User´sManual–SaluTronD2X(Rel.2.1)
Contents
1. Preface_____________________________________________________________________________4
2. DeviceDescription____________________________________________________________________5
3. Maintenance_________________________________________________________________________6
4. PowerSupply________________________________________________________________________6
5. Measuring___________________________________________________________________________6
6. WorkModesofSaluTronD2X___________________________________________________________7
7. Zeroingofthedevice__________________________________________________________________9
8. Workingwiththemenu________________________________________________________________9
8.1Average(onlyinpointmeasurement)___________________________________________________11
8.2Reset_____________________________________________________________________________12
8.3Background________________________________________________________________________12
8.4Mode_____________________________________________________________________________12
8.5Unit______________________________________________________________________________13
8.6Buzzer____________________________________________________________________________13
8.7Language_________________________________________________________________________13
8.8Time/Date_________________________________________________________________________13
8.9Limits_____________________________________________________________________________14
8.10Port_____________________________________________________________________________15
8.11Online___________________________________________________________________________15
8.12Application_______________________________________________________________________15
8.13Device___________________________________________________________________________17
9. AdditionalItemsinMemoryMode______________________________________________________18
9.1Block_____________________________________________________________________________18
9.2Values____________________________________________________________________________18
9.3Lastdelete________________________________________________________________________18
9.4Memodelete______________________________________________________________________19
9.5Statistic___________________________________________________________________________19
9.6Print_____________________________________________________________________________20
10. TechnicalData_____________________________________________________________________22
User´sManual–SaluTronD2X(Rel.2.1)
4
1. Preface
Thankyouforchoosingourproduct.Youhavepurchasedaproductthatmeetsprecisespecificationsand
upholdsgloballyrecognizedqualitystandards.
Thepurposeofthisthicknessgaugeistowithstandthemostdemandingconditions,includingtemperature
variations,humidity,shock,dust,andvibration.Ourrigoroustestingstandards,alongwithourunwavering
commitmenttoensuringcustomersatisfaction,guaranteethatyoucanrelyonitsqualityatalltimes.
Youcanstartusingthedeviceimmediately,evenwithoutpriorexpertise,thankstoitsuser‐friendlydesign.
Thedeviceincorporatesadvancedtechnology,allowingyoutoeffortlesslyactivatetheextensiverangeof
additionalfunctions.
Shouldyouhaveanyinquiriesregardingthicknessmeasurements,ourdedicateddistributorsorwe
ourselvesareavailabletoassistyou.
SaluTronMesstechnikGmbH
User´sManual–SaluTronD2X(Rel.2.1)
5
2.DeviceDescription
TheSaluTronD2Xcoatingthicknessgaugeisacompact,durable,anduser‐friendlydeviceoptimizedfor
yourconvenience.Itisdesignedasaversatiletoolwithmemoryandinterfacecapabilities,enablingnon‐
destructivemeasurementsonbothmagnetic(Fe)andnon‐magnetic(NFE)metalsurfaces(substrates).
TheFEprobeisspecificallydesignedformeasuringnon‐magneticcoatings,includinglacquer,plastic,
chrome,copper,zinc,enamel,etc.,onsteelorironsurfaces.
TheNFeprobeisintendedformeasuringinsulatingcoatings,suchaslacquer,plastic,enamel,etc.,onnon‐
magneticmetalssuchasaluminum,copper,brass,andevencertaintypesofstainlesssteel.
User´sManual–SaluTronD2X(Rel.2.1)
6
3.Maintenance
Toachieveoptimalresultsandensurealongservicelife,itiscrucialtohandlethedeviceproperly.Please
followtheseguidelines:
Avoidsubjectingthedevicetostrongshocksandpreventtheingressofdirt,chemicals,corrosive
substances,andwater.Thiswillhelpmaintainitsperformanceandaccuracy.
Regularlycleantheprobestoensureaccuratemeasurements.Removeanydirtorpaintfromthe
measuringheadtopreventinterferencewithreadings.
Ifthedeviceisnotgoingtobeusedforanextendedperiod,werecommendremovingthebatteries.
Thiswillhelppreservebatterylifeandpreventpotentialdamageduetobatteryleakage.
Intheeventofanyfaultsorissueswiththedeviceorprobes,pleaserefrainfromattemptingrepairs
onyourown.Instead,wekindlyrequestyoutocontactourservicecenter.Ourdedicatedteamwill
beavailabletoassistyouandprovidethenecessarysupport.
Byadheringtotheseguidelines,youcanensureoptimalperformance,longevity,andreliable
measurementsfromyourcoatingthicknessdevice.
4.PowerSupply
Thisgaugeispoweredbytwo1.5VAAbatteries.Thesebatteriesprovideextendedusageformany
thousandsofmeasurements,equivalenttoapproximately60operatinghourswithoutactivatingthe
backlight.Thebatterycapacitylevelisindicatedbyabatterysymbollocatedintheupperleftcornerofthe
display(refertothepicture).
Note:
Pleasedonotdisposeofusedbatterieswithhouseholdwaste.Instead,ensureproperdisposalat
designatedcollectionsites.
5.Measuring
Thegaugecomeswithanexternalcableprobe,two1.5VAAAlkalinebatteries,asetofmeasuringfoils,a
zeroplate,akitfordatatransfertoaPCandausermanual.Toturnonthedevice,simplypressthe
button.Onceturnedon,thedevicewilldisplaythedeviceIDandthelastmeasuredvalue.Tobegin
measurements,placetheprobeonthecoatingsurface.TheV‐grooveontheprobeheadisespecially
usefulformeasurementsonrods,pipes,andsimilarobjects.
Thegaugeisdeliveredwithanattachedprobe,batteries,asetofmeasuringfoils,azeroplate,kitfordata
transfertoPCandusermanual.Withthebutton
Magneticfields,electricfields,andelectromagneticradiationcanaffectthemeasurementaccuracyin
boththeFerro(Fe)andNon‐Ferro(NFE)sectors.Insuchsituations,itisnecessarytoperformazeroing
procedureforthedevice.Ifrequired,theprobeshouldbecalibratedusingthreenewstandardfoils.
Detailedinstructionsonhowtocarryoutthisadjustmentcanbefoundinthemainmenuunderthe
'Applications'section.
User´sManual–SaluTronD2X(Rel.2.1)
7
Pleaserefrainfrommeasurementsonmagnetsastheymayproduceinaccurateresults.Additionally,to
preventanypotentialdamage,thedeviceautomaticallyshutsoffwhenexposedtohighelectrostatic
charges.
Whenthedeviceispoweredonandyoupressthe
button,theSaluTronD2Xwillimmediatelypoweroff.Ifthedeviceisnotused,itwillautomaticallypower
offafterapproximatelythreeminutes.Ifthedeviceisturnedonwithouttheprobescrewedin,ablinking
probeiconwillappearonthedisplayaccompaniedbyanaudiblesignal.Afterabriefperiod,the
devicewillautomaticallypoweroff.
6.WorkModesofSaluTronD2X
Thedevicecanworkinthreeworkmodes.
workmode:normal/continuous/memory
Ineachmodespecialiconsappearintheupperpartofthedisplay.
battery:capacityofthebatterysupply
noprobeconnected
probetype:FE/NFE(steel/non‐steelmetals)
limit:withinlimits/abovelimit/belowlimit
transferport:USB‐RS/HPInfrared
online:totransferthemeasuringresultsonline
DataisretrievedandtransferredfromthePC.
Inthestandardnon‐memorymode(),measurementsaredisplayedbutnotstored.Furthermore,the
meanvalueiscalculatedcontinuouslyandshownalongwiththetotalnumberofmeasurements.Youhave
theoptiontodeletethisinformationatanytimebyaccessingtheResetmenuitem(refertothemenu
descriptionformoredetails).
User´sManual–SaluTronD2X(Rel.2.1)
8
Theactiveapplication(calibrationoftheprobe)isshowninthefigureafterAp.Bypressingthebutton:
theinformation(dateandcomment)isshownforthisapplication.
Inadditiontothebasicpointmeasurement(withoutstorage),youcanalsoperformcontinuoussurface
measurements( )withthisdevice.Inthismode,twoorthreemeasurementsarerecordedand
displayedwithinasecond.However,pleasenotethatthesemeasurementsarenotusedtocalculatethe
continuouslydeterminedmeanvalue,soitwillnotbedisplayed.Onlinetransferofthedataisnotavailable
inthismodeeither.
Inthememorymode( )themeasurementsarenotonlydisplayedbutalsostoredindifferentblocks.
Thedisplayofthemean‐valuerefersherealwaystothemeasurementsthatarecurrentlystoredinthe
activemeasurementblock.
Justlikeinthenormalmode,youcanretrieveinformationabouttheactiveapplicationbypressingthe
button:
.
Furthermore,bypressingthekey
,
relevantinformationsuchasthedateandcommentisdisplayedoutsidethecurrentlyselectedblock.
User´sManual–SaluTronD2X(Rel.2.1)
9
7.Zeroingofthedevice
Specialconditions,suchasfluctuatingtemperatures,theintroductionofnewbatteries,extendedperiods
ofnon‐use,orvariationsinsubstrates(surfaces),canpotentiallyimpacttheaccuracyofthe
measurements.Intheseinstances,itisadvisabletoperformregularzeroingprocedures.
‐Press inmeasuringmode.
‐Placetheprobeonthemeasuringfoil.Youwillhearabeep.
‐Lifttheprobeatleast5cmfromthefoil.Youwillhearabeep.
Thezeroingisnowcomplete.Thedevicegoesautomaticallyintothemeasurementmodeandisreadyfor
measurements.
Thefollowingsectionofthemanualdemonstratesthevariousoptionsavailabletotheuser,including
devicesettings,storage,andotheravailablefeatures.Theselectionoftheseoptionscanbetailoredtosuit
yourspecificrequirements.
8.Workingwiththemenu
Themainmenuofthedevicecanberetrievedbypressing:
User´sManual–SaluTronD2X(Rel.2.1)
10
Toselectindividualitems,usethebuttons:
andconfirmyourselectionbypressingthe
button.Inthemainmenu,youcanquicklynavigatefromthelastitemtothefirstitem.
Allfourbuttonshavethefunctionofarrowkeysbywhichtheinputofdatasuchasblocknumbers,limits
andcommentsarepossible.Press
andthenextcharacterfromthelettersordigitsline(e.g.0,1,2,3....orA,B,C,D....)isshown.Pressing
pushesthecursoronthedevicedisplayaccordingtotheleftorright.Ifyoupressthearrowkeysformore
than2secondsyoucanstepquicklytothenextinputofscrollfast.Forexample,ifyouwanttoexceedthe
limitby125µm,proceedasfollows:
‐Press or aslonguntil"1"isdisplayed.
‐With youpushtheblinkingcursoroneplacetotheright.
‐Press or until"2"isdisplayed.
User´sManual–SaluTronD2X(Rel.2.1)
11
‐With youpushtheblinkingcursoroneplacetotheright.
‐Press or until"5"isdisplayed.
‐Confirmwith.
Theinputprocessisnowcomplete.Theprocedureremainsthesamewhetheryouneedtoenterthetime,
date,orcommentsforthemeasurementorapplications.
TheSaluTronD2Xoffersthreedifferentworkmodes:pointmeasurement,continuousmeasurement,and
memorymeasurement(refertoitem‐MODE).Themenustructureadaptsbasedontheselectedwork
mode.SettingsthatareirrelevantinthechosenmodeareconcealedwithintheMENU.Theinstrumentwill
savethelastusedworkmodewhenpoweredoff.
Average
Reset
Background
Mode
Unit
Buzzer
Language
Time/Date
Limits
Port
Online
Application
Device
Background
Mode
Block
Values
Lastdelete
Memodelete
Statistic
Print
Unit
Buzzer
Language
Time/Date
Limits
Port
Online
Application
Device
Pointand
continuous
measurement
memory
measurement
8.1Average(onlyinpointmeasurement)
TheSaluTronD2Xcontinuouslycalculatestheaveragevalueduringeachmeasurement(excludingthe
storageofindividualmeasurements).Whenthisfunctionisenabled,theaveragevalue,alongwiththe
numberofmeasurements,willbedisplayed.Thisfeatureisparticularlyvaluablewhendealingwith
User´sManual–SaluTronD2X(Rel.2.1)
12
surfacesthatexhibithighroughness,whererepeatedmeasurementsatthesamepointmayyielddifferent
values.Insuchcases,itisadvisabletotakeanaverageofapproximatelyfivemeasurementstoobtaina
reliableresult.
8.2Reset
Thisitemallowsyoutoresetthemeanvalue,whichisrecalculatedwitheachmeasuredvalueand
displayedinthebottomline.
Iftheaverageshouldbecalculatedanewbeforethenextmeasurement,changeitwith
or
fromN(No)intoY(Yes)andconfirmwith
.
8.3Background
Thisitemcontrolsthebackgroundilluminationofthedisplay.Thisfunctionprovestobehighlybeneficialin
low‐lightsettings,enablinguserstoconvenientlyusethedeviceevenindarkenvironments.
8.4Mode
Inadditiontoperformingsinglepointmeasurementswithoutstorage,youcanalsocarryoutcontinuous
surfacemeasurementsusingthedevice.Inthismode,twotothreemeasurementsarerecordedand
displayedpersecond.Whenusingthememorymode,thesemeasurementsarestoredinthedevice's
database.
Whenenteringstoragemode,thedevicewilldisplayinformationaboutthememorycontents.Thefirstline
ofthewindowshowsthetotalnumberofblocksstoredinthememory.Thesecondlinedisplaysthe
‐pointmeasurement
‐continuousmeasurement
‐memorymeasurement
On
Off
‐displayofaveragevalueison
‐displayofaveragevalueisoff
Average
reset?N
‐backgroundilluminationison
‐backgroundilluminationisoff
normal
continuous
memory
On
Off
User´sManual–SaluTronD2X(Rel.2.1)
13
numberofthemostrecentlyaccessedblock.Bymodifyingthisnumber,youcanaccesseitheranexisting
blockorcreateanewone(thenumberofthenewblockshouldbethenumberofexistingblocks+1).
Pleaseensurethatthedeviceonlyacceptsvalidinput.Forinstance,ifablockisassignedthenumber"0"or
anumbergreaterthanthetotalnumberofexistingblocks+1,thedisplaywillshow:
Whenanewblockiscreated,thedateisautomaticallysaved.Furthermore,itispossibletoenterupto12
charactersintheblockcommentfield(e.g.,informationregardingthemeasurementobject),whichwill
alsobesaved.
Includingmeasurementsindifferentblockscanbeadvantageous,especiallywhendrawingconclusions
aboutthequality.
8.5Unit
Thedeviceallowsyoutochoosebetweendisplayingreadingsinµm‐mmortheAmericanunitmil(1mil=
25.4µm=0.0254mm).
8.6Buzzer
Inthissetting,youcanenableordisabletheconfirmationbeepforeachkeypress.
8.7Language
Thedeviceoffersamenuguideandinstructionsinthreedifferentlanguagesforyourconvenience.Youcan
chooseyourpreferredlanguagefromtheavailableoptions.
8.8Time/Date
Inthismenuitem,youcancorrectorre‐enterboththetimeanddate.
total:2
actual:2
Block‐No.not
correct
B.Comment:
xxx…
‐measurementdisplayinµmormm
‐measurementdisplayinmils
‐keypresswithbeep
‐keypresswithoutbeep
‐activatedlanguageisgerman
‐activatedlanguageisenglish
‐activatedlanguageispolish
µm‐mm
mil
On
Off
deutsch
english
polski
12:00
change‐ENTER
User´sManual–SaluTronD2X(Rel.2.1)
14
‐foracorrectionpress andthen or tochangethetime.
Confirmwith.
‐foracorrectionpress andthen or tochangethedate.
Confirmwith.
Ifthedisplayedtimeanddatearenottobecorrected,theentrycanbeinterruptedwith.
Note:
Whenreplacingthebatteries,pleasenotethatthesetdateandtimewillbelost.Therefore,itisnecessary
toresetthetimeanddateafterbatteryreplacement.
8.9Limits
Inordertoensurequalityassurance,itisnecessarytomaintainspecificupperandlowerlimitsforthe
coatingthickness.Whenmeasurementsfallbeloworexceedtheseboundaries,specialsymbols( ,
)alongwithanaudiblebeepwillbedisplayed.
‐enterupperlimit
Upperlimit
‐EnterTheupperlimitwithand or .
0.0µm
Limitup?N
01/01/07
change‐ENTER
User´sManual–SaluTronD2X(Rel.2.1)
15
‐ActivatewithY‐YesorN‐No.
Lowerlimit
‐Enterthelowerlimitvaluewithand or.
‐ActivatewithY‐YesorN‐No.
lowerlimitexceeded upperlimitexceeded
8.10Port
ThissettingactivatesthecorrespondingoutputportoftheSaluTron®D2Xdevice.Youhavetheoptionto
selecteitherinfraredtransmissiontoaportableIRHPprinter(usinganIRadapter)orthetraditionalserial
interface,USB.IfyouchoosetheUSBinterface,pleaseusetheUSBcableforthedatatransfer.Formore
detailedinstructions,refertothe"FTDIDriverInstallationunderWindows"sectionforadditional
information.
Thetransmissionformatoftheserialinterfaceisasfollows:
‐Baudrate:9600
‐Datalength:8bits
‐Parity:non
‐Stopbit:1
‐Xon/Xoffactive
TheIRadapter,alongwiththeevaluationsoftware,canbeorderedasadditionalaccessories.Moreover,
ourevaluationsoftwareisalsoavailableforfreedownloadonourwebsite,www.salutron.de.
8.11Online
Onlinemeansthatanymeasuredvaluecanbetransferredimmediatelytoaprinter(viainfrared,serial
connection,orPCtransfer)atthetimeofmeasurement.
8.12Application
Thefollowingisarevisedversionofthetext:
‐IR‐HP‐transferbyIR‐Adapter
‐USB/RS232‐transferbyinterface
‐directtransferison
‐directtransferisof
f
0.0µm
Limitdown?N
IR‐HP
RS232
On
Off
User´sManual–SaluTronD2X(Rel.2.1)
16
Bydefault,thedeviceissetforstandardmeasurementsasperthemanufacturer'sspecifications.However,
therearesituationswherenon‐standardmeasurementsarerequired,suchasmeasurementsoncurved
surfaces,andsoon.
Toenablethesespecializedmeasurements,theSaluTronD2Xoffersatotalof16applicationmemories.
Adjustingthedevicefortheseuniqueconditionsinvolvesconductingfourmeasurementsatdifferent
layersacrosstheentirerange.
Thefirstmeasurementpoint,knownasthe"zeropoint,"remainsfixedandrepresentsathicknessofzero.
Thismeasurementistypicallyperformedonbaremetal,azeroplate,oranuncoatedobjectmodel.
Additionally,threemeasurementsneedtobetakenusingsamplefilmsofvaryingthicknesses.Thechoice
ofthicknessforthesespecimenfoilsisflexible.Thefactorydefaultsettingsincludemeasurementsusing
foilsof50,250,and700µmforboththeFeandNFEprobes.
It'simportanttonotethattheselectedcalibrationfoilsmustalwaysbemeasuredinascendingorder,such
as10,100,and700μm.
Werecommendselectingmeasurementpointsthatadequatelycovertheanticipatedrangeofcoatings.
Forinstance,iftheexpectedlayerthicknessesprimarilyfallbetween20and200μm,performthe
adjustmentusingfoilsof20,100,and200μm.
‐Entertheapplicationnumber(1to16)with and or.
‐Entertheapplicationcomment(ifnecessary)with and or.
Ifonlythepreviouslysavedapplicationneedstobeactivated,confirmbypressingthe
.
Thedeviceisinitializedwiththenewcalibrationvaluesstoredintheapplicationmemory,makingitready
tomeasure.
Tosaveanewapplicationinthecalibrationmemory,youneedtoproceedwiththezeromeasurement.
App‐No.15
01/01/07
Fe:16
Zero:4x
Probezero
Zero:4x
Probeup
Zero:4x
Probezero
User´sManual–SaluTronD2X(Rel.2.1)
17
‐Zeropoint:measure4x
‐forcorrectionpress andthensettherightfoilvaluewith or .
‐Foil1:measure4x
‐forcorrectionpressandthensettherightfoilvaluewith or.
‐Foil2:measure4x
‐forcorrectionpressandthensettherightfoilvaluewith or.
‐Foil3:measure4x
Thecalibrationprocesshasbeensuccessfullycompletedandisnowactivatedandstoredintheapplication
memory.
Note:
Youmustfollowthesameproceduredescribedhereifyouareusinganewprobeforyourdevice,asthe
previousprobemayhavebeenreplacedduetodefects.
8.13Device
Inthismenuitem,youcanaccessinformationaboutthedevice,includingitsnameandserialnumber.
Pleasenotethatnoadjustmentsareavailableinthismenu.
State:50.0µm
change‐ENTER
SaluTronD2X
Serial‐No:
State:250µm
change‐ENTER
State:700µm
change‐ENTER
User´sManual–SaluTronD2X(Rel.2.1)
18
9.AdditionalItemsinMemoryMode
9.1Block
Inthismenuitem,youcaneitheropenanexistingblockorcreateanewone.Pleaserefertotheitem
Modesectioninthismanualformoreinformation.
9.2Values
Thissubmenuoptionprovidestheabilitytoviewmeasurementsforaspecificblock.Thetotalnumberof
createdblocksisdisplayedonthefirstlineofthescreen.Thesecondlineshowsthecurrentblock,whichis
theblockwherethemostrecentmeasurementswerestored.Toviewthereadingsofadifferentblock,use
thebuttons or toenterthenumberofthedesiredblockandconfirmwith .
Thedisplaypresentsascrollablelistofvaluesaccessiblethrough , buttons.
Note:
Inthissubmenuitem,individualreadingscanbemarkedasdeleted.Thismeansthatthemeasuredvalue
willnotberemovedfromthemeasurementsrowbutwillbeexcludedfromthestatisticalcalculations.This
featureisimportantincaseswhereitisdiscoveredthatareadingwasmistakenlyrecordedandhas
thereforedistortedthestatistics.Tomarkareadingasdeleted,placethemeasuredvalueinthefirstrowof
thedisplayandpressthekey.Themarkedvaluewillbeindicatedwithanasterisk(*)andwillnot
beconsideredinthestatisticalanalysis.
Returntomenuwith.
9.3Lastdelete
Withinthismenuitem,youcandeleteeitherthemostrecentrecordedreadingorthenewlycreatedblock.
All:3
Actual:3
FE111.5µm
FE224.7µm
*FE111.5µm
FE124.7µm
measuredvalueexcludedfromstatistic
Lastdata
delete?N
User´sManual–SaluTronD2X(Rel.2.1)
19
‐SelectY‐YesorN‐Nowith or andconfirmwith.
9.4Memodelete
Thismenuitemallowsyoutodeletetheentirememory,includingthemeasuredvaluesandallcreated
blockswiththeirassociatedcomments.
‐SelectY‐YesorN‐Nowith or andconfirmwith.
9.5Statistic
Allpreviouslyrecordedandstoredmeasurementswillbeprocessedbythedeviceanddisplayedas
statisticaldata.Thefollowinginformationisincludedinthesestatistics:
N=........(numberofallmeasurements)
Fe=........(numberofFe‐measuredvalues)
NFe=........(numberofNFe‐measuredvalues)
Nst=........(numberofreadingsforstatistics)
*N=........(numberofdeletedreadings)
Min=........(smallestmeasuredvalue)
Max=........(largestmeasuredvalue)
Ave=........(arithmeticalmean‐value)
Sta=........(StandardDeviation)
Vk=........(coefficientofvariationin%)
Thestatisticscanbecalculatedforindividualmeasurementblocksormultiplemeasurementblocks.Ifyou
wanttocalculatethestatisticsforonlyoneblock,enterthesamevalueforboth"fromblock"and"till
block".
‐Enterthenumberofthefirstblockforthestatisticswith or andconfirmwith .
‐Enterthenumberofthelastblockforthestatisticswith or andconfirmwith.
Alldata
delete?N
frombl:1
tillbl:2
User´sManual–SaluTronD2X(Rel.2.1)
20
‐Youcannavigatethroughthestatisticaldatabypressingthe or.
9.6Print
WiththeSaluTronD2X,youhavetheabilitytoprintallmeasurementsandstatisticsortransferthemtoa
PC.ThiscanbedoneusingaportableinfraredHPcompatibleprinter(refertothePortmenuiteminthis
manual)oraserialprinterconnectedviaaUSB/RS232interfacecable.
ThemeasurementprotocolanddatacanbetransferredtoaPCandsavedintoafileusingaprogramand
aninterfacecable.Oncesaved,youcanfurtherprocessthedataasneeded.
Ifyouselectthe"report"option,youwillreceivealistinginaformatthatcanbedirectlyreadbyprograms
likeExcel.Therequiredsoftwarecanbefoundonourhomepageatwww.salutron.de.Thetransmission
formatfortheserialinterfaceisasfollows:
‐Baudrate:9600
‐Datalength:8Bit
‐Parity:none
‐Stopbit:1
‐Xon/Xoff:active
Toprintouttheprotocol,followthesesteps:
‐Confirmwith.
Pleaseentertherequiredinformationforthemeasurementreport,includingtheexaminer,supplier,
customer,object,commissionnumber,andbatchnumber.Additionally,configuretheprintoutsettingsfor
individualmeasurements,statisticsblocks,andhistograms.Pressthe keyrepeatedlyuntilthe
nextitemisdisplayed.
N51
Fe 27
Report
Measure
Examiner:
xxxx
Table of contents
Other Salutron Measuring Instrument manuals
