Salus Connected Wireless System User manual

SMC-GM-CWSG-M2-2019.11v1_2019-11-14
Connected Wireless System Guide
Module 2 – Wireless Accessories

Section Page
1 Accessories Overview
Using this Manual...................................................................................................1-1
System Overview ...................................................................................................1-2
2 SS881ZB Embedded Door Sensor
Included Parts / Installation Tools....................................................................................2-1
Pairing Instructions .................................................................................................2-2
Installation Instructions .............................................................................................2-4
Battery Replacement................................................................................................2-6
Resetting Factory Defaults ..........................................................................................2-7
3 SS882ZB Window/Door Sensor
Included Parts / Installation Tools....................................................................................3-1
Pairing Instructions .................................................................................................3-2
Installation Instructions .............................................................................................3-4
Battery Replacement................................................................................................3-5
Resetting Factory Defaults ..........................................................................................3-6
4 SX885ZB miniSmartPlug
Included Parts / Installation Tools....................................................................................4-1
Pairing Instructions .................................................................................................4-1
Using the Switch....................................................................................................4-3
Schedule Setup with SALUS Smart Home Application ................................................................4-4
Resetting Factory Defaults ..........................................................................................4-5
Rejoining a Current Network ........................................................................................4-5
LED Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Troubleshooting ....................................................................................................4-6
5 SS912ZB Slim Window/Door Sensor
Included Parts / Installation Tools....................................................................................5-1
Pairing Instructions .................................................................................................5-2
Installation Instructions .............................................................................................5-4
Battery Replacement................................................................................................5-5
Resetting Factory Defaults ..........................................................................................5-5
6 SS909ZB Temperature Sensor
Included Parts / Installation Tools....................................................................................6-1
Pairing Instructions .................................................................................................6-2
Installation Instructions .............................................................................................6-4
Battery Replacement................................................................................................6-5
Resetting Factory Defaults ..........................................................................................6-6
SALUS Connected Wireless System Guide
Contents: Wireless Accessories
Module 2
i

Section Page
7 SS901ZB Water Leak Sensor
Included Parts / Installation Tools ....................................................................................7-1
Pairing Instructions .................................................................................................7-2
Installation Instructions .............................................................................................7-4
Testing the Sensor ..................................................................................................7-5
Battery Replacement................................................................................................7-6
Resetting Factory Defaults ..........................................................................................7-7
8 SC904ZB Inline Shutoff Valve
Included Parts / Installation Tools ....................................................................................8-1
Pairing Instructions .................................................................................................8-2
Installation .........................................................................................................8-4
Local Opening/Closing..............................................................................................8-4
Manual Override ....................................................................................................8-5
Resetting Factory Defaults ..........................................................................................8-5
9 SC824ZB Smart Relay – Low Voltage
Included Parts / Installation Tools ....................................................................................9-1
Installation – Wall Mount with Cover.................................................................................9-2
Installation – Adhesive Surface Mounting............................................................................9-3
Pairing Instructions .................................................................................................9-4
Local Relay Operation ...............................................................................................9-6
Schedule Setup – SALUS Smart Home ...............................................................................9-6
Setup Options ......................................................................................................9-8
Resetting Factory Defaults ..........................................................................................9-9
SALUS Connected Wireless System Guide
Contents: Wireless Accessories
Module 2
ii

1-1
Using this Manual
For the latest Instructions go to: WWW.SALUSINC.COM
To cover all SALUS Wireless Products without requiring customers to download documentation
unrelated to their installations, the Connected Wireless Systems Guide has been divided into 5
modules. Module 1 is required for all wireless systems since it covers installation of the SG888ZB
Gateway and the SALUS Smart Home application. The remaining modules are specic to a particular
group of controls.
Below is a description of several icons used to direct the reader’s attention.
Special Attention Boxes
This manual uses special attention icons to alert the reader of important safety concerns, information
important to reliable operation of the controls or helpful installation/setup information.
Safety:
Indicates a condition which may cause severe personal
injury, death or major property damage
Important Information:
Indicates information which requires special attention
for correct operation of the control
Your Benet:
Indicates helpful installation or setup information
Module 2 – Wireless Accessories
Introduction
Section 1

1-2
Module 2 – Wireless Accessories
Introduction
Section 1
Accessories Overview
The SALUS Smart Home application can access wireless sensors and other accessories for control and
notication of household systems from a smart device or computer. The following diagram shows an
overview of wireless accessories available from SALUS. Volume 2 of the Wireless System Guide covers
the installation and operation of these devices. Instructions for installing the SG888ZB Gateway and
connecting it to the SALUS Smart Home application are provided in Volume 1.
SS881ZB
Embedded Door
Sensor
SX885ZB
miniSmartPlug
SS882ZB
Door/Window
Sensor
SS912ZB
Slim Door/Window
Sensor
SC904ZB
Inline Shuto
Valve
SS901ZB
Water Leak Sensor
SS909ZB
Temperature
Sensor
SS824ZB
Smart Relay
Low Voltage
SG888ZB
Universal Gateway

2-1
Module 1 of the SALUS Wireless Systems Guide provides information about installation/setup of the
SG888ZB Gateway that provides communication between devices and, if desired, with the internet.
The following descriptions provide instructions for installation of the hydronic components.
Overview
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Pair the SS881ZB Embedded Door Sensor with the SG888ZB Gateway prior to installation.
Item Description
Installation
Slots Slots for installation tool
Plunger
Switch/LED
Detects open/close status of
door. LED Indicator
Tamper
Switch
Detects if sensor is removed
from Hole Sleeve
Hole Sleeve Accepts sensor and allows for
sensor height adjustment
Sleeve
“Clicker”
Aligns with Sleeve Slots to limit
unwanted sensor rotation
Battery
Cover
Encloses the battery
compartment
Parts Included / Installation Tools
Conrm that all required parts are present in the SS881ZB package:
Installation
Slots Sleeve
Slots
Plunger Switch/LED Tamper Switch
Battery Cover
Sleeve
"Clicker"
Hole
Sleeve
CR2 Battery
Sensor w/ Battery
(CR2, 3Vdc)
Sensor Sleeve Installation Tools (2) Self-adhesive Drill
Guides (2)
Installation Manual
Conrm that required tools are available:
7/8” Drill Bit Power Drill Rubber Mallet

2-2
Pairing Instructions
Step 1. Open the SALUS Smart Home application, select the drop-down menu from the upper
right of the screen and select: All Devices Add New Device
Locate the SS881ZB Embedded Door Sensor in or near the location that it will be installed to account for
radio interference.
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Step 2. Press Scan Devices. After pressing“Scan for Equipment”,
the SALUS Smart Home application
scans for devices.
Step 3. Remove the battery tab
to start the pairing process.

2-3
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Step 7. Choose from setup
options specic to this device.
Press “Complete set up.”
Step 8. Press “Finish” to
complete pairing.
A new icon will appear on
your home screen. Since the
sensor is not installed it shows
the door open.
Step 4. Select the check box
next to Embedded Door Sensor
and press “Connect equipment”
Step 5. Enter a unique
descriptive name to identify
the device. Press “Next”
Step 6. Press “Please click
here to setup.”
After several minutes without the plunger switch depressed, an issue alert will show on the home screen.

2-4
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Step 1. Apply a self-
adhesive drill guide
to mark the desired
location.
Step 2. Drill a 7/8”
diameter hole at least 2.6”
deep through the guide.
Then remove the guide
remnants.
Step 3. Insert the sensor
sleeve in the hole until the
ange seats on the surface.
SALUS recommends locating the embedded door sensor in the door jamb on the hinge
side of the door so that closing the door activates the plunger (A1 Above). If this location
is not convenient due to obstacles such as glass panels, the sensor can be mounted
on the opposite door jamb (A2), in the lintel above the door (B) or in the door itself (C).
Location C is not recommended for steel doors due to potential signal interference issues.
If required, remove the ange from
the sleeve before inserting.
Installation Instructions

2-5
If closing the door doesn’t activate the Sensor and show a closed door on the SALUS Smart Home
application, turn the Sensor counter-clockwise in ¼ turn increments until it activates when the
door is closed.
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Step 4. Insert the Sensor into the Sensor
Sleeve using the Installation tool until the face
of the sensor is ush with the Sensor Sleeve.
Step 5. Close the door and make sure the
Sensor operates properly, with the SALUS
Smart Home application showing the correct
door position.
Step 6. Once the Sensor is at the correct depth, align the Sensor slots with the grooves in the Sensor
Sleeve to prevent undesireable rotation.

2-6
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Battery Replacement
Use only Duracell DL-CR2, Energizer EL-CR2, GP Batteries GPCR1, or Ray-O-Vac RL-CR2 batteries to meet
UL certication requirements.
Note the installation depth of the Sensor in the Sensor Sleeve before removing. If convenient, mark the
sensor depth before proceeding to STEP 1.
Step 4. Insert the new
battery, negative end rst.
Step 5. Replace the battery
cover as shown and re-install
the Sensor.
Step 1. Remove the Sensor by
turning counter-clockwise with
the Installation Tool, a coin or a
washer.
Step 2. Open the battery
compartment by pressing on
the back and lifting.
Step 3. Remove the old battery
by lifting the positive side.
Battery
Disposal
Lithium batteries are considered
hazardous waste in most
municipalities. Dispose of the
used lithium batteries in
accordance with all applicable
local regulations.

2-7
Module 2 – Wireless Accessories
SS881ZB Embedded Door Sensor
Section 2
Resetting Factory Defaults
Step 4. Press and hold
the tamper switch while
re-inserting the battery.
Release the switch when the
LED plunger switch lights.
Step 5. Close the battery cover
and pair and name the Sensor as
described in Pairing Instructions.
Re-install the Sensor, making
sure it activates when the door
closes.
Step 1. Select the SS881ZB
icon from the SALUS Smart
Home dashboard. After the
tile ips, choose the device
name in the upper left.
Step 2. Scroll to the bottom
of the next screen and select
“Remove shared door monitor.”
Step 3. Remove the Sensor from
the Sensor Sleeve and remove the
battery as described under Battery
Replacement.
Step 6. Follow the steps for pairing
shown in Pairing Instructions.

3-1
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
Overview
Pair the SS882ZB Door/Window Sensor with the SG888ZB Gateway prior to installation.
Item Description
LED “Hidden” LED indicates network
status during pairing
Tamper
Switch
Detects if sensor is removed
from mounted location
Mounting
Plate
Mounting base for Sensor to
allow no-tool battery change
Battery CR3032 lithium battery
(3 volts dc)
Included Parts / Installation Tools
Conrm that all required parts are present in the SS881ZB package:
Sensor w/ Mounting
Plate & Lithium Battery
(CR3032, 3Vdc)
Sensor Sleeve Mounting Kit Installation Manual
Conrm that required tools are available:
#1 Phillips
Screwdriver
1/16” Drill Bit
(Optional)
Power Drill
(Optional)
LED Tamper Switch
Battery
Mounting
Plate
Sensor Front Sensor Back

3-2
Step 1. Open the SALUS Smart Home application, select the drop-down menu from the upper
right of the screen and select: All Devices Add New Device
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
The SS882ZB Door/Window Sensor should be near the location that it will be installed to account for
radio interference.
Pairing Instructions
Step 2. Press Scan Devices. After pressing“Scan for
Equipment”, the SALUS Smart
Home application scans for
devices.
Step 3. Detach the mounting
plate from the Sensor and
remove the battery tab to start
the pairing process.

3-3
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
Step 7. Choose from setup
options specic to this device.
Press “Complete set up.”
Step 8. Press “Finish” to
complete setup.
If the door or window opens,
the symbol indicates this by
showing an open window.
Also, the Issue indicator will
appear.
Step 4. Select the check box
next to Window Sensor and
press “Connect equipment
Step 5. Choose a unique
descriptive name for each
sensor location and press“Next”
Step 6. Press “Please click
here to setup.”

3-4
Step 1. Locate the Sensor and Magnet. MAKE SURE that the square corners of the Sensor and the Magnet
face each other. If the SALUS recommended option (Figure A) is not possible, the sensor can be mounted on
thedoororwindowwith themagnet mountedon thecasing. If necessary, thecomponents canbemounted
on dierent levels (Figure B) or dierent orientations (Figure C). Because of the narrow gap between the
window and the screen on a casement window, the sensor can be mounted inside of the screen (Figure D).
The double-sided tape, included with the SS882ZB Door/Window Sensor may be used in cases where
water/vapor seals or barriers may cause an issue. For UL certied installation, screws must be used.
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
Installation Instructions
The key criteria for locating the magnet in relation to the sensor are:
- The magnet should be within 1 inch of the center of the square cornered edge of the sensor
- The magnet should be along the same axis as the straight cornered edge
SALUS recommends locating the Window/Door Sensor on the window or door casing on the handle
side. The Magnet should be mounted on the window or door as close as possible to the Sensor. To be UL
compliant, the Sensor and Magnet must be mounted using the screws.
Figure A Figure B Figure C Figure D
Step 2. Attach the Sensor
and Magnet mounting plates
in the desired locations.
NOTE: If the tamper switch is not
engaged, an“Issues”indicator will appear
on the dashboard and the Sensor icon will
turn red. Pressing “Issues”will show that
the “Sensor is Tampered”
Step 3. Snap the sensor
onto the mounting plate
and verify that the tamper
switch is engaged.

3-5
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
Step 1. Remove the
SS882ZB Sensor from
the Mounting Plate,
exposing the battery
attached to the Sensor.
Step 4. Open the Magnet
Case and position the bottom
housing to the surface using
the provided screws or double-
sided tape. Once it is secure,
snap the top housing with
the magnet onto the bottom
housing.
Step 5. With the door or window
closed, make sure the dashboard
icon shows a closed window.
Step 6. Open the window and
make sure the window icon is
open and, after 60 seconds, the
Issue indicator will register the
issue.
Battery Replacement
If the battery is low, the sensor icon on the SALUS Smart Home
dashboard will turn red and the Issue indicator will register a
message. Use only Panasonic CR3032 or EVE Energy CR3032 to
meet UL certication requirements.
Battery Disposal
Lithium batteries are considered hazardous waste in most
municipalities. Dispose of the used lithium batteries in accordance
with all applicable local regulations.
Step 4. Snap the
Sensor back onto
the Mounting Plate,
making sure the
rounde corners
match.
Step 2. Lift the battery
to remove it from the
battery socket.
Step 3. Insert the new
battery into the socket.
Make sure the positive
terminal faces up after
inserting.

3-6
Module 2 – Wireless Accessories
SS882ZB Door/Window Sensor
Section 3
Resetting Factory Defaults
To reset the SS882ZB Door/Window Sensor to factory default values, rst remove the sensor from the
SALUS Smart Home application.
Step 3. Notication that the
Sensor will be removed is
displayed. Press “Delete” to
continue. The SS882ZB Icon
will be removed from the
application.
Step 4. Remove the Sensor
from the Mounting Plate
and remove the battery.
Step 1a. If the Sensor is pinned
to the SALUS Smart Home
application dashboard, select it
and then select the tile label in
the upper left corner.
Step 1b. If the Sensor is not on
the dashboard, choose Menu 
All Devices and nd the Sensor.
Click on the icon.
Step 2. Scroll down and
choose “Remove shared
window monitor” from the
screen.
Step 5. While holding down
the Tamper Switch, re-insert
the battery and, when the LED
illuminaes, release the switch.
The Sensor is no ready to join
a network. Follow the pairing
sequence to join the network.
Step 6. Snap the Sensor onto
the Mounting Plate observing
the proper orientation of the
round corners.

4-1
Module 2 – Wireless Accessories
SX885ZB miniSmartPlug
Section 4
Included Parts / Installation Tools
Conrm that all required parts are present in the SX885ZB package:
Item Description
Plug NEMA 5-15 (Type B) plug compatible
with US/CAN 120VAC/15 A outlets
Socket
NEMA 5-15 grounded (Type B) outlet
compatible with US/CAN 120VAC/15 A
electrical outlets
Multi
Button
Multi-functional user input button: Pair,
Rejoin, Factory Defaults and On/Off
LED White LED status indicator
Pairing Instructions
The SX885ZB miniSmartPlug should be near the location that it will be installed to account for
radio interference.
Step 1. Open the SALUS Smart Home application, select the drop-down menu from the upper
right of the screen and select: All Devices Add New Device
LED
Plug
Socket
Multi Button
miniSmartPlug Installation/
User Guide
Overview

4-2
Step 2. Press Scan Devices. After pressing“Scan for
Equipment”, the SALUS Smart
Home application scans for
devices.
Step 3. Plug the SX885ZB
miniSmartPlug switch
into the desired AC outlet
location to account for any
radio interference.
Module 2 – Wireless Accessories
SX885ZB miniSmartPlug
Section 4
Step 4. Press the multi button to
begin pairing. The LED will ash,
indicating that the Smart Plug is
searching for a network.
Step 5. Select the check box
next to Smart Plug and choose
“Connect Devices.”
Step 3. After Choose a unique,
descriptive name for the Smart
Plug and press“Next”.
LED Multi
Button
