Samsung AM017HN1DEH/EU User manual
SYSTEM AIRCONDITIONER CONTENTS
SYSTEM AIRCONDITIONER
AM112/140JNCDKH/EU
AM015/022/028/036/045/056/071/082JNVDKH/EU
AM015/022/028/036/045/056/071/082JNADKH/EU
AM015/022/028/036/045/056/071/082JNVDEH/TK
AM036FN1DEH/TL
AM056/071FN1DEH/TL
AM056/071FN2DEH/TL
AM045/056/071/090/112/128/140FN4DEH/TL
AM045/056/071/090/112/128/140FN4DEH/TS
AM045/056/071/090/112/128/140KN4DEH/TL
AM022/028/036/045/056/060FNNDEH/TL
AM022/028/036/045/056/071FNLDEH/TL
AM056/071/090/112/128/140FNMDEH/TL
AM022/028/036/045/056/071/082JNVDKH/TL
AM140/220/280JNEPEH/EU
AM012/018/024/030/036/048/054/060/072JNZDCH/AA
AM160KNMDEH/EU, AM022/045KNJDEH/EU
AM140/280JNPDKH/TK
AM015/022/028/036/045/056/071KNTDEH/EU
AM015/022/028/036/045/056/071KNQDEH/EU
AM022/028/036/045/056/071KNQDEH/TL
AM007/009/012/018/020/024KNTDCH/TC
AM007/009/012/018/020/024KNQDCH/TC
AM017/022/028/036KNLDEH/EU
AM045/056/071/090/112/128/140KN4DEH/AR
AM022/028/036KNLDEH/TK
AM022/028/036KNLDEH/TL
AM036/056/071MNFDEH/EU
AM140/220/280MNEPEH/EUAM093MNQDEH/EU
AM093MNQDEH/TK
AE022/028/036/056MNLDEH/EU
AE071/090MNMPEH/EU
AE022/028/036/056/071MNADEH/EU
AE022/028/036/056MNJDEH/EU
AM017/022NN1PEH/EU
AM022/028/036/056/071NN1DEH/
66
AM022/028/036/045/056/071/082JNADKH/TS
AM022/028/036/045/056/071/082JNVDKH/TS
AM093MNQDEH/TS
AM022/028/036/045/056/060FNNDEH/TS
AM112/128/140FNHDEH/TS
AM180/224JNHFKH/TS
AM036/045/056/071/090/112/128/140HNMPKH/TS
AM112/128/140HNHPKH/TS
AM022/028/036/045/056/071/090/112/128/140KNMDEH/TS
AM160KNMDEH1TS
AM017/022/028/036/045/056/071/090/112/128/140KNLDEH/TS
AM056/071FNCDEH/TS
AM112/140JNCDKH/TS
AM028/036/045HNNDEH/TL
INDOOR UNIT
AM017/022HN1DEH/EU
AM022/028/036FN1DEH/EU
AM071JN1DEH/EU, AM056/071FN2DEH/EU
AM045/056/071/090/112/128/140/FN4DEH/EU
AM045/056/071/090/112/128/140/FN4DEH/AR
AM045/056/071/090/112/128/140KN4DEH/EU
AM022/028/036/045/056/060FNNDEH/EU
AM015HNNDEH/EU
AM112/128/140/220/280FNHDEH/EU
AM036/056/071FNFDEH/EU
AM050/100FNKDEH/EU
AM017/022/028/036/045/056/071/090/112/128/140FNLDEH/EU
AM022/028/036/045/056/071/090/112//128/140FNMDEH/EU
AM056/071FNCDEH/EU
AM028/036/056FNJDEH/EU
AM022/028/036/056/071FNTDEH/EU
AM015HNTDEH/EU
AM022/028/036/045/056/071FNQDEH/EU
AM015HNQDEH/EU
AM160FNBFEB/EU,250FNBFEB/EU
AM160FNBFGB/EU,250FNBFGB/EU
AM160FNBDEH/EU,320FNBDEH/EU,500FNBDEH/EU
AM036/045/056/071/090/112/128/140HNMPKH/EU
AM112/128/140 HNHPKH/EU
AM180/224JNHFKH/EU
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram and Parts List
6. Wiring Diagram
7. Reference Sheet
Contents
1. Precautions.................................................................................................................................. 1
1-1 Precautions for the Service.................................................................................................................................... 1
1-2 Precautions for the Static Electricity and PL........................................................................................................ 1
1-3 Precautions for the Safety ..................................................................................................................................... 1
1-4 Precautions for Handling Refrigerant for Air Conditioner................................................................................. 2
1-5 Precautions for Welding the Air Conditioner Pipe.............................................................................................. 2
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant ......................................................... 2
1-7 Other Precautions................................................................................................................................................... 2
2. Product Specifications ............................................................................................................... 3
2-1 Product Specifacations .......................................................................................................................................... 3
2-1-1 Indoor Unit................................................................................................................................................................................................3
ŶSlim 1way cassette type.............................................................................................................................................................................3
Ŷ2 way cassette type......................................................................................................................................................................................7
Ŷ4 way cassette ................................................................................................................................................................................................8
ŶGlobal 4Way Cassette(600x600)...........................................................................................................................................................10
Ŷ4Way Cassette(600x600) ........................................................................................................................................................................12
ŶSlim duct.........................................................................................................................................................................................................13
ŶSlim Home Duct ..........................................................................................................................................................................................15
ŶDuct Type (Uplevel Static Pressure)....................................................................................................................................................16
ŶMSP duct.........................................................................................................................................................................................................17
Ŷ360 cassette...................................................................................................................................................................................................19
ŶBig Duct...........................................................................................................................................................................................................21
ŶGD-S(Big Duct)............................................................................................................................................................................................ 22
ŶHSP Duct ....................................................................................................................................................................................................... 23
ŶGlobal Duct................................................................................................................................................................................................... 24
ŶGlobal Duct (cont.) .................................................................................................................................................................................... 27
ŶCeiling type .................................................................................................................................................................................................. 29
ŶBig Ceiling ..................................................................................................................................................................................................... 30
ŶConsole type.................................................................................................................................................................................................31
ŶWall Mounted type(Neo Forte without EEV)................................................................................................................................. 32
ŶWall Mounted type(Neo Forte with EEV)........................................................................................................................................ 34
ŶWall Mounted type(Boracay with EEV) ............................................................................................................................................ 36
ŶWall Mounted type(Boracay without EEV)..................................................................................................................................... 38
ŶWall Mounted type(Boracay with EEV) ............................................................................................................................................40
ŶWall mounted type(Boracay without EEV)..................................................................................................................................... 44
ŶFloor Standing Type.................................................................................................................................................................................. 46
ŶFloor Standing Type.................................................................................................................................................................................. 47
ŶERV Plus.......................................................................................................................................................................................................... 48
ŶHydro Unit..................................................................................................................................................................................................... 49
ŶHydro unit HT .............................................................................................................................................................................................. 50
ŶWall Mounted type(A3050 With EEV)................................................................................................................................................51
ŶWall Mounted type(A3050 With EEV)............................................................................................................................................... 53
ŶWall Mounted type(A3050 Without EEV)........................................................................................................................................ 55
ŶWall Mounted type (MAX With EEV) ................................................................................................................................................. 57
ŶFresh Air Duct.............................................................................................................................................................................................. 58
ŶV-AHU.............................................................................................................................................................................................................. 59
ŶOAP DUCT ..................................................................................................................................................................................................... 63
ŶEHS TDM PLUS - SLIM DUCT..................................................................................................................................................................64
ŶEHS TDM PLUS - GLOBAL DUCT ......................................................................................................................................................... 65
ŶEHS TDM PLUS -Console type .............................................................................................................................................................. 66
ŶEHS TDM PLUS -Wall Monuted type ................................................................................................................................................. 67
2-2 Accessory and Option Specifications .................................................................................................................69
2-2-1 Accessories............................................................................................................................................................................................. 69
3. Disassembly and Reassembly ................................................................................................. 72
ŶNecessary Tools .......................................................................................................................................................................................... 72
3-1 Indoor Unit ............................................................................................................................................................73
Contents
ŶAM017/022HN1DEH/EU ........................................................................................................................................................................... 73
ŶAM017/022NN1PEH/EU............................................................................................................................................................................ 76
ŶSlim 1 way cassette type ........................................................................................................................................................................ 83
ŶAM022/028/036NN1DEH/EU................................................................................................................................................................. 85
ŶAM056/071NN1DEH/EU...........................................................................................................................................................................88
ŶAM052/060/072FN1DBH, AM052/060/072HN1DBH1, AM056/071FN1DEH, AM056/071JN1DEH........................... 98
ŶBIG DUCT .....................................................................................................................................................................................................105
ŶGD-S(Big Duct) - AM180JNHFKH/AM224JNHFKH.....................................................................................................................108
ŶGlobal 4way Cassette type.................................................................................................................................................................. 119
ŶDuct type(Slim1,2) ...................................................................................................................................................................................134
ŶDuct type(Slim3).......................................................................................................................................................................................139
ŶSlim Home Duct .......................................................................................................................................................................................146
ŶDuct type(Mid pressure1)..................................................................................................................................................................... 151
ŶDuct type (Mid Pressure2, High Pressure).....................................................................................................................................156
ŶAM036/045/056/071/090/112/128/140HNMPKH, AM112/128/140HNHPKH/EU, AE071/090MNMPEH/EU .....161
ŶCEILING.........................................................................................................................................................................................................166
ŶAM112/140JNCDKH/EU..........................................................................................................................................................................175
ŶCONSOLE .....................................................................................................................................................................................................180
ŶERV PLUS......................................................................................................................................................................................................185
ŶFloor Standin Type ..................................................................................................................................................................................194
ŶWall mount type.......................................................................................................................................................................................198
ŶWall Mounted type (Boracay).............................................................................................................................................................201
ŶWall Mounted type (MAX)...................................................................................................................................................................205
ŶGlobal 4Way Cassette type(600x600)............................................................................................................................................. 213
ŶAM160FNBDEH/320FNBDEH/500FNBDEH ..................................................................................................................................219
ŶAM160/250FNBFEB, AM160/250FNBFGB.......................................................................................................................................223
ŶWall Mounted type(A3050) ................................................................................................................................................................229
ŶOAP DUCT ...................................................................................................................................................................................................238
ŶOAP Duct (AM140MNEPEH/EU).........................................................................................................................................................240
ŶOAP Duct (AM220/280MNEPEH/EU) ...............................................................................................................................................247
ŶV-AHU............................................................................................................................................................................................................252
ŶAM280JNPDKH/TK ..................................................................................................................................................................................257
ŶAM140JNPDKH/TK...................................................................................................................................................................................263
Ŷ
4Way Cassette type(600x600.............................................................................................................................................................271
4. Troubleshooting...................................................................................................................... 274
4-1 Check-up Window Description..........................................................................................................................274
4-2 Service Operation .............................................................................................................................................275
4-2-1 Special Operation............................................................................................................................................................................275
4-2-2 DVM S Models EEPROM Code Table.........................................................................................................................................279
4-3 Troubleshooting .................................................................................................................................................280
4-3-1 Setting Option Setup Method....................................................................................................................................................280
4-3-2 Option Items.......................................................................................................................................................................................296
4-3-3 What to check before diagnosis ...........................................................................................................................................304
- Floor Standing type..................................................................................................................................................................... 316
- ERV Plus type .................................................................................................................................................................................. 318
- Hydro unit / Hydro unit HT....................................................................................................................................................... 319
4-3-4 Number Display Method (Outdoor Unit, MCU, Cable remote control, wall-mount, etc.)...............................320
4-4 Appropriate Measures for Different Symptom ...............................................................................................326
4-4-1 Outdoor Unit Operation Flow...................................................................................................................................................326
4-4-2 Main PCB has no power phenomenon.................................................................................................................................327
4-4-3 Indoor Unit ROOM sensor Error (Open/Short) ..................................................................................................................328
4-4-4 Indoor unit EVAP IN sensor Error (Open/Short).................................................................................................................329
4-4-5 Indoor EVAP OUT sensor Error (Open/Short).....................................................................................................................330
4-4-6 Indoor Heat Exchanger's EVAP IN sensor dislocation error ........................................................................................331
4-4-7 Indoor Heat Exchanger's EVA OUT sensor dislocation error (Open/Short)..........................................................332
4-4-8
Simultaneous Indoor Heat Exchanger's EVA IN, OUT sensor dislocation error (Open/Short)..............333
4-4-9 Electronic Expansion Valve opening malfunction (2nd stage) - ..........................................................334
4-4-10 Breakdown of EEV (2nd).............................................................................................................................................................335
Contents
4-4-11 Problem with EEV closure (2nd)..............................................................................................................................................336
4-4-12 EEV(Electronic Expansion Valve) opening malfunction (2nd stage) ....................................................................337
4-4-13 : EEV(Electronic Expansion Valve) closure malfunction (2nd stage) ................................................338
4-4-14 : Detection of Floating Switch of Indoor Unit's Drain Pump..................................................................339
4-4-15 The operational error of Indoor Unit's Fan Motor .........................................................................................................340
4-4-16 Mixed operation Error (Only applicable to Heat Pump Model/Not to HR model)..........................................341
4-4-17 EEPROM error ................................................................................................................................................................................342
4-4-18 Option error of the Remote Controller for an Indoor Unit .......................................................................................343
4-4-19 Error due to confused use of Fahrenheit and Celsius .................................................................................................343
4-4-20 Simultaneous opening of Cooling/heating MCU SOL Valves 1st/2nd .................................................................344
4-4-21 Error due to incorrect Indoor Unit Power/Communication Cable Connection ...............................................345
4-4-22 SPI Feedback Error.......................................................................................................................................................................346
4-4-23 Outdoor Unit Pipe Inspection Error......................................................................................................................................347
4-4-24 Communication Error between Indoor and Outdoor Units during Tracking...................................................348
4-4-25 Communication Error between Indoor and Outdoor Units after Tracking .......................................................349
4-4-26 Communication error between main and sub Unit of outdoor unit or between outdoor units ............350
4-4-27 Communication Error between MCU and Outdoor Unit ............................................................................................351
4-4-28 Internal Communication error of the Outdoor Unit C-Box........................................................................................352
4-4-29 Internal PCB Communication error of the Outdoor Unit C-Box..............................................................................353
4-4-30 Communication Error between MCU and Outdoor Unit after Tracking is Completed ................................354
4-4-31 MCU branch part setup error – inconsecutive connection with the use of 2 branch parts.......................355
4-4-32 MCU branch part setup error – Repeated setup for the same address over 3 times....................................356
4-4-33 MCU branch part setup error – non-installed address setup ..................................................................................357
4-4-34 Setup Error for MCU Branch part – Setup Error for MCU Quantity Used............................................................358
4-4-35 MCU branch part setup error – Overlapping Indoor unit Address setup...........................................................359
4-4-36 MCU branch part setup error – Set as being used without connection to an Indoor unit .......................360
4-4-37 MCU branch part setup error – Connect an Indoor unit to a branch part not being used........................361
4-4-38
MCU branch part setup error – Connect more Indoor units than what is actually set up in MCU.... 362
4-4-39 Outdoor Temperature Sensor Error.....................................................................................................................................363
4-4-40 Outdoor Temperature dislocation error............................................................................................................................364
4-4-41 Cond Out Temperature Sensor Error (Open/Short)......................................................................................................365
4-4-42 Outdoor Cond Out sensor breakaway error....................................................................................................................366
4-4-43 Digital Compressor Discharge Temperature Sensor Error (OPEN/SHORT)........................................................367
4-4-44 Constant Rate Compressor Discharge Temperature Sensor Error (OPEN/SHORT) ........................................368
4-4-45 Compressor Discharge or Top 1/2 Temperature sensor error ................................................................................369
4-4-46 : Dislocation error of Compressor SUMP Temperature (oil temperature) Sensor .......................370
4-4-47 : Suction Temperature sensor breakaway error........................................................................................371
4-4-48 SUMP Temperature Sensor Error (OPEN/SHORT)..........................................................................................................372
4-4-49 High Pressure sensor error (Open/Short)..........................................................................................................................373
4-4-50 Low Pressure sensor error (Open/Short)........................................................................................................................... 374
4-4-51 Suction Temperature sensor error (Open/Short)...........................................................................................................375
4-4-52 Liquid Pipe Temperature sensor error (Open/Short)...................................................................................................376
4-4-53 EVI In Temperature sensor error (Open/Short)...............................................................................................................377
4-4-54 EVI Out Temperature sensor error (Open/Short)...........................................................................................................378
4-4-55 Suction-2 Temperature Sensor Error (OPEN/SHORT)...................................................................................................379
4-4-56 : Comp. Down due to High Pressure Protection Control......................................................................380
4-4-57 : Comp. Down due to Low Pressure Protection Control ........................................................................381
4-4-58 Sump Sensor Error Due to Protection Control................................................................................................................382
4-4-59 : Comp. Down due to Compressor Discharge Temperature sensor.................................................383
4-4-60 3-phase Input Wiring error......................................................................................................................................................384
4-4-61 : Comp. Down by Compression Ratio Control ..........................................................................................385
4-4-62 EVI EEV Open error......................................................................................................................................................................386
4-4-63 Refrigerant Leakage Error........................................................................................................................................................387
4-4-64 , :
Prohibition of the operation of Compressor due to Ooutdoor Temperature..388
4-4-65 High Pressure Standard Not Met before Air Conditioning (Inability to Re-operate) ...................................389
4-4-66 CCH Malfunction and Sump Sensor Miswiring Error...................................................................................................390
4-4-67 Fan starting error.........................................................................................................................................................................391
4-4-68 Fan lock error.................................................................................................................................................................................392
Contents
4-4-69 Momentary Blackout error .....................................................................................................................................................393
4-4-70 Outdoor Fan Motor overheating...........................................................................................................................................394
4-4-71 Outdoor Unit Fan Motor RPM Error......................................................................................................................................395
4-4-72 Fan IPM Overheat error..............................................................................................................................................................396
4-4-73 Over-Voltage Error of an Outdoor Fan Motor..................................................................................................................397
4-4-74 Counter-Rotation Error of an Outdoor Fan Motor.........................................................................................................397
4-4-75 : Compressor Excess Current Error ..................................................................................................................398
4-4-76 Compressor starting error........................................................................................................................................................399
4-4-77 Inverter Overcurrent error........................................................................................................................................................400
4-4-78 Overvoltage / Low voltage error...........................................................................................................................................401
4-4-79 DC Link voltage sensor error...................................................................................................................................................402
4-4-80 Liquid Compression Prevention Control...........................................................................................................................403
4-4-81 Fan Motor Overcurrent error ..................................................................................................................................................404
4-4-82 Input / Output Current sensor error....................................................................................................................................405
4-4-83 Outdoor Fan PCB Overvoltage / Low voltage error .....................................................................................................406
4-4-84 Hall IC(Fan) error...........................................................................................................................................................................407
4-4-85 Inverter Overheat error.............................................................................................................................................................408
4-4-86 Model mismatching of Indoor unit.....................................................................................................................................409
4-4-87 Breakdown of an EEV(1st) ......................................................................................................................................................... 410
4-4-87 Breakdown of an EEV closure................................................................................................................................................. 411
4-4-88
Electronic expansion valve closing malfunction (2nd stage)...............................................................................412
4-4-89
Electronic expansion valve opening malfunction (2nd stage)............................................................................413
4-4-90
Hydro Unit Water In Temperature Sensor Error (Open/Short) ............................................................................414
4-4-91
Hydro Unit Water Out Temperature Sensor Error (Open/Short) ........................................................................415
4-4-92
Hydro Unit Water Tank Temperature Sensor Error (Open/Short).......................................................................416
4-4-93
Emergency Error (Check the Water Piping Equipment).........................................................................................417
4-4-94
Error to prevention from freezing and bursting of Heat Exchanger ...............................................................418
4-4-95
Breakaway of Water Out temperature sensor.............................................................................................................419
4-4-96
Breakaway of Flow switch................................................................................................................................................... 420
4-4-97 Thermostat Wiring Error...........................................................................................................................................................421
4-4-98 DC FAN Motor Feedback Error...............................................................................................................................................422
4-4-99 Water Tank Sensor defective..................................................................................................................................................423
5. PCB Diagram and Parts List ................................................................................................... 424
5-1 Indoor Unit ..........................................................................................................................................................424
5-1-1 Slim 1 way cassette type (medium)..........................................................................................................................................424
5-1-2 2 way cassette type ........................................................................................................................................................................426
5-1-3 4way cassette , Global 4Way Cassette type(600x600), Slim 1way cassette (small/large) ................................428
5-1-4 360 cassette.......................................................................................................................................................................................430
5-1-5 Indoor Unit Power PCB...................................................................................................................................................................432
5-1-6 Display PCB .........................................................................................................................................................................................433
5-1-7 Duct type (Slim Duct 2) .................................................................................................................................................................434
5-1-8 Duct type (Slim Duct 3) .................................................................................................................................................................437
5-1-9 Slim Home Duct................................................................................................................................................................................440
5-1-10 Duct type(MSP, HSP, Big Duct)..................................................................................................................................................442
5-1-11 Duct type(HSP) ............................................................................................................................................................................... 444
5-1-12 Duct type (Super).......................................................................................................................................................................... 446
5-1-13 Duct type (Global Duct)............................................................................................................................................................ 448
5-1-14 Duct type (Global Duct_HSP) .................................................................................................................................................451
5-1-15 Big Duct.............................................................................................................................................................................................454
5-1-16 Celing type.......................................................................................................................................................................................457
5-1-17 Big Ceiling ........................................................................................................................................................................................459
5-1-18 Console..............................................................................................................................................................................................461
5-1-19 Wall-Mounted type (Neo Forte)..............................................................................................................................................465
5-1-20 Wall-Mounted type (Boracay)...................................................................................................................................................467
5-1-21 ERV Plus ...........................................................................................................................................................................................469
5-1-22 Hydro unit/Hydro unit HT .........................................................................................................................................................471
5-1-23 Hydro unit HT .................................................................................................................................................................................473
Contents
5-1-24 Wall Mounted type(A3050 ) ....................................................................................................................................................480
5-1-25 OAP DUCT ........................................................................................................................................................................................483
5-1-26 OAP DUCT..........................................................................................................................................................................................485
5-1-27 V-AHU ................................................................................................................................................................................................492
5-1-28 STAND.................................................................................................................................................................................................494
5-1-29 Floor Standing Type.....................................................................................................................................................................501
5-1-30 Wall Mounted type(MAX) .........................................................................................................................................................505
5-1-30 Wall Mounted type(MAX) .........................................................................................................................................................508
5-1-31 Wind-free 1way cassette type................................................................................................................................................. 510
5-1-32 4Way Cassette(600x600) .......................................................................................................................................................... 513
5-1-33 4Way Cassette(600x600) .......................................................................................................................................................... 515
6. Wiring Diagram ....................................................................................................................... 516
6-1 Indoor...................................................................................................................................................................516
6-1-1 Global 4Way (Global 4Way(600x600)) cassette type, Slim 1way cassette (small/large)...................................516
6-1-2 Slim 1 way cassette type (medium) ........................................................................................................................................ 517
6-1-3 360 cassette.......................................................................................................................................................................................518
6-1-4 BIG Duct ..............................................................................................................................................................................................519
6-1-5 GD-S(Big Duct)..................................................................................................................................................................................520
6-1-6 Ceiling ..................................................................................................................................................................................................521
6-1-7 Big Ceiling...........................................................................................................................................................................................522
6-1-8 Console................................................................................................................................................................................................523
6-1-9 RAC(Neo Forte).................................................................................................................................................................................524
6-1-10 Wall-Mounted type (Boracay)...................................................................................................................................................525
6-1-11 2way cassette type.......................................................................................................................................................................526
6-1-12 DUCT type (Slim III).......................................................................................................................................................................527
6-1-13 DUCT type (Slim I, II, MSP).........................................................................................................................................................528
6-1-14 Slim Home Duct..............................................................................................................................................................................529
6-1-15 Duct type (HSP)..............................................................................................................................................................................530
6-1-16 Duct type (Global Duct, MSP)...................................................................................................................................................531
6-1-17 Duct type (Global Duct, HSP)....................................................................................................................................................532
6-1-18 Floor Stand Type............................................................................................................................................................................533
6-1-19 ERV Plus .............................................................................................................................................................................................535
6-1-20 Hydro unit ........................................................................................................................................................................................536
6-1-21 Hydro unit HT 3 phase................................................................................................................................................................537
6-1-22 Hydro unit HT Single phase......................................................................................................................................................538
6-1-23 Wall Mounted type(A3050)......................................................................................................................................................539
6-1-24 Wall Mounted type(MAX)...........................................................................................................................................................540
6-1-25 OAP DUCT(AM140JNEPEH/EU).................................................................................................................................................541
6-1-26 OAP Duct (AM140MNEPEH/EU) ...............................................................................................................................................542
6-1-27 OAP Duct (AM140MNEPEH/EU) ...............................................................................................................................................543
6-1-28 OAP DUCT(AM220/280*NEPEH/EU).......................................................................................................................................544
6-1-29 V-AHU..................................................................................................................................................................................................545
6-1-30 Stand....................................................................................................................................................................................................546
6-1-31 4Way Cassette type(600x600)..................................................................................................................................................550
7. Reference Sheet ...................................................................................................................... 551
7-1 Index for Model Name........................................................................................................................................551
7-1-1 Indoor Unit...........................................................................................................................................................................................551
7-1-2 Panel.......................................................................................................................................................................................................552
7-2 Pump-down Method ..........................................................................................................................................553
7-2-1 Precautions for Pump-down .......................................................................................................................................................553
7-2-2 For Single Installation of Outdoor Unit (Only One Outdoor Unit Installed)...........................................................553
7-2-3 When Two or More Outdoor Units are Installed.................................................................................................................553
7-3 How to Put Refrigerant in Refrigerant Container ...........................................................................................554
7-3-1 How to put refrigerant in container before pump-down..............................................................................................554
Samsung Electronics 1
1. Precautions
1-1 Precautions for the Service
OUse the correct parts when changing the electric parts.
– Please check the labels and notices for the model name, proper voltage, and proper current for the electric parts.
OFully repair the connection for the types of harness when repairing the product after breakdown.
– A faulty connection can cause irregular noise and problems.
OWhen disassembling or assembling, make sure that the product is laid down on a work cloth.
– Doing so will prevent scratching to the exterior of the rear side of the product.
OCompletely remove dust or foreign substances on the housing, connection, and inspection parts when performing repairs.
– This can prevent fire hazards for tracking, short, etc.
OPlease tighten the service valve of the outdoor unit and the valve cap of the charging valve as securely as possible by using
a monkey spanner.
OCheck whether the parts are properly and securely assembled after performing repairs.
– These parts should be in the same condition as before the repair.
1-2 Precautions for the Static Electricity and PL
OPlease carefully handle the PCB power terminal during repair and measurement when it is turned on since it is vulnerable
to static electricity.
– Please wear insulation gloves before performing PCB repair and measurement.
OCheck if the place of installation is at least 2m away from electronic appliances such as TV, video players, and stereos.
– This can cause irregular noise or degrade the picture quality.
OPlease make sure the customer does not directly repair the product.
– Arbitrary dismantling may result in electric shock or fire.
1-3 Precautions for the Safety
ODo not pull or touch the power plug or the subsidiary power switch with wet hands.
– This may result in electric shock or fire.
OIf the power line or the power plug is damaged, then it must be changed since this is a hazard.
ODo not bend the wire too much or position it so that it can be damaged by a heavy object on top.
– This may result in electric shock or fire.
OThe use of multiple electric outlets should be prohibited.
– This may result in electric shock or fire.
OGround the connection if it is necessary.
– The connection must be grounded if there is any risk of electrical short due to water or moisture.
OUnplug the power or turn off the subsidiary power switch when changing or repairing electrical parts.
– Doing so will prevent electric shock.
OExplain to workers that the battery for the remote control needs to be separated for storage purposes when the product
will not be used for a long time.
– This can cause a problem for the remote control since battery fluid may trickle out.
2Samsung Electronics
1-4 Precautions for Handling Refrigerant for Air Conditioner
Environmental Cautions: Air pollution due to gas release
OSafety Cautions
If liquid gas is released, then body parts that come into contact with it may experience frostbite/blister/numbness.
If a large amount of gas is released, then suffocation may occur due to lack of oxygen. If the released gas is heated, then noxious
gas may be produced by combustion.
OContainer Handling Cautions
Do not subject container to physical shock or overheating. (Flowage is possible while moving within the regulated pressure.)
1-5 Precautions for Welding the Air Conditioner Pipe
ODangerous or flammable objects around the pipe must be removed before the welding.
OIf the refrigerant is kept inside the product or the pipe, then remove the refrigerant prior to welding.
If the welding is carried out while the refrigerant is kept inside, the welding cannot be properly performed. This will also produce
noxious gas that is a health hazard. This leakage will also explode with the refrigerant and oil due to an increase in the refrigerant
pressure, posing a danger to workers.
OPlease remove the oxide produced inside the pipe during the welding with nitrogen gas.
Using another gas may cause harm to the product or others.
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant
OPrecisely calculate the refrigerant by using a scale and S-net, and proceed with the test operation.
Excessive supplement can cause harm to the product since it can cause an inflow of the liquid refrigerant into the compressor.
ODo not heat the refrigerant container for a forced injection.
This may cause harm to the product or others since the refrigerant container may burst.
ODo not operate the product after removing the product safety pressure switch and sensor.
If the product is blocked inside, then this may cause harm to the product or others due to the excess pressure increase of the
refrigerant gas.
1-7 Other Precautions
OThere should be no leakage of the pipes after installation. When withdrawing the refrigerant, the compressor should be
stopped before removing the connecting pipe.
If the compressor is operating while the refrigerant pipe is not correctly connected and the service valve is opened, then
air and other substances can enter the pipe. The interior of the refrigerant cycle may then build up excessive high pressure
resulting in explosion and damage.
Samsung Electronics 3
2. Product Specifications
2-1 Product Specifacations
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM017HN1DEH/EU AM022HN1DEH/EU AM022FN1DEH/EU AM028FN1DEH/EU AM036FN1DEH/6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP/HR HP/HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 1.7 2.2 2.2 2.8 3.6
Btu/h 5800 7500 7,500 9,500 12,200
Heating*
3)
kW 1.9 2.5 2.6 3.2 4.0
Btu/h 6400 8500 8,500 10,900 13,600
Condensate
(with High fan speed) Liters/h 1.6 1.6 1.12 1.44 1.6
Power Input W 24 25 50*
5)
45*
5)
50*
5)
Running Current A 0.14 0.15 0.20*
5)
0.23*
5)
0.25*
5)
Sound Level Sound Pressure*
4)
dB(A) 33 34 34 37 40
Fan
Type - Crossflow fan Crossflow fan Crossflow fan Crossflow fan Crossflow fan
Motor
Model - SIC-41CVJ-F127-2 SIC-41CVJ-F127-2 Y4S476B041L Y4S476B041L Y4S476B041L
Type - BLDC BLDC Feedback SSR Feedback SSR Feedback SSR
Output W 27W 27W - - -
Air Flow Rate m
3
/min 4.8/4.3/4.1 5.1/4.6/4.3 6/5/4 7/6/5 8/7/6
Refrigerant Type - R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7 12.7
Drain (Quick Lock) ø, mm VP20 VP20 VP20 (OD 25, ID 20) VP20 (OD 25, ID 20) VP20 (OD 25, ID 20)
Weight Net Weight kg 8 8 10.5 10.5 10.5
Shipping Weight kg 10.8 10.8 13.0 13.0 13.0
Dimensions Net Dimensions (W x H x D) mm 740x135x360 740x135x360 970x135x410 970x135x410 970x135x410
Shipping Dimensions (W x H x D) mm 895x223x435 895x223x435 1,164x212x478 1,164x212x478 1,164x212x478
Panel Size
Model - PC1MWSKAN PC1MWSKAN PC1NUSMAN PC1NUSMAN PC1NUSMAN
Net Weight kg 2.6 2.6 3.0 3.0 3.0
Shipping Weight kg 4.2 4.2 5.0 5.0 5.0
Net Dimensions (W x H x D) mm 900x25x420 900x25x420 1,180x25x460 1,180x25x460 1,180x25x460
Shipping Dimensions (W x H x D) mm 958x112x482 958x112x482 1,259x144x539 1,259x144x539 1,259x144x539
Functions
Auto Restart - O O O O O
Auto Swing - O O O O O
Group/Individual Control - O O O O O
External Contact Control - O O O O O
Trouble Shooting by LED - O O O O O
Standard
Accessories
Installation Manual - O O O O O
Operation Manual - X XXXX
Pattern Sheet for Installation - O O O O O
Flexible Drain Hose - O O O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump
(Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact
Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
2-1-1 Indoor Unit
ŶSlim 1way cassette type
Product Specifications
4Samsung Electronics
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM0566N1DEH6AM0716N1DEH6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50
Mode*1) HP/HR HP/HR
Performance Capacity
Cooling*2) kW 5.6 7.1
Btu/h 19,100 24,200
Heating*3) kW 6.3 8.0
Btu/h 21,500 27,300
Condensate (with High fan speed) Liters/h - -
Power Input W 55.0 80.0
Running Current A 0.28 0.40
Sound Level Sound Pressure *4) dB(A) 36 39
Fan
Type - Crossflow Fan Crossflow Fan
Motor
Model - SIC-55CVL-F158-3
FDA6531SSH
SIC-55CVL-F158-3
FDA6531SSH
Type - BLDC BLDC
Output W 54W 54W
Airflow Rate Cooling (High) m3/min 16.00/14.00/12.50 17.00/15.50/14.00
Heating (High) m3/min 16.00/14.00/12.50 17.00/15.50/14.00
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 9.52
Gas (Flare) ø, mm 12.7 15.88
Drain (Quick Lock) ø, mm VP20 (OD 26,ID 20) VP20 (OD 26,ID 20)
Weight Net Weight kg 14 14
Shipping Weight kg 18 18
Dimensions Net Dimensions (W x H x D) mm 1200 x 138 x 450 1200 x 138 x 450
Shipping Dimensions (W x H x D) mm 1435 x 224 x 525 1435 x 224 x 525
Panel Size
Model - PC1BWSMAN PC1BWSMAN
Net Weight kg 6.3 6.3
Shipping Weight kg 8.3 8.3
Net Dimensions (W x H x D) mm 1410 x 23 x 500 1410 x 23 x 500
Shipping Dimensions (W x H x D) mm 1474 x 122 x 566 1474 x 122 x 566
Functions
Auto Restart - O O
Auto Swing - O O
Group/Individual Control - O O
External Contact Control - O O
Trouble Shooting by LED - O O
Standard
Accessories
Installation Manual - O O
Operation Manual - X X
Pattern Sheet for Installation - O O
Flexible Drain Hose - O O
Filter / Safety Grille - Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Wired Remote Controller - MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14
Indoor Unit (cont.)
ŶSlim 1way cassette type (cont.)
Product Specifications
Samsung Electronics 5
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM017NN1PEH* AM022NN1PEH* AM022NN1DEH* AM028NN1DEH* AM036NN1DEH*
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1)
HP/HR HP/HR HP/HR HP/HR HP/HR
Performance
Capacity
Cooling*2) kW
1.70 2.20 2.20 2.80 3.60
Btu/h
5,800 7,500 7,500 9,600 12,300
Heating*3) kW
1.90 2.50 2.50 3.20 4.00
Btu/h
6,500 8,500 8,500 10,900 13,600
Condensate
(with High fan speed) Liters/h
-----
Power Input W
24.0 25.0 40.0 45.0 50.0
Running Current A
0.14 0.15 0.20 0.23 0.25
Sound Level Sound Pressure *4) dB(A)
46 47 47 50 55
Fan
Type -
Cross flow fan Cross flow fan Cross flow fan Cross flow fan Y4S476B041L
Motor
Model -
SIC-41CVJ-F127-2 SIC-41CVJ-F127-2 Y4S476B041L Y4S476B041L Y4S476B041L
Type -
BLDC BLDC Feedback SSR Feedback SSR Feedback SSR
Output W
27 x 1 27 x 1 17 x 1 17 x 1 17 x 1
Air Flow Rate m/min
4.80/4.30/4.10 5.10/4.60/4.30 6.00/5.00/4.00 7.00/6.00/5.00 8.00/7.00/6.00
Refrigerant Type -
R410A R410A R410A R410A R410A
Control Method -
EEV EEV EEV EEV EEV
Temperature Control -
Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices -
Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm
12.70 12.70 12.70 12.70 12.70
Drain (Quick Lock) ø, mm
VP20 (OD 26,ID 20) VP20 (OD 26,ID 20) VP20 (OD 26,ID 20) VP20 (OD 26,ID 20) VP20 (OD 26,ID 20)
Weight Net Weight kg
8.0 8.0 10.0 10.0 10.0
Shipping Weight kg
10.5 10.5 12.8 12.8 12.8
Dimensions Net Dimensions (W x H x D) mm
740 x 135 x 360 740 x 135 x 360 970 x 135 x 410 970 x 135 x 410 970 x 135 x 410
Shipping Dimensions (W x H x D) mm
895 x 223 x 435 895 x 223 x 435 1,173 x 231 x 487 1,173 x 231 x 487 1,173 x 231 x 487
Panel Size
Model -
PC1MWFMAN PC1MWFMAN PC1NWFMAN PC1NWFMAN PC1NWFMAN
Net Weight kg
2.6 2.6 4.3 4.3 4.3
Shipping Weight kg
3.8 3.8 6.3 6.3 6.3
Net Dimensions (W x H x D) mm
960 x 35 x 420 960 x 35 x 420 1198 x 35 x 500 1198 x 35 x 500 1198 x 35 x 500
Shipping Dimensions (W x H x D) mm
1003 X 482 X 112 1003 X 482 X 112 1262 X 568 X 124 1262 X 568 X 124 1262 X 568 X 124
Functions
Auto Restart -
OOOOO
Auto Swing -
OOOOO
Group/Individual Control -
OOOOO
External Contact Control -
OOOOO
Trouble Shooting by LED -
OOOOO
Standard
Accessories
Installation Manual -
OOOOO
Operation Manual -
XXXXX
Pattern Sheet for Installation -
OOOOO
Flexible Drain Hose -
OOOOO
Filter / Safety Grille -
Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump
(Pumping speed, lift) /h,mm
24/750 24/750 24/750 24/750 24/750
Optional
Accessories
Wireless Remote Controller -
AR-EH03E AR-EH03E AR-EH03E AR-EH03E AR-EH03E
Wired Remote Controller -
MWR-WE13N MWR-WE13N MWR-WE13N MWR-WE13N MWR-WE13N
External Contact Interface Module -
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Indoor Unit (cont.)
ŶWind-free 1way cassette type (cont.)
Product Specifications
6Samsung Electronics
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM056NN1DEH* AM071NN1DEH*
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50
Mode*1)
HP/HR HP/HR
Performance
Capacity
Cooling*2) kW
5.60 7.10
Btu/h
19,100 24,200
Heating*3) kW
6.30 8.00
Btu/h
21,500 27,300
Condensate
(with High fan speed) Liters/h
--
Power Input W
55.00 80.00
Running Current A
0.28 0.40
Sound Level Sound Pressure *4) dB(A)
59 60
Fan
Type -
Cross flow fan Cross flow fan
Motor
Model -
SIC-55CVL-F158-3 SIC-55CVL-F158-3
Type -
BLDC BLDC
Output W
54 x 1 54 x 1
Air Flow Rate m/min
16.00/14.00/12.50 17.00/15.50/14.00
Refrigerant Type -
R410A R410A
Control Method -
EEV EEV
Temperature Control -
Micom & Thermistors Micom & Thermistors
Safety Devices -
Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm
6.35 9.52
Gas (Flare) ø, mm
12.70 15.88
Drain (Quick Lock) ø, mm
VP20 (OD 26,ID 20) VP20 (OD 26,ID 20)
Weight Net Weight kg
13.5 13.5
Shipping Weight kg
17.3 17.3
Dimensions Net Dimensions (W x H x D) mm
1200 x 138 x 450 1200 x 138 x 450
Shipping Dimensions (W x H x D) mm
1,435 x 224 x 525 1,435 x 224 x 525
Panel Size
Model -
PC1BWFCAN PC1BWFCAN
Net Weight kg
5.0 5.0
Shipping Weight kg
7.0 7.0
Net Dimensions (W x H x D) mm
1,410 x 35 x 500 1,410 x 35 x 500
Shipping Dimensions (W x H x D) mm
1,473 X 568 X 124 1,473 X 568 X 124
Functions
Auto Restart -
OO
Auto Swing -
OO
Group/Individual Control -
OO
External Contact Control -
OO
Trouble Shooting by LED -
OO
Standard
Accessories
Installation Manual -
OO
Operation Manual -
XX
Pattern Sheet for Installation -
OO
Flexible Drain Hose -
OO
Filter / Safety Grille -
Filter (Washable) Filter (Washable)
Drain Pump
(Pumping speed, lift) /h,mm
24/750 24/750
Optional
Accessories
Wireless Remote Controller -
AR-EH03E AR-EH03E
Wired Remote Controller -
MWR-WE13N MWR-WE13N
External Contact Interface Module -
MIM-B14 MIM-B14
Indoor Unit (cont.)
ŶWind-free 1way cassette type (cont.)
Product Specifications
Samsung Electronics 7
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM056FN2DEH/6AM071FN2DEH/6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR
Performance Capacity
Cooling*2) kW 5.6 7.1
Btu/h 19,100 24,200
Heating*3) kW 6.3 8.0
Btu/h 21,400 27,200
Condensate (with High fan speed) Liters/h 2.87 3.19
Power Input W 70 75
Running Current A 0.38 0.40
Sound Level Sound Pressure *4) dB(A) 45 46
Fan
Type - Crossflow fan Crossflow fan
Motor
Model - PFS027WTVB PFS027WTVB
Type - Feedback SSR Feedback SSR
Output W 14.0 x 2 14.0 x 2
Airflow Rate H/M/L (UL) CMM 14.00/13.00/12.00 15.00/14.00/13.00
l/s 233.33/216.67/200.00 250.00/233.33/216.67
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 9.52
Gas (Flare) ø, mm 12.70 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32, ID 25) VP25 (OD 32, ID 25)
Weight Net Weight kg 21.0 22.0
Shipping Weight kg 25.0 26.0
Dimensions Net Dimensions (W x H x D) mm 890x230x575 890x230x575
Shipping Dimensions (W x H x D) mm 1,077x299x642 1,077x299x642
Panel Size
Model - PC2NUSMEN PC2NUSMEN
Net Weight kg 4.0 4.0
Shipping Weight kg 8.0 8.0
Net Dimensions (W x H x D) mm 1,030x25x650 1,030x25x650
Shipping Dimensions (W x H x D) mm 1,103x151x727 1,103x151x727
Functions
Auto Restart - OO
Auto Swing - OO
Group/Individual Control - OO
External Contact Control - OO
Trouble Shooting by LED - OO
Standard
Accessories
Installation Manual - OO
Operation Manual - XX
Pattern Sheet for Installation - OO
Flexible Drain Hose - OO
Filter / Safety Grille - Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Wired Remote
Controller
-MWR-WE10N MWR-WE10N
-MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14
Indoor Unit (cont.)
Ŷ2 way cassette type
Product Specifications
8Samsung Electronics
Model AM045FN4DEH/6AM056FN4DEH/6AM071FN4DEH/6AM090FN4DEH/6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 4.5 5.6 7.1 9.0
Btu/h 15,300 19,100 24,200 30,700
Heating*3) kW 5.0 6.3 8.0 10.0
Btu/h 17,000 21,400 27,200 34,100
Condensate (with High fan speed) Liters/h 2.23 2.71 3.51 4.46
Power Input W 32 32 45 62
Running Current A 0.22 0.22 0.31 0.43
Sound Level
Sound Pressure (Cooling/Heating)*4)
dB(A) 42 / 44 42 /44 44 / 44 47 / 47
Fan
Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model - FMC6531SSH FMC6531SSH FMC6531SSH FMC6531SSH
Type - BLDC BLDC BLDC BLDC
Output W *5) *5) *5) *5)
Airflow Rate H/M/L (UL) CMM 14.50/13.50/12.50 15.00/14.00/13.00 17.00/15.50/14.50 19.50/18.00/16.50
l/s 241.67/225.00/208.33 250.00/233.33/216.67 283.33/258.33/241.67 325.00/300.00/275.00
Refrigerant Type - R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 9.52 9.52
Gas (Flare) ø, mm 12.7 12.7 15.88 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 15.5 15.5 15.5 15.5
Shipping Weight kg 19.5 19.5 19.5 19.5
Dimensions Net Dimensions (W x H x D) mm 840x204x840 840x204x840 840x204x840 840x204x840
Shipping Dimensions (W x H x D) mm 898x275x898 898x275x898 898x275x898 898x275x898
Panel Size
Model - PC4NUSKAN PC4NUSKAN PC4NUSKAN PC4NUSKAN
Net Weight kg 5.8 5.8 5.8 5.8
Shipping Weight kg 8.4 8.4 8.4 8.4
Net Dimensions (W x H x D) mm 950 x 45 x 950 950 x 45 x 950 950 x 45 x 950 950 x 45 x 950
Shipping Dimensions (W x H x D) mm 1005 x 100 x 1005 1005 x 100 x 1005 1005 x 100 x 1005 1005 x 100 x 1005
Functions
Auto Restart - O O O O
Auto Swing - O O O O
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - O O O O
Standard
Accessories
Installation Manual - O O O O
Operation Manual - X X X X
Pattern Sheet for Installation - O O O O
Flexible Drain Hose - O OOO
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
Indoor Unit (cont.)
Ŷ4 way cassette
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Product Specifications
Samsung Electronics 9
Model AM112FN4DEH/6AM128FN4DEH/6AM140FN4DEH/6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 11.2 12.8 14.0
Btu/h 38,200 43,600 47,700
Heating*3) kW 12.5 13.8 16.0
Btu/h 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h 5.58 6.22 7.18
Power Input W 78 73 89
Running Current A 0.55 0.51 0.62
Sound Level
Sound Pressure (Cooling / Heating)*4)
dB(A) 49 / 49 50 / 50 53 / 53
Fan
Type - Turbo Fan Turbo Fan Turbo Fan
Motor
Model - DAI33585ZLB DAI33585ZLB DAI33585ZLB
Type - BLDC BLDC BLDC
Output W *5) *5) *5)
Airflow Rate H/M/L (UL) CMM 26.00/24.00/22.00 28.00/26.00/23.00 30.00/28.00/26.00
l/s 433.33/400.00/366.67 466.67/433.33/383.33 500.00/466.67/433.33
Refrigerant Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52 9.52
Gas (Flare) ø, mm 15.88 15.88 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 17.0 19.0 19.0
Shipping Weight kg 20.0 22.5 22.5
Dimensions Net Dimensions (W x H x D) mm 840x246x840 840x288x840 840x288x840
Shipping Dimensions (W x H x D) mm 898x316x898 898x357x898 898x357x898
Panel Size
Model - PC4NUSKAN PC4NUSKAN PC4NUSKAN
Net Weight kg 5.8 5.8 5.8
Shipping Weight kg 8.4 8.4 8.4
Net Dimensions (W x H x D) mm 950 x 45 x 950 950 x 45 x 950 950 x 45 x 950
Shipping Dimensions (W x H x D) mm 1005 x 100 x 1005 1005 x 100 x 1005 1005 x 100 x 1005
Functions
Auto Restart - O O O
Auto Swing - O O O
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - O O O
Standard
Accessories
Installation Manual - O O O
Operation Manual - X X X
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - Filter / Safety Grille Filter / Safety Grille Filter / Safety Grille
Drain Pump (Pumping speed, lift) /h,mm 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - AR-DH00 AR-DH00 AR-DH00
Wired Remote
Controller
- MWR-WE10N MWR-WE10N MWR-WE10N
- MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
Indoor Unit (cont.)
Ŷ4 way cassette (cont.)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Product Specifications
10 Samsung Electronics
Model AM015HNNDEH/EU AM022FNNDEH6AM028FNNDEH6AM036FNNDEH6
Power Supply ø/V/Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode*1) HP/HR HP/HR HP/HR HP/HR
Performance Capacity
(Nominal)
Cooling*2) kW 1.5 2.2 2.8 3.6
Btu/h 5,100 7,500 9,600 12,300
Heating*3) kW 2.2 2.5 3.2 4
Btu/h 7,500 8,500 10,900 13,600
Power
Power Input
(Nominal)
Cooling*2)
W18 18 18 20
Heating*3) 18 18 18 20
Current Input
(Nominal)
Cooling*2)
A0.17 0.17 0.17 0.19
Heating*3) 0.17 0.17 0.17 0.19
Fan
Motor Type - Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Output W 65 x 1 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L (UL) CMM 8.50/7.20/6.50 9.80/8.60/7.40 10.60/9.40/8.20 11.40/10.20/9.00
CFM 300/260/230 350/300/260 370/330/290 400/360/320
External
Pressure Min / Std / Max mmAq----
Pa----
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35
ø, inch 1/4 1/4 1/4 1/4
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7
ø, inch 1/2 1/2 1/2 1/2
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Field
Wiring
Power
Source Wire
Below 20m /
over 20m mm² 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Transmission Cable mm² 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Refrigerant Type - R410A R410A R410A R410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED EEV INCLUDED
Sound Sound
Pressure
COOLING /
HEATING (HIGH) dBA 38/40 38/40 40/40 42/40
Dimensions
Net Weight kg 12.0 12.0 12.0 12.0
Shipping Weight kg 14.0 14.0 14.0 14.0
Net Dimensions (W x H x D) mm 575 x 250 x 575 575 x 250 x 575 75 x 250 x 575 575 x 250 x 575
Shipping Dimensions
(W x H x D) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 623 623 x 298 x 653
Panel Size
Panel model - PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN
Panel Net Weight - 2.7 2.7 2.7 2.7
Shipping Weight - 4.2 4.2 4.2 4.2
Net Dimensions (W×H×D) - 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670
Shipping Dimensions
(W×H×D) - 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724
Additional
Accessories
Drain pump
Drain pump - / Model Built-in Built-in Built-in Built-in
Max. lifting
Height /
Displacement
mm/liter/
h750/24 750/24 750/24 750/24
Air Filter - Long life filter Long life filter Long life filter Long life filter
Indoor Unit (cont.)
ŶGlobal 4Way Cassette(600x600)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Product Specifications
Samsung Electronics 11
Indoor Unit (cont.)
Ŷ
Global 4Way Cassette(600x600) (cont.)
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AM045FNNDEH6AM056FNNDEH6AM060FNNDEH6
Power Supply ø/V/Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode*1) -HP/HR HP/HR HP/HR
Performance Capacity
(Nominal)
Cooling*2) kW 4.50 5.60 6.00
Btu/h 15,400 19,100 20,500
Heating*3) kW 5.00 6.30 6.80
Btu/h 17,100 21,500 23,200
Power
Power Input
(Nominal)
Cooling*2)
W23.00 28.00 31.00
Heating*3) 23.00 28.00 31.00
Current Input
(Nominal)
Cooling*2)
A0.22 0.27 0.30
Heating*3) 0.22 0.27 0.30
Fan
Motor Type - Turbo Fan Turbo Fan Turbo Fan
Output W 65 x 1 65 x 1 65 x 1
Air Flow Rate H/M/L (UL) CMM 12.20/11.00/9.80 13.40/11.80/10.20 14.20/12.60/11.00
CFM 430/390/350 470/420/360 500/440/390
External
Pressure Min / Std / Max mmAq - - -
Pa - - -
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
ø, inch 1/4 1/4 1/4
Gas (Flare) ø, mm 12.7 12.7 12.7
ø, inch 1/2 1/2 1/2
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Field
Wiring
Power Source Wire mm² 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
Transmission Cable mm² 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Refrigerant Type - R410A R410A R410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED
Sound Sound
Pressure
COOLING /
HEATING (HIGH) dBA 43/43 46/47 47/47
Dimensions
Net Weight kg 12 12 12
Shipping Weight kg 14 14 14
Net Dimensions (W x H x D) mm 575 x 250 x 575 575 x 250 x 575 575 x 250 x 575
Shipping Dimensions (W x H x D) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 653
Panel Size
Panel model - PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN PC4SUSMAN/PC4SUSMEN
Panel Net Weight kg 2.7 2.7 2.7
Shipping Weight kg 4.2 4.2 4.2
Net Dimensions (W×H×D) mm 670 x 45 x 670 670 x 45 x 670 670 x 45 x 670
Shipping Dimensions
(W×H×D) mm 714 x 106 x 724 714 x 106 x 724 714 x 106 x 724
Additional
Accessories
Drain pump
Drain pump - / Model Built-in Built-in Built-in
Max. lifting
Height /
Displacement
mm/liter/h 750/24 750/24 750/24
Air Filter - Long life filter Long life filter Long life filter
Product Specifications
12 Samsung Electronics
Model AM028HNNDEH/TL AM036HNNDEH/TL AM045HNNDEH/TL
Power Supply 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Mode*1) HP/HR HP/HR HP/HR
Performance Capacity
(Nominal)
Cooling*2) kW 2.8 3.6 4.5
Btu/h 9,600 12,300 15,400
Heating*3) kW 3.2 4 5
Btu/h 10,900 13,600 17,100
Power
Power Input
(Nominal)
Cooling*2) W 120 120 120
Heating*3) 120 120 120
Current Input
(Nominal)
Cooling*2) A 0.87 0.87 0.89
Heating*3) 0.87 0.87 0.89
Fan
Motor Type - Turbo Fan Turbo Fan Turbo Fan
Output W 40 x 1 40 x 1 40 x 1
Air Flow Rate H/M/L (UL) CMM 11.8/10.8/9.8 12/11/10 13/12/11
External
Pressure Min / Std / Max mmAq ---
Pa ---
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
ø, inch 1/4" 1/4" 1/4"
Gas (Flare) ø, mm 12.70 12.70 12.70
ø, inch 1/2" 1/2" 1/2"
Drain (Quick Lock) ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Field
Wiring
Power Source Wire mm² 2.5 2.5 2.5
Transmission Cable mm² VCTF 0.75 ~ 1.5 VCTF 0.75 ~ 1.5 VCTF 0.75 ~ 1.5
Refrigerant Type - R410A R410A R410A
Control Method - EEV INCLUDED EEV INCLUDED EEV INCLUDED
Sound Sound Pressure H/M/L dBA 40 / 36 / 34 40 / 36 / 34 43 / 41 / 38
Dimensions
Net Weight ΜΘ 16.0 16.0 16.0
Shipping Weight ΜΘ 18.4 18.4 18.4
Net Dimensions (W x H x D) ΞΞ 575 x 260 x 575 575 x 260 x 575 575 x 260 x 575
Shipping Dimensions (W x H x D) ΞΞ 669 x 339 x 644 669 x 339 x 644 669 x 339 x 644
Panel Size
Panel model - PC4SUSE1N PC4SUSE1N PC4SUSE1N
Panel Net Weight kg 3.0 3.0 3.0
Shipping Weight kg 5.0 5.0 5.0
Net Dimensions (W×H×D) mm 670 x 35 x 670 670 x 35 x 670 670 x 35 x 670
Shipping Dimensions (W×H×D) mm 723 x 117 x 723 723 x 117 x 723 723 x 117 x 723
Additional
Accessories"
Drain pump
Drain pump - / Model Built-in Built-in Built-in
Max. lifting
Height /
Displacement
mm/liter/
h750/24 750/24 750/24
Air Filter - Pre filter Pre filter Pre filter
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Indoor Unit (cont.)
Ŷ4Way Cassette(600x600)
Product Specifications
Samsung Electronics 14
Product Specifications
13 Samsung Electronics
Indoor Unit (cont.)
ŶSlim duct
Model
AM017FNLDEH/EU AM022FNLDEH6AM028FNLDEH6AM036FNLDEH6AM045FNLDEH6AM056FNLDEH6
AM071FNLDEH6AM090FNLDEH/EU AM112FNLDEH/EU AM128FNLDEH/EU AM140FNLDEH/EU
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1)
HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR
HP / HR HP / HR HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW
1.7 2.2 2.8 3.6 4.5 5.6
7.1 9.0 11.2 12.8 14.0
Btu/h
4,600 7,500 9,500 12,200 15,300 19,100
24,200 30,700 38,200 43,600 47,700
Heating*3) kW
1.9 2.5 3.2 4.0 5.0 6.3
8.0 10.0 12.5 13.8 16.0
Btu/h
5,200 8,500 10,900 13,600 17,000 21,400
27,200 34,100 42,600 47,000 54,500
Condensate (with High fan speed) Liters/h
0.80 1.12 1.28 2.07 2.39
2.87 3.83 4.63 4.95 5.26
Power Input W
55 55 60 65 90 95
120 170 170 200 220
Running Current A
0.3 0.3 0.32 0.33 0.52 0.53
0.6 0.96 0.96 1.28 1.43
Sound Level Sound Pressure *4) dB(A)
37 37 37 37 40 43
47 / 47 43 / 44 43 / 44 45 / 46 45 / 46
Fan
Type -
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model -
YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK110-50-4SM YSK110-50-4SM
YSK140-60-4B DL-12840SSBC DL-12840SSBC DL-12840SSBC DL-12840SSBC
Type -
Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Non Feedback SSR BLDC BLDC BLDC BLDC
Output W
*5) *5) *5) *5) *5) *5)
*5) *5) *5) *5) *5)
Airflow Rate
Cooling (High) m3/min
5.0 4 7.5 7.5 11.0 12.0
16.5 29.0 31.2 34.0 36.0
Heating (High) m3/min
5.5 8.2 9.0 9.0 14.0 15.0
20.0 34.0 34.0 36.0 38.0
External Static Pressure
Standard
(Min.~Max)
mmH2O
1(0~3) 1 (0~3) 1 (0~3) 1 (0~3) 2 (0~4) 2 (0~4)
2 (0~4) 3 (0~6) 3 (0~6) 3 (0~6) 3 (0~6)
Refrigerant Type -
R410A R410A R410A R410A R410A R410A
R410A R410A R410A R410A R410A
Control Method -
EEV EEV EEV EEV EEV EEV
EEV EEV EEV EEV EEV
Temperature Control -
Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors Micom & Thermistors
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices -
Fuse Fuse Fuse Fuse Fuse Fuse
Fuse Fuse Fuse Fuse Fuse
Piping Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 6.35 6.35
9.52 9.52 9.52 9.52 9.52
Gas (Flare) ø, mm
12.70 12.7 12.7 12.7 12.7 12.7
15.88 15.88 15.88 15.88 15.88
Drain ø, mm
VP25 (OD 32,ID 25) VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg
19.0 19.0 19.0 19.5 23.5 23.5
30.0 44.0 44.0 46.0 46.0
Shipping Weight kg
23.0 23.0 23.0 23.5 28.0 28.0
35.0 52.0 52.0 54.0 54.0
Dimensions Net Dimensions (W x H x D) mm
700×199×600 700×199×600 700×199×600 700×199×600 900×199×600 900×199×600
1,100x199x600 1,300x295x690 1,300x295x690 1,300x295x690 1,300x295x690
Shipping Dimensions (W x H x D) mm
950x270x710 950x270x710 950x270x710 950x270x710 1150×280×710 1150×280×710
1350x280x710 1575x370x835 1575x370x835 1575x370x835 1575x370x835
Functions
Auto Restart -
OOOOOO
OOOOO
Auto Swing -
XXXXXX
XXXXX
Group/Individual Control -
OOOOOO
OOOOO
External Contact Control -
OOOOOO
OOOOO
Trouble Shooting by LED -
XXXXXX
XXXXX
Standard Accessories
Installation Manual -
OOOOOO
OOOOO
Operation Manual -
OOOOOO
OOOOO
Pattern Sheet for Installation -
XXXXXX
XXXXX
Flexible Drain Hose -
OOOOOO
OOOOO
Filter / Safety Grille -
Filter(Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) -
MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Optional Accessories
Wireless Remote Controller -
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver Kits
Receiver
-
MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
ReceiverWire
-
MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller Simplified -
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump
MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
MDP-E075SEE3D MDP-E075SEE3D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Product Specifications
15 Samsung Electronics
Indoor Unit (cont.)
ŶSlim Home Duct
Model AM017KNLDEH/EU AM022KNLDEH6AM028KNLDEH6AM036KNLDEH6
Power Supply ø, #, V, Hz 1,220~240,50 1,220~240,50 1,220~240,50 1,220~240,50
Mode -HP HP HP HP
Performance
Capacity
(Nominal)
Cooling 2) kW 1.7 2.2 2.8 3.6
Btu/h 4,600 7,500 9,500 12,200
Heating 2) kW 1.9 2.5 3.2 4.0
Btu/h 5,200 8,500 10,900 13,600
Condensate
(with high fan speed) Liter/h
Power Input W 28 30 34 40
Running Current A 0.23 0.25 0.28 0.33
Sound Level Sound Pressure *4) dB(A) 31 32 34 36
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model - DB31-00670A DB31-00670A DB31-00670A DB31-00670A
Type - BLDC Feedback BLDC Feedback BLDC Feedback BLDC Feedback
Output W 69 69 69 69
Airflow Rate Cooling (High) m3/min 4.8 5.4 6.4 7.3
Heating (High)
m3/min 6.75 7.35 8.5 9.75
Refrigerant Type - R410A R410A R410A R410A
Control Method - EDM EEV 2.4C Sanhua EDM EEV 2.4C Sanhua EDM EEV 2.4C Sanhua EDM EEV 2.4C Sanhua
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse:3.15A/1.6A Fuse:3.15A/1.6A Fuse:3.15A/1.6A Fuse:3.15A/1.6A
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7 12.7
Drain ø, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Weight Net Weight kg 15.3 15.3 15.3 15.7
Shipping Weight kg 18.2 18.2 18.2 18.6
Dimensions
Net Dimensions
(W x H x D) mm 700*199*440 700*199*440 700*199*440 700*199*440
Shipping Dimensions
(W x H x D) mm 949*280*544 949*280*544 949*280*544 949*280*544
Functions
Auto Restart - O O O O
Auto Swing - XXXX
Group/Individual Control - O O O O
External Contact Control - OOOO
Trouble Shooting by LED - X X X X
Standard
Accessories
Installation Manual - OOOO
Operation Manual - O O O O
Pattern Sheet for Installation - XXXX
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter(Washable) Filter(Washable) Filter(Washable) Filter(Washable)
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver - MRK-A10 MRK-A10 MRK-A10 MRK-A10
Receiver Wire
- MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller
Simplied
- MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
