Salus RT510BC User manual

TEST/ PAIRING
SELECT
+Hr
SET
iOnce paired please close the
boiler control panel.
The LED will start flashing red.
TEST/ PAIRING
+Hr
SELECT SET
RXBC605 Installation
RXBC605 Wiring Terminals
RXBC605
1
3
6
2
5
4
Remove the front panel from the boiler.
Do not remove boiler loop.
Replace the front panel ensuring a good seal is made.
Connect the electrical plug.
Pull out the mechanical timer.
Push fit boiler control into housing.
7Power up the boiler and check the correct operation.
Quick Guide
RT510BC
Always isolate the AC Mains supply before installing or working on any components
that require 230 VAC 50Hz supply.
RT510TX Button Functions
Introduction
The RT510TX thermostat will switch your heating system on or o, as needed, in accordance
with the time and temperature set by you. It can be used with the RXBC605 integral plug-in RF
boiler control.The RF boiler control is a direct replacement for the basic time clock or blanking
plate usually supplied with the boiler. Installing the RF boiler control takes minutes. Once
installed, you will benefit from all the control features of the RT510TX thermostat.
868.0-868.6MHz; <13dBm
Safety Information
Use in accordance with the regulations. Indoor use only. Keep your device completely dry. Disconnect
your device before cleaning it with a dry cloth. This accessory must be tted by a competent person, and
installation must comply with the guidance, standards and regulations applicable to the city, country or
state where the product is installed. Failure to comply with the relevant standards could lead to prosecution.
Product Compliance
Thisproductcomplieswith the essential requirementsand other relevantprovisionsofthe following EU Directives: EMC
2014/30/EU, LVD 2014/35/EU, RED 2014/53/EU and RoHS 2011/65/EU. Full text of the EU Declaration of Conformity is
available on www.saluslegal.com
+Hr
SELECT
SELECT
SET
SET
+
+
+
Key Function
1. Press once to activate Frost Mode
2. Press for 3 seconds in order to activate Holiday Mode
Press once to activate/deactivate Boost function
Press once to enter/exit Permanent Override function
Increase button
Decrease button
Select the clock or programme settings
Press to conrm your settings
1. Press once to enter/exit inTest Mode
2. Press for 3 seconds to enter/exit Pairing Mode
Press the buttons for 3 seconds to enter Installer Mode
Press the buttons for 3 seconds to enter Clock Settings
Box content
Quick Guide 2 x AA Alkaline
Batteries 2 x Fixing Screws
RT510TX Desk Stand
RT510TX Dip Switch Settings
The DIP Switches can be found on the rear of your thermostat.
Control feature TPI Span
Operation When TPI is selected on DIP
switch № 2, the DIP switch
№ 1 is functional. You can
choose the Cycles Per Hour
between a lower comfort
level (6CPH) and a higher
comfort level (9CPH).
When Span is selected
on DIP switch № 2,
the DIP switch № 1 is
not functional. The
temperature accuracy of
your thermostat is set to
± 0.25 °C.
TEST/ PAIRING
SELECT
+Hr
SET
TEST/ PAIRING
SELECT
+Hr
SET
3 Sec
TEST/ PAIRING
+Hr
SELECT SET
3
4
Test the Pairing Process
Pairing Process
Once the LED stops flashing, press the
TEST / PAIRING button for 3 sec.
12
Begin the pairing process
End the pairing process
i
i
i
During test pairing, boiler control should ash conrming pair. If not, please follow
Pairing Process.
When enter test pairing
mode, after a 10 minute
countdown the thermostat
will time out.
Terminal Identier Description
1 N Neutral
2 L Live input (230V AC)
3COM Common terminal (volt free)
4 N.O. Normally Open
RXBC605 User Controls
RXBC605 Switch Position
LED - It will be on when the thermostat is demanding
heat.
Mode Switch
The AUTO / MANUAL switch allows you to turn on the
Boiler Control manually if required.
SYNC Button - This is used only for pairing the RF
communications.
Press the SYNC button for 3
seconds until LED starts ashing.
The LG+5V is ready to be paired
with your thermostat.
3 Sec
2. MANUAL mode. The user
can also move the switch to the
MANUAL position; when in this
mode, the boiler will be always turned
on and the LED indicator will also
be lit constantly. The manual mode
is only to be used as a temporary
control if problems develop with the
communication from the thermostat.
1. AUTO mode. When the switch
on the Boiler Control is in the AUTO
(normal) position, the Boiler Control
will automatically receive the RF signal
from the transmitter and control the
boiler based on the programming of
the transmitter. 1 2
When the thermostat is operating in
NORMAL mode, if the Boiler Control has
not received a signal from the transmitter
after 1 hour, the Boiler Control will turn
off the boiler, and the LED indicator will
flash constantly (two times every second).
Once the Boiler Control receives a valid
ON or OFF signal, the Boiler Control will
control the heating system accordingly.
SALUS Controls plc
SALUS House
Dodworth Business Park South,
Whinby Road, Dodworth,
Barnsley S75 3SP, UK.
T: [phone]
E: [email protected]
E: [email protected]
SALUS Controls is a member of the Computime Group.
Maintaining a policy of continuous product development SALUS Controls plc reserve the right to
change specification, design and materials of products listed in this brochure without prior notice.
www.salus-tech.com
Issue Date: February 2018
V005
For PDF Installation guide please go to www.salus-manuals.com
TEST/ PAIRING
SELECT
+Hr
SET
3 Sec

+Hr
SELECT SET
TEST/ PAIRING
Setting Time and Date
Programming
Press SET to return to the Main Screen.
+Hr
+Hr
+Hr +Hr
+Hr
SELECT
SELECT
SELECT SELECT
SELECT
SET
SET
SET SET
SET
+Hr
SELECT SET
You can create personalized programmes for your controller. You have the option to choose
between a 5-2 days programme or a daily one by using the parameter d04 from Installer mode.
Press UP or DOWN to selectWeekday/Weekend/
Day and press SELECT.
Press SET to change your programmes.
+Hr
SELECT SET
Press UP or DOWN to set the minutes and
press SELECT to conrm your option.
Press UP or DOWN to set the temperature and
press SELECT to conrm your option.
Follow the same procedure for the next
set of time.
Review the Setpoint (desired) temperature
Press UP or DOWN to review the setpoint
temperature.
Press UP or DOWN to set the temperature.
Actual room temperature Setpoint (desired) temperature
Boost function
Frost protection
Frost Mode ON.
+Hr
SELECT SET
Press OVERRIDE in order to activate the
mode.
Press UP or DOWN to set the temperature.
+Hr
+Hr
SELECT SET
SELECT SET
Press SET to conrm the changes.
Press +Hr to activate the
Boost function.
Press the FROST button once to activate the
function.
The Override sign will appear on the Main
screen.
Press +Hr to set boost hours and then press
UP or DOWN to set the boost temperature
for your boost period.
+Hr
SELECT SET
Frost Mode OFF.
+Hr
SELECT SET
Holiday Mode
Press the HOLIDAY button for 3 sec. Press the UP or DOWN button to set the
Holiday period.
+Hr
SELECT SET
+Hr
SELECT SET
Press the HOLIDAY button for 3 sec to exit
Holiday Mode.
Reset function RT510TX
Remove the batteries without pressing any button. Wait 2 minutes and insert the batteries
again. Your device will be restarted.
+Hr
SELECT SET
+Hr
SELECT SET
+Hr
SELECT SET
+Hr
SELECT SET
+Hr
+Hr
SELECT SET
SELECT SET
+Hr
SELECT SET
Press UP or DOWN to set the hour and press
SELECT to conrm your option.
+Hr
SELECT SET
+Hr
SELECT SET
+Hr
SELECT SET
+Hr
SELECT SET
Permanent Override
1
1
5
3
1
3
1
3
5-2 Days Programme 24h Programme
Weekdays
6 sets of time/channel
Weekends
6 sets of time/channel
Total: 12 settings/week
24h
6 sets of time/channel
Total: 42 settings/week
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING
TEST/ PAIRING TEST/PAIRING
Continue with the same steps for setting
the Day.
Press the FROST button once to deactivate
the function.
Temporary Override
6
12
4
56
3
2
+Hr
SELECT SET
Press SET to conrm the changes.
+Hr
SELECT SET
3
TEST/ PAIRING TEST / PAIRING
4
2
4
2
4
2
4
3sec
3sec
Press the buttons together for 3 sec.
Press UP or DOWN to select the hour format
and then press SELECT to conrm your
option.
Press UP or DOWN to select the hour
and then press SELECT to conrm your
option.
Press UP or DOWN to select the minutes
and then press SELECT to conrm your
option.
+Hr
SELECT SET
+Hr
SELECT SET
3 Sec3 Sec
+Hr
SELECT SET
+Hr
SELECT SET
1
3
TEST/ PAIRING TEST/ PAIRING
TEST/ PAIRING TEST/ PAIRING
2
4
i
i
i
i
After you have done all the changes, please press SET to conrm all your choices
and to return to the Main Screen.
The Frost protection temperature can be reviewed by pressing the UP button
once, but can only be changed in Installer Mode.
You can also exit Holiday Mode by setting the days to zero.
When you want to change the batteries your device will use the internal
memory to backup your settings. You have 30 seconds to change the
batteries before losing your settings.
Installer Mode
+Hr
SELECT SET TEST/ PAIRING
dxx Function Parameter Default value
d01 Temperature display increments 0.1°C or 0.5°C 0.5°C
d02 Temperature oset +/- 3.0°C 0.0°C
d03 Frost Protection setpoint temperature 5.0°C - 17.0°C 5.0°C
d04 Programmer selection 5/2 or 24 hr (7d) 52d
Press the three buttons together
simultaneously for 3 seconds.
+Hr
SELECT SET
3 Sec
3 Sec
