Salus KL08RF User manual

KL08RF
Installation and Wiring Guide
www.salus-controls.com Technical Helpline [phone]
GROUP 2
GROUP CONTROL
THERMOSTAT
MAINS POWERED
(MODEL VS10WRF)
BATTERY POWERED
PROGRAMMABLE
ROOM THERMOSTAT
(MODEL VS20WRF)
GROUP 1
THERMOSTAT
(VS20WRF)
GROUP 1
THERMOSTAT
(VS20WRF)
GROUP 1
THERMOSTAT
(VS10WRF)
GROUP 2
THERMOSTAT
(VS10WRF)
GROUP 2 CONTROL
THERMOSTAT
(VS20WRF)
GROUP 1
STANDALONE
PROGRAMMABLE
ROOM THERMOSTAT
(MODEL
VS10W
(M
ODEL VS20WRF
)
WRF)
WRF)
SUPPLIED CABLES
230V TO UFH PUMP
UNDERFLOOR HEATING MANIFOLD
1.5MM 2CABLE (INSTALLER SUPPLIED)
Optional boiler connection
NL
External power supply
NL
These instructions apply to the SALUS model stated above.
Warning
This product must be tted by a competent person, and
installation must comply with the guidance, standards and
regulations applicable to the country or state where the
product is installed. Failure to comply with the requirements
of the relevant guidance, standards and regulations could lead
to injury, death or prosecution.
Warning
Always isolate the AC mains supply before installing or working
on any components that require 230 V AC 50Hz supply.
For PDF Installation guide go to www.salus-controls.com
Meets the following EC Directives
• Electro-Magntic Compatibility directive 2004 / 108 / EC
• Low-voltage Directive 2006/95/EC
Optional wireless
receiver RX10RF
Maintaining a policy of continued product development SALUS Controlsplc reserves the right to change
specication, design and materials of products listed on this installation guide without prior notice.
Issue Date: October 2014 Document Number 00106
Warning
The earth terminals on the KL08RF are for earth parking only.
These terminals provide no earth protection.
iT600 Wiring Centre KL08RF 028 V9.qxp_Layout 1 04.12.2014 12:30 Strona 1

Installation and Wiring Guide KL08RF
www.salus-controls.com Technical Helpline [phone]
Installing and Connecting the KL08RF
Use the KL08RF wireless wiring centre to simply and safely connect thermostats and
corresponding thermal actuators. The KL08RF connects to the wireless network through the
CO10RF coordinator. One coordinator can support up to nine wiring centres, which means
that if you buy more than one wiring centre, you will only need one of the included
coordinators. Keep the other coordinators in a safe place as spares. Install the KL08RF only
in dry and closed interior rooms. Relative air humidity in the room may not exceed 95%. Clean
the KL08RF only with a dry and soft cloth. Do not use solvents or aggressive cleaning agents.
Remove the plastic
cover. Open (and
close) the four white
screws with a quarter
turn only. Note that
screws on opposite sides
turn in the opposite
direction.
2Remove the
white terminal
connection board
3Attach the back of
the KL08RF to the
DIN rail or wall.
4Cut the power and
device cable to
length.
6Push the power
wires into the round
power holes.
Attach the white
strain-relief using
the two screws to secure
the power wires.
8Push the thermal actuator wires into the
round holes at the bottom of the
KL08RF. You can connect up to three
actuators in each zone.
9
Push in the Pump wires at the bottom
right of the KL08RF for volt-free pump
switching.
10 Push in the Boiler wires at the bottom
right of the KL08RF for volt-free boiler
switching. When a zone calls for heat,
the boiler switch closes causing the
boiler to run.
11 Push in the CO wires at the bottom
right of the KL08RF for volt-free
heating/cooling changeover switching.
An open switch is for heating (red LED).
A closed switch is for cooling (blue LED).
12 Push in the Dew Point wires at the
bottom right of the KL08RF for volt-free
humidity sensing.
13
Attach the red strain-relieving strip
using the three screws to secure the
pump, boiler, CO, and dew point wires
to the bottom side of the KL08RF.
14 Set the boiler delay, wireless, and thermal
actuator jumpers at the top right of the
KL08RF.
Jumper Settings/Positions for Pump/Boiler On/O Delay
The pump/boiler on delay and the pump o
delay are xed at three minutes. The default
setting for the boiler o delay is also three
minutes, but can be changed to 15 minutes.
To do this, carefully remove the jumper and
re-insert it in the other position as shown below:
Wireless
The default setting for the wireless connection
is internal (INT). To change this setting to
external (EXT), carefully remove the jumper and
re-insert it in the other position as shown below:
Type of Actuator
The default setting for the type of actuator is
normally closed (NC). To change this setting to
normally open (NO), carefully remove the
jumper and re-insert it in the other position as
shown below. Note that the actuator setting and
thermostat setting must be the same.
15 Make sure there is a fuse in the fuse
holder.
LED indications
Name Colour Meaning
Power •KL08RF is supplied with 230V power
G1 •Wireless network activity on group 1 thermostats
G2 •Wireless network activity on group 2 thermostats
Network Status •KL08RF is waiting to pair
•KL08RF is connected to the wireless network
Zone 1 actuators •Demand from group 1, zone 1 thermostat: actuator open
Zone 2 actuators •Demand from group 1, zone 2 thermostat: actuator open
Zone 3 actuators •Demand from group 1, zone 3 thermostat: actuator open
Zone 4 actuators •Demand from group 1, zone 4 thermostat: actuator open
Zone 5 actuators •Demand from group 2, zone 1 thermostat: actuator open
Zone 6 actuators •Demand from group 2, zone 2 thermostat: actuator open
Zone 7 actuators •Demand from group 2, zone 3 thermostat: actuator open
Zone 8 actuators •Demand from group 2, zone 4 thermostat: actuator open
Pump •Pump on
Boiler •Boiler on
CO •Heating mode
•Cooling mode
16 Plug in the CO10RF coordinator.
Replace the
plastic cover.
Switch on mains
power supply to
the unit. The red
LED comes on.
Connecting the KL08RF(s) to the ZigBee
Wireless Network
1. On powering up the KL08RF, all actuator
LEDs light up green then go o, then the
Network Status LED ashes green.
2. Press and hold the button on the
coordinator for ve seconds. The button
ashes red to indicate the coordinator is
ready to pair.
The Network Status LED on the KL08RF goes steady green when
connected.
3. Repeat the process for every KL08RF in the system. Note that one
coordinator can support up to nine KL08RFs.
4. To identify your KL08RF (WC) number press Pair for one second. The
LED on the zone number lights green: Zone 1 = WC -1, Zone 2 = WC -
2, and so on. The Network Status LED is used to identify WC-9.
5. To pair your VS10RF or VS20RF thermostats, see your thermostat
manual.
6. Press the coordinator button for ve seconds until the LED shines
steady red.
Note: To restore the KL08RF back to factory default settings at any time,
using a suitable tool, press the Reset button to the right of the Pair
button.
Checking the System Conguration and Communication
· Press and hold the coordinator button for one second. All devices
connected to the system ash. To stop checking, press and hold the
coordinator button again for one second.
· Press and hold the Pair button on theWC for ve seconds. All devices
connected to the KL08RF ash. To stop checking, press and hold the
Pair button again for ve seconds.
Deleting all Devices from the Wireless Network
· To delete all devices connected to the network, press and hold the
coordinator button for 15 seconds. The colour of the button changes
from red to amber.
· To delete all devices connected to the KL08RF, press and hold the
Network Status button on the KL08RF for 15 seconds. The G1 and G2
LEDs turn from ashing red to solid red then go o.
Note: After all devices have been deleted from the wireless network, they
will need to be reinstalled. Refer to the instruction manuals.
17
7
Device
Power/Thermostat
50mm
110mm
10mm
10mm
If you need to install the optional
external antenna and have set the
Wireless jumpers to EXT:
a. Disconnect power.
b. Remove the protective
cap from the antenna
connection on the
underside of the
KL08RF.
c. Screw the antenna into
the KL08RF.
d. Reconnect power. The
KL08RF will now use
the external antenna
and not the internal
antenna.
19
•Heating mode
•Cooling mode
5Replace the
white terminal
connection board
1
18
