Samsung AR07TSFABWKN User manual

AIR CONDITIONER CONTENTS
MULTI AIR CONDITIONER
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram
6. Wiring Diagram
7. Reference Sheet
INDOOR UNIT OUTDOOR UNIT
AR07/09/12/15/18/24TSFABWKN
AR07/09/12/15/18/24TSFYBWKN
AJ009/012/018TNNDCH
AJ009/012/018TNLDCH
AJ009/012/015/018TNJDCH
AJ020TXJ2CH
AJ024TXJ3CH
AJ036TXJ4CH
AJ048TXJ5CH
AJ020TXS3CH
AJ024TXS4CH
AJ030TXS4CH
AJ036TXS4CH

Contents
1. Precautions···································································································································1-1
1-1 Precautions for the Service....................................................................................................1-1
1-2 Precautions forthe Static Electricity and PL.......................................................................1-1
1-3 During operation................................................................................................................... 1-2
1-4 Disposing of the unit ............................................................................................................ 1-2
1-5 Precautions for the Pump Down.......................................................................................... 1-2
1-6 Others..................................................................................................................................... 1-2
2. Product Specifications··············································································································· 2-1
2-1 The Feature of Product ......................................................................................................... 2-1
2-1-1 Features ......................................................................................................................... 2-1
2-2 Product Specifications..........................................................................................................2-3
2-2-1 Indoor Unit ....................................................................................................................2-3
2-2-2 Outdoor Unit................................................................................................................ 2-5
2-3 The Comparative Specifications of Product ...................................................................... 2-7
2-4 Combination Table (Outdoor-Indoor).................................................................................2-9
2-5 Accessory and Option Specifications ................................................................................2-11
2-5-1 Indoor Unit Accessories ............................................................................................ 2-11
2-5-2 Outdoor Unit Accessories.........................................................................................2-13
3. Disassembly and Reassembly··································································································· 3-1
3-1 Outdoor Unit ..........................................................................................................................3-2
3-1-1 AJ020TXJ3CH, AJ024TXJ3CH.................................................................................... 3-2
3-1-2 AJ036TXJ4CH, AJ020TXS3CH, AJ024TXS4CH, AJ030TXS4CH ............................ 3-5
3-1-3 AJ048TXJ5CH, AJ036TXS4CH..................................................................................3-12
4. Troubleshooting ························································································································ 4-1
4-1 Display and Check Method .................................................................................................. 4-1
4-1-1 Indoor unit .....................................................................................................................4-1
4-1-2 Outdoor Unit................................................................................................................ 4-4
4-2 Setting an indoor unit address and installation option.................................................. 4-6
4-3 Setting Option...................................................................................................................... 4-9
4-3-1 Setting Option...........................................................................................................4-10
4-3-2 The procedure of setting option ............................................................................ 4-10
4-3-3 Setting an indoor unit address (MAIN/RMC) ........................................................4-12
4-3-4 Setting an indoor unit installation option
(suitable for the condition of each installation location) ...................................4-13
4-3-5 Changing the addresses and option individually.................................................4-17
4-3-6 Changing a particular option.................................................................................. 4-18
4-4 Items to be checked first ..................................................................................................4-20

Contents
4-5 Setting to Cool orHeat onlymode, checking and Cool/Heat modes operation test ............................4-25
4-6 Fault Diagnosis by Symptom ............................................................................................4-27
4-6-1 Indoor.......................................................................................................................... 4-27
4-6-2 Outdoor unit is not powered on – Initial diagnosis .............................................4-31
4-6-3 Checking Outdoor Controller ................................................................................. 4-32
4-6-4 Outdoor unit fan error.............................................................................................. 4-33
4-6-5 Compressor startup error, Compressor lock error,
Compressor rotation error...................................................................................... 4-34
4-6-6 IPM Over current error............................................................................................. 4-35
4-6-7 Checking Temperature sensor................................................................................ 4-36
4-7 PCB Inspection ................................................................................................................... 4-38
4-7-1 Cautions for Part Replacement ............................................................................... 4-38
4-7-2 Procedure...................................................................................................................4-38
5. PCB Diagram······························································································································· 5-1
5-1 Indoor unit.............................................................................................................................. 5-1
5-2 Outdoor PCB Diagram ......................................................................................................... 5-8
6. Wiring Diagram ·························································································································· 6-1
6-1 Indoor Unit ............................................................................................................................. 6-1
6-2 Outdoor unit ......................................................................................................................... 6-4
7. Preference Sheet··························································································································7-1
7-1 Selecting Area for Installation ..............................................................................................7-1
7-1-1 Indoor Unit ..................................................................................................................... 7-1
7-1-2 Outdoor Unit..................................................................................................................7-2
7-1-3 Remote Control Unit ....................................................................................................7-2
7-2 Connecting Up and Purging the Circuit.............................................................................. 7-3
7-3 Refrigerant Refill................................................................................................................... 7-4
7-4 Refrigerant Adjustment ....................................................................................................... 7-5
7-5 Flare Nut Fixing Torque ........................................................................................................ 7-5
7-6 "Pump down" Procedure ......................................................................................................7-6
7-7 Index of Model Name............................................................................................................ 7-7
7-8 Refrigerating Cycle Diagram ............................................................................................. 7-10
7-9 Pressure & Capacity mark .................................................................................................. 7-14
7-10 The abbreviated technology words & the definition of technology terms ................ 7-14
7-11 Q & A for Non-trouble ........................................................................................................ 7-15
7-12 Common sense of refrigeration....................................................................................... 7-18

Precautions
Samsung Electronics 1-1
• If the power cord of the air conditioner is damaged, it must be replaced by
themanufacturer or a qualified person in order to avoid a hazard.
• The air conditioner must be plugged into an independent circuit if
applicable or connect the power cable to the auxiliary circuit breaker.
An all pole disconnection from the power supply must be incorporated in
the fixed wiring with a contact opening of >3mm.
• Do not extend an electric cord to the air conditioner.
• The air conditioner must be plugged in afteryou complete the
installation.
• Users should not install the air conditioner by themselves.
Ask the dealer or authorized company to install the air conditioner
except the window-type air conditioner in U.S.A and Canada.
• If you don’t install the air conditioner properly, it may cause a fire,
a water leakage or an electric shock.
• You must install the air conditioner according to the national wiring
regulations and safety regulations.
• Install the indoor unit higher than 2.5m from the floor to avoid
the injury caused by the operation of the fan.
(except the window-type air conditioner)
• The manufacturer is not responsible for any accidents or injury
caused by an incorrect installation.
When installing the built-in type air conditioner, keep all electric cables such as the power cable and the
connection cord in pipes, ducts, or cable channels to protect them from the danger of impact or any other incidents.
• More than 2 indoor units should be installed when you use Free Joint Multi air conditioner.
• AJ020TX**CH outdoor unit
- AR18/24TSF*BWKN, AJ018TNNDCH, AJ018TNLDCH, AJ018TNJDCH indoor units cannot be connected
AJ024TXJ3CH outdoor unit
- AR24TSF*BWKN indoor units cannot be connected
AJ024TXS4CH outdoor unit
- AR24TSF*BWKN, AJ018TNJDCH indoor units cannot be connected
1. Precautions
1-1 Precautions for the Service
su oreg na d
Avoid Dangerous Contact
1-2 Precautions for the Static Electricity and PL
No Tapping and No Extension Cords

Precautions
1-2 Samsung Electronics
1-3 During operation
• Do not repair the air conditioner at your discretion.
It is recommended to contact a service center directly.
• Never spill any kind of liquid on the air conditioner.
If this happens, turn off the air conditioner and contact an authorized
service center.
• Do not insert anything between the airflow blades to prevent damage
of the inner fan and consequent injury.
Keep children away from the air conditioner.
• Do not place any obstacles in front of the air conditioner.
• Do not spray any kind of liquid into the indoor unit. If this happens,
turn off the air conditioner and contact a service center.
• Make sure that the air conditioner is well ventilated at all times:
Do not place a cloth or other materials over it.
• Remove the batteries if you don’t use the remote control for a long time. (If applicable)
• Use the remote control within 7 meters from the indoor unit. (If applicable)
1-4 Disposing of the unit
• Before throwing out the air conditioner, remove the batteries from the remote control.
• When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant may
blow out and cause air pollution. When it contacts with your skin, it can cause skin injury.
• The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
No children Nearby
1-5 Precautions for the Pump Down
1-6 Others
• The pipes should have no leaks during installation, and the compressor must be stopped before removing
connecting pipes for pump down work. Operating the compressorwhile the service valve is open and coolant
pipe is not properly connected may cause explosion or injury due to abnormal high pressure created inside
the coolant cycle as the air can be absorbed through the pipe.
• Pump Down work procedure (When uninstalling the product)
- Turn on the air conditioner, select cooling operation, and run the compressor for more than 5 minutes.
- Release the high pressure and low pressure valve caps.
- Close the high pressure valve completely using an L-wrench.
- After about 2 minutes, close the low pressure valve completely.
• Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
• Young children or infirm persons should be always supervised when they use the air conditioner.
• Max current is measured according to IEC standard for safety.
• Current is measured according to ISO standard for energy efficiency.
• For servicing the units containing flammable refrigerants, safety checks are required to minimise the risk of
ignition.
•
Servicing shall be performed following the controlled procedure to minimize the risk of flammable refrigerant
or gases.
• For servicing with handling the R-32 refrigerant, use the special tools for the R32 refrigerant
(manifold gauge, vacuu pump, charging hose, etc.).

Product Specifications
Samsung Electronics 2-1
2. Product Specifications
2-1 The Feature of Product
2-1-1 Features
FJM (Free Joint Multi)
 Ɵ˵ʪϑΧʪθʒʪϑ˝ͱ˙ϩ˵ʪͱЇϩʒͱͱθЇϩЇϑʪϑϑΧɇʀʪͱθʪʪ˙ѣʀʪϩцࢋ
Universal Connection
Multi Inverter(Free Joint Multi) Series delivers comfort to 2~5 rooms with a Single Outdoor Unit.
Free Joint Multi added Universal indoor units, which can be universally connected to other Samsung
outdoor units, to all lineup.
ǤɇθͱЇϑÃʒͱͱθЇϩϑʀͱɵɇϩͱϑ
· QMD Wind-Free
· QMD Normal
· Wind-Free Mini 4way Cassette
· Home Duct
· Console

Product Specifications
2-2 Samsung Electronics
Їϩͱʒʒθʪϑϑ˝ЇϩͱťΧʪÃϑΧʪʀϩͱ
Improved Installation Procedure
- It can automatically set the address of the indoor unit and inspect pipes with one push of the button.
Installation is very simple.
âߡߣߡƟǹâߣA²ࢥâߡߣߥƟǹâߤA² âߡߤߧƟǹâߥA²ࢥâߡߥߩƟǹâߦA²ࢥâߡߣߡƟǹƊߤA²ࢥ
âߡߣߥƟǹƊߥA²ࢥâߡߤߡƟǹƊߥA²ࢥâߡߤߧƟǹƊߥA²
Ɗʪϩϩ˝ϩͱAͱͱͱθ²ʪɇϩͱцͱʒʪ
Ɵ˵ϑ˙Їʀϩͱʪɇɵʪϑϩ˵ʪʒͱͱθЇϩϑʀͱʪʀϩʪʒϩͱϩ˵ʪͱЇϩʒͱͱθЇϩϩͱͱΧʪθɇϩʪɇϑΧʪʀѣʀͱʒʪࢋ
When you want to operate all indoor units with the cooling mode or heating mode.
ǮࣗЇʀϩͱ࣍ƊɇθϩƟ˵˝ϑɇΧΧ࣎
SmartThings app is the easy way to turn your home into a smart home.
Control the FJM with only one application.
This feature is optional to the several models.

Product Specifications
Samsung Electronics ߣࣗߤ
2-2 Product Specifications
2-2-1 Indoor Unit
Type Cassette
Model Mini 4Way
AJ009TNNDCH AJ012TNNDCH AJ018TNNDCH
Performance Capacity Cooling Btu/h 8900 11900 17700
Heating 9900 13000 19100
Noise High/Mid/Low dB(A)
33/29/24 35/31/27 39/36/32
Power
Power ڕࡡǤࡡ²і 1, 208-230, 60 1, 208-230, 60 1, 208-230, 60
Power
Consumption
Cooling W19.0 22.0 28.0
Heating 19.0 22.0 28.0
Operating
Current
Cooling A0.51 0.52 0.53
Heating 0.51 0.52 0.53
Size
Net Size W*H*D mm 575*250*575 575*250*575 575*250*575
Net Weight kg 11.5 11.5 11.8
Panel Size W*H*D mm 670*45*670 670*45*670 670*45*670
Panel Weight kg
2.6 2.6 2.6
Part
Refrigerant
Pipe
Liquid mm 6.35 6.35 6.35
Gas 9.52 9.52 12.7
Fan Type - Turbo Fan Turbo Fan Turbo Fan
Fan Motor Type - BLDC BLDC BLDC
Code - DB31-00578C DB31-00578C DB31-00578C
Heat Exchanger Row, Step 2R*8S 2R*8S 2R*10S
Refrigerant Control Device - kkǤĘĮƟÃĘAøƸUkU kkǤĘĮƟÃĘAøƸUkU kkǤĘĮƟÃĘAøƸUkU
Type Duct
Model Home Duct
AJ009TNLDCH AJ012TNLDCH AJ018TNLDCH
Performance Capacity Cooling Btu/h 8900
11900 17700
Heating 9900 13000 19100
Noise High/Mid/Low dB(A) 28/25/23 30/25/23 33/29/23
Power
Power ڕࡡǤࡡ²і
1, 208-230, 60 1, 208-230, 60 1, 208-230, 60
Power
Consumption
Cooling W
50.0 50.0 50.0
Heating 50.0 50.0 50.0
Operating
Current
Cooling A
0.45 0.45 0.45
Heating 0.45 0.45 0.45
Size
Net Size W*H*D mm
900 x 199 x 440 900 x 199 x 440 900 x 199 x 440
Net Weight kg 18.9 18.9 18.9
Refrigerant Pipe
Liquid mm 6.35 6.35 6.35
Gas 9.52 9.52 12.7
Part
Fan Type - Cross Flow Fan Cross Flow Fan Cross Flow Fan
Fan Motor Type - BLDC BLDC BLDC
Code - DB61-00671A DB61-00671A DB61-00671A
Heat Exchanger Row, Step 2R*10S 2R*10S 2R*10S
Refrigerant Control Device - kkǤĘĮƟÃĘAøƸUkU kkǤĘĮƟÃĘAøƸUkU kkǤĘĮƟÃĘAøƸUkU

Product Specifications
2-4 Samsung Electronics
Type Floor Standing
Model Console
AJ009TNJDCH AJ012TNJDCH
AJ015TNJDCH AJ018TNJDCH
Performance
Capacity Cooling Btu/h 8900 11900
15000 17700
Heating 9900 13000 18000 19100
Noise Cooling dB(A)
41 42 47 47
Heating 43 44 49 49
Power
Power עࡡǤࡡ²і 1, 208-230, 60 1, 208-230, 60
1, 208-230, 60 1, 208-230, 60
Power
Consumption
Cooling W30.0 35.0
50.0 50
Heating 30.0 35.0
50.0 50
Operating
Current
Cooling A0.25 0.29
0.35 0.35
Heating 0.25 0.29
0.35 0.35
Size Net Size W*H*D mm 720*620*199 720*620*199
720*620*199 720*620*199
Net Weight kg 15.7 15.7
15.7 15.7
Part
Refrigerant Pipe Liquid mm 6.35 6.35
6.35 6.35
Gas 9.52 9.52
12.7 12.7
Fan Type - Cross Flow Fan Cross Flow Fan
Cross Flow Fan Cross Flow Fan
Fan Motor Type - BLDC BLDC
BLDC BLDC
Code - DB31-00517A DB31-00517A
DB31-00517A DB31-00517A
Heat Exchanger Row, Step 2R*20S 2R*20S
2R*20S 2R*20S
Refrigerant Control Device - kkǤĘĮƟ
INCLUDED
kkǤĘĮƟ
INCLUDED
kkǤĘĮƟ
INCLUDED
kkǤĘĮƟ
INCLUDED

Product Specifications
Samsung Electronics 2-5
2-2-2 Outdoor Unit
Type Free Joint Multi
Model AJ020TXJ2CH/AA AJ024TXJ3CH/AA AJ036TXJ4CH/AA AJ048TXJ5CH/AA
Performance
Capacity Cooling Btu/h 18000 22000 32000 47000
Heating 22000 25000 36000 48500
Noise Sound
Pressure dB(A) 48.0 48.0 54.0 52.0
Power
Power עࡡǤࡡ²і 1, 208-230, 60 1, 208-230, 60 1, 208-230, 60 1, 208-230, 60
Power
Consumption
Cooling W1410 1730 2560 4470
Heating 1730 1780 2830 3790
Operating
Current
Cooling A6.4 7.9 11.7 20.5
Heating 7.8 8.1 12.9 16.9
Size Net Size W*H*D mm 880 x 798 x 310 880 x 798 x 310 940 x 998 x 330 940 x 1,210 x 330
Net Weight kg 53.0 57.0 76.5 90.5
Part
Refrigerant
Pipe
Liquid mm 6.35*2 6.35*3 6.35*4 6.35*5
Gas 9.52*2 9.52*2+12.7*1 9.52*2+12.7*2 9.52*2+12.7*3
Compressor
Type - Twin BLDC Rotary BLDC Rotary Twin BLDC Rotary Twin BLDC Rotary
Model Name - UG4T200FUAE4 G8T260FUAEW KTF310D43UMT KTF310D43UMT
Output kW 5.919 7.766 10.01 10.01
Fan Motor Type - BLDC BLDC BLDC BLDC
Code - DB31-00579A DB31-00579A DB31-00579A DB31-00579A
Heat Exchanger Row,
Step 2R*36S 2R*36S 2R*46S 2R*56S
Refrigerant Control Device - kkǤ kkǤ kkǤ kkǤ
Refrigerant Type - R-410A R-410A R-410A R-410A
Factory Charging g 2200 2650 3100 3800

Product Specifications
ߣࣗߧ Samsung Electronics
Type Free Joint Multi
Model AJ020TXS3CH/AA AJ024TXS3CH/AA AJ030TXS4CH/AA AJ036TXS4CH/AA
Performance
Capacity Cooling Btu/h 21000 25000 28400 34000
Heating 22000 25000 28600 36600
Noise Sound
Pressure dB(A) 54.0 54.0 54.0 52.0
Power
Power עࡡǤࡡ²і 1, 208-230, 60 1, 208-230, 60 1, 208-230, 60 1, 208-230, 60
Power
Consumption
Cooling W1550 1920 2270 2720
Heating 1620 1840 2100 2520
Operating
Current
Cooling A6.9 8.7 10.2 12.5
Heating 7.2 8.3 9.5 11.2
Size Net Size W*H*D mm 940 x 998 x 330 940 x 998 x 330 940 x 998 x 330 940 x 1,210 x 330
Net Weight kg 76.0 76.5 76.5 90.5
Part
Refrigerant
Pipe
Liquid mm 6.35*3 6.35*4 6.35*4 6.35*4
Gas 9.52*2+12.7*1 9.52*2+12.7*2 9.52*2+12.7*2 9.52*2+12.7*2
Compressor
Type - Twin BLDC Rotary Twin BLDC Rotary Twin BLDC Rotary Twin BLDC Rotary
Model Name - UG8T300FUBJU UG8T300FUBJU UG8T300FUBJU KTF310D43UMT
Output kW 9.171 9.171 9.171 10.01
Fan Motor Type - BLDC BLDC BLDC BLDC
Code - DB31-00579A DB31-00579A DB31-00579A DB31-00579A
Heat Exchanger Row,
Step 2R*46S 2R*46S 2R*46S 2R*56S
Refrigerant Control Device - kkǤ kkǤ kkǤ kkǤ
Refrigerant Type - R-410A R-410A R-410A R-410A
Factory Charging g 3400 3400 3400 3600

Product Specifications
Samsung Electronics 2-8
Product Specifications
2-7 Samsung Electronics
2-3 The Comparative Specifications of Product
Item AJ020TXJ2CH AJ024TXJ3CH AJ036TXJ4CH AJ048TXJ5CH AJ020TXS3CH AJ024TXS4CH AJ030TXS4CH AJ036TXS4CH
Design
Outdoor
Unit
Indoor
Unit
Net
Weigth
[kg]
Outdoor
Unit AJ020TXJ2CH 53.0 AJ024TXJ3CH 57.0 AJ036TXJ4CH 76.5 AJ048TXJ5CH 90.5 AJ020TXS3CH 76.0 AJ024TXS4CH 76.5 AJ030TXS4CH 76.5 AJ036TXS4CH 90.5
Indoor
Unit
AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1 AR07/09/12/15TSFABWKN 10.1
AR18TSFABWKN 12.5 AR18TSFABWKN 12.5 AR18TSFABWKN 12.5 AR18TSFABWKN 12.5 AR18TSFABWKN 12.5 AR18TSFABWKN 12.5
AR24TSFABWKN 12.5 AR24TSFABWKN 12.5 AR24TSFABWKN 12.5 AR24TSFABWKN 12.5
AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2 AR07/09/12/15TSFYBWKN 9.2
AR18TSFYABWKN 11.5 AR18TSFYABWKN 11.5 AR18TSFYABWKN 11.5 AR18TSFYABWKN 11.5 AR18TSFYABWKN 11.5 AR18TSFYABWKN 11.5
AR24TSFYABWKN 11.5 AR24TSFYABWKN 11.5 AR24TSFYABWKN 11.5 AR24TSFYABWKN 11.5
AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5 AJ009/012TNNDCH 11.5
AJ018TNNDCH 11.8 AJ018TNNDCH 11.8 AJ018TNNDCH 11.8 AJ018TNNDCH 11.8 AJ018TNNDCH 11.8 AJ018TNNDCH 11.8
AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9 AJ009/012TNLDCH 18.9
AJ018TNLDCH 18.9 AJ018TNLDCH 18.9 AJ018TNLDCH 18.9 AJ018TNLDCH 18.9 AJ018TNLDCH 18.9 AJ018TNLDCH 18.9
AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7 AJ009/012TNJDCH 15.7
AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7 AJ015TNJDCH 15.7
AJ018TNJDCH 15.7 AJ018TNJDCH 15.7 AJ018TNJDCH 15.7 AJ018TNJDCH 15.7 AJ018TNJDCH 15.7

Product Specifications
Samsung Electronics 2-10
Product Specifications
2-9 Samsung Electronics
Model
AJ020TXJ2CH AJ024TXJ3CH AJ036TXJ4CH AJ048TXJ5CH AJ020TXS3CH AJ024TXS4CH AJ030TXS4CH AJ036TXS4CH
Model Capacity 20K 24K 36K 48K 20K 24K 30K 36K
AR07/09/12/15/18/24TSFABWKN
7 KBtu مممممممم
9 Kbtu مممممممم
12 Kbtu مممممممم
15 Kbtu مممممممم
18 Kbtu ممم ممم
24 Kbtu مم مم
AR07/09/12/15/18/24TSFYBWKN
7 KBtu مممممممم
9 Kbtu مممممممم
12 Kbtu مممممممم
15 Kbtu مممممممم
18 Kbtu ممم ممم
24 Kbtu مم مم
AJ009/012/018TNNDCH
9 Kbtu مممممممم
12 Kbtu مممممممم
18 Kbtu ممم ممم
AJ009/012/018TNLDCH
9 Kbtu مممممممم
12 Kbtu مممممممم
18 Kbtu ممم ممم
AJ009/012/015/018TNJDCH
9 Kbtu مممممممم
12 Kbtu مممممممم
15 Kbtu مممممممم
18 Kbtu ممم مم
2-4 Combination Table (Outdoor-Indoor)
Outdoor Unit
Indoor Unit

Product Specifications
2-11 Samsung Electronics
2-5 Accessory and Option Specifications
2-5-1 Indoor Unit Accessories
đߥǮɇц
Item Descriptions Code No. Q'ty Remark
Ass'y drain hose Joint U9ߪߥࣗߡߤߣߩߨ 1
Indoor
Unit
Cable-tie U9ߧߦࣗߢߡߡߩߩA ߧ
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩ
øߣߣߡࡡÃUߥߦ 1
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩ²
øߢߦߡࡡÃUߤߡ 1
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩâ
øߣߡߡࡡÃUߦߦ 1
User Manual U9ߧߩࣗߡߩߨߤߩ 1
Installation Manual U9ߧߩࣗߡߩߨߤߥ 1
࢘Ɵ˵ʪʒʪϑ˝ɇʒϑ˵ɇΧʪʀɇɵʪʀ˵ɇ˝ʪʒɇʀʀͱθʒ˝ϩͱϩ˵ʪͱʒʪࢋ

Product Specifications
Samsung Electronics 2-12
²ͱʪUЇʀϩ
Item Descriptions Code No. Q'ty Remark
User Manual U9ߧߩࣗߡߩߨߥߡ 1
Indoor
Unit
Installation Manual U9ߧߩࣗߡߩߨߤߧ 1
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩ
øߣߣߡࡡÃUߥߦ
1
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩ
øߣߡߡࡡÃUߤߦ
1
Insulation-Drain Hose U9ߧߣࣗߢߢߡߣߩk
øߣߡߡࡡÃUߤߦ
4
Rubber
(Grommet Hanger)
U9ߧߤࣗߡߡߣߤߨ ߩ
Insulation-Drain U9ߧߣࣗߡߥߤߢߩƊ 1
Ass'y Drain Hose Joint U9ߪߥࣗߡߧߪߧߥ9 1
Cable-Tie U9ߧߦࣗߢߡߡߩߩA ߩ
࢘Ɵ˵ʪʒʪϑ˝ɇʒϑ˵ɇΧʪʀɇɵʪʀ˵ɇ˝ʪʒɇʀʀͱθʒ˝ϩͱϩ˵ʪͱʒʪࢋ

Product Specifications
ߣࣗߢߤ Samsung Electronics
2-5-2 Outdoor Unit Accessories
Item Descriptions Code No. Q'ty Remark
Drain Plug
DB67-00477A
(AJ020TXJ2CH, AJ024TXJ3CH)
1
DB67-00806A
(AJ036TXJ4CH, AJ048TXJ5CH,
AJ***TXS*CH)
Rubber Leg DB73-20134A 4
Installation Manual
DB68-08737A
(AJ020TXJ2CH, AJ024TXJ3CH)
1
DB68-08940A
(AJ036TXJ4CH, AJ048TXJ5CH,
AJ***TXS*CH)
Nipple Connector DB67-00789A
1
(AJ020TXJ2CH)
2
(AJ024TXJ3CH)
ߢߣࢋߨߪࢋߦߣ
Flare Nuts DB60-30010B
1
(AJ020TXJ2CH)
2
(AJ024TXJ3CH)
ߢߣࢋߨߪࢋߦߣ
Ass'y Tube
Connector
DB96-16155A
2
(AJ***TX*4CH)
3
(AJ***TX*5CH)
ߢߣࢋߨߪࢋߦߣ
DB96-16155B
2
(AJ020TXS3CH,
AJ***TX*4CH,
AJ***TX*5CH)
ߢߣࢋߨߢߦࢋߩߩ
࢘Ɵ˵ʪʒʪϑ˝ɇʒϑ˵ɇΧʪʀɇɵʪʀ˵ɇ˝ʪʒɇʀʀͱθʒ˝ϩͱϩ˵ʪͱʒʪࢋ
âࡐࡐࡐƟǹࡐࡐA²

Disassembly and Reassembly
Samsung Electronics 3-1
Item Remark
+Screw driver
Monkey spanner
ĘʪʀʪϑϑɇθцƟͱͱϑ
3. Disassembly and Reassembly

Disassembly and Reassembly
3-2 Samsung Electronics
3-1 Outdoor Unit
No Parts Procedure Remark
1 Common Work
&
Control Out
You must turn off the Power before
disassembly.
1) Loosen 4 fixing screws(CCW) of the Cover-
Valve. (Use +Screw Driver).
2) Loosen each 9 screws(CCW) on Cabi-Top.
(Use +Screw Driver).
3) Loosen 2 screws(CCW) fixed to assemble
Plate Control Out with Cabinet-Side RH.
(Use +Screw Driver.)
4) Loosen 10 fixing screws(CCW) on Cabinet-
Side RH. (Use +Screw Driver.)
3-1-1 AJ020TXJ3CH, AJ024TXJ3CH

Disassembly and Reassembly
Samsung Electronics 3-3
No Parts Procedure Remark
5) Loosen each 7 screws (CCW) on Cabinet
Front.
(Use +Screw Driver.)
6) Loosen each 4 screws (CCW) on Cabinet-
Side LF.
(Use +Screw Driver.)
2 Ass’y
Control Out
1) Detach the Motor Wire from the PCB of
Ass'y Control Out.
2) Detach comp wire and pressure switch-
wire from the PCB of A’ssy Control Out.
3) Detach 2 Connect Wires from Reactor.

Disassembly and Reassembly
3-4 Samsung Electronics
No Parts Procedure Remark
4) Detach several connectors from the PCB
of Ass'y Control Out.
5) Loosen 2 screws (CCW) fixed to assemble
Ass'y Control Out with Partition.
(Use +Screw Driver.)
3Fan
&
Motor
1) Loosen the fixing nut (CW) and detach
the Fan.
(Use Monkey Spanner.)
2) Loosen 4 fixing bolts and detach the
Motor. (Use +Screw Driver.)
3) Loosen 2 fixing screws and detach the
Bracket Motor. (Use +Screw Driver.)
4HeatExchanger
&
Compressor
1) Release the refrigerant at first.
2) Disassemble the Inlet and Outlet Pipe by
welding.
3) Loosen the fixing 3 screws of the
Heat Exchanger. (Use +Screw Driver.)
4) Detach the Heat Exchanger.
Befor you disassemble the pipes and
Condensor, be sure that there should be
no refrgerant remained in the unit.
5) Loosen 3 nuts of the Compressor.
(Use Monkey Spanner.)
6) Detach the Compressor.
