Samsung MIM-H03U Guide

Air conditioner
User & installation manual
Wi-Fi Kit MIM-H03U
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this manual carefully and retain it for future reference.

2
Contents
Safety precautions ....................................................................................................... 3
Check before installing Wi-Fi kit .......................................................................................... 5
Parts......................................................................................................................5
Exterior dimension........................................................................................................5
How to install Wi-Fi kit ................................................................................................... 6
Wi-Fi kit installation.......................................................................................................6
Checking the Wi-Fi kit...................................................................................................11
Initializing user data ....................................................................................................12
Updating the Wi-Fi kit by SD card .......................................................................................12
Setting the network .................................................................................................... 13
Specication of wired/wireless router for Samsung Smart Air conditioner................................................13
Starting Samsung Smart Home App .................................................................................... 14
Downloading Samsung Smart Home App...............................................................................14
Running the Samsung Smart Home App ................................................................................14
Connecting the air conditioner to Samsung Smart Home app ...........................................................14
Starting SmartThings app ............................................................................................... 15
Checking the power connections .......................................................................................15
Setting up and connecting to a Wi-Fi access point using your smartphone...............................................15
Downloading the SmartThings app and registering your Samsung account .............................................16
Connecting the SmartThings app to your product.......................................................................16
Starting System Air conditioner App .................................................................................... 18
Controlling the air conditioner with Samsung Smart Home or SmartThings app .........................................18
Troubleshooting ........................................................................................................ 19
Open Source Announcement ........................................................................................... 20

3
ENGLISH
Safety precautions
California Proposition 65 Warning (US)
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
This installation manual explains how to install aWi-Fi kit to an indoor unit of Samsung system air conditioners.
Read the installation manual thoroughly before installing the Wi-Fi kit.
(Refer to the appropriate manual for installing product or other optional parts.)
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
WARNING
f Contact service center for installation.
- There is a risk of product malfunction, water leakage, electric shock or re.
f Install the Wi-Fi kit securely in a place that can withstand the weight of the product.
- If the installation location is not strong enough, Wi-Fi Kit may fall and be damaged.
f Connect the power with rated voltage when installing.
- If not, there is risk of re or damage to theWi-Fi kit.
f Do not attempt to move or re-install the Wi-Fi kit that is already installed.
- There is risk of electric shock and re.
f Do not attempt to modify or repair the Wi-Fi kit on your own.
- There is potential risk of product damage, electric shock or re. When repair is needed, consult service center.
f Check if the installation was done properly according to the installation manual.
- If the Wi-Fi kit is installed incorrectly, there is risk of electric shock or re.
f Make sure that all wiring work is done by a qualied person complying with regional standards and instructions in this
manual.
- If the installation is done by unqualied person, there is risk of product malfunction, electric shock or re caused by
incorrect installation.
f Contact the service center if you need to dispose the Wi-Fi kit.

4
Safety precautions
CAUTION
f Do not install the product in a place where it is or might be exposed to inammable gas leakage.
- There is risk of re or explosion.
f Do not install the product in a place where it will be exposed to oil or vapor etc.
- If the product is used in a place where it is exposed to oil, vapor or sulphur dioxide, parts of the product may get
damaged or product may function abnormally.
f Make sure that water does not get into the Wi-Fi kit.
- There is risk of electric shock and re.
f Make sure there is no tension to the cable during installation.
- Cable may get cut and cause re.
f Install the product in a place with temperature between 0 °C~39 °C (32 °F~102 °F) with no direct sunlight.
- If not, there is risk of electric shock or abnormal operation.
f Do not install the product in a place where special spray or acid/alkali solution is used.
- There is risk of electric shock or abnormal operation.
f Do not press the button with sharp object.
- There is risk of electric shock or damaging the parts.
f Do not connect the power cable to the communication cable terminal.
- There is risk of re.
f When installing the product in hospitals or other places, make sure that the product does not interrupt with other
products.
- Abnormal operation may occur.

5
ENGLISH
Check before installing Wi-Fi kit
Parts
Assy Wi-Fi kit Cable tie (2) Cable clamp (3) M4×16 screw (5)
User & Installation manual U- terminal (6)
• Wi-Fi kit should be installed by a certied installer.
• Before installing a Wi-Fi kit, you should check whether the power of the kit is turned o.
• The wire of Wi-Fi kit should be installed in accordance with electric wiring regulation and should also be installed
inside the wall so that it cannot be touched by users.
Exterior dimension
120 (4 3/4)
124 (4 7/8)
29 (1 1/8)
Unit : mm (inches)
CAUTION

6
How to install Wi-Fi kit
Wi-Fi kit installation
• For smooth operation, install the Wi-Fi kit and the wireless router in open space with no obstacles between them.
Operation may not be possible if the distance between the Wi-Fi kit and the wireless router is too far or if there's any
obstacle between them.
1. After pushing the two hooks on the bottom of the Wi-Fi kit at the same time, lift the front cover up and then detach it
from the rear cover.
❋ Push the two hooks at the same time.
• It might be easier to disassemble the Wi-Fi kit if you put a at-head screw driver
into the square hole above the xing hook.
2. Place the power wire and communication wire through openings in the rear cover.
<When the cover is not recessed> <When the cover is recessed>
15 cm
(5 7/8 inches) 10 cm
(3 15/16 inches)
The opening can be cut and
removed if you need more
space.
CAUTION
NOTE

7
ENGLISH
3. Use two or more screws to x the rear cover of the Wi-Fi kit to a wall.Then, connect the power cable (V1, V2) and the
communication cable(F1, F2) to the terminals on the back of the front cover in appropriate length.
4. When connecting the V1 and V2, tighten the screws for the terminal block (CN5) with a tightening torque of 5 ±2 Kgf·cm.
Size of the screw is M3 x 6.
• Maximum number of indoor unit installation that can be connected to Wi-Fi kit is 16.
• One Wi-Fi kit can be registered with maximum 5 users.
- If you register more than 5 users to single Wi-Fi kit, its operation may become slower.
• Each account (one mobile phone) can be registered with maximum 4 Wi-Fi kits.
Ⓑ
ⒺⒻ
Ⓐ
Ⓓ
Ⓒ
10 mm
(9/16inch) or
more
10 mm
(9/16inch) or more
50 mm (2inches)
or more
10 mm
(9/16inch) or more
Screw
xing
hole
Rear cover
❋ Before xing the rear cover, allow
10mm or more space for upper,
left, and right sides and 50mm
space for bottom side.
❋ Fix the screws in the
provided screw holes.
❋ Do not tighten the PCB terminal with
too much force.
V1 V2 F1 F2
Wi-Fi kit
PCB
terminal
Indoor unit
Item Contents
ⒶPower/communication connection terminal
ⒷTracknig/Initializing button
ⒸSD Card Slot
ⒹLED
ⒺNetwork PBA
ⒻInterface module PBA
NOTE

8
How to install Wi-Fi kit
5. Reassemble the Wi-Fi kit.
• Put the front cover of the kit into the upper grooves rst and then t it as shown in the picture. After
assembling the Wi-Fi kit, please check if there is any gap because of the connection cable between
front cover and rear cover.
❋ Connection diagram of Wi-Fi kit
F1
F1 F1
F1 F1 V1V1 F1F2
F2 F2
F2 F2 V2V2 F2F1 F2
< Connecting the Wi-Fi kit to a multi type product >
NOTE

9
ENGLISH
❋ If an indoor unit does not have V1 and V2 terminal block, use the SUB PBA (sold separately) to supply power to theWi-Fi
kit.
ORG : Connect the ORG wire to V1
YEL : Connect the YEL wire to V2
ORG RED RED : Don’t use it
YEL BLU BLU : Don’t use it
SUB PBA (MIM-A00)
12 V COM2
F1
F1 F1
F1 F1 V1
V1(ORG)
F1F2
F2 F2
F2 F2 V2
V2(YEL)
F2F1 F2
< Connecting the Wi-Fi kit to an indoor unit without V1 and V2 terminal block >

10
• When installing a Wi-Fi kit with 10 m (32.8 feet) or more wire, the communication wire and power wire of a Wi-Fi kit
should be installed separately. (The Wi-Fi kit will malfunction because of electrical fault. )
• When installing a Wi-Fi kit on the wall, select proper thickness of wires in the consideration of the hole size for wire
on the wall.
• Wire for Wi-Fi kit PCB connection
- When installing a Wi-Fi kit in a buried way, install the kit in accordance with U-terminal wiring Specication.
- When installing a Wi-Fi kit with 4 core PVC cable, peel o 30 cm (0.98 feet) of the sheath before installing.
(Recommendation: AWG22)
• Specication of compressed U-terminal for connecting Wi-Fi kit PCB
W
t
G
E
F
L
Stud D
Wire range for
connection
Rated
size
Stud
size Basic size(mm)
AWG mm2mm2mm t ΦD G E F W L
22~16 0.25~
1.65 1.5 3 0.7 3.8 10.0 4.5 6.5 6.0 21.2
The maximum wiring length for communication and power : 50 m (164 feet)
• Tighten the xing screws to the PCB terminal with less than 6N·cm torque. When the screws are tightened with
more than 6N·cm torque, the screw thread will be damaged.
6. Run the Wi-Fi kit.
f When the Wi-Fi kit is turned on, all the lamps are turned on until system operates.
f After the system operates, tracking is performed automatically.
7. Perform the tracking.
❋ Tracking :You can search the devices connected to the Wi-Fi kit with the tracking function. The devices connected to Wi-Fi
kit recognize that they are connected to the Wi-Fi kit. To monitor or control the system air conditioner with Wi-Fi
kit, tracking should be performed.
f When the Wi-Fi kit is turned on, the tracking is performed automatically. During the tracking, the lamp of
the Wi-Fi kit ( ) ( ) blinks.
f If the tracking is completed but the lamp ( ) blinks, it means the Wi-Fi kit does not nd connected indoor units. In this
case, check whether the connection of communication cable between indoor unit and outdoor unit is correct or is
aected by noise.
f If the conguration of indoor unit or outdoor unit is changed, tracking should be performed again manually by pressing
the button (SW3) inside the Wi-Fi kit. (Ⓑ-)
• If you want to control the indoor unit with the Wi-Fi kit, indoor unit’s centralized control usage option must be set to
“Enable”.
• If you want to control the indoor unit with the Wi-Fi kit, tracking must be done properly and connect the Wi-Fi kit to
a wired/wireless router.
• When the tracking is completed correctly, the lamp ( ) is turned on until the process which connects the wired/
wireless router to Wi-Fi kit is completed.
CAUTION
CAUTION
NOTE
How to install Wi-Fi kit
