Samsung AF28FVSDA Series Guide

QUESTIONS OR COMMENTS
COUNTRY CALL OR VISIT US ONLINE AT
INDONESIA 021-56997777
08001128888 www.samsung.com/id/support
PHILIPPINES
1-800-10-7267864 [PLDT]
1-800-8-7267864
[Globe landline and Mobile]
02-4222111 [Other landline]
www.samsung.com/ph/support
THAILAND 0-2689-3232
1800-29-3232 www.samsung.com/th/support
VIETNAM 1 800 588 889 www.samsung.com/vn/support
Importir:
PT. Samsung Electronics Indonesia Jl. Jababeka Raya Blok F 29-33
Kawasan Industri Cikarang, Cikarang Bekasi 17530
S-east_MEMORY_IBIM_03955A-02_co_EN.indd 2 2014-10-31 오후 1:49:13

AF28FVSDA Series
AF28FVZDA Series
Air Conditioner
user & installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DB68-03955A-02
EN TH IN VI
S-east_MEMORY_IBIM_03955A-02_co_EN.indd 3 2014-10-31 오후 1:49:14

2
Features of your new air conditioner
Samsung Air Solution! Cool, Clean and refreshing feeling at once
Cool Air : Your air conditioner uses air flow direction control which provide direct air flow in hot days and indirect air flow
when you are cooled down.
Refreshing Air : Auto mode will provide refreshing air by selecting the operation mode automatically from Cool, Dry, Purity
depending on the indoor air environment.
4 seasons of eective cleaning
Purity mode
 Purity mode can be selected solely to save energy.
 When the air conditioner operates, Zero filter and the Virus Doctor eliminates harmful contaminants to provide us with
the cleanest air.
Smart sensor
Camera on the top of the indoor unit will detect the movement within the indoor and when there is no movement for a
certain time, air conditioner will adjust the indoor temperature or turn off power automatically to save the energy
 Applicable to AFFVSD only
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 2 2014-10-28 오후 12:00:46

3
ENGLISH
Contents
Safety precautions ....................................................................................................... 4
Checking before use .................................................................................................... 11
Checking the name of the parts ........................................................................................ 13
Checking the remote controller ......................................................................................... 16
Basic operation ......................................................................................................... 18
Turbo operation ........................................................................................................ 20
Air flow direction ....................................................................................................... 20
good'sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the On/Off timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Smart sensor operation ................................................................................................. 25
Lighting function ....................................................................................................... 25
Quiet operation ......................................................................................................... 26
Auto clean operation ................................................................................................... 26
Cleaning the air conditioner ............................................................................................. 27
Troubleshooting ........................................................................................................ 30
Open Source Announcement ........................................................................................... 33
Safety precautions ...................................................................................................... 34
Required tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Choosing the installation location ....................................................................................... 37
Indoor/outdoor unit installation diagram ............................................................................... 38
Accessories ............................................................................................................. 40
Drilling a hole and fixing the indoor unit ................................................................................ 41
Connecting pipes ....................................................................................................... 41
Connecting drain hose .................................................................................................. 44
Electrical work .......................................................................................................... 45
Vacuum pump .......................................................................................................... 49
Performing leak test .................................................................................................... 50
Installing the earth wire ................................................................................................. 51
Charging refrigerant .................................................................................................... 51
Check and test operation ............................................................................................... 52
Pump down procedure (When removing the product) .................................................................. 52
USING PARTS
INSTALLATION PARTS
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 3 2014-10-28 오후 12:00:46

4
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that
you know how to safely and efficiently operate the extensive features and functions of
your new appliance.
If you have any questions, call your nearest contact center or find help and information
online at www.samsung.com.
Important safety symbols and precautions:
WARNING Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal
injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut the power at the circuit breaker.
Do NOT disassemble.
FOR INSTALLATION WARNING
Use the power line with the power specications of the product or higher and use
the power line for this appliance only. In addition, do not use an extension line.
 Extending the power line may result in electric shock or fire.
 Do not use an electric transformer. It may result in electric shock or fire.
 If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualied technician or
service company.
 Failing to do so may result in electric shock, fire, explosion, problems with the
product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
 Failing to do so may result in electric shock or fire.
Fix the outdoor unit rmly so that the electric part of the outdoor unit is not
exposed.
 Failing to do so may result in electric shock or fire.
USING PARTS
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 4 2014-10-28 오후 12:00:46

5
ENGLISH
Do not install this appliance near a heater, inammable material. Do not install
this appliance in a humid, oily or dusty location, in a location exposed to direct
sunlight and water (rain drops). Do not install this appliance in a location where
gas may leak.
 This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where
it could fall.
 If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas
pipe, plastic water pipe, or telephone line.
 Failure to do so may result in electric shock, fire, an explosion, or other problems at
the product.
 Make sure to use a socket-outlet with ground.
FOR INSTALLATION CAUTION
Install your appliance on a level and hard oor that can support its weight.
 Failing to do so may result in abnormal vibrations, noise, or problems with the
product.
Conrm that the indoor unit xing device has been installed by conrming this
with an installation engineer.
 If the indoor unit fixing device is not installed, the indoor unit may vibrate and fall
and this may result in injury.
Install the draining hose properly so that water is drained correctly.
 Failing to do so may result in water overflowing and property damage.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 5 2014-10-28 오후 12:00:46

6
Safety precautions
FOR POWER SUPPLY WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power
line. Do not hook the power line over a metal object, place a heavy object on the
power line, insert the power line between objects, or push the power line into the
space behind the appliance.
 This may result in electric shock or fire.
FOR POWER SUPPLY CAUTION
When not using the air conditioner for a long period of time or during a thunder/
lightning storm, cut the power at the circuit breaker.
 Failing to do so may result in electric shock or fire.
FOR USING WARNING
If the appliance is ooded, please contact your nearest service center.
 Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, cut-o the
power supply immediately and contact the nearest service center.
 Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line. Do not touch the appliance or
power line.
 Do not use a ventilating fan.
 A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service center.
 Failing to do so may result in problems with the product, water leakage, electric
shock, or fire.
 A delivery service for the product is not provided. If you reinstall the product in
another location, additional construction expenses and an installation fee will be
charged.
 Especially, when you wish to install the product in an unusual location such as
in an industrial area or near the seaside where it is exposed to the salt in the air,
please contact your nearest service center.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 6 2014-10-28 오후 12:00:46

7
ENGLISH
Do not operate the appliance with wet hands.
 This may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
 This may result in fire, injury, or problems with the product.
 Importantly, if the support bracket is excessively impacted, it may become
damaged.
Do not place an object near the outdoor unit that allows children to climb onto
the machine.
 This may result in children seriously injuring themselves.
Do not turn the air conditioner o with the circuit breaker while it is operating.
 Turning the air conditioner off and then on again with the circuit breaker may
cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the
reach of children, as packaging materials can be dangerous to children.
 If a child places a bag over its head, it may result in suffocation.
Do not insert your ngers or foreign substances into the outlet when the air
conditioner is operating or the front panel is closing.
 Take special care that children do not injure themselves by inserting their fingers
into the product.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 7 2014-10-28 오후 12:00:46

8
Safety precautions
FOR USING WARNING
Do not insert your ngers or foreign substances into the air inlet/outlet of the air
conditioner.
 Take special care that children do not injure themselves by inserting their fingers
into the product.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near inrm people.
 Since this may be dangerous due to a lack of oxygen, open a window at least once
an hour.
If any foreign substance such as water has entered the appliance, cut-o the
power supply and contact the nearest service center.
 Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
 Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
 Failing to do so may result in electric shock, fire, problems with the product, or
injury.
FOR USING CAUTION
Do not place objects or devices under the indoor unit.
 Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a
year.
 Failing to do so may result in injury, death or property damage.
Do not stand on top of the appliance or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the
appliance.
 This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
 This may result in electric shock.
Do not forcefully open the front panel while air conditioner is operating.
 This may cause damage to the product.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 8 2014-10-28 오후 12:00:46

9
ENGLISH
Do not spray volatile material such as insecticide onto the surface of the
appliance.
 As well as being harmful to humans, it may also result in electric shock, fire or
problems with the product.
Do not drink the water from the air conditioner.
 The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble
the remote controller.
Do not touch the pipes connected with the product.
 This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food, animals,
plants or cosmetics, or for any other unusual purposes.
 This may result in property damage.
Avoid directly exposing humans, animals or plants from the air ow from the air
conditioner for long periods of time.
 This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy eciency.
FOR CLEANING WARNING
Do not clean the appliance by spraying water directly onto it. Do not use
benzene, thinner, alcohol or acetone to clean the appliance.
 This may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, cut-o the power supply and wait
until the fan stops.
 Failing to do so may result in electric shock or fire.
S-east_MEMORY_IBIM_EN_03955A-02_EN.indd 9 2014-10-28 오후 12:00:46
