Salutron Mini GlossTector 60 User manual




GlossTector

(3angleunit)

20°60°85°


Operationmanual

1.Generalinformation
Thankyouforpurchaseofourglossmeter.
Thisdeviceisdesignedandmanufacturedaccordingtointernatioanal
standardISO2813,ASTMD523andDIN67530.Thetechnicalparameters
meettheJJG696‐2002.TheGlossTectorcanbeusedtodeterminethe
glosslevelofpaintcoatings,plastic,ceramicsandmetalsurfaces.

2.Applications:
Measurementofpaintanddopesurfaceglossoncar,electronic
applianceandmusicalinstrumentindustry.
Measurementoffloorboard,marble,graniteandceramictile
glossonarchitecture,decorationindustry.
Measurementofprintinginkandpaperinprintingandcasing
industry.
Harddrawnaluminiumalloys.

3.Features:
Smallandlightandeasytouse.
Smallpowerconsumption‐1.5Valkalineatterycanbeusedfor
almost60hoursand100000reading.
Highstability.
Long‐termstablelightsourcedonotneedbereplacedforever.
Quartzcrystalstandardboard,noexcursion.

4.Technicaldata:
Measurerange:0199.9GU
Stability:lessthan0.4GU/30min.
Readouterror:lessthan1.5GU
Powersupply:1.5VAAalkalinebattery
Voltage:0.8V1.5V.
Measurementunitsareequippedwithstandardgeometriesof
20°,60°or85°.
Faculadimension20°:10x10mm,60°:10x20mm,85°:7x24mm.
Dimensionsofmeasurearea:11x54mm.
Environmenttemperature:0°C40°C
Relativehumidity:lessthan85%.
Dimension:142mmx32mmx64mm.
Dimensionofstandardboard:67mmx46mmx13mm.
Weight:320g

5.Operationinstruction:
PressingtheON/OFFbuttonstartsmeasurementsorperforms
functionsthataredisplayed.
PresstheGeometrykeyoftheangle’schoice:Incommonuse
the60°angle.Formeasuringofhighgloss,selectforuse20°.
The85°istobeselectedformeasurementsonsurfaceswithlow
gloss.
Thereisalwaystobeusedtheblackstandardboardboxfor
adjusting.Placetheinstrumentonstandardboardwithablack
glass.Theunderpartofthedevicesignedmustaimtheother
one()ofthestandardbox.
Adjustingstandard:RegulatetheCALscrollwheelontheright
untilthereadingonscreenaccordstogivenvalueatthe
standardboardbox.Pleasenote,thatthestandardboardmust
bekeptcleanforguaranteeofaccuratemeasurement.
Testing:Payattentiontonotmovethewheelagain.Putthe
instrumentonotherstandardboardfromwhitebox.The
differencebetweenthedisplayedvalueandgivenoneinthebox
shouldnotbegreaterthan1.5GU.
Measuring:PuttheGlossTectorontheobject,thenreadthe
valuedisplayedonthescreen.
Measurementwithdifferentangles:selecttheotherangleby
pressingakeyandrepeatthestepsabove.

6.Safetyinstructions:
Avoiddirectstronglightwhileusing,otherwiseitcaninfluence
theaccuracyofmeasuring.
Keepthestandardboardsclean,besurenottotouchthesurface
withthefingerandpolishwiththelenspaperorabsolutealcohol.
Anytypeofspotsonthesurfacewillcausethemeasuringerror.
Verifyregulartheadjustingbymakingofcontrolmeasurements
onstandardboards.
Thelowcapacityofthebatteryissignalizedbyredlightonthetop
ofthedevice.Inthiscasereplacethepowerbatterywithanew
one.
Istheadjustingoftheinstrumentonstandardboardsnot
possible,theopticslensofinstrumentcanbepollutedseriously.
Trytopolishtheopticlenswithlenspaperandabsolutealcohol.
Thegivenvaluesofthestandardsmaychangedueto
environmentalinfluences.Forthisreason,itisrecommended

regular(onesayear)tosendthedevicewithstandardsboardsfor
inspectionandcalibrationtothemanufacturer.

7.SalesService:
Forfurtherquestionswearealwaysatyourdisposal

8.StandardScheme:
DeviceGlossTector.
Twostandardboardboxes.
Battery
Usermanual
Duster
Carryingcase
SaluTronMesstechnikGmbH
Dr.‐Gottfried‐Cremer‐Alle30/7
D‐50226Frechen
Tel.+49(0)22349999960‐Fax.+49(0)22342534977
[email protected]‐www.salutron.de
