Salus VS10WRF User manual

VS10WRF/VS10BRF THERMOSTAT - FULL USER MANUAL

Table Of Contents
1. Introduction...............................................................................................................................................................5
1.1 Product Compliance...................................................................................................................................................................... 5
1.2 Safety Informations.......................................................................................................................................................................5
1.3 Product Overview.......................................................................................................................................................................... 5
2. Montage.................................................................................................................................................................... 6
2.1 Package content............................................................................................................................................................................6
2.2 Proper thermostat location........................................................................................................................................................... 6
2.3 Connection Description (VS10WRF/VS10BRF thermostat).............................................................................................................6
3. About ZigBee network................................................................................................................................................ 7
3.1 ZigBee network - creation and work............................................................................................................................................. 7
3.2 Compatibility with SALUS devices (ONLINE AND OFFLINE).............................................................................................................8
4. Before you start (rst power up).................................................................................................................................. 9
4.1 LCD icon description...................................................................................................................................................................... 9
4.2 Button description.........................................................................................................................................................................9
4.3 First power up sequence, language choice and preparing to the pair process..............................................................................10
5. Installation by SALUS Smart Home application (ONLINE MODE).....................................................................................11
5.1 General informations about SALUS Smart Home application.......................................................................................................11
5.2 Conguration as a programmable thermostat.............................................................................................................................12
5.2.1 Pairing with underoor heating wiring centre (KL08RF/Control Box)........................................................................ 12
5.2.2 Pairing with wireless TRV radiator head..................................................................................................................... 15
5.2.3 Pairing with Smart Plug SPE600................................................................................................................................ 17
5.2.4 Pairing with Smart Relay SR600.................................................................................................................................19
5.2.5 Pairing with RX10RF receiver......................................................................................................................................21
5.3 Conguration as a hot water timer.............................................................................................................................................. 23
5.3.1 Pairing with Room Extension Receiver (RX2)..............................................................................................................23
6. OPERATING in ONLINE MODE (by app).......................................................................................................................... 25
6.1 General informations...................................................................................................................................................................25
6.2 App icons description.................................................................................................................................................................. 25
6.2.1 Programmable thermostat.........................................................................................................................................25
6.2.2 Hot Water Timer......................................................................................................................................................... 26
6.3 Change thermostat name (pencil icon)....................................................................................................................................... 27
6.4 Work as a programmable thermostat..........................................................................................................................................28
6.4.1 Setpoint temperature change.................................................................................................................................... 28
6.4.2 Heat/Cool mode change (KL08RF connection)........................................................................................................... 29
6.4.3 Thermostat modes..................................................................................................................................................... 30
6.4.3.1 Schedule mode.........................................................................................................................................30
6.4.3.2 Temporary override mode.........................................................................................................................34
6.4.3.3 Manual mode........................................................................................................................................... 34
6.4.3.4 Frost protection........................................................................................................................................ 35
6.4.4 Key lock function........................................................................................................................................................36
6.4.5 Compatibility with window/door sensor OS600 / SW600...........................................................................................37
6.4.6 Compatibility with Smart Plug SPE600...................................................................................................................... 38
6.4.7 Compatibility with Smart Relay SR600.......................................................................................................................39
6.5 Work as a hot water timer (work modes).....................................................................................................................................40
6.5.1 Turned ON mode - .................................................................................................................................................40
6.5.2 AUTO mode - .........................................................................................................................................................41
6.5.3 Turned OFF mode - ................................................................................................................................................42
6.5.4 Temporarily ON mode - .........................................................................................................................................43
6.6 Identication mode.....................................................................................................................................................................44

6.7 Pinning/unpinning thermostat to/from application dashboard.................................................................................................. 45
6.8 User settings (basic settings).......................................................................................................................................................46
6.9 Admin settings (installer parameters).........................................................................................................................................47
6.10 OneTouch rules (add/edit).........................................................................................................................................................48
6.11 Error codes (exclamation mark in app)...................................................................................................................................... 52
6.12 Wireless signal strength test......................................................................................................................................................53
6.13 Factory reset (removing thermostat from the app and ZigBee network)...................................................................................54
7. Installation in OFFLINE MODE without SALUS SmartHome application.......................................................................... 56
7.1 General informations...................................................................................................................................................................56
7.2 Conguration as a programmable thermostat.............................................................................................................................57
7.2.1 Pairing with underoor heating wiring centre (KL08RF/Control Box)........................................................................ 57
7.2.2 Pairing with wireless TRV radiator head..................................................................................................................... 59
7.2.3 Pairing with RX10RF receiver......................................................................................................................................60
7.3 Conguration as a hot water timer.............................................................................................................................................. 61
7.3.1 Pairing with Room Extension Receiver (RX2)............................................................................................................. 61
7.4 VS10WRF/VS10BRF thermostat - additional conguration options.............................................................................................63
7.4.1 Available operation modes.........................................................................................................................................63
7.4.2 VS10WRF/VS10BRF thermostats grouping (MASTER and SLAVE operation)...............................................................64
8. OPERATING in OFFLINE MODE......................................................................................................................................66
8.1 Work as a programmable thermostat..........................................................................................................................................66
8.1.1 Work modes............................................................................................................................................................... 66
8.1.2 Heat/cool mode change (KL08RF connection)............................................................................................................67
8.2 Work as a hot water timer with RX10RF receiver..........................................................................................................................68
8.2.1 Work modes............................................................................................................................................................... 68
8.3 User settings (basic settings).......................................................................................................................................................69
8.3.1 Schedule mode - programming schedule...................................................................................................................69
8.3.2 Time/Date.................................................................................................................................................................. 71
8.3.3 Thermostat calibration...............................................................................................................................................72
8.3.4 Key lock function........................................................................................................................................................73
9. Installer parameters................................................................................................................................................. 74
10. Factory Reset..........................................................................................................................................................76
11. Error codes (error codes description with possible solutions)...................................................................................... 77
12. Cleaning and Maintenance...................................................................................................................................... 80
13. Technical Informations............................................................................................................................................ 80
14. Warranty................................................................................................................................................................ 80

5
This product complies with the essential requirements and other relevant provisions of Directives 2014/53/EU and 2011/65/EU. The full text of the EU
Declaration of Conformity is available at the following internet address: www.saluslegal.com.
• Before starting installation work and before using the product, read the entire manual.
• The information contained in the instructions is essential for proper functioning.
• To avoid accidents resulting in personal injury and material damage, please follow all safety precautions, specied in this manual.
• The device should not be used by people with limited mental, sensory or mental abilities, without experience, of insucient knowledge as well as
children.
• Do not use an unassembled device (eg without a cover).
• The device may only be opened by a qualied person.
• Keep electrical devices out of the reach of children and ensure that they do not play with it. Children should not be left unattended. If necessary,
disconnect the control system for the entire room.
• Do not leave the packaging, cabinet, or any loose parts of the device unattended, as they pose a risk to children.
WARNING!
• Installation must be carried out by a qualied person with appropriate electrical qualications in accordance with standards and regulations in force in
the given country and in the EU.
• Never try to connect the device other than as described in the manual.
• Before assembly, repair or maintenance as well as during any connection works it is absolutely necessary disconnect the mains supply and make sure
that the terminals and electric wires are not live.
• The device may not be exposed to extreme temperatures, strong vibrations or subjected to mechanical shock.
• The device should not be used in unfavorable environmental conditions or in rooms where there is a concentration of ammable gases, fumes or dust.
WARNING!
• There may be additional protection requirements for the entire installation that the installer is responsible for maintaining.
VS10WRF / VS10BRF is a room temperature thermostat that is used for wireless control of iT600 series devices such as: KL08RF wiring centre, TRV
radiator valve and RX10RF boiler receiver. In combination with Universal Gateway UGE600 this regulator can be controlled over the Internet using SALUS
SmartHome app (Online mode). Without Internet connection (Oine mode) thermostat works locally, but its communication with other devices must be
done through the coordinating unit - CO10RF. Full version of the PDF manual instruction is available on the website www.salus-controls.eu
1. Introduction
1.1 Product Compliance
1.2 Safety Informations
1.3 Product Overview
Care for the natural environment is of paramount importance to us. The awareness that we manufacture electronic devices obliges us
to dispose of used electronic components and devices safely. Therefore the company has received a registration number issued by the
Chief Inspector for Environmental Protection.The crossed out symbol the trash can on the product means that the product must not be
disposed of with ordinary waste containers. Sorting waste for recycling helps to protect the environment. It is the user’s responsibility
to surrender used equipment to a designated collection point for recycling waste from electrical and electronic equipment.

6
2. Montage
2.1 Package content
1) VS10WRF/VS10BRF thermostat
2) Short instructions
3) Mounting screws
2.2 Proper thermostat location
Please note:
Wall mounting
2.3 Connection Description (VS10WRF/VS10BRF thermostat)
1, 2 terminals:
- air or oor temperature sensor
- external volt-free contact to connect any ON/OFF switch or occupancy
sensor (Hotel card)
- external hot water thermostat
Symbols explanation:
S – volt-free contact
T – temperature sensor eg. FS300
L, N – power supply 230V AC
Mounting: to mount thermostat you can use accesories included with the set (mounting screws). Remove back cover to mount the plate to the wall.
Now please insert the batteries inside the thermostat. After this just attach thermostat to the plate right into designed holes in the plate.
The ideal position to thermostat mounting is about 1,5m under oor level far from heating or cooling sources.
Thermostat can’t be exposed to sunlight or any extreme conditions like for example draft.
Because of re and explosion risk there is not allowed to use thermostat in atmosphere of explosive gases and ammable liquids (eg coal dust). In case
if any of listed dangers occur you have to use additional protection measures – anti-dust and explosive gases (tight cover) or prevent their formation.
Furthermore, thermostat can’t be used in condensation of water vapor conditions and be exposed to water action.
1 2 3

7
3. About ZigBee network
3.1 ZigBee network - creation and work
ZigBee is a wireless network based on IEEE 802.15.4 standard and it’s communication takes place in the 2.4 GHz band. The network is based on a mesh
topology, which allows for a very large range and high reliability. The maximum range of direct communication between two network nodes (devices) is
about 100m in open space.
The devices included in the ZigBee network are divided into three types:
- coordinator - there can only be one such device in each network. It acts as a connection node for all devices;
- router (repeater) - this device is powered by 230VAC, with functionality similar to classic network routers, and it’s task is to forward data packets and
increase the range of the network;
- terminal device - battery powered, sends data to the coordinator (also through the router) to which it is connected. It is usually put to sleep
temporarily, which helps reduce energy consumption.
Built-in security in the ZigBee protocol (ISO-27001 and SSAE16 / ISAE 3402 Type II - SOC 2 certication) ensure high transmission reliability, detection and
removal of transmission errors, as well as connectivity between established priority devices.
Security measures include:
- devices authenticated using a unique key pair;
- encrypted communication between the mobile application and the device;
- data encryption - HTTPS encrypted using TLS, UDP channel with AES-128 encryption;
- layered access control to prevent tampering with one device threatening the entire system.
The ability to work many devices at a short distance from each other was achieved through the use of radio transmission of the spread spectrum signal.
The main advantages of devices working in the ZigBee system are two-way communication and minimization of energy consumption, which in many
cases allows them to be powered from 230V AC.
Four Simple steps to create ZigBee network:
1. Coordinator Installation - Universal Gateway for
ONLINE and OFFLINE systems with internet application
or CO10RF for only OFFLINE systems without application.
2. Now - add any device you want powered 230VAC.
Note to locate it as near coordinator as possible.
3. Now you can increase range of ZigBee network
by adding more devices powered 230 VAC.
4. To extend your network you can add more battery
devices and accesories.

8
3.2 Compatibility with SALUS devices (ONLINE AND OFFLINE)
COMPATIBILTY WITH OTHER SALUS CONTROLS DEVICES
VS10 thermostat can work in ONLINE or OFFLINE mode.
At rst step you need to decide in which mode your thermostat will work.
ONLINE MODE OFFLINE MODE
Universal Gateway is
CONNECTED TO THE INTERNET
You can congure and use all your
devices in the Smart Home App
Download the Smart Home App
on your iOS or Android device
for remote access to your SALUS
equipment. SALUS
Smart Home
CO10RF Coordinator - You can use
standard ZigBee network coordinator
to install and use your devices.
Universal Gateway is NOT
CONNECTED TO THE INTERNET
You can use your devices locally
without the SmartHome App. Gateway
works in this mode as standard ZigBee
coordinator.
Compatibile devices:
KL08RF wireless wiring
centre for 8-zone
underoor heating.
KL04RFextension TRV
(Thermostatic
Radiator Valve) with
wireless communication.
RX10RF
receiver
SR600
Smart Relay
SPE600
Smart Plug
GET IT ON
Download on the
OR
Other SmartHome devices/accessories
Only with Online Mode
Water leak sensor
WLS600
Double/single OneTouch button
SB600/CSB600
Smoke detector
SD600
Window/door Sensor
SW600 or OS600
RS600
Roller shutter
RE600
ZigBee network signal repeater
(only with UGE600)
RE10RF
ZigBee network signal
repeater

9
Button Function
4. Before you start (rst power up)
Hold down these buttons to enter installer parameter settings
1. Mode selection.
2. Long press to return to home display without saving.
3. Short press to return to the previous screen when it is in user/installer
setting mode.
1. OK key: Short press to conrm selection.
2. Long press to save and exit.
3. Long press to enter the user settings.
Hold down these buttons to lock or unlock the keyboard
1. Increase or decrease setpoint temperature.
2. Increase or decrease Day, Clock, Timer, Party, Holiday and Boost.
3. Select installer parameter value.
Button Description
4.2 Button description
4.1 LCD icon description
1. Comfort temperature
2. Standard temperature
3. Economic temperature
4. Automatic mode
5. PARTY mode
6. Holiday mode
7. Frost protection mode
8. Temperature unit
9. Group controller
10. Manual mode / override temp.
11. Current / set temperature
12. Program number
13. AM / PM
14. Lock function
15. Clock
16. Day indicator
17. Settings
18. Low battery indicator
19. External temperature sensor
20. Hot water heating
21. Modes for Hot Water
22. Cooling mode ON
23. Internet connection indicator
24. Gateway wireless connection
25. Heating mode ON
OR
OR
+
+ +

10
4.3 First power up sequence, language choice and preparing to the pair process
After that, thermostat will automatically power
up and start boot sequence...
Set your thermostat for underoor
heating or radiator heating by
„ ” or „ ”buttons.
Then conrm by button.
...it will display all icons...
...then thermostat will display the
software version.
Remove the protection foil and insert
4xAAA batteries by removing back cover.
3
2
1
5
4

11
SALUS
Smart Home
GET IT ON
Download on the
3
2
5. Installation by SALUS Smart Home application (ONLINE MODE)
5.1 General informations about SALUS Smart Home application
Thanks to UGE600 Universal Gateway and SALUS Smart Home app system allows you to remote control of your heating system in any place you are
in the moment by smartphone, tablet or computer with Internet connection. Then you have also access to advanced functions of VS10WRF/VS10BRF
thermostat. You can also create OneTouch rules to customize system to your needs.
1
First make sure that you have downloaded the Salus Smart Home App from the Google Play or App
Store. You will need to follow a few easy steps to create an account and then link your thermostat to the
Universal Gateway and to the App.
You can also access the web version on:
http://eu.salusconnect.io/
To begin the pairing process the Gateway should be plugged into the power supply and connected to the
Internet. Also, make sure that the UGE600 is added to your Salus Smart Home App. For the installation of
the Universal Gateway, please refer to the UGE600 manual on salus-manuals.com
Make sure that your UGE600 Universal Gateway is added to the App.
The LED of the Gateway should be steady blue. Then go to VS10WRF/
VS10BRF thermostat and begin paring process with the UGE600 and
add it to the App.

12
5.2.1 Pairing with underoor heating wiring centre (KL08RF/Control Box)
5.2 Conguration as a programmable thermostat
564
SALUS
SmartHome
Go to SALUS Smart Home app.
3
Now thermostat is looking for the
signal from the coordinator...
Open main menu. Select„Settings”. Now enter to the„Setup Equipment”.
Press„Scan for equipment”button.
7 8
App has started scanning...
1
2
For easier installation, please make sure you have already added underoor heating wiring centre (KL08RF/Control Box) to your ZigBee network (please
refer to the underoor heating wiring centre manual instruction).
Please note:
Set your thermostat for underoor heating
by„ ” or „ ”buttons. Then
conrm by button.
9
...Gateway has started ashing red and
searching for the thermostat...

13
Thermostat is connected. Go to the
Smart Home app to congure it.
10
Select your thermostat and press
„Connect equipment”button.
Name your thermostat and go
„Next”...
Press gear icon.
11 12
13 14 15
Select option„Programmable
Thermostat”.
Now choose
„UFH Wiring Centre”option.

14
17 18
2119
Choose„No”if you want to set your
own schedule later or„Yes”if default
now.
After that thermostat will display
main screen.
You succesfully congured
VS10WRF/VS10BRF
thermostat with KL08RF Control Box.
Select the zone which you want attribute to
your thermostat.
Press„Finish”button to end the set
up process in the app.
20
3
Gateway stop ashing and turn to steady
blue color which means pair process has
been nished.
16
Select your KL08RF/Control Box
added before.

15
5.2.2 Pairing with wireless TRV radiator head
1
SALUS
SmartHome
Go to SALUS Smart Home app.
3
Now thermostat is looking for the
signal from the coordinator...
564
Open main menu. Select„Settings”. Now enter to the„Setup Equipment”.
Thermostat is connected. Go to the
Smart Home app to congure it.
Press„Scan for equipment”button.
7 8
App has started scanning...
2
For easier installation, please make sure you have already added wireless TRV radiator heads to your ZigBee network (please refer to the wireless TRV
radiator head manual instruction).
Please note:
Set your thermostat for radiators by
„ ” or „ ”buttons.
Then conrm by button.
9
...Gateway has started ashing red and
searching for the thermostat...

16
After that thermostat will display main screen.
You succesfully conguredVS10WRF/VS10BRF
thermostat withWireless TRV radiator head.
1817
13 14 15
16
Now choose Smart Radiator Control. Select your TRV radiator
head from the list.
Choose„No”if you want to set your own
schedule later or„Yes”if default now.
Select your thermostat and press
„Connect equipment”button.
Name your thermostat and go
„Next”...
Press gear icon.
10 11 12
Select option„Programmable Thermostat”.
Press„Finish”button to end the set
up process in the app.
3
Gateway stop ashing and turn to steady blue
color which means pair process has been nished.

17
5.2.3 Pairing with Smart Plug SPE600
1
SALUS
SmartHome
Go to SALUS Smart Home app.
3
Now thermostat is looking for the
signal from the coordinator...
564
Open main menu. Select„Settings”. Now enter to the„Setup Equipment”.
Press„Scan for equipment”button.
7 8
App has started scanning...
2
For easier installation, please make sure you have already added Smart Plug SPE600 to your ZigBee network (please refer to the Smart Plug SPE600
manual instruction).
Please note:
Set your thermostat for underoor heating
by„ ” or „ ”buttons. Then
conrm by button.
Thermostat is connected. Go to the
Smart Home app to congure it.
9
...Gateway has started ashing red and
searching for the thermostat...

18
Select your thermostat and press
„Connect equipment”button.
Name your thermostat and go
„Next”...
Press gear icon.
10 11 12
17
16
Choose„No”if you want to set your own
schedule later or„Yes”if default now.
13
Now choose Smart Plug. Select your Smart Plug from the list.
14 15
Select option„Programmable Thermostat”.
Press„Finish”button to end the set
up process in the app.
After that thermostat will display main screen.
You succesfully conguredVS10WRF/VS10BRF
thermostat with Smart Plug SPE600.
18
3
Gateway stop ashing and turn to steady blue
color which means pair process has been nished.

19
5.2.4 Pairing with Smart Relay SR600
1
SALUS
SmartHome
Go to SALUS Smart Home app.
3
Now thermostat is looking for the
signal from the coordinator...
564
Open main menu. Select„Settings”. Now enter to the„Setup Equipment”.
Press„Scan for equipment”button.
7 8
App has started scanning...
2
For easier installation, please make sure you have already added Smart Relay SR600 to your ZigBee network (please refer to the Smart Relay SR600
manual instruction).
Please note:
Set your thermostat for underoor heating
by„ ” or „ ”buttons. Then
conrm by button.
Thermostat is connected. Go to the
Smart Home app to congure it.
9
...Gateway has started ashing red and
searching for the thermostat...

20
Select your thermostat and press
„Connect equipment”button.
Name your thermostat and go
„Next”...
Press gear icon.
10 11 12
17
16
Choose„No”if you want to set your own
schedule later or„Yes”if default now.
13
Now choose Smart Relay. Select your Smart Relay from the list.
14 15
Select option„Programmable Thermostat”.
Press„Finish”button to end the set
up process in the app.
After that thermostat will display main screen.
You succesfully conguredVS10WRF/VS10BRF
thermostat with Smart Relay SR600.
18
3
Gateway stop ashing and turn to steady blue
color which means pair process has been nished.
