Samson TROVIS 5578-E Setup guide

Translation of original instructions
KA 5578-E EN
Edition May 2022
QUICK GUIDE
TROVIS5578-E Heating and District Heating Controller

Definition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip
2 KA 5578-E EN
Notes on this document
This quick guide assists you in mounting and operating the device safely. The instructions in
this quick guide are binding for handling SAMSON devices.
ÎFor the safe and proper use of these instructions, read them carefully and keep them for
later reference.
ÎIf you have any additional questions not related to the contents of these instructions,
contact SAMSON's After-sales Service ([email protected]om).

Contents
KA 5578-E EN 3
1 Liability.........................................................................................................4
2 Safety instructions .........................................................................................4
3 Electrical connection ......................................................................................5
4 Operating controls ........................................................................................8
5 Operation.....................................................................................................9
5.1 Selecting the operating mode..........................................................................9
5.2 Schedules....................................................................................................10
5.2.1 Setting the time and date..............................................................................10
5.2.2 Setting the times-of-use.................................................................................12
5.2.3 Setting the party timer (special time-of-use) ....................................................15
5.2.4 Programming public holidays (special times-of-use) ........................................16
5.2.5 Programming vacation periods (special times-of-use) ......................................17
5.3 Entering day and night set points ..................................................................20
5.4 Reset to default settings.................................................................................21
5.5 Reading information ....................................................................................22
5.5.1 Adapting the Trend-Viewer ...........................................................................26
5.6 Operating the controller in manual mode.......................................................28
6 Error list......................................................................................................29

4 KA 5578-E EN
Liability
1 Liability
We are constantly developing our products and therefore, reserve the right to change the
product at any time without notice.
We do not assume any liability for the accuracy or completeness of this document. Moreover,
we do not guarantee that the buyer can use the product for an intended purpose. SAMSON
rejects any liability for claims by the buyer, especially claims for compensation including lost
prots or any other nancial loss, except the damage was caused intentionally or by gross
negligence. If an essential term of the contract is breached by negligence, SAMSON’s
liability is limited to the foreseeable damage.
2 Safety instructions
The device must be mounted, started up or operated only by trained and experienced per-
sonnel familiar with the product. Proper shipping and storage are assumed.
The device has been designed for use in electrical power systems. For wiring and mainte-
nance, you are required to observe the relevant safety regulations.
This quick guide is intended to provide the necessary information for operating the device.

KA 5578-E EN 5
Electrical connection
3 Electrical connection
RS485
BE1
BE2
BE3
BE4
BE5
BE6
BE7
BE8
BE9
BE10
BE11
BE12
BE13
29
1 3 5 7 9
11 13 15 17
19
21 23 25 27
BE14
BE15 / AE1
BE16 / AE2
2
4
6 8
10 12 14 16 18 20 22 24 26 28 30
BE17 / AE3
AA1
GND
GND
GND
AA2
AA3
AA4
42
32
31
BA1 BA2 BA5 BA6
BA7
45
46
47
44
43
SLP
41
40
39 38
37 36
35
34
33
44 41
Rk1_3-Pkt
Rk2_3-Pkt
Rk2_2-Pkt Rk1_2-Pkt
M-Bus
AF2 / RÜF4
F1A
SF1
SF2
RF1
RF2
VF1
VF2
VF3
VF4
RüF1
RüF2
N L1
UP1
UP2
L1
ZP
BA4
L1
L1
BA8 BA9
RF3
RüF3
47
Rk3_3-Pkt
Rk3_2-Pkt
L1
BA10 BA11
BA3
UP3
0...10V / PWM 0...10V / PWM
0...10V / PWM 0...10V / PWM
0...10V / FG1 0...10V / FG2 0...10V / FG3 / SF3
B
A
+ + + + + + +
-
-
Fig.1: Electrical connection of the TROVIS5578-E Heating Controller

6 KA 5578-E EN
Electrical connection
Legend for Fig.1:
AA Analog output
AE Analog input
AF Outdoor sensor
BA Binary output
BE Binary input
FG Potentiometer
PWM Pulse width
modulation
RF Room sensor
RK Control circuit
RüF Return ow sensor
SF Storage tank sensor
SLP Storage tank
charging pump
UP Circulation pump
(heating)
VF Flow sensor
ZP Circulation pump
(DHW)
2417
TROVIS 5578-E
20
br/sw
gnws
Water ow sensor
ws = white
gn = green
br = brown
sw = black
Fig.2: Connection of a water ow sensor

KA 5578-E EN 7
Electrical connection
518
TROVIS 5578-E
15123
Type5257-5(x) Room Panel1)
For RK1:
618
TROVIS 5578-E
16123
Type5257-5(x) Room Panel1)
For RK2:
718
TROVIS 5578-E
17123
Type5257-5(x) Room Panel1)
For RK3:
1) Type5244 no longer available
Fig.3: Wiring of a room panel for RK1, RK2 or RK3
Table1: Permissible wire cross-section for terminals
Cable Wire cross-section
Single-wire 0.33 to 2mm²
Multi-wire 0.33 to 2mm²
Length of insulation to be stripped off wire ends: 6mm

8 KA 5578-E EN
Operating controls
4 Operating controls
The heating controller is operated on site using the operating controls on the front. They are
located in the front panel of the controller.
Rotary pushbutton
*
Turn [q]:
Select readings, parameters and function blocks
Press [Û]:
Conrm adjusted selection or settings
Rotary switch
The rotary switch is used to set the operating mode and the relevant parameters for each
control circuit.
Operating level
Operating modes
Manual level
Day set point (rated room temperature)
Night set point (reduced room temperature)
Times-of-use for heating/DHW
Special time-of-use
Time/date
Settings

KA 5578-E EN 9
Operation
5 Operation
5.1 Selecting the operating mode
The controller can be operated in the following modes:
Day mode (rated operation): regardless of the programmed times-of-use and summer mode,
the set points relevant to rated operation are used by the controller. Icon:
Night mode (reduced operation): regardless of the programmed times-of-use, the set points
relevant to reduced operation are used by the controller. Icon:
Control operation deactivated: regardless of the programmed times-of-use, control opera-
tion of the heating circuits and DHW heating remains deactivated. The frost protection is ac-
tivated, if need be. Icon:
Icons when the frost protection is activated: HC , DHW
Automatic mode: During the programmed times-of-use, the controller works in day mode.
Outside these times-of-use, the controller is in night mode, unless control operation is deacti-
vated depending on the outdoor temperature. The controller switches automatically between
both operating modes. Icon within the times-of-use: , icon outside the times-of-use:
Manual mode: valves and pumps can be controlled manually. For further details, see sec-
tion5.6.
Turn the rotary switch to (operating modes). The oper-
ating states of all system control circuits are displayed:
−Heating circuit HC1
−Heating circuit HC2
−Heating circuit HC3
−Heating circuit HC11
−Heating circuit HC12
−Heating circuit HC13
−DHW heating
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
qSelect the control circuit.

10 KA 5578-E EN
Operation
¼Activate editing mode for the control circuit. The operat-
ing mode is shown inverted on the display.
qSelect the operating mode:
Automatic mode
Day mode
Night mode
System deactivated
¼Conrm the operating mode.
The controller is usually in automatic mode.
5.2 Schedules
The controller operates according to the schedules in automatic mode.
5.2.1 Setting the time and date
The current time and date need to be set immediately after start-up and after a power failure
lasting more than 24 hours. This is the case when the time blinks on the display.
Turn the rotary switch to (time/date). The current time is
selected (gray background).

KA 5578-E EN 11
Operation
¼Activate editing mode for the time. The time reading is
inverted.
qChange the time.
¼Conrm the time setting.
qSelect 'Date' (dd.mm) [q].
¼Activate editing mode for the date. The date reading is
inverted.
qChange date (day.month).
¼Conrm the date setting.
qSelect 'Year'.
¼Activate editing mode for the year. The year reading is
inverted.
qChange the year.
¼Conrm the year setting.
Deactivate or activate the automatic summer/standard time
switchover as required.

12 KA 5578-E EN
Operation
qSelect 'Auto summertime'.
¼Activate the editing mode for automatic summer/stan-
dard time switchover. The current setting is shown invert-
ed on the display:
ON = Summer/standard time switchover active
OFF = Summer/standard time switchover not active
qDeactivate or activate the automatic summer/standard
time switchover.
¼Conrm deactivation/activation.
Turn the rotary switch back to (operating level).
The correct time is guaranteed after a power failure of 24 hours. Normally, the correct time
is still retained at least 48 hours after a power failure.
5.2.2 Setting the times-of-use
Three times-of-use can be set for each day of the week.
Parameters WE Value range
HC1, HC2, HC3,
HC11, HC12, HC13
DHW, CP
Start rst time-of-use 06:00 00:00
00:00 to 24:00 h
in steps of 15 minutes
Stop rst time-of-use 22:00 24:00
Start second time-of-use --:-- --:--
Stop second time-of-use --:-- --:--
Start third time-of-use --:-- --:--
Stop third time-of-use --:-- --:--
Note

KA 5578-E EN 13
Operation
Turn the rotary switch to (times-of-use). The rst control
circuit is displayed together with its programmed times-of-
use.
qProgram the times-of-use of another control circuit, if re-
quired:
– Heating circuit HC2
– Heating circuit HC3
– Heating circuit HC11
– Heating circuit HC12
– Heating circuit HC13
– DHW heating
– Circulation pump (DHW) CP
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
¼Activate editing mode for the control circuit. The times-
of-use for Monday are displayed.
qSelect period/day for which the times-of-use are to be
valid. The times-of-use can be programmed for individu-
al days or for a block of days, e.g. Monday to Friday,
Saturday and Sunday or Monday to Sunday. The select-
ed days are shown inverted on the display.

14 KA 5578-E EN
Operation
¼Activate editing mode for the period/day.
The start time of the rst time-of-use period can now be
edited (inverted reading).
qChange start time.
(in steps of 15 minutes)
¼Conrm the start time.
The stop time of the rst time-of-use period can now be
edited.
qEnd stop time.
(in steps of 15 minutes)
¼Conrm the stop time.
The start time of the second time-of-use period can now
be edited.
To set the second and third times-of-use periods, repeat
steps with gray background. If no further times-of-use are to
be programmed for the selected time period/day, exit the
menu by conrming the indicated start time twice (2x Û).
Proceed in the same manner to program further periods/
days.
After setting all times-of-use:
qSelect 'Back'.
¼Exit the times-of-use setting.
Turn the rotary switch back to (operating level).

KA 5578-E EN 15
Operation
5.2.3 Setting the party timer (special time-of-use)
Rated operation in the corresponding control circuit (HC1, HC2, HC3 or DHW) is started or
continued for the time period set in the party mode. When the party timer has elapsed, the
party timer returns to --:--.
Parameters WE Value range
HC1 party timer --:-- h 0 to 48h; in steps of 15 minutes
HC2 party timer --:-- h 0 to 48h; in steps of 15 minutes
HC3 party timer --:-- h 0 to 48h; in steps of 15 minutes
DHW party timer --:-- h 0 to 48h; in steps of 15 minutes
Turn the rotary switch to (special times-of-use). The party
timer for the rst control circuit is now selected.
qSet time for party mode of another control circuit, if re-
quired:
– Heating circuit HC2
– Heating circuit HC3
– DHW heating
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
¼Activate editing mode for the party timer. The party tim-
er is now in the editing mode (inverted display).
qExtend day operation as required.
(in steps of 15 minutes)
¼Conrm setting.
After setting the party timer:
Turn the rotary switch back to (operating level).
Party timer runs down in steps of 15 minutes.
Note

16 KA 5578-E EN
Operation
5.2.4 Programming public holidays (special times-of-use)
On public holidays, the times-of-use specied for Sunday apply.
A maximum of 20 public holidays may be entered.
Parameters WE Value range
Public holidays --:-- 01.01 to 31.12
Turn the rotary switch to (special times-of-use). The party
timer for the rst control circuit is now selected.
qSelect 'Public holidays'.
¼Start the public holiday setting. The rst public holiday
setting is now selected. --:-- is displayed if no public hol-
idays (default setting) have been programmed.
qSelect --:--, if applicable.
¼Activate editing mode for public holidays.
qSet the date of the public holiday.
¼Conrm the date.
Proceed in the same manner to program further public holi-
days.
Deleting a public holiday:
qSelect the holiday you wish to delete.
¼Conrm the date.
qSelect --:--.
¼Conrm setting.
The public holiday is deleted.

KA 5578-E EN 17
Operation
After programming all public holidays:
qSelect 'Back'.
¼Exit the public holiday setting.
Turn the rotary switch back to (operating level).
Public holidays that are not assigned to a specic date
should be deleted by the end of the year so that they are not
carried on into the following year.
5.2.5 Programming vacation periods (special times-of-use)
The system runs constantly in reduced mode during vacation periods. A maximum of ten va-
cation periods can be entered. Each vacation period can be separately assigned to the heat-
ing circuits HC1, HC2, HC3 and DHW circuit or to all control circuits.
If a vacation period is programmed to apply to all control circuits, it also applies to control
circuits HC11, HC12 and HC13.
Parameters WE Value range
Vacation period --.-- - --.-- 01.01 to 31.12
Turn the rotary switch to (special times-of-use). The party
timer for the rst control circuit is now selected.
qSelect 'Vacations'.
Note
Note

18 KA 5578-E EN
Operation
¼Start the vacations setting. The rst vacations setting is
now selected. --.-- - --.--.is displayed if no vacations (de-
fault setting) have been programmed.
qSelect --.-- - --.--, if applicable.
qActivate editing mode for vacations.
The start date can now be edited (inverted reading).
qSet the start date.
qConrm the start date.
The end date can now be edited.
qSet the end date.
qConrm the year setting. 'All' is selected. The vacation
period then applies to all control circuits.
qIf the vacation period is to be only valid for one control
circuit, select the required control circuit:
– Heating circuit HC1
– Heating circuit HC2
– Heating circuit HC3
– DHW heating
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
The control circuits HC11, HC12 and HC13 are not
available.
¼Conrm the control circuit.
An active vacation period is indicated on the display by the
icon.
Proceed in the same manner to program further vacations.
Note

KA 5578-E EN 19
Operation
Deleting vacation periods:
qSelect the start date of the period you wish to delete.
¼Conrm vacation period.
qSelect --.-- - --.--.
¼Conrm setting.
The vacation period is deleted.
After programming all vacation periods:
qSelect 'Back'.
¼Exit the vacations setting.
Turn the rotary switch back to (operating level).
Vacations should be deleted by the end of the year so that
they are not carried on into the following year.
Note

20 KA 5578-E EN
Operation
5.3 Entering day and night set points
The day set points apply during day mode (rated operation) and during times-of-use pro-
grammed for automatic mode.
The night set points apply during night mode (reduced operation) and outside the times-of-
use programmed for automatic mode.
The desired room temperature for the day and night set points can be programmed.
Switch position
Parameters WE Value range
HC1 room temperature 20.0°C 0.0 to 40.0°C
HC2 room temperature 20.0°C 0.0 to 40.0°C
HC3 room temperature 20.0°C 0.0 to 40.0°C
HC11 room temperature 20.0°C 0.0 to 40.0°C
HC12 room temperature 20.0°C 0.0 to 40.0°C
HC13 room temperature 20.0°C 0.0 to 40.0°C
DHW temperature 60.0°C Min. to max. DHW temperature
HC1 OT deactivation value 22.0°C 0.0 to 50.0°C
HC2 OT deactivation value 22.0°C 0.0 to 50.0°C
HC3 OT deactivation value 22.0°C 0.0 to 50.0°C
HC11 OT deactivation value 22.0°C 0.0 to 50.0°C
HC12 OT deactivation value 22.0°C 0.0 to 50.0°C
HC13 OT deactivation value 22.0°C 0.0 to 50.0°C
Switch position
Parameters WE Value range
HC1 room temperature 15.0°C 0.0 to 40.0°C
HC2 room temperature 15.0°C 0.0 to 40.0°C
HC3 room temperature 15.0°C 0.0 to 40.0°C
HC11 room temperature 15.0°C 0.0 to 40.0°C
HC12 room temperature 15.0°C 0.0 to 40.0°C
HC13 room temperature 15.0°C 0.0 to 40.0°C
DHW temperature 40.0°C Min. to max. DHW temperature
