................................................................................... 1
1.4 Environment ......................................................................... 2
1.5 Use of Test Fixture ................................................................. 2
1.6 Warm-up .............................................................................. 2
1.7 Other features....................................................................... 3
Chapter 2 Introduction.......................................................................... 4
2.1 Introduction to front panel ...................................................... 4
2.2 Introduction to rear panel ....................................................... 6
2.3 Introduction to display zone .................................................... 7
2.4 Main menu keys and corresponding displayed pages ................... 8
2.4.1 [MEAS] ..................................................................... 8
2.4.2 [SETUP] .................................................................... 9
2.4.3 [SYSTEM] .................................................................. 9
2.5 Basic Operation ..................................................................... 9
2.6 Start the instrument .............................................................. 9
Chapter 3 Introduction to [MEAS] ......................................................... 11
3.1 <MEAS DISPLAY>................................................................ 11
3.1.1 Test function ............................................................ 11
3.1.2 Test range ............................................................... 15
3.1.3 Test frequency.......................................................... 15
3.1.4 Test level ................................................................. 16
3.1.5 DC BIAS .................................................................. 17
3.1.6 Test speed ............................................................... 18
3.1.7 Tools ....................................................................... 18
3.2 <BIN NO. DISP> ................................................................. 19
3.2.1 Comparator function ................................................. 20
3.3 <BIN COUNT DISP>............................................................. 20
3.3.1 PARAM .................................................................... 21
3.3.2 NOM. ...................................................................... 21
3.3.3 BIN......................................................................... 21
3.3.4 HIGH/LOW............................................................... 22
3.3.5 COUNT .................................................................... 22
3.3.6 AUX ........................................................................ 22
3.3.7 OUT ........................................................................ 22
3.4 <LIST SWEEP DISP>............................................................ 22
3.4.1 Sweep mode ............................................................ 23
3.4.2 FREQ (Hz) ............................................................... 24
3.4.3 R[:] X[:].................................................................. 24
3.4.4 CMP (Compare) ........................................................ 24

STB8827Series Operation Manual Contents
3.5 <MEASURE SETUP> ............................................................. 24
3.5.1 Trigger mode............................................................ 25
3.5.2 Auto level control function.......................................... 26
3.5.3 Bias current isolation function..................................... 26
3.5.4 Average................................................................... 27
3.5.5 Level monitor function ............................................... 27
3.5.6 Delay time ............................................................... 28
3.5.7 Output impedance .................................................... 28
3.5.8 Deviation test function............................................... 29
3.6 <CORRECTION>.................................................................. 30
3.6.1 OPEN ...................................................................... 31
3.6.2 SHORT .................................................................... 33
3.6.3 LOAD ...................................................................... 34
3.6.4 Load correction test function ...................................... 35
3.6.5 Cable length selection ............................................... 36
3.7 <LIMIT TABLE> ................................................................... 36
3.7.1 Swap parameter ....................................................... 37
3.7.2 Limit modes of compare function ................................ 37
3.7.3 Set nominal value of tolerance mode ........................... 39
3.7.4 Comparator function ON/OFF...................................... 39
3.7.5 Auxiliary bin ON/OFF ................................................. 39
3.7.6 HIGH/LOW............................................................... 40
3.8 <LIST SWEEP SETUP> ......................................................... 41
3.8.1 MODE ..................................................................... 42
3.8.2 Test parameter ......................................................... 42
3.8.3 Sweep parameter setup ............................................. 42
Chapter 4 [SYSTEM] and <FILE MANAGE>............................................. 44
4.1 <SYSTEM SETUP> ............................................................... 44
4.1.1 PASS BEEP............................................................... 44
4.1.2 FAIL BEEP................................................................ 45
4.1.3 LANGUAGE .............................................................. 45
4.1.4 PASS WORD............................................................. 45
4.1.5 BUS MODE (Reserved function)................................... 46
4.1.6 GPIB ADDR (Reserved function) .................................. 46
4.1.7 TALK ONLY............................................................... 46
4.1.8 BIAS SRC ................................................................ 47
4.1.9 BAUD RATE .............................................................. 47
4.1.10 DATA/TIME .............................................................. 47
4.2 LCR <FILE MANAGE> ........................................................... 47
4.2.1 Setup file for single-group component (*.STA) .............. 48
4.2.2 U-disk manage performance....................................... 49
4.2.3 Operation steps for file management ........................... 49
Chapter 5 Execute LCR operation and some examples ............................. 52
5.1 Correction operation
III
............................................................. 52

STB8827Series Operation Manual Contents
5.1.1 Sweep correction ...................................................... 52
5.1.2 Point-freque
IV
ncy correction.......................................... 52
5.2 Correct connection of DUT..................................................... 53
5.3 Eliminate the influence of stray impedance .............................. 54
5.4 Operation example for testing inductance with STB8827A ...........
55 5.5 Operation example of testing capacitance by multi-frequency
list sweep 57
5.6 Transformer Measurement..................................................... 59
5.6.1 Primary and secondary inductance L2A, L2B ................. 60
5.6.2 Turn ratio and polarity measurement N, 1/N ................. 60
5.6.3 Mutual inductance M ................................................. 61
5.6.4 Direct current resistance measurement R2, DCR ........... 61
5.6.5 Leakage inductance Lk .............................................. 62
5.6.6 Winding capacitance Co ............................................. 62
5.7 Setup example of comparator................................................ 62
5.7.1 Capacitor sorting ...................................................... 63
5.8 Operation example of load correction...................................... 64
Chapter 6 Performance and Test ........................................................... 66
6.1 Test function ....................................................................... 66
6.1.1 Parameter and symbol............................................... 66
6.1.2 Equivalent mode....................................................... 66
6.1.3 Range ..................................................................... 66
6.1.4 Trigger .................................................................... 66
6.1.5 Delay time ............................................................... 67
6.1.6 Connection modes of test terminals ............................. 67
6.1.7 Test speed (Frequency>=10kHz) ................................ 67
6.1.8 Average................................................................... 67
6.1.9 Display digit............................................................. 67
6.2 Test signal .......................................................................... 67
6.2.1 Test signal frequency................................................. 67
6.2.2 Signal mode............................................................. 68
6.2.3 Test signal level ........................................................ 68
6.2.4 Output impedance .................................................... 68
6.2.5 Monitor for test signal level ........................................ 68
6.2.6 Maximum measurement display range ......................... 68
6.2.7 DC bias voltage source .............................................. 69
6.3 Measurement accuracy ......................................................... 69
6.3.1 Accuracy of │Z│,│Y│, L, C, R, X, G, B ...................... 69
6.3.2 Accuracy of D........................................................... 69
6.3.3 Accuracy of Q........................................................... 70
6.3.4 Accuracy of ........................................................... 70
6.3.5 Accuracy of G........................................................... 70
6.3.6 Accuracy of Rp ......................................................... 70
6.3.7 Accuracy of Rs.......................................................... 71

STB8827Series Operation Manual Contents
6.3.8 Accuracy factor......................................................... 71
6.3.9 Accuracy of DCR ....................................................... 75
6.4 Safety requirement .............................................................. 75
6.4.1 Insulation resistance ................................................. 75
6.4.2 Insulation intensity ................................................... 75
6.4.3 Leakage current ....................................................... 76
6.5 Electromagnetic compatibility ................................................ 76
6.6 Performance test ................................................................. 76
6.6.1 Working condition ..................................................... 76
6.6.2 The used instruments and devices............................... 76
6.6.3 Function check ......................................................... 77
6.6.4 Test signal level ........................................................ 77
6.6.5 Frequency................................................................ 77
6.6.6 Measurement accuracy .............................................. 77
6.6.7 Accuracy of C and D .................................................. 77
6.6.8 Accuracy of L ........................................................... 78
6.6.9 Accuracy of Z ........................................................... 78
Chapter 7 Command Reference ............................................................ 80
7.1 Subsystem commands for STB8827......................................... 80
7.1.1 DISPlay subsystem commands ................................... 80
7.1.2 FREQuency subsystem commands............................... 82
7.1.3 VOLTage subsystem commands................................... 83
7.1.4 CURRent subsystem commands .................................. 83
7.1.5 AMPLitude subsystem commands ................................ 84
7.1.6 Output RESister subsystem commands ........................ 84
7.1.7 OUTPut subsystem commands .................................... 84
7.1.8 BIAS subsystem commands ....................................... 85
7.1.9 FUNCtion subsystem commands ................................. 87
7.1.10 LIST subsystem commands ........................................ 91
7.1.11 APERture subsystem commands ................................. 95
7.1.12 TRIGger subsystem commands ................................... 95
7.1.13 FETCh? subsystem commands .................................... 96
7.1.14 CORRection subsystem commands .............................. 99
7.1.15 COMParator subsystem commands .............................104
7.1.16 Mass MEMory subsystem commands...........................109
7.2 GPIB Common Commands ...................................................110
Chapter 8 The description for Handler (optional)....................................113
8.1 Technical description ...........................................................113
8.2 The operation description.....................................................113
8.2.1 The definition for the signal line .................................113
8.2.2 Electrical feature......................................................121
8.2.3 HANDLER Interface board circuit ................................122
8.2.4 Operation ...............................................................
V
125

STB8827Series Operation Manual Contents
VI
Announcement
The description of the manual may not cover all contents of the instrument, and
our company is subject to change and to improve the performance, function,
inner structure, appearance, accessory and package of the instrument without
notice. If there is puzzle caused by inconsistency of manual and instrument, then
you can contact with our company by the address on the cover.

STB8827Series Operation Manual Chapter 1 Out of Box Audit
Chapter 1
1
Out of Box Audit
When you receive the instrument, some inspections are necessary, and the
condition must be understood and available before installing the instrument.
1.1 To Inspect the package
Inspect the shipping container for damage after unpacking it. It is not
recommended to power on the instrument in the case of a damaged container.
If the contents in the container do not conform to the packing list, notify us or
your dealer.
1.2 Power connection
1) Power-supplying voltage range: 100~120Vac or 198~242Vac. Being related
with the power setup on the rear panel.
2) Power-supplying frequency range: 47~63Hz.
3) Power-supplying power range: less than 80VA.
4) Power supplying input phase line L, zero line N, ground lead E should be as
same as the power plug of the instrument.
5) After careful design, the instrument can reduce the clutter jamming caused
by AC power terminal input, however, it should be used under the
environment with low-noise. Please install power filter if being unavoidable.
———————————————————————————————————————
Warning: In order to prevent user and instrument from being hurt by
leakage, it is necessary for user to guarantee the ground line of supply
power being reliably grounded.
———————————————————————————————————————
1.3 Fuse
The instrument has installed fuse, so operators should use the installed fuse of
our company.
———————————————————————————————————————
Warning: Be sure that the location of fuse is consistent with
power-supplying voltage range before charging.
———————————————————————————————————————

STB8827Series Operation Manual Chapter 1 Out of Box Audit
1.4
2
Environment
1) Please do not operate the instrument in the place that is vibrative, dusty,
under direct sunlight or where there is corrosive air.
2) The normal working temperature is 0℃～40℃, relative humidity 75%, so
the instrument should be used under above condition to guarantee the
accuracy.
3) There is heat abstractor on the rear panel to avoid the inner temperature
rising. In order to keep good airiness, please don’t obstruct the left and right
airiness holes to make the instrument maintain the accuracy.
4) Although the instrument has been specially designed for reducing the noise
caused by ac power, a place with low noise is still recommended. If this
cannot be arranged, please make sure to use power filter for the instrument.
5) Please store the instrument in the place where temperature is between 5℃
and 40℃, humidity is less than 85%RH. If the instrument will not be put in
use for a time, please have it properly packed with its original box or a similar
box for storing.
6) The instrument, especially the test cable should be far from strong
electro-magnetic field, to avoid the jamming on measurement.
1.5 Use of Test Fixture
Please use the accessory test fixture or cable, the test fixture made by user or
from other company may cause the incorrect measurement result. The
test fixture or cable should be kept clean, as well as the pin of DUT, thus to
guarantee the good connection between DUT and fixture.
Connect the fixture or cable to four test terminals Hcur, Hpot, Lcur, Lpot on the
front panel. As for the DUT with shielding shell, connect shielding layer or ground
“┴”.
Note: When test fixture or cable has not being installed, the instrument will
display an unstable test result.
1.6 Warm-up
1) To guarantee the accurate measurement, the warm-up time is no less than
15min.
2) Please not turn on or off instrument frequently, in order to avoid the inner
data fluster.

STB8827Series Operation Manual Chapter 1 Out of Box Audit
1.7
3
Other features
1) Power: consumption power80VA.
2) Dimension (W*H*D): 430mm*185mm*473mm
3) Weight: About 13kg.

STB8827Series Operation Manual Chapter 2 Introduction
Chapter 2 Introduction
In this chapter, the basic operation features of STB8827 series are described
. Please read the content carefully before using STB8827 series instruments,
thus you can learn the operation of STB8827.
2.1 Introduction to front panel
Figure 2-1 shows the front panel of STB8827.
POWER
CATⅠ
！
±42VDC Max
MEAS SETUP SYSTEM
LPOT HPOT
UNKNOWN
COPY PQRS 98 TUV WXYZ
6
5
GHI JKL MNO
7
4
321 ABC DEF
LCUR
ENTER
ESC
+/-
0
RESET
KEYLOCK
DC BIAS
DC
SOURCE
PASS FAIL
TRIGGER
HCUR
LOG
STB8827C Precision LCR Meter 20Hz-1MHz
1
20 19
6 9
15 1418
2
17 16
710
23
22
21
8
11
12
13
3 4 5
Figure 2-1 Front panel
1) Brand and model
Brand and model USB.
2) [COPY]
Copy the currently displayed page to USB memory.
3) [MEAS]
Press this key to enter into the corresponding measurement display page of
instrument functions.
4) [SETUP]
Press this key to enter into the corresponding measurement setup page of
instrument functions.
5) [SYSTEM]
Press this key to enter into the system setup page.
6) Numerical keys
These keys are used to input data to the instrument. The key consists of
numerical keys [0] to [9], decimal point [.] and [+/-] key.
7) [ESC]
4

STB8827Series Operation Manual Chapter 2 Introduction
5
ESCAPE key.
8) [←]
BACKSPACE key is used delete the last numeric of the input value.
9) PASS indicator
LED indicator shows the test result has passed.
10) FAIL indicator
LED indicator shows the test result has failed.
11) [RESET]
Press this key, other operation cannot be executed on other pages.
12) [TRIGGER]
When the trigger mode is set to MAN mode, press this key to trigger the
instrument.
13) [ENTER]
This key is used to end the input of data, and confirm and save the data
displayed on the inputting line (the bottom line on LCD).
14) Test terminals (UNKNOWN)
4-teminal test pair is used to connect 4-terminal test fixture or cable to
measure DUT.
The 4 terminals are respectively as follows: Hcur, Hpot, Lpot and Lcur.
15) Ground terminal
The ground terminal is connected with the case of instrument, which can be
used to protect or shield the ground connection.
16) CURSOR
This key is used to move the cursor on the LCD displayed page. When the
cursor moves to a zone, the corresponding zone will be lightened.
17) Soft keys
Six soft keys are used to select parameters. The corresponding function of
each soft key has been displayed on its left (the right part of LCD). The
function definition varies with different pages.
18) LOG
This key can record the measurement data automatically after inserting the
U-disk on the MEAS interface.

STB8827Series Operation Manual Chapter 2 Introduction
19)
6
LCD
800*480 colorful TFT LCD displays measurement results and conditions.
20) POWER
Power switch
21) [DC BIAS]
Press this key, it will be lighted which means DC bias output is permitted.
Press this key once more, it will be off which means DC bias output is
prohibited. The key is useless in some pages where the DC BIAS cannot be
added.
22) [KEYLOCK]
Press [KEYLOCK], it will be lighted, which means the function of current panel
is locked. Press it again, it will be off, which means discharging the lock status.
If the password function is ON, it means correct password is necessary when
discharging the key-lock, or the key cannot be unlocked.
When the instrument is controlled by RS232, [KEYLOCK] will be lighted. Press
[KEYLOCK] again, it will be off, which means returning to the local
discharging lock status.
23) USB HOST interface
Connect U flash disk so as to save or load the file.
24) [DC SOURCE]
This key is reserved for future use of extension.
2.2 Introduction to rear panel
Figure 2-2 shows the rear panel of STB8827.
RS-232C
DEVICE
HANDLER
贴标签
LAN
FUSE
T4AL 250V
110V/60Hz 80VA
220V/50Hz 80VA T2AL 250V
!
TO AVOID ELE CTRIC SHOCK,
THE POWER CORD PROTECTIVE GROUNDING CONDUCTOR
MUST BE CON NECTED TO GROUND.
DISCONNECT P OWER SUPPLY BEFORE REPLACING FUSE.
WARNING
IEEE-488 DC BIAS
~
~
RATING
1 2 3 4 5
8 7 6
Figure 2-2 Rear panel
1) LAN interface
LAN interface is used to realize the control and the communication of network

STB8827Series Operation Manual Chapter 2 Introduction
system.
2)
7
USB DEVICE interface
The tester can communicate with PC through the USB DEVICE interface.
3) RS232 interface
Series communication interface can realize the communication with PC.
4) HANDLER interface
Handler interface is used to realize the sorting output of test results.
5) IEEE-488 interface
The tester can communicate with PC through GPIB interface.
6) Ground terminal
The ground terminal is connected with instrument casing, being available for
protecting or shielding ground connection.
7) Power socket
Input AC power.
8) Nameplate
Information about production date, instrument number and manufacturer
etc..
———————————————————————————————————————
Warning: Be sure that the direction of fuse is accordant with
power-supply voltage range before charging.
———————————————————————————————————————
2.3 Introduction to display zone
STB8827 applies a 65k, 4.3-inch TFT display. The display screen is divided into
the following zones:

STB8827Series Operation Manual Chapter 2 Introduction
8
1
4 3 2
Figure 2-3 display zones
1) Display page name
Indicate the name of the currently displayed page.
2) Soft keys
The zone is used to display the function definition of soft key. The definition of
soft key can be different as the difference of cursor’s direction in the zone.
3) Test result/ condition display zone
In this zone, test result information and current condition are displayed.
4) Help
In this zone, information about system and user data input is displayed.
2.4 Main menu keys and corresponding displayed
pages
2.4.1 [MEAS]
When the LCR function is active, press this key-[MEAS] to enter into the LCR
measurement display page, the following soft keys will be displayed in the soft
key zone.
<MEAS DISPLAY>
<BIN NO.>
<BIN COUNT>
<LIST SWEEP>
<FILE MANAGE>

STB8827Series Operation Manual Chapter 2 Introduction
2.4.2
9
[SETUP]
When the LCR function is active, press this key-[SETUP], the following soft keys
will be displayed in the soft key zone on the LCR measurement setup page.
<MEAS SETUP>
<CORRECTION>
<LIMIT TABLE>
<LIST SETUP>
<FILE MANAGE>
2.4.3 [SYSTEM]
This key-[SYSTEM] is used to enter into the system setup page. The following
soft keys will be available:
<SYSTEM SETUP>
<LAN SETUP>
2.5 Basic Operation
Basic operation of STB8827 is as follows:


Use menu keys ([MEAS], [SETUP], [SYSTEM]) and soft keys to select the
desired page.
Use cursor keys ([←][→] [↑] [↓]) to move the cursor to the desired zone.
When the cursor moves to a specified zone, the zone will become reverse
expression.
The soft key functions corresponding to the current zone of the cursor will be
displayed in the soft key zone. Users can select and use the desired key.
Numeric keys, [←] and [ENTER] are used to input data.
When a numeric key is pressed down, the usable unit soft key will be
displayed in the soft key zone. You can choose a unit soft key or press [ENTER]
to end data inputting. When [ENTER] is used to terminate data inputting, the
unit of data will be set to a default unit, such as Hz, V or A. For example, the

default unit for frequency is Hz.
2.6 Start the instrument
Plug in 3-line power plug.
Caution: Keep the power-supply voltage and frequency conform to above
specifications. Power input phase line L, zero line N, ground line E should be the
same as that of the instrument.
Press the power switch at the left corner on the front panel and then a boot screen
will appear which displays our company logo, instrument model (STB8827A),
and

STB8827Series Operation Manual Chapter 2 Introduction
10
the version number of the software.
If the password protection function is on, users are required to input the
password and then press [ENTER] to enter into the page of main menu.
———————————————————————————————————————
Note: The instrument has a default password-2827. In your practical use, you
can change it and set your own one. Please see <SYSTEM> section for more
information.

STB8827Series Operation Manual Chapter 3 Introduction to [MEAS]
Chapter 3
11
Introduction to [MEAS]
3.1 <MEAS DISPLAY>
When the LCR function is applied, press [MEAS], the <MEAS DISPLAY> page will
be displayed on screen as shown in the following figure.
STB8827-301
On this page, the test result is displayed in upper-case character. The
measurement control parameters can be set in this page:
Test function (FUNC)
Test frequency (FREQ)
Test level (LEVEL)
Test ran ge ( RA NG E)
Test speed (SPEED)





DC BIAS
There are 6 zones in this page: FUNC, FREQ, LEVEL, RANG, SPEED and DC
BIAS. The details will be discussed later.
The test result/ condition display zone shows the information about test condition.
These conditions can be set on <MEAS SETUP> page or <CORR> page.
Signal source voltage/ current monitor (Vm, Im)
Open, short, load correction ON/OFF status (CORR

)
3.1.1 Test function
In a measurement period, STB8827 can test two parameters for an
impedance component: one primary parameter and one secondary parameter.
Parameters that can be tested are as follows:

STB8827Series Operation Manual Chapter 3 Introduction to [MEAS]
12
Primary parameter
|Z| (Module of impedance)
|Y| (Module of admittance)
L (Inductance)
C (Capacitance)
R (Resistance)
G (Conductance)
DCR (DC resistance)
L2A (Primary inductance)








L2B (Secondary inductance)
Secondary Parameter
D (Dissipation factor)
Q (Quality factor)
Rs(Equivalent Series Resistance ESR)
Rp(Equivalent Parallel Resistance)
X (Reactance)
B (Susceptance)
(Phase Angle)
N, 1/N (Turn ratio and polarity)
M (Mutual inductance)









R2 (DC resistance)
Test results of primary and secondary parameters are respectively displayed in
two lines in the form of upper-case characters. The primary parameter displays in
the upper line while the secondary parameter displays in the lower line.
Operation steps for setting test function:
1) Move the cursor to FUNCA zone, the following soft keys will be displayed on
the screen.
Cp—…→
Cs—…→
Lp—…→
Ls—…



→
↓
2) Press the soft key corresponding to Cp—…→, the following parameters will be
shown for your choice.
Cp-D
Cp-Q
Cp-G
Cp-R



p
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.

STB8827Series Operation Manual Chapter 3 Introduction to [MEAS]
3) Press Cs—…→
13
, the following parameters will be shown for your choice.
Cs-D
Cs-Q


Cs-Rs
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
4) Press Lp—…→, the following parameters will be shown for your choice.
Lp-D
Lp-Q
Lp-G
Lp



-Rp
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
5) Press Ls—…→, the following parameters will be shown for your choice.
Ls-D
Ls-Q


Ls-Rs
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
6) Press ↓, another group of soft keys will be shown.
Z—…→
Y—…→
R—…


→
↑
↓
7) Press Z—…→, the following parameters will be shown for your choice.
Z-d
Z-r
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
8) Press Y—…→, the following parameters will be shown for your choice.
Y-d
Y-r
←

STB8827Series Operation Manual Chapter 3 Introduction to [MEAS]
Press the soft key corresponding to your desired parameter. Then press ←to
14
return to upper soft key menu.
9) Press R—…→, the following parameters will be shown for your choice.
R-X
Rp-Q


Rs-Q
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
10) Press ↓, the following parameters will be shown for your choice.
G-B
DCR
L2A—…→
L2B —…



→
↑
11) Press G-B, choose the desired parameter.
12) Press DCR, choose the desired parameter.
13) Press L2A-…→, the following parameters will be shown for your choice.
L2A-N
L2A-1/N
L2A-M



L2A-R2
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
14) Press L2B-…→, the following parameters will be shown for your choice.
L2B-N
L2A-1/N
L2B-M



L2B-R2
←
Press the soft key corresponding to your desired parameter. Then press ←to
return to upper soft key menu.
