Samsung AG026MN1DEH/EU User manual

1. Precautions
2. Product Specifications
3. Disassemblyand Reassembly
4. Troubleshooting
5. PCB Diagram and Parts List
6.Wiring Diagram
7. Reference Sheet
ContentsFan Coil Unit
Fan Coil Unit
AG026/32MN1DEH/EU
AG042MN1DEH/EU
AG060/072/090/105MN4DKH/EU
AG060/072/090/105MN4PKH/EU
SystemAirconditoner

1 1
Contents
1. Precautions................................................................................................................................................................................... 1-1
1-1. Precautions for the Service............................................................................................................................................................... 1-1
1-2. Precautions for the Static Electricity and PL.............................................................................................................................. 1-1
1-3. Precautions for the Safety................................................................................................................................................................ 1-1
2. Product Specifications.............................................................................................................................................................. 2-1
2-1. Product Specifications ...................................................................................................................................................................... 2-1
2-2. Specifications of optional items.................................................................................................................................................... 2-4
2-2-1. Accessories.............................................................................................................................................................................. 2-4
3. Disassembly and reassembly ................................................................................................................................................ 3-1
Necessary tools............................................................................................................................................................................................ 3-1
3-1. Fan Coil Unit ......................................................................................................................................................................................... 3-2
3-1-1. 1-Way Cassette Type ............................................................................................................................................................ 3-2
   ■AG026/032MN1DEH/EU..................................................................................................................................................... 3-2
   ■AG042MN1DEH/EU .............................................................................................................................................................. 3-11
3-1-3. Circular Cassette Type......................................................................................................................................................... 3-18
   ■AG041/060/072/090/105MN4DKH/EU........................................................................................................................ 3-18
3-1-3. Circular Cassette Type......................................................................................................................................................... 3-24
   ■AG060/072/090/105MN4PKH/EU................................................................................................................................. 3-24
4. Troubleshooting......................................................................................................................................................................... 4-1
4-1. Set fan coil unit address and installation options .................................................................................................................... 4-1
4-1-1. Option setting procedure and setting method (Normal remote controller) ................................................... 4-1
  4-1-2.Optionsettingprocedureandsettingmethod(360cassetteremotecontrolleronly)................................ 4-5
  4-1-3.FanCoilUnitAddress(MAIN/RMC)Setting................................................................................................................ 4-10
  4-1-4.FanCoilUnitInstallationOptionSetting(settingoptiontosuitinstallationsiteconditions).................... 4-11
  4-1-5.Optioncodepermodel ....................................................................................................................................................... 4-14
4-2. What to check before diagnosis .......................................................................................................................................... 4-15
  4-2-1.LampcombinationexpressionmethodDISPLAY..................................................................................................... 4-15
  4-2-2.NumberexpressionmethodDISPLAY(fancoilunit,cableremotecontrol,etc.)........................................... 4-19
  4-3.AppropriateMeasuresforDifferentSymptoms............................................................................................................ 4-20
  4-3-1.FancoilunitROOMsensorerror(OPEN/SHORT)..................................................................................................... 4-20
  4-3-2.FancoilunitEVAPINsensorerror(OPEN/SHORT).................................................................................................. 4-21
  4-3-3.FancoilunitEVAPOUTsensorerror(OPEN/SHORT).............................................................................................. 4-22
4-3-4. Water temperature increase prevention error ......................................................................................................... 4-23
  4-3-5.E153:FloatingSwitchdetectionoffancoilunitDrainPump............................................................................... 4-24
  4-3-6.FancoilunitFanoperationerror.................................................................................................................................... 4-25
  4-3-7.EEPROMerror....................................................................................................................................................................... 4-26
4-3-8. Fan coil unit remote control option error .................................................................................................................... 4-27
  4-3-9.ErrorduetoconfusionbetweenuseofFahrenheitandCelsius.......................................................................... 4-28

2
- 2 -
Contents
5.PCBDiagram...............................................................................................................................................................................  5-1
 5-1.FanCoilUnit ......................................................................................................................................................................................... 5-1
  5-1-1.Slim1waycassettetype(Medium)................................................................................................................................ 5-1
  5-1-2.Slim1waycassettetype(Large),4waycasettetype............................................................................................... 5-4
  5-1-3.Circularcassettetype.......................................................................................................................................................... 5-7
  5-1-4.FCUSUBPBA......................................................................................................................................................................... 5-9
  5-1-5.CircularcassettetypeDISPLAY........................................................................................................................................ 5-10
  5-1-6.Slim1waycassettetypepanel(Normal)..................................................................................................................... 5-11
  5-1-7.Slim1waycassettetypepanel(Interiortype)............................................................................................................. 5-12
  5-1-8.Slim1waycassettetypepanel(Europe) ...................................................................................................................... 5-13
  5-1-9.Small4waycassettetypepanel ..................................................................................................................................... 5-14
6.WiringDiagram..........................................................................................................................................................................  6-1
 6-1.FanCoilUnit ......................................................................................................................................................................................... 6-1
  6-1-1.Slim1waycassette(Medium_JSF1)............................................................................................................................... 6-1
  6-1-2.Slim1waycassette(Small_Medium_JSF2),4waycassette(G4WAY)............................................................. 6-2
  6-1-3.Circularcassettetype(360).............................................................................................................................................. 6-3
7.ReferenceSheet..........................................................................................................................................................................  7-1
 7-1.IndexforModelName....................................................................................................................................................................... 7-1
  7-1-1.FanCoilUnit............................................................................................................................................................................ 7-1
  7-1-2.Panel......................................................................................................................................................................................... 7-2

21-1
1. Precautions
1-1. Precautions for the Service
● Use the standard parts when replacing the electric parts.
 –Confirmthemodelname,ratedvoltage,ratedcurrentoftheelectricparts.
● When repairing the equipment, connection of the harness parts must be firm and solid.
– A loose connection may cause noise or other malfunction.zzz
● When assembling and disassembling the equipment while it is laid down, lay it on soft cloth.
 –Otherwiseitmayscratchthebackoftheexterioroftheproduct.
● Remove dust ordirt completely from the housing block, wiring block and service parts during repair.
– This helps prevent the danger of fire caused by tracking or short circuit.
● Check the status of the components’ assembly afterrepair service.
– The status must be the same as before the repair service
1-2. Precautions for the Static Electricity and PL
● Please carefully handle the PCB powerterminal during repair and measurement when it is turned on since it is vulnerable
to static electricity.
 –PleasewearinsulationglovesbeforeperformingPCBrepairandmeasurement..
●Check if the place of installation is at least 2m away from electronic appliances such as TV, video players, and stereos.
- This can cause irregular noise or degrade the picture quality.
●Please make sure the customer does not directly repair the product.
- Arbitrary dismantling may result in electric shock or fire.
1-3. Precautions for the Safety
● Do not pull or touch the power plug or the subsidiary power switch with wet hands.
- This may result in electric shock or fire.
● If the power line or the power plug is damaged, then it must be changed since this is a hazard.
● Do not bend the wire too much or position it so that it can be damaged by a heavy object on top.
- This may result in electric shock or fire.
● The use of multiple electric outlets should be prohibited.
- This may result in electric shock or fire.
● Ground the connection if it is necessary.
 - Theconnectionmustbegroundedifthereisanyriskofelectricalshortduetowaterormoisture.
● Unplug the power or turn off the subsidiary power switch when changing or repairing electrical parts.
 - Doingsowillpreventelectricshock.
● Explain to workers that the battery for the remote control needs to be separated for storage purposes when the product will
not be used for a long time.
- This can cause a problem for the remote control since battery fluid may trickle out.

2. Product Specifications
2-1. Product Specifications
Model
(Slim 1 way cassette type)
Type 1Way Cassette 1Way Cassette 1Way Cassette
Model AG026MN1DEH/EU AG032MN1DEH/EU AG042MN1DEH/EU
Power Supply Φ, #, V, Hz 1,2,220,60 1,2,220,60 1,2,220,60
Performance
Cooling
Capacity
Cooling
(Eurovent
Condition)
T1 (kW) 2.60 3.00 4.15
T1 (Btu/h) - - -
T3 (kW) N/A N/A N/A
Heating
Capacity
Heating
(Eurovent
Condition)
T1 (kW) 2.90 3.35 5.00
T1 (Btu/h) - - -
T3 (kW) N/A N/A N/A
Power
Power Input
(Nominal)
Cooling T1 (W) 47. 0 50.0 55.0
T3 (W) N/A N/A N/A
Heating T1 (W) 47. 0 50.0 55.0
Current Input
(Nominal)
Cooling T1 (A) 0.24 0.26 0.29
T3 (A) N/A N/A N/A
Heating T1 (A) 0.24 0.26 0.29
Heat
Exchanger
Type -Fin & Tube Fin & Tube Fin & Tube
Material Fin -Al Al Al
Tube -Cu Cu Cu
Fin Surface Treatment -Green water-friendly Green water-friendly Green water-friendly
Fan
Type -Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output x n W12.0 12.0 54.0
Air Flow Rate H/M/L (UL) CMM 6.8/5.8/4.9 7.8/6.8/4.9 14.6/12.6/10.7
l/s - - -
External
Pressure
Min / Std /
Max
mmAq N/A N/A N/A
Pa - - -
Fan Motor Type -AC AC DC
Output x n W17 x 1 17 x 1 54 x 1
Water
Water Flow
Rate (Cooling) H/M/L (UL)
LPM 7. 5 9.6 11.9
l/s - - -
Water Flow
Rate (Heating) H/M/L (UL) LPM 8.4 9.7 14.4
l/s - - -
Loss of Head
(Cooling)
H/M/L (UL) kPa 23 34.5 45
- - -
Loss of Head
(Heating)
H/M/L (UL) kPa 28 35.8 64.6
- - -
Water Pipe
Inlet Type PF MALE PF MALE PF MALE
Φ, mm (inch) 20A (3/4") 20A (3/4") 20A (3/4")
Outlet Type PF MALE PF MALE PF MALE
Φ, mm (inch) 20A (3/4") 20A (3/4") 20A (3/4")
Insulation -Both inlet/outlet pipes Both inlet/outlet pipes Both inlet/otu tpleipes
Drain Pipe Φ,mm VP20 (OD 26, ID 20) VP20 (OD 26, ID 20) VP25 (OD 32, ID 25)
Wiring Communication
Cable
Min.
thickness mm2 0.75 0.75 0.75
Remarks -F1, F2 F1, F2 F1, F2
Dimensions
Net Weight kg 10.5 10.5 14
Shipping Weight kg 13.5 13.5 1 7. 5
Net Dimensions (WxHxD) mm 970*135*410 970*135*410 1200*138*450
Shipping Dimensions
(WxHxD) mm 1164*212*478 1164*212*478 1435*214*525
Case Material -Plastic Plastic Plastic

2-2 2-3
Product Sepcifications
Model
(Small/Medium4WayCassettetype)
TYPE G4W/C-Small G4W/C-Small G4W/C-Mid G4W/C-Mid
ModelName AG060MN4DKH/EU AG072MN4DKH/EU AG090MN4DKH/EU AG105MN4DKH/EU
Power Supply Φ, #, V, Hz 1,220,60 1,220,60 1,220,60 1,220,60
Performance
Cooling Capacity
Cooling
(Eurovent
Condition)
T1 (kW) 67. 2 910
T1 (Btu/h) - - - -
T3 (kW) N/A N/A N/A N/A
Heating Capacity
Heating
(Eurovent
Condition)
T1 (kW) 7. 3 8.5 10 10.7
T1 (Btu/h) - - - -
T3 (kW) N/A N/A N/A N/A
Power
Power Input
(Nominal)
Cooling T1 (W) 50 73 82 99
T3 (W) N/A N/A N/A N/A
Heating T1 (W) 50 73 82 99
Current Input
(Nominal)
Cooling T1 (A) 0.37 0.5 0.58 0.79
T3 (A) N/A N/A N/A N/A
Heating T1 (A) 0.37 0.5 0.58 0.79
Fan
Type Type -Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output x n W65 65 65 65
Air Flow Rate H/M/L (UL) CMM 18.9/16.5/13.6 21.3/18.2/13.6 23.3/21.3/19.4 30.1/26.2/19.4
l/s - - - -
External Pressure Min / Std /
Max
mmAq N/A N/A N/A N/A
Pa - - - -
Heat
Exchanger
Type -Fin & Tube Fin & Tube Fin & Tube Fin & Tube
Material Fin -Al Al Al Al
Tube -Cu Cu Cu Cu
Fin Surface Treatment -
Green water-friendly Green water-friendly Green water-friendly Green water-friendly
Water
Water Flow Rate
(Cooling) H/M/L (UL) LPM 1 7. 5 20.8 26 28.9
l/s - - - -
Water Flow Rate
(Heating) H/M/L (UL) LPM 21.1 24.5 28.9 30.9
l/s - - - -
Loss of Head
(Cooling)
H/M/L (UL) kPa 27 36 46.8 56.3
- - - -
Loss of Head
(Heating)
H/M/L (UL) kPa 3 7. 3 48.6 56.3 63.4
- - - -
Water Pipe
Inlet Φ,mm 20A 20A 20A 20A
Φ, inch PF 3/4" Male PF 3/4" Male PF 3/4" Male PF 3/4" Male
Outlet Φ,mm 20A 20A 20A 20A
Φ, inch PF 3/4" Male PF 3/4" Male PF 3/4" Male PF 3/4" Male
Drain Φ,mm VP25(OD32, ID25) VP25(OD32, ID25) VP25(OD32, ID25) VP25(OD32, ID25)
Field Power Wire mm2 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Wiring Communication Cable mm2 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Sound
Sound Pressure(Dev. SPEC.) dB(A) 45 49 50 53
Sound Pressure High / Mid /
Low dB(A) 37/33/30 41/35/30 42/38/35 45/40/35
Sound Power Cooling 56 60 58 60
Dimensions
Net Weight kg 15.5 15.5 18 18
Shipping Weight kg 19.5 → 19.0 19.5 → 19.0 22.0 → 19.0 22.0 → 19.0
Net Dimensions (W×H×D) mm 840*204*840 840*204*840 840*246*840 840*246*840
Shipping Dimensions (W×H×D) mm 898*275*898 898*275*898 898*316*898 898*316*898
Drain Pump
Drain Pump - / Model
name Built In Built In Built In Built In
Max. Pump-up head / Distributed
amount mm / cc/min 1200 / 400 1200 / 400 1200 / 400 1200 / 400
Panel Size
Panel model -
PC4NUSK1N
PC4NUAK1N
PC4NUSK5N
PC4NUSK1N
PC4NUAK1N
PC4NUSK5N
PC4NUSK1N
PC4NUAK1N
PC4NUSK5N
PC4NUSK1N
PC4NUAK1N
PC4NUSK5N
Panel Net Weight kg 5.9 5.9 5.9 5.9
Shipping Weight kg 8.4 8.4 8.4 8.4
Net Dimensions (W×H×D) mm 950*45*950 950*45*950 950*45*950 950*45*950
Shipping Dimensions (W×H×D) mm 1013*101*1013 1013*101*1013 1013*101*1013 1013*101*1013

2-2 2-3
Product Sepcifications
Model
(Small/Large360Cassettetype)
TYPE 360CST-Small 360CST-Large 360CST-Large 360CST-Large
ModelName AG060MN4PKH/EU AG072MN4PKH/EU AG090MN4PKH/EU AG105MN4PKH/EU
Power Supply Φ, #, V, Hz 1,220,60 1,220,60 1,220,60 1,220,60
Performance
Cooling
Capacity
Cooling
(Eurovent
Condition)
T1 (kW) 67. 2 910
T1 (Btu/h) - - - -
T3 (kW) N/A N/A N/A N/A
Heating
Capacity
"Heating
(Eurovent
Condition)"
T1 (kW) 7. 3 8.5 10 10.7
T1 (Btu/h) - - - -
T3 (kW) N/A N/A N/A N/A
Power
Power
Input(Nominal)
Cooling T1 (W) 58 58 77 100
T3 (W) N/A N/A N/A N/A
Heating T1 (W) 58 58 77 100
Current Input
(Nominal)
Cooling T1 (A) 0.5 0.5 0.62 0.79
T3 (A) N/A N/A N/A N/A
Heating T1 (A) 0.5 0.5 0.62 0.79
Fan
Type Type -Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output x n W65 97 97 97
Air Flow Rate H/M/L (UL) CMM 21/17.5/15 25.5/22/19.8 29.5/24/19.8 31.5/22.5/19.8
l/s - - - -
External
Pressure Min / Std / Max mmAq N/A N/A N/A N/A
Pa - - - -
Heat
Exchanger
Type -Fin & Tube Fin & Tube Fin & Tube Fin & Tube
Material Fin -Al Al Al Al
Tube -Cu Cu Cu Cu
Fin Surface Treatment -Green water-friendly Green water-friendly Green water-friendly Green water-friendly
Water
Water Flow Rate
(Cooling) H/M/L (UL) LPM 1 7. 5 20.8 26 28.9
l/s - - - -
Water Flow Rate
(Heating) H/M/L (UL) LPM 21.1 24.5 28.9 30.9
l/s - - - -
Loss of Head
(Cooling) H/M/L (UL) kPa 27 26 38.5 47.4
- - - -
Loss of Head
(Heating) H/M/L (UL) kPa 37.6 35.6 47.4 53.2
- - - -
Water Pipe
Inlet Φ,mm 20A 20A 20A 20A
Φ, inch PF 3/4" Male PF 3/4" Male PF 3/4" Male PF 3/4" Male
Outlet Φ,mm 20A 20A 20A 20A
Φ, inch PF 3/4" Male PF 3/4" Male PF 3/4" Male PF 3/4" Male
Drain Φ,mm VP25(OD32, ID25) VP25
(OD32, ID25)
VP25
(OD32, ID25)
VP25
(OD32, ID25)
Field Power Wire mm2 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Wiring Communication Cable mm2 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Sound
Sound Pressure(Dev. SPEC.) dB(A) 47 46 50 53
Sound Pressure High / Mid / Low dB(A) 40/37/32 39/35/33 43/38/33 45/39/33
Sound Power Cooling 57 58 60 62
Dimensions
Net Weight kg 21 25 25 25
Shipping Weight kg 25.5 29.5 29.5 29.5
Net Dimensions (W×H×D) mm 947*281*947 947*365*947 (TBD) 947*365*947 947*365*947
Shipping Dimensions (W×H×D) mm 990*330*990 990*414*990 (TBD) 990*414*990 990*414*990
Drain Pump
Drain Pump - / Model
name Built In Built In Built In Built In
Max. Pump-up head / Distributed
amount
mm / cc/
min 1200 / 400 1200 / 400 1200 / 400 1200 / 400
Panel Size
Panel model -PC4NUDK1N
PC4NUNK1N
PC4NUDK1N
PC4NUNK1N
PC4NUDK1N
PC4NUNK1N
PC4NUDK1N
PC4NUNK1N
Panel Net Weight kg 3.6 3.6 3.6 3.6
Shipping Weight kg 6 6 6 6
Net Dimensions (W×H×D) mm 1050*66*1050 1050*66*1050 1050*66*1050 1050*66*1050
Shipping Dimensions (W×H×D) mm 1093*85*1083 1093*85*1083 1093*85*1083 1093*85*1083

2-4 2-5
Product Sepcifications
2-2. Specifications of optional items
2-2-1. Accessories
Item Description Code No. Q’ty
Front Panel
Slim 1 way cassette PC1NWSK1N
PC1NWAK1N -
Slim 1 way cassette PC1BWSK1N
PC1BWAK1N -
Front Panel
(4 way cassette, General)
PC4NUSK1N
PC4NBSK1N
PC4NSSK1N
PC4NUSK5N
-
Front Panel
(4 way cassette, Automatic lift) PC4NUAK1N -
Buried Panel
(Circular cassette) PC4NUDK1N -
Exposed Panel
(Circular cassette)
PC4NUNK1N (WHT)
PC4NBNK1N (BLK) -

2-4 2-5
Product Sepcifications
Item Description Code No. Q’ty Remark
-S-NET CLOUD AST-EP01D
AST-EP05D -Option
DMS2.5 AIM-D01AN -Option
BACnet G/W AIM-B17BN -Option
External Contact Interface Module AIM-B14 -Option
ON/OFF Controller ACM-A202DN -Option
Touch Central Controller ACM-A300N -Option
FCU Interface Module AIM-F10N -Option
PowerMonitoring Interface Module AIM-B12N -Option
SIM Interface Module AIM-B16N -Option
PIM Interface Module AIM-B16N -Option
Wireless Remote Controller
AR-EH00 -Option
AR-KH00 -Option
Wired Remote Controller AWR-WE11N -Option
S-NET Converter AIM-C01A -Option
WIFI-KIT AIM-H03N -Option

3-1 3-1
3. Disassembly and reassembly
■Necessary tools
Item Remark
+SCREW DRIVER
MONKEY SPANNER
-SCREW DRIVER
NIPPER
Electric drill

3-2 3-3
Disassembly and Reassembly
3-1. Fan Coil Unit
3-1-1. 1-Way Cassette Type
■AG026/032MN1DEH/EU
No Parts Procedure Remark
1PANEL and FILTER
NORMAL type
(PC1NWSK1N
PC1NWAK1N )
1) Open by pressing the GRILLE’s PUSH button.
2) Remove 1 clip from the PANEL and tilt the
GRILLE 45 degrees to separate it from the
PANEL.
3) Remove the FILTER from the PANEL.
4) Remove the 3 COVER SCREWS.
5) Remove the 6 screws in the PANEL and remove
it from the fan coil unit (use +SCREWDRIVER)

3-2 3-3
Disassembly and Reassembly
No Parts Procedure Remark
2) Press the left and right hooks on the PANEL to
remove it from the fan coil unit.

3-4 3-5
Disassembly and Reassembly
No Parts Procedure Remark
1Panel and FILTER
Interior type
(PC1NWSK1
PC1NWSK2
PC1BWXK1
PC1BWXK2)
1) Open the GRILLE as shown in the figure.
2) Remove the FILTER from the panel.
3) Remove the 2 COVER SCREWS.
4) Remove the 5 screws on the panel and remove it
from the fan coil unit . (use +SCREWDRIVER)
5)
Press the left and right hooks on the PANEL to
remove it from the fan coil unit..

3-4 3-5
Disassembly and Reassembly
No Parts Procedure Remark
Panel and FILTER
(continued)
6) Open the GRILLE and then raise the LINK LEVER
switch (yellowish green) of both sides in the
direction of the arrow and remove the LINK LEVER.
7) Remove the COVER DISPLAY screws with an
electric drill and remove the COVER DISPLAY.
8) Remove the remote controller receiver PBA and
display PBA connectors.
[ASSYGRILLEINLET]
[ASSYPanelFRONT]

3-6 3-7
Disassembly and Reassembly
No Parts Procedure Remark
Panel and FILTER
(continued)
9) Remove the STEP MOTOR screws and remove the
MOTOR.
10) Remove BLADE H.

3-6 3-7
Disassembly and Reassembly
No Parts Procedure Remark
2DRAIN PAN 1) Remove the 5 screws of the DRAIN PAN (use
+SCREWDRIVER).
2) Pull the DRAIN PAN and remove it from the pan coil
unit.
When removing the PAN, be careful not
to touch the heat exchanger pin with your
bare hands.
3Electronics 1) Remove the 3 screws of the electronics board
and remove the cover. (use +screwdriver).

3-8 3-9
Disassembly and Reassembly
No Parts Procedure Remark
2) Remove the 8 connectors connected to the fan
coil unit PCB.
3) Remove the electronics board from the fan coil
unit.
4DRAIN SUB 1) Press the DRAIN SUB’s HOOK to remove it.

3-8 3-9
Disassembly and Reassembly
No Parts Procedure Remark
5Heat exchanger 1) Remove 1 screw from the heat exchanger. (use
+SCREWDRIVER)
2) Remove the fan coil unit SENSOR from the heat
exchanger.
3) Remove the heat exchanger from the fan coil
unit.
When turning on the cold/hot water after
replacing the heat exchanger, make sure
to open the air release valve to sufficiently
remove air from inside the coil and pipe by
collecting the water using the tube before
closing the valve. Failure to do so may
result in decreased performance and noise
generation.
6CROSS FAN 1) Remove the 3 screws of the COVER FAN MOTOR.
(use +SCREWDRIVER)
2) Remove the COVER FAN MOTOR from the fan
coil unit.

3-10 3-11
Disassembly and Reassembly
No Parts Procedure Remark
3) Remove the CROSS FAN from the fan coil unit.
7DRAIN PUMP 1) Remove 1 screw from the COVER DRAIN PUMP.
(use +SCREWDRIVER)
2) Remove the DRAIN HOSE from the DRAIN Pump.
3) SSW remove the DRAIN PUMP from the fan coil
unit.
8SPI KIT 1) Remove the SPI KIT from CABI IN.

3-10 3-11
Disassembly and Reassembly
■AG042MN1DEH/EU
No Parts Procedure Remark
1PANEL and FILTER 1) Open by pressing the GRILLE’s PUSH button.
2) Remove 1 clip from the PANEL and tilt the
GRILLE 90 degrees to separate it from the
PANEL.
3) Remove the FILTER from the PANEL.
4) Remove the 4 COVER SCREWS.
\
5) Remove the 6 screws in the PANEL and remove
it from the fan coil unit. (use +SCREWDRIVER)
