VRF
Technical
Data Book
DVM S Water for Global
(R410A, 50/60Hz, HP/HR)
Model : Premium energy efficiency Type
Premium compact type
Samsung Electronics Co., LTD.
B2B PM / SE
Head Ofce (Suwon Korea) 129, Samsung-Ro, Yeongtong-Gu, Suwon City, Gyeonggi-Do, Korea 16677
Website : www.samsung.com, http://btsp.samsunggsbn.com Email : [email protected]om
Images and data in this book may subject to change without prior notice.

2
Version Modification Date Remark
Ver. 1.0 Release DVM S Water TDB '14. 06. 17
Ver. 1.1 Add Note information in Specification regarding EU F-Gas regulation. '15. 06. 17
Ver. 2.0 Update all contents '16. 09. 12
Ver. 2.1 Add tCO2e data (Specifications) ‘16. 12. 09
Ver. 3.0 Add New Model (30HP) & Premium compact type ’17. 02. 23
History
Ver. 3.1 Change the TDB Title to 'Global' from 'Europe' ’17. 07.03
Ver. 3.11 Modify the Accessory Compatibility table for MCU kit(P67) ’17. 09.13

3
Outdoor units
Nomenclature
(1) Classification
AM DVM
(2) Capacity
x 1/10 HP (3 digits)
(3) Version
F2013
H2014
J2015
K2016
(4) Product Type
XOutdoor Unit
NIndoor Unit
(5) Feature1
WDVM WATER
(6) Feature2
AStandard + General Temp.+ Module
(7) Rating Voltage
N3Ø, 380~415V, 50/60Hz
G3Ø, 380~415V, 50Hz
(8) Mode
RHeat Recovery
HHeat Pump
(1) Classification
AM DVM
(2) Capacity
x 1/10 HP (3 digits)
(3) Version
F2013
H2014
J2015
K2016
(4) Product Type
XOutdoor Unit
NIndoor Unit
(5) Feature1
WDVM WATER
(6) Feature2
AStandard + General Temp.+ Module
(7) Rating Voltage
N3Ø, 380~415V, 50/60Hz
G3Ø, 380~415V, 50Hz
(8) Mode
RHeat Recovery
HHeat Pump
Model name
RVX 100 HTTFEE/100
(1) (2) (3) (4) (5) (6) (7) (8)

4
Features & Benefits
More efficient, more eco-friendly
The DVM S WATER air conditioning system saves money and
the environment, while providing a powerful performance. Its
innovative Dual Inverter Compressor with a high efficiency Vapor
Injection System ensures powerful, rapid cooling and heating with
minimum energy consumption, so it’s very eco-friendly. A Plate
Heat Exchanger also improves the heat exchange efficiency and
ensures stable cooling and heating performances.
Flexible installation almost anywhere
The DVM S WATER air conditioning system can be installed almost
anywhere, regardless of its location or distance from the building.
It has a maximum piping length of up to 170 meters (558 feet)
between the outdoor and indoor units, while still ensuring complete
reliability. It can also reach up to a height of 50 meters (164 feet),
which is the equivalent of 10 stories.
Lower installation costs, great capacity
The DVM S WATER air conditioning system is much more
economical to install as it has a small footprint and lightweight
design, but a large 30 horsepower (HP) capacity. So instead of
installing two 10HP units you only need one 30HP Samsung unit –
using 56% less space and significantly reducing the costs of valves,
fittings and gauges. You can also combine up to three units to
create a total capacity of 90HP.
56 %
Saved
30HP
30HP
30HP
Independently cool and heat
With the DVM S WATER air conditioning system’s optional Mode
Control Unit (MCU) you can independently cool and heat different
spaces at the same time. Instead of just heating or cooling all spaces
at the same time, with the MCU each indoor unit can be operated
separately, so you can simultaneously heat some rooms or areas of
the building, while cooling others.

5
Contents
1. Line-up 6
2. Specication 10
3. Electric Characteristics 21
4. Dimensional Drawing 23
5. Center of Gravity 26
6. Electrical Wiring Diagram 28
7. Sound Level 30
8. Operating Range 34
9. Piping Diagram 37
10. Installation 40
11. Accessory 60

6
1) Outdoor units combination Table
Premium energy efficiency type
System Model Capacity (HP)
Capa.(HP) Model No. of Modules 810 12 20
8AM080FXWANR 1 1
10 AM100FXWANR 1 1
12 AM120FXWANR 1 1
16 AM160FXWANR2 2 2
18 AM180FXWANR2 2 1 1
20 AM200FXWANR 1 1
22 AM220FXWANR2 2 1 1
24 AM240FXWANR2 2 2
26 AM260FXWANR2 3 2 1
28 AM280FXWANR2 2 1 1
30 AM300FXWANR2 2 1 1
32 AM320FXWANR2 2 1 1
34 AM340FXWANR2 3 1 2
36 AM360FXWANR2 3 2 1
38 AM380FXWANR2 3 1 1 1
40 AM400FXWANR2 2 2
42 AM420FXWANR2 3 1 1 1
44 AM440FXWANR2 3 2 1
48 AM480FXWANR2 3 1 2
50 AM500FXWANR2 3 1 2
52 AM520FXWANR2 3 1 2
60 AM600FXWANR2 3 3
1. Line-up

7
1) Outdoor units combination Table
1. Line-up
Premium compact type
System Model Capacity (HP)
Capa.(HP) Model No. of Modules 810 12 20 30
30 AM300KXWANR 1 1
38 AM380KXWANR1 2 1 1
40 AM400KXWANR1 2 1 1
42 AM420KXWANR1 2 1 1
46 AM460KXWANR1 3 2 1
48 AM480KXWANR1 3 1 1 1
50 AM500KXWANR1 2 1 1
52 AM520KXWANR1 3 1 1 1
54 AM540KXWANR1 3 2 1
58 AM580KXWANR1 3 1 1 1
60 AM600KXWANR1 2 2
62 AM620KXWANR1 3 1 1 1
68 AM680KXWANR1 3 1 2
70 AM700KXWANR1 3 1 2
80 AM800KXWANR1 3 1 2
90 AM900KXWANR1 3 3
NOTE
• Make sure to use an indoor unit that is compatible with DVM S WATER-GEO.
• Indoor units can be connected within the range indicated in following table.
• If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating
capacityof the indoor unit may decrease.
• Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × ∑(Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × ∑(Outdoor unit capacity)
• You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is
set to 64 since outdoor unit only support up to 64 communication address. Indoor unit address can be assigned
from 0~63. If the indoor unit address was assigned from 64~79, E201 error will occur.
• Minimum capacity of the indoor unit is 1.7 kW.
• Installation combination must be complied when composing outdoor unit combination.
• Sum of total amout of additional refrigerant and the basic amount of refrigerant should not exceed 100kg (220lb).
If the refrigerant exceeds 100kg (220lb), separate the module so that the weight of the refrigerant doesn't exceed
100kg.
2) External appearance (outdoor unit)
Capacity (HP) 810 12 20 30
Type HR / HP
Model

8
3) Indoor units
1. Line-up
Model Capacity (kW)
1.7 2.2 2.8 3.6 4.5 5.6 6.0 7.1 9.0
Slim 1way cassette
(JSF)
2way cassette
Global 4way cassette
4way CST
(600 X 600)
360 CST
Floor Standing Unit
Slim duct
MSP duct
HSP duct
Ceiling
Console
Neo forte
Neo forte (with EEV)
Hydro unit / HE
Hydro unit / HT
ERV plus

9
3) Indoor units
1. Line-up
Model Capacity (kW)
11.2 12.8 14.0 22.0 28.0 44.8 500CMH 1000CMH
Slim 1way cassette(JSF)
2way cassette
Global 4way cassette
4way CST (600 X 600)
360 CST
Floor Standing Unit
Slim duct
MSP duct
HSP duct
Ceiling
Console
Neo forte
Neo forte (with EEV)
Hydro unit / HE
Hydro unit / HT
ERV plus

10
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM080FXWANR AM100FXWANR AM120FXWANR AM160FXWANR2
Outdoor unit module 1 AM080FXWANR AM100FXWANR AM120FXWANR AM080FXWANR
Outdoor unit module 2 AM080FXWANR
Outdoor unit module 3
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 810 12 16
Ton Ton 6.37 7.96 9.55 12.74
Capacity
(Nominal)
Cooling kW 22.4 28.0 33.6 44.8
Btu/h 76,400 95,500 114,600 152,900
Heating
2)*
kW 25.2 31.5 37.8 50.4
Btu/h 86,000 107,500 129,000 172,000
Heating
4)*
kW 21.64 25.75 31.1 -
Btu/h 73,700 88,000 106,500 -
Maximum
number of
connectable
indoor units
ea 14 18 22 29
Total capacity of
the connected
Indoor Units 3)
Min. kW 11.2 14.0 16.8 22.4
Max. kW 29.1 36.4 43.7 58.2
Power
Power Input
(Nominal)
Cooling
1)*
kW
3.84 5.05 6.46 7.68
Heating
2)*
4.12 5.25 6.51 8.24
Heating
4)*
4.65 5.70 7.05 -
Current Input
(Nominal)
Cooling
1)*
A6.2 8.1 10.3 12.4
Heating
2)*
6.6 8.4 10.4 13.2
Current
Minimum Ssc value MVA 3.9 3.9 4.8 7.8
MCA A16.1 16.1 20.0 31.8
MFA A20.0 20.0 25.0 40.0
COP
Nominal Cooling
1)*
W/W 5.83 5.54 5.20 5.83
Nominal Heating
2)*
W/W 6.12 6.00 5.81 6.12
Nominal Heating
4)*
W/W 4.65 4.52 4.41 -
Casing Material Cabinet -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 1 (4.96) x 1 (6.13) x 1 (4.96) x 2
Model Name -DS-GB052FAVBSG x 1 DS-GB052FAVBSG x 1 DS-GB066FAVBSG x 1 DS-GB052FAVBSG x 2
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 3.9 3.9 3.9 3.9 x 2
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 PT 1-1/4 PT 1-1/4 PT 1-1/4 x 2
Pressure Drop kPa 22.0 30.0 43.0 22 .0 x 2
Water Flow Rate LPM 80.0 96.0 114.0 80.0 x 2
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 9.52 9.52 12.7 12.7
Ø , inch 3/8" 3/8" 1/2" 1/2"
Gas Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 19.05 22.22 28.58 28.58
Ø , inch 3/4" 7/8" 1 1/8" 1 1/8"
Discharge Gas Pipe
Ø , mm 15.88 19.05 19.05 22.22
Ø , inch 5/8" 3/4" 3/4" 7/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R410A R410A R410A R410A
Factory Charging kg/tCO2e5.5/11.48 5.8/12.11 6.0/12.53 11.0/22.97
Sound
3)*
Sound Pressure Cooling
dB(A)
48 48 50 51
Heating 51 51 52 54
Sound Power 70 70 70 73
External
Dimension
Net Weight kg 160 160 160 160 x 2
Shipping Weight kg 167 167 167 167 x 2
Net Dimensions (WxHxD) mm 770 x 1,000 x 545 770 x 1,000 x 545 770 x 1,000 x 545 (770 x 1,000 x 545) x 2
Shipping Dimensions (WxHxD) mm 840 x 1,200 x 620 840 x 1,200 x 620 840 x 1,200 x 620 (840 x 1,200 x 620) x 2
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0

11
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM180FXWANR2 AM200FXWANR AM220FXWANR2 AM240FXWANR2
Outdoor unit module 1 AM080FXWANR AM200FXWANR AM100FXWANR AM120FXWANR
Outdoor unit module 2 AM100FXWANR AM120FXWANR AM120FXWANR
Outdoor unit module 3
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 18 20 22 24
Ton Ton 14.33 15.92 17.52 19.11
Capacity
(Nominal)
Cooling kW 50.4 56.0 61.6 67.2
Btu/h 172,000 191,100 210,200 229,300
Heating
2)*
kW 56.7 63.0 69.3 75.6
Btu/h 193,500 215,000 236,500.0 258,000
Heating
4)*
kW - - -
Btu/h - - -
Maximum
number of
connectable
indoor units
ea 32 36 40 44
Total capacity of
the connected
Indoor Units 3)
Min. kW 25.2 28.0 30.8 33.6
Max. kW 65.5 72.8 80.1 87.4
Power
Power Input
(Nominal)
Cooling
1)*
kW
8.89 10.77 11.51 12.02
Heating
2)*
9.37 10.86 11.76 13.02
Heating
4)*
- - -
Current Input
(Nominal)
Cooling
1)*
A14.3 17.3 18.4 20.6
Heating
2)*
15.0 17.4 18.8 20.8
Current
Minimum Ssc value MVA 7.8 7.7 8.7 9.6
MCA A32.2 32.2 36.1 40.0
MFA A40.0 40.0 40.0 50.0
COP
Nominal Cooling
1)*
W/W 5.67 5.20 5.35 5.20
Nominal Heating
2)*
W/W 6.05 5.80 5.89 5.81
Nominal Heating
4)*
W/W - - -
Casing Material Cabinet -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 2 (4.96) x 2 (4.96) x 1 + (6.13) x 1 (6.13) x 2
Model Name -DS-GB052FAVBSG x 2 DS-GB052FAVBSG x 2 DS-GB052FAVBSG x 1 +
DS-GB066FAVBSG X 1 DS-GB066FAVBSG x 2
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 3.9 x 2 6.2 3.9 x 2 3.9 x 2
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 x 2 PT 1-1/4 PT 1-1/4 x 2 PT 1-1/4 x 2
Pressure Drop kPa 22 .0 + 30.0 54.0 30.0 + 43.0 43.0 x 2
Water Flow Rate LPM 80.0 + 96.0 190.0 96.0 + 114.0 114.0 x 2
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 15.88 15.88 15.88 15.88
Ø , inch 5/8" 5/8" 5/8" 5/8"
Gas Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 28.58 28.58 28.58 28.58
Ø , inch 1 1/8" 1 1/8" 1 1/8" 1 1/8"
Discharge Gas Pipe
Ø , mm 22.22 28.58 28.58 28.58
Ø , inch 7/8" 1 1/8" 1 1/8" 1 1/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R410A R410A R410A R410A
Factory Charging kg/tCO2e11.3/23.59 9.8/20.46 11.8/24.64 12.0/25.06
Sound
3)*
Sound Pressure Cooling
dB(A)
51 51 52 53
Heating 54 52 55 55
Sound Power 73 73 73 73
External
Dimension
Net Weight kg 160 x 2 240 160 x 2 160 x 2
Shipping Weight kg 167 x 2 250 167 x 2 167 x 2
Net Dimensions (WxHxD) mm (770 x 1,000 x 545) x 2 1,100 x 1,000 x 545 (770 x 1,000 x 545) x 2 (770 x 1,000 x 545) x 2
Shipping Dimensions (WxHxD) mm (840 x 1,200 x 620) x 2 1,170 x 1,200 x 620 (840 x 1,200 x 620) x 2 (840 x 1,200 x 620) x 2
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0

12
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM260FXWANR2 AM280FXWANR2 AM300FXWANR2 AM320FXWANR2
Outdoor unit module 1 AM080FXWANR AM080FXWANR AM100FXWANR AM120FXWANR
Outdoor unit module 2 AM080FXWANR AM200FXWANR AM200FXWANR AM200FXWANR
Outdoor unit module 3 AM100FXWANR
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 26 28 30 32
Ton Ton 20.70 22.29 23.88 25.48
Capacity
(Nominal)
Cooling kW 72.8 78.4 84.0 89.6
Btu/h 248,400 267,500 286,600 305,700
Heating
2)*
kW 81.9 88.2 94.5 100.8
Btu/h 279,500 301,000 322,400 343,900
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 47 51 55 58
Total capacity of the
connected Indoor Units 3)
Min. kW 36.4 39.2 42.0 44.8
Max. kW 94.6 101.9 109.2 116.5
Power
Power Input
(Nominal)
Cooling
1)*
kW
12.73 14.61 15.82 17.23
Heating
2)*
13.49 14.98 16.11 17.37
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A20.5 23.5 25.4 27.6
Heating
2)*
21.6 24.0 25.8 27.8
Current
Minimum Ssc value MVA 11.7 11.6 11.6 12.5
MCA A48.3 47.9 47.9 51.8
MFA A63.0 63.0 63.0 63.0
COP
Nominal Cooling
1)*
W/W 5.72 5.37 5.31 5.20
Nominal Heating
2)*
W/W 6.07 5.89 5.87 5.80
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 3 (4.96) x 3 (4.96) x 3 (4.96) x 2 + (6.13) x 1
Model Name -DS-GB052FAVBSG x 3 DS-GB052FAVBSG x 3 DS-GB052FAVBSG x 3 DS-GB066FAVBSG x 1 +
DS-GB052FAVBSG x 2
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 3.9 x 3 3.9+6.2 3.9+6.2 3.9+6.2
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 x 3 PT 1-1/4 x 2 PT 1-1/4 x 2 PT 1-1/4 x 2
Pressure Drop kPa 22.0 x 2 + 30.0 22.0 + 54.0 30.0 +54.0 43.0 + 54.0
Water Flow Rate LPM 80.0 x 2 + 96.0 80.0 + 190.0 96.0 + 190.0 114.0 + 190.0
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 19.05 19.05 19.05 19.05
Ø , inch 3/4" 3/4" 3/4" 3/4"
Gas Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 34.92 34.92 34.92 34.92
Ø , inch 1 3/8" 1 3/8" 1 3/8" 1 3/8"
Discharge Gas Pipe
Ø , mm 28.58 28.58 28.58 28.58
Ø , inch 1 1/8" 1 1/8" 1 1/8" 1 1/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R410A R410A R410A R410A
Factory Charging kg/tCO2e16.8/35.08 15.3/31.95 15.6/32.57 15.8/32.99
Sound
3)*
Sound Pressure Cooling
dB(A)
53 53 53 54
Heating 56 55 55 55
Sound Power 75 75 75 75
External
Dimension
Net Weight kg 160 x 3 160 + 240 160 + 240 160 + 240
Shipping Weight kg 167 x 3 167 + 250 167 + 250 167 + 250
Net Dimensions (WxHxD) mm (770 x 1,000 x 545) x 3 770 x 1,000 x 545 +
1,100 x 1,000 x 545
770 x 1,000 x 545 +
1,100 x 1,000 x 545
770 x 1,000 x 545 +
1,100 x 1,000 x 545
Shipping Dimensions (WxHxD) mm (840 x 1,200 x 620) x 3 840 x 1,200 x 620 +
1,170 x 1,200 x 620
840 x 1,200 x 620 +
1,170 x 1,200 x 620
840 x 1,200 x 620 +
1,170 x 1,200 x 620
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0

13
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM340FXWANR2 AM360FXWANR2 AM380FXWANR2 AM400FXWANR2
Outdoor unit module 1 AM100FXWANR AM080FXWANR AM080FXWANR AM200FXWANR
Outdoor unit module 2 AM120FXWANR AM080FXWANR AM100FXWANR AM200FXWANR
Outdoor unit module 3 AM120FXWANR AM200FXWANR AM200FXWANR
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 34 36 38 40
Ton Ton 27.07 28.66 30.26 31.85
Capacity
(Nominal)
Cooling kW 95.2 100.8 106.4 112.0
Btu/h 324,800 343,900 363,100 382,200
Heating
2)*
kW 107.1 113.4 119.7 126.0
Btu/h 365,400 386,900 408,400 429,900
Heating
4)*
kW ----
Btu/h ----
Maximum
number of
connectable
indoor units
ea 62 64 64 64
Total capacity of
the connected
Indoor Units 3)
Min. kW 47.6 50.4 53.2 56.0
Max. kW 123.8 131.0 138.3 145.6
Power
Power Input
(Nominal)
Cooling
1)*
kW
17.97 18.45 19.66 21.54
Heating
2)*
18.27 19.10 20.23 21.72
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A28.7 29.7 31.6 34.6
Heating
2)*
29.2 30.6 32.4 34.6
Current
Minimum Ssc value MVA 13.5 15.5 15.5 15.4
MCA A56.1 64.0 64.0 63.6
MFA A63.0 75.0 75.0 75.0
COP
Nominal Cooling
1)*
W/W 5.30 5.46 5.41 5.20
Nominal Heating
2)*
W/W 5.86 5.94 5.92 5.80
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 1 + (6.13) x 2 (4.96) x 4 (4.96) x 4 (4.96) x 4
Model Name -DS-GB052FAVBSG x 1 +
DS-GB066FAVBSG x 2 DS-GB052FAVBSG x 4 DS-GB052FAVBSG x 4 DS-GB052FAVBSG x 4
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 3.9 x 3 (3.9 x 2)+6.2 (3.9 x 2)+6.2 (3.9 x 2)+6.2
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 x 3 PT 1-1/4 x 3 PT 1-1/4 x 3 PT 1-1/4 x 2
Pressure Drop kPa 30.0 + 43.0 x 2 22.0 x 2 + 54.0 22.0 + 30.0 + 54.0 54.0 x 2
Water Flow Rate LPM 96.0 + 114.0 x 2 80.0 x 2 + 190.0 80.0 + 96.0 +190.0 190.0 x 2
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 19.05 19.05 19.05 19.05
Ø , inch 3/4" 3/4" 3/4" 3/4"
Gas Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 34.92 41.28 41.28 41.28
Ø , inch 1 3/8" 1 5/8" 1 5/8" 1 5/8"
Discharge Gas Pipe
Ø , mm 28.58 34.92 34.92 34.92
Ø , inch 1 1/8" 1 3/8" 1 3/8" 1 3/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R410A R410A R410A R410A
Factory Charging kg/tCO2e17.8/37.17 20.8/43.43 21.1/44.06 19.6/40.92
Sound
3)*
Sound Pressure Cooling
dB(A)
54 54 54 54
Heating 56 56 56 55
Sound Power 75 76 76 76
External
Dimension
Net Weight kg 160 x 3 160 x 2 + 240 160 x 2 + 240 240 x 2
Shipping Weight kg 167 x 3 167 x 2 + 250 167 x 2 + 250 250 x 2
Net Dimensions (WxHxD) mm (770 x 1,000 x 545) x 3 (770 x 1,000 x 545) x 2 +
1,100 x 1,000 x 545
(770 x 1,000 x 545) x 2 +
1,100 x 1,000 x 545 (1,100 x 1,000 x 545) x 2
Shipping Dimensions (WxHxD) mm (840 x 1,200 x 620) x 3 (840 x 1,200 x 620) x 2 +
1,170 x 1,200 x 620
(840 x 1,200 x 620) x 2 +
1,170 x 1,200 x 620 (1,170 x 1,200 x 620) x 2
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0

14
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM420FXWANR2 AM440FXWANR2 AM480FXWANR2 AM500FXWANR2
Outdoor unit module 1 AM100FXWANR AM120FXWANR AM080FXWANR AM100FXWANR
Outdoor unit module 2 AM120FXWANR AM120FXWANR AM200FXWANR AM200FXWANR
Outdoor unit module 3 AM200FXWANR AM200FXWANR AM200FXWANR AM200FXWANR
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 42 44 48 50
Ton Ton 33.44 35.03 38.22 39.81
Capacity
(Nominal)
Cooling kW 117.6 123.2 134.4 140.0
Btu/h 401,300 420,400 458,600 477,700
Heating
2)*
kW 132.3 138.6 151.2 157.5
Btu/h 451,400 472,900 515,900 537,400
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 64 64 64 64
Total capacity of the
connected Indoor Units 3)
Min. kW 58.8 61.6 67.2 70.0
Max. kW 152.9 160.2 174.7 182.0
Power
Power Input
(Nominal)
Cooling
1)*
kW
22.28 23.69 25.38 26.59
Heating
2)*
22.62 23.88 25.84 26.97
Heating
4)*
- -
Current Input
(Nominal)
Cooling
1)*
A35.7 37.9 40.8 42.7
Heating
2)*
36.2 38.2 41.4 43.2
Current
Minimum Ssc value MVA 16.4 17.3 19.3 19.3
MCA A67.9 71.8 79.7 79.7
MFA A75.0 80.0 90.0 90.0
COP
Nominal Cooling
1)*
W/W 5.28 5.20 5.30 5.27
Nominal Heating
2)*
W/W 5.85 5.80 5.85 5.84
Nominal Heating
4)*
W/W - -
Casing Material Cabinet -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 3 + (6.13) x 1 (4.96) x 2 + (6.13) x 2 (4.96) x 5 (4.96) x 5
Model Name -DS-GB052FAVBSG x 3 +
DS-GB066FAVBSG x 1
DS-GB052FAVBSG x 2 +
DS-GB066FAVBSG x 2 DS-GB052FAVBSG x 5 DS-GB052FAVBSG x 5
Oil Type -PVE PVE PVE PVE
Initial Charge Liter (3.9 x 2)+6.2 (3.9 x 2)+6.2 3.9+(6.2 x 2) 3.9+(6.2 x 2)
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 x 3 PT 1-1/4 x 3 PT 1-1/4 x 3 PT 1-1/4 x 3
Pressure Drop kPa 30.0 + 43.0 + 54.0 43.0 x 2 + 54.0 22.0 +54.0 x 2 30.0 + 54.0 x 2
Water Flow Rate LPM 96.0 + 114.0 + 190.0 114.0 x 2 + 190.0 80.0 +190.0 x 2 96.0 + 190.0 x 2
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 19.05 19.05 19.05 19.05
Ø , inch 3/4" 3/4" 3/4" 3/4"
Gas Pipe
Type Braze connection Braze connection Braze connection Braze connection
Ø , mm 41.28 41.28 41.28 41.28
Ø , inch 1 5/8" 1 5/8" 1 5/8" 1 5/8"
Discharge Gas Pipe
Ø , mm 34.92 34.92 34.92 34.92
Ø , inch 1 3/8" 1 3/8" 1 3/8" 1 3/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R410A R410A R410A R410A
Factory Charging kg/tCO2e21.6/45.10 21.8/45.52 25.1/52.41 25.4/53.04
Sound
3)*
Sound Pressure Cooling
dB(A)
55 55 55 55
Heating 56 57 56 56
Sound Power 76 76 77 77
External
Dimension
Net Weight kg 160 x 2 + 240 160 x 2 + 240 160 + 240 x 2 160 + 240 x 2
Shipping Weight kg 167 x 2 + 250 167 x 2 + 250 167 + 250 x 2 167 + 250 x 2
Net Dimensions (WxHxD) mm (770 x 1,000 x 545) x 2 +
1,100 x 1,000 x 545
(770 x 1,000 x 545) x 2 +
1,100 x 1,000 x 545
770 x 1,000 x 545 +
(1,100 x 1,000 x 545) x 2
770 x 1,000 x 545 +
(1,100 x 1,000 x 545) x 2
Shipping Dimensions (WxHxD) mm (840 x 1,200 x 620) x 2 +
1,170 x 1,200 x 620
(840 x 1,200 x 620) x 2 +
1,170 x 1,200 x 620
840 x 1,200 x 620 +
(1,170 x 1,200 x 620) x 2
840 x 1,200 x 620 +
(1,170 x 1,200 x 620) x 2
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0

15
Premium Energy Efficiency
2. Specification
Type DVM S Water DVM S Water
Model Name
AM520FXWANR2 AM600FXWANR2
Outdoor unit module 1 AM210FXWANR AM200FXWANR
Outdoor unit module 2 AM200FXWANR AM200FXWANR
Outdoor unit module 3 AM200FXWANR AM200FXWANR
Outdoor unit module 4
Power Supply
Ø, #, V, Hz 3,4,380-415,50/60 3,4,380-415,50/60
Mode -HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 52 60
Ton Ton 41.4 47.77
Capacity
(Nominal)
Cooling kW 145.6 168.0
Btu/h 496,800 573,200
Heating
2)*
kW 163.8 189.0
Btu/h 558,900 644,900
Heating
4)*
kW - -
Btu/h - -
Maximum
number of
connectable
indoor units
ea 64 64
Total capacity of
the connected
Indoor Units 3)
Min. kW 72.8 84.0
Max. kW 189.3 218.4
Power
Power Input
(Nominal)
Cooling
1)*
kW
28.00 32.31
Heating
2)*
28.23 32.58
Heating
4)*
- -
Current Input
(Nominal)
Cooling
1)*
A44.9 51.9
Heating
2)*
45.2 52.2
Current
Minimum Ssc value MVA 20.2 23.1
MCA A83.6 95.4
MFA A100.0 125.0
COP
Nominal Cooling
1)*
W/W 5.20 5.20
Nominal Heating
2)*
W/W 5.80 5.80
Nominal Heating
4)*
W/W - -
Casing Material Cabinet -EGI steel plate EGI steel plate
Base -EGI steel plate EGI steel plate
Compressor
Type -Inverter Scroll Inverter Scroll
Output kW × n (4.96) x 4 + (6.13) x 1 (4.96) x 6
Model Name -DS-GB052FAVBSG x 4 + DS-GB066FAVBSG x 1 DS-GB052FAVBSG x 6
Oil Type -PVE PVE
Initial Charge Liter 3.9+(6.2 x 2) 6.2 x 3
Condenser
Type Type PHE(Plate Heat Exchanger) PHE(Plate Heat Exchanger)
Pipe Size
Ø , inch PT 1-1/4 x 3 PT 1-1/4 x 3
Pressure Drop kPa 43.0 + 54.0 x 2 54.0 x 3
Water Flow Rate LPM 114.0 + 190.0 x 2 190.0 x 3
Max. Pressure Mpa 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze connection Braze connection
Ø , mm 19.05 19.05
Ø , inch 3/4" 3/4"
Gas Pipe
Type Braze connection Braze connection
Ø , mm 41.28 41.28
Ø , inch 1 5/8" 1 5/8"
Discharge Gas Pipe
Ø , mm 34.92 34.92
Ø , inch 1 3/8" 1 3/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190)
After branch Max. m90 90
Total piping length System Actual m500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50
Indoor unit in highest position m40 40
IDU-IDU Max. m50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75
Remark -F1, F2 F1, F2
Refrigerant Type -R410A R410A
Factory Charging kg/tCO2e25.6/53.45 29.4/61.39
Sound
3)*
Sound Pressure Cooling
dB(A)
55 56
Heating 57 57
Sound Power 77 78
External
Dimension
Net Weight kg 160 + 240 x 2 240 x 3
Shipping Weight kg 167 + 250 x 2 250 x 3
Net Dimensions (WxHxD) mm 770 x 1,000 x 545 + (1,100 x 1,000 x 545) x 2 (1,100 x 1,000 x 545) x 3
Shipping Dimensions (WxHxD) mm 840 x 1,200 x 620 + (1,170 x 1,200 x 620) x 2 (1,170 x 1,200 x 620) x 3
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0

16
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM300KXWANR AM380KXWANR1 AM400KXWANR1 AM420KXWANR1
Outdoor unit module 1 AM300KXWANR AM300KXWANR AM300KXWANR AM300KXWANR
Outdoor unit module 2 -AM080FXWANR AM100FXWANR AM120FXWANR
Outdoor unit module 3 ----
Outdoor unit module 4 ----
Power Supply
Ø, #, V, Hz 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 30 38 40 42
Ton Ton 23.9 30.3 31.9 33.5
Capacity
(Nominal)
Cooling kW 84.0 106.4 112.0 117.6
Btu/h 286,600 363,027 382,133 401,240
Heating
2)*
kW 94.5 119.7 126.0 132.3
Btu/h 322,400 408,373 429,867 451,360
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 55 64 64 64
Total capacity of the
connected Indoor Units 3)
Min. kW 42.0 53.2 56.0 58.8
Max. kW 109.2 138.3 145.6 152.9
Power
Power Input
(Nominal)
Cooling
1)*
kW
16.80 20.64 21.85 23.26
Heating
2)*
16.88 21.00 22.13 23.39
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A26.4 32.6 34.5 36.7
Heating
2)*
26.5 33.1 34.9 36.9
Current
Minimum Ssc value MVA ----
MCA A48 64.1 64.1 68
MFA A63 75 75 75
COP
Nominal Cooling
1)*
W/W 5.00 5.16 5.13 5.06
Nominal Heating
2)*
W/W 5.60 5.70 5.69 5.66
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n (6.75)x2 (6.75)x2 + (4.96)x1 (6.75)x2 + (4.96)x1 (6.75)x2 + (6.13)x1
Model Name -DS-GB070FAV* x 2 DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 1
DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 1
DS-GB070FAV* x 2 +
DS-GB066FAVBSG x 1
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 6.2 6.2 + 3.9 6.2 + 3.9 6.2 + 3.9
Condenser
Type Type
PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger)
Pipe Size Ø , inch PT2 PT2 + PT 1-1/4 PT2 + PT 1-1/4 PT2 + PT 1-1/4
Pressure Drop kPa 50 50 + 22 50 + 30 50 + 43
Water Flow Rate LPM 285 285 + 80 285 + 96 285 + 114
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 19.05 19.05 19.05 19.05
Ø , inch 3/4" 3/4" 3/4" 3/4"
Gas Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 34.92 41.28 41.28 41.28
Ø , inch 1 3/8" 1 5/8" 1 5/8" 1 5/8"
Discharge Gas Pipe
Ø , mm Braze Connection Braze Connection Braze Connection Braze Connection
Ø , inch 28.58 34.92 34.92 34.92
Ø , inch 1 1/8" 1 3/8" 1 3/8" 1 3/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R-410A R-410A R-410A R-410A
Factory Charging kg/tCO2e11.0 19.0 16.8 17.0
Sound
3)*
Sound Pressure Cooling
dB(A)
55 56 56 57
Heating 58 59 59 59
Sound Power 75 77 77 77
External
Dimension
Net Weight kg 280 160 + 280 160 + 280 160 + 280
Shipping Weight kg 290 167 + 290 167 + 290 167 + 290
Net Dimensions (WxHxD) mm 1100 x 1000 x 545 (770 X 1000 X 545)+
(1100 x 1000 x 545)
(770 X 1000 X 545)+
(1100 x 1000 x 545)
(770 X 1000 X 545)+
(1100 x 1000 x 545)
Shipping Dimensions (WxHxD) mm 1170 x 1200 x 620 (840 X 1200 X 620)+
(1170 x 1200 x 620)
(840 X 1200 X 620)+
(1170 x 1200 x 620)
(840 X 1200 X 620)+
(1170 x 1200 x 620)
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Premium Compact
2. Specification

17
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM460KXWANR1 AM480KXWANR1 AM500KXWANR1 AM520KXWANR1
Outdoor unit module 1 AM300KXWANR AM300KXWANR AM300KXWANR AM300KXWANR
Outdoor unit module 2 AM080FXWANR AM100FXWANR AM200FXWANR AM120FXWANR
Outdoor unit module 3 AM080FXWANR AM080FXWANR -AM100FXWANR
Outdoor unit module 4 ----
Power Supply
Ø, #, V, Hz 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 46 48 50 52
Ton Ton 36.6 38.2 39.8 41.4
Capacity
(Nominal)
Cooling kW 128.8 134.4 140.0 145.6
Btu/h 439,453 458,560 477,667 496,773
Heating
2)*
kW 144.9 151.2 157.5 163.8
Btu/h 494,347 515,840 537,333 558,827
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 64 64 64 64
Total capacity of the
connected Indoor Units 3)
Min. kW 64.4 67.2 70.0 72.8
Max. kW 188.4 174.7 182.0 189.3
Power
Power Input
(Nominal)
Cooling
1)*
kW
24.48 25.69 27.57 28.31
Heating
2)*
25.12 26.25 27.74 28.64
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A38.8 40.7 43.7 44.8
Heating
2)*
39.7 41.5 43.9 45.3
Current
Minimum Ssc value MVA ----
MCA A80.2 80.2 79.8 84.1
MFA A90 90 90 100
COP
Nominal Cooling
1)*
W/W 5.26 5.23 5.08 5.14
Nominal Heating
2)*
W/W 5.77 5.76 5.68 5.72
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n
(6.75)x2 + (4.96)x2 (6.75)x2 + (4.96)x2 (6.75)x2 + (4.96)x2 (6.75)x2 + (6.13)x1 + (4.96)x1
Model Name -DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 2
DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 2
DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 2
DS-GB070FAV* x 2 +
DS-GB066FAVBSG x 1 +
DS-GB052FAVBSG x 1
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 6.2 + (3.9)x2 6.2 + (3.9)x2 (6.2)x2 6.2 + (3.9)x2
Condenser
Type Type
PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger)
Pipe Size Ø , inch PT2 + PT 1-1/4 x 2 PT2 + PT 1-1/4 x 2 PT2 + PT 1-1/4 PT2 + PT 1-1/4 x 2
Pressure Drop kPa 50 + 22 x 2 50 + 22 + 30 50 + 54 50 + 43 + 30
Water Flow Rate LPM 285 + 80 x 2 285 + 80 + 96 285 + 190 285 + 114 + 96
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 19.05 19.05 19.05 19.05
Ø , inch 3/4" 3/4" 3/4" 3/4"
Gas Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 41.28 41.28 41.28 41.28
Ø , inch 1 5/8" 1 5/8" 1 5/8" 1 5/8"
Discharge Gas Pipe
Ø , mm Braze Connection Braze Connection Braze Connection Braze Connection
Ø , inch 34.92 34.92 34.92 34.92
Ø , inch 1 3/8" 1 3/8" 1 3/8" 1 3/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R-410A R-410A R-410A R-410A
Factory Charging kg/tCO2e22.0 22.3 20.8 22.8
Sound
3)*
Sound Pressure Cooling
dB(A)
57 57 57 57
Heating 60 60 59 60
Sound Power 78 78 78 78
External
Dimension
Net Weight kg 160 X 2 + 280 160 X 2 + 280 240 + 280 160 X 2 + 280
Shipping Weight kg 167 X 2 + 290 167 X 2 + 290 250 + 290 167 X 2 + 290
Net Dimensions (WxHxD) mm (770 X 1000 X 545) X 2+
(1100 x 1000 x 545)
(770 X 1000 X 545) X 2+
(1100 x 1000 x 545) (1100 x 1000 x 545) X 2 (770 X 1000 X 545) X 2+ (1100 x 1000 x 545)
Shipping Dimensions (WxHxD) mm (840 X 1200 X 620) X 2+
(1170 x 1200 x 620)
(840 X 1200 X 620) X 2+
(1170 x 1200 x 620) (1170 x 1200 x 620) X2 (840 X 1200 X 620) X 2+ (1170 x 1200 x 620)
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Premium Compact
2. Specification

18
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM540KXWANR1 AM580KXWANR1 AM600KXWANR1 AM620KXWANR1
Outdoor unit module 1 AM300KXWANR AM300KXWANR AM300KXWANR AM300KXWANR
Outdoor unit module 2 AM120FXWANR AM200FXWANR AM300KXWANR AM200FXWANR
Outdoor unit module 3 AM120FXWANR AM080FXWANR -AM120FXWANR
Outdoor unit module 4 ----
Power Supply
Ø, #, V, Hz 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 54 58 60 62
Ton Ton 43.0 46.2 47.8 49.4
Capacity
(Nominal)
Cooling kW 151.2 162.4 168.0 173.6
Btu/h 515,880 554,093 573,200 592,307
Heating
2)*
kW 170.1 182.7 189.0 195.3
Btu/h 580,320 623,307 644,800 666,293
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 64 64 64 64
Total capacity of the
connected Indoor Units 3)
Min. kW 75.6 81.2 84.0 86.8
Max. kW 221.1 237.5 218.4 225.7
Power
Power Input
(Nominal)
Cooling
1)*
kW
29.72 31.41 33.6 34.03
Heating
2)*
29.90 31.86 33.76 34.25
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A47 49.9 52.8 54
Heating
2)*
47.3 50.5 53 54.3
Current
Minimum Ssc value MVA ----
MCA A88 95.9 96 99.8
MFA A100 125 125 125
COP
Nominal Cooling
1)*
W/W 5.09 5.17 5.00 5.10
Nominal Heating
2)*
W/W 5.69 5.73 5.60 5.70
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n
(6.75)x2 + (6.13)x2 (6.75)x2 + (4.96)x3 6.75 x 4 (6.75)x2 + (4.96)x2 + (6.13)x1
Model Name -DS-GB070FAV* x 2 +
DS-GB066FAVBSG x 2
DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 3 (DS-GB070FAV* x 2) x 2
DS-GB070FAV* x 2 +
DS-GB052FAVBSG x 3 +
DS-GB066FAVBSG x 1
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 6.2 + (3.9)x2 (6.2)x2 + 3.9 6.2 x 2 (6.2)x2 + 3.9
Condenser
Type Type
PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger)
Pipe Size Ø , inch PT2 + PT 1-1/4 x 2 PT2 + PT 1-1/4 x 2 PT2 x 2 PT2 + PT 1-1/4 x 2
Pressure Drop kPa 50 + 43x2 50 + 54 + 22 50 x 2 50 + 54 + 43
Water Flow Rate LPM 285 + 114x2 285 + 190 + 80 285 x 2 285 + 190 + 114
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 19.05 19.05 19.05 22.22
Ø , inch 3/4" 3/4" 3/4" 7/8"
Gas Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 41.28 41.28 41.28 53.98
Ø , inch 1 5/8" 1 5/8" 1 5/8" 2 1/8"
Discharge Gas Pipe
Ø , mm Braze Connection Braze Connection Braze Connection Braze Connection
Ø , inch 34.92 34.92 34.92 41.28
Ø , inch 1 3/8" 1 3/8" 1 3/8" 1 5/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R-410A R-410A R-410A R-410A
Factory Charging kg/tCO2e23.0 26.3 22.0 26.8
Sound
3)*
Sound Pressure Cooling
dB(A)
58 58 59 58
Heating 60 60 62 60
Sound Power 78 78 79 78
External
Dimension
Net Weight kg 160 X 2 + 280 160 + 240 + 280 280 x 2 160 + 240 + 280
Shipping Weight kg 167 X 2 + 290 167 + 250 + 290 290 x 2 167 + 250 + 290
Net Dimensions (WxHxD) mm (770 X 1000 X 545) X 2+
(1100 x 1000 x 545)
(770 X 1000 X 545) +
(1100 x 1000 x 545) X 2 (1100 x 1000 x 545) x 2 (770 X 1000 X 545) + (1100 x 1000 x 545) X 2
Shipping Dimensions (WxHxD) mm (840 X 1200 X 620) X 2+
(1170 x 1200 x 620)
(840 X 1200 X 620) +
(1170 x 1200 x 620) X 2 (1170 x 1200 x 620) x 2 (840 X 1200 X 620) + (1170 x 1200 x 620) X 2
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Premium Compact
2. Specification

19
Type DVM S Water DVM S Water DVM S Water DVM S Water
Model Name
AM680KXWANR1 AM700KXWANR1 AM800KXWANR1 AM900KXWANR1
Outdoor unit module 1 AM300KXWANR AM300KXWANR AM300KXWANR AM300KXWANR
Outdoor unit module 2 AM300KXWANR AM300KXWANR AM300KXWANR AM300KXWANR
Outdoor unit module 3 AM080FXWANR AM100FXWANR AM200FXWANR AM300KXWANR
Outdoor unit module 4 ----
Power Supply
Ø, #, V, Hz 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60 3, 4, 380-415, 50/60
Mode -HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY HEAT RECOVERY
Performance
HP HP 68 70 80 90
Ton Ton 54.2 55.8 63.7 71.7
Capacity
(Nominal)
Cooling kW 190.4 196.0 224.0 252.0
Btu/h 649,627 668,733 764,267 859,800
Heating
2)*
kW 214.2 220.5 252.0 283.5
Btu/h 730,773 752,267 859,733 967,200
Heating
4)*
kW ----
Btu/h ----
Maximum number
of connectable
indoor units
ea 64 64 64 64
Total capacity of the
connected Indoor Units 3)
Min. kW 95.2 98.0 112.0 126.0
Max. kW 247.5 254.8 291.2 327.6
Power
Power Input
(Nominal)
Cooling
1)*
kW
37.44 38.65 44.37 50.4
Heating
2)*
37.88 39.01 44.62 50.64
Heating
4)*
----
Current Input
(Nominal)
Cooling
1)*
A59 60.9 70.1 79.2
Heating
2)*
59.6 61.4 70.4 79.5
Current
Minimum Ssc value MVA ----
MCA A112.1 112.1 127.8 144
MFA A125 125 150 175
COP
Nominal Cooling
1)*
W/W 5.09 5.07 5.05 5.00
Nominal Heating
2)*
W/W 5.65 5.65 5.65 5.60
Nominal Heating
4)*
W/W ----
Casing Material Cabinet -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Base -EGI Steel Plate EGI Steel Plate EGI Steel Plate EGI Steel Plate
Compressor
Type -Inverter Scroll Inverter Scroll Inverter Scroll Inverter Scroll
Output kW × n
(6.75)x4 + (4.96)x1 (6.75)x4 + (4.96)x1 (6.75)x4 + (4.96)x2 6.75 x 6
Model Name -DS-GB070FAV* x 4 +
DS-GB052FAVBSG x 1
DS-GB070FAV* x 4 +
DS-GB052FAVBSG x 1
DS-GB070FAV* x 4 +
DS-GB052FAVBSG x 2 (DS-GB070FAV* x 2) x 3
Oil Type -PVE PVE PVE PVE
Initial Charge Liter 6.2x2 + 3.9 6.2x2 + 3.9 (6.2)x3 6.2 x 3
Condenser
Type Type
PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger) PHE (Plate Heat Exchanger)
Pipe Size Ø , inch PT2x2 + PT 1-1/4 PT2x2 + PT 1-1/4 PT2x2 + PT 1-1/4 PT2 x 3
Pressure Drop kPa 50x2 + 22 50x2 + 30 50x2 + 54 50 x 3
Water Flow Rate LPM 285x2 + 80 285x2 + 96 285x2 + 190 285 x 3
Max. Pressure Mpa 1.96 1.96 1.96 1.96
Piping
Connections
Liquid Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 22.22 22.22 22.22 22.22
Ø , inch 7/8" 7/8" 7/8" 7/8"
Gas Pipe
Type Braze Connection Braze Connection Braze Connection Braze Connection
Ø , mm 53.98 53.98 53.98 53.98
Ø , inch 2 1/8" 2 1/8" 2 1/8" 2 1/8"
Discharge Gas Pipe
Ø , mm Braze Connection Braze Connection Braze Connection Braze Connection
Ø , inch 41.28 41.28 41.28 41.28
Ø , inch 1 5/8" 1 5/8" 1 5/8" 1 5/8"
Heat insulation -Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length ODU-IDU Max. m170 (190) 170 (190) 170 (190) 170 (190)
After branch Max. m90 90 90 90
Total piping length System Actual m500 500 500 500
Level difference
ODU-IDU Outdoor unit in highest position m50 50 50 50
Indoor unit in highest position m40 40 40 40
IDU-IDU Max. m50 50 50 50
Wiring
connections Communication Minimum mm
2
0.75 0.75 0.75 0.75
Remark -F1, F2 F1, F2 F1, F2 F1, F2
Refrigerant Type -R-410A R-410A R-410A R-410A
Factory Charging kg/tCO2e27.5 27.8 31.8 33.0
Sound
3)*
Sound Pressure Cooling
dB(A)
59 59 59 60
Heating 62 62 62 63
Sound Power 79 79 80 80
External
Dimension
Net Weight kg 160 + 280 X 2 160 + 280 X 2 240 + 280 X 2 280 x 3
Shipping Weight kg 167 + 290 X 2 167 + 290 X 2 250 + 290 X 2 290 x 3
Net Dimensions (WxHxD) mm (770 X 1000 X 545) +
(1100 x 1000 x 545) X 2
(770 X 1000 X 545) +
(1100 x 1000 x 545) X 2 (1100 x 1000 x 545) x 3 (1100 x 1000 x 545) x 3
Shipping Dimensions (WxHxD) mm (840 X 1200 X 620) +
(1170 x 1200 x 620) X 2
(840 X 1200 X 620) +
(1170 x 1200 x 620) X 2 (1170 x 1200 x 620) x 3 (1170 x 1200 x 620) x 3
Operating
Temp. Range
Cooling
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Heating
°C 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0 10.0 ~ 45.0
Premium Compact
2. Specification

20
2. Specification
NOTE
• Specification may be subject to change without prior notice.
• 1)* Nominal cooling capacities are based on;
-Indoor temperature : 27°C DB, 19°C WB, Inlet water temperature : 30°C, Equivalent refrigerant piping : 7.5m,
Level differences : 0m
• 2)* Nominal heating capacities are based on;
-Indoor temperature : 20°C DB, 15°C WB, Inlet water temperature : 20°C, Equivalent refrigerant piping : 7.5m,
Level differences : 0m
• 3)* Sound power level is an absolute value that a sound source generates.
-Sound pressure level is a relative value, depending on the distance and acoustic environment.
-Sound values are obtained in an anechoic room.
-Sound values of multi comvination are theoretical values based on sound results of individual installed
units.
• 4)* Nominal heating capacityes are based on Eurovent test conditions:
-Indoor temperature : 20°C DB, 15°C WB, Inlet water temperature : 10°C, Outlet water temperature : 7°C,
Equivalent refrigerant piping : 7.5m, Level differences : 0m
• These products contain R410A(GWP=2,088) which is fluorinated greenhouse gas.
• Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit capacity.
0.5 × ∑(Outdoor unit capacity) ≤ Total capacity of the connected indoor units ≤ 1.3 × ∑(Outdoor unit capacity)
• You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor unit is
set to 64 since outdoor unit only support up to 64 communication address. Indoor unit address can be assigned
from indoor unit address was assigned from 64~79, E201 error will occur.0~63. If the If the indoor unit address
was assigned from 64~79, E201 error will occur.
