Contents
1. Precautions 4
1-1 Installing the air conditioner 4
1-2 Power supply and circuit breaker 4
1-3 During operation 4
1-4 Disposing of the unit 5
1-4 Others 5
2. Product Specications 6
2-1 The Feature of Product 6
2-2 Product Specifications 7
2-3 The comparative specifications of product 8
2-4 Accessory and option specifications 9
3. Alignment and Adjustments 10
3-1 Test mode 10
3-2 Display Error and Check Method 11
3-3 Setting Option Setup Method 13
4. Disassembly and Reassembly 18
4-1 Indoor Unit 19
4-2 Outdoor Unit 25
5. ASSY CONTROL 36
5-1 ASSY KIT CODE DB92-04454D 36
5-2 ASSY KIT CODE DB92-04454H 37
5-3 ASSY KIT CODE DB92-04376B 38
5-4 ASSY KIT CODE DB92-04378B 39
5-5 ASSY KIT CODE DB92-04379B 40
6. Electrical Parts List 41
6-1 INDOOR MAIN PCB CODE DB92-03467G 41
6-2 OUTDOOR MAIN PCB CODE DB92-04029D 47
6-3 OUTDOOR PCB INVERTER CODE DB92-04025C 51
6-4 OUTDOOR PCB INVERTER CODE DB92-04027B 59
7. Wiring Diagram 67
7-1 Indoor unit 67
7-2 Outdoor unit 68
8. PCB Diagram 70
8-1 Indoor main PCB code 70
8-2 Outdoor main PCB code 71

2 3
Contents
9. Operating Instructions 76
9-1 Name of Each Part 76
9-2 Wireless Remote Control-Buttons and Display 77
10. Troubleshootin 78
10-1 Items to be checked First 78
10-2 Communication Error 79
10-2-1 Communication Error 79
10-2-2 Indoor temperature sensor Error 80
10-2-3 Indoor fan motor speed detecting error (BLDC fan) 81
10-2-4 Outdoor temperature sensor error 82
10-2-5 Outdoor Cond temperature sensor error 83
10-2-6 Outdoor Discharge temperature sensor error 84
10-2-7 Operation condition secession error 85
10-2-8 EEPROM error/OTP error 86
10-2-9 Outdoor Fan motor error 87
10-2-10 Compressor starting error 88
10-2-11 Compressor wire missing error/rotation error 89
10-2-12 Current sensor error/Input current sensor error 90
10-2-13 O.C(Over Current) error 91
10-2-14 No power outdoor (Initial Diagnosis) (Not displayed) 93
10-2-15 When the Up/Down, Left/Right, Grill louver motor does not operate 94
10-2-16 When the remote control is not receiving 95
10-2-17 Smart Install error 96
10-2-18 Outdoor OLP over temperature error (One way Inverter Only) 97
11. Block Diagram 98
11-1 Indoor unit 98
11-2 Outdoor unit 99
12. Reference Sheet 102
12-1 Low Refrigerant Pressure Distribution 102
12-2 Pressure & Capacity mark 102
12-3 Q & A for Non-trouble 103
12-4 Cleaning /Filter Change 106
12-5 Installation 107
12-6 Installation Diagram of Indoor Unit and Outdoor Unit 108
12-7 Reference sheet 111

4
1-1 Installing the air conditioner
• Uses should not install the air conditioner by themselves. Ask the dealer or authorized company to install
the air conditioner except window-type air conditioner in U.S.A and Canada.
• If you don't install the air conditioner properly, it may cause a fire, a water leakage or an electric shock.
• You must install the air conditioner according to the national wiring regulations and safety regulations.
• Install the indoor unit higher than 2.5m from the floor to avoid the injury caused by the operation of the fan.
(except the window-type air conditioner)
• The manufacturer is not responsible for any accidents or injury caused by an incorrect installation.
• When installing the built-in type air conditioner, keep all electric cables such as the power cable and the
connection cord in pipes, ducts, or cable channels to protect them from the danger of impact or any other
incidents.
1-2 Powersupply and circuit breaker
• If the power cord of the air conditioner is damaged, it must be replaced by the manufacturer or a qualified
person in order to avoid a hazard.
• The air conditioner must be plugged into an independent circuit if applicable or connect the power cable to
the auxiliary circuit breaker. An all pole disconnection form the power supply must be incorporated in the
fixed wiring with a contact opening of>3mm.
• Do not extend an electric cord to the air conditioner.
• The air conditioner must be plugged in after you complete the installation.
1-3 During operation
• Do not repair the air conditioner at your discretion. It is recommended to contact a service center directly.
• Never spill any kind of liquid on the air conditioner. If this happens, turn off the air conditioner and contact
an authorized service center.
• Do not insert anything between the airflow blades to prevent damage of the inner fan and consequent
injury. Keep children away from the air conditioner.
• Do not place any obstacles in front of the air conditioner.
• Do not spray any kind of liquid into the indoor unit. If this happens, turn off the air conditioner and contact
a service center.
• Make sure that the air conditioner is well ventilated at all times. Do not place a cloth or other materials over
it.
• Remove the batteries if you don't use the remote control for a long time. (If applicable)
• Use the remote control within 7 meters from the indoor unit. (If applicable)
1. Precautions

5
1-4 Disposing of the unit
• Before the throwing out the air conditioner, remove the batteries from the remote control.
• When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant
may blow out and cause air pollution. When it contacts with your skin, it can cause skin injury.
• The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
1-5 Others
• Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
• Young children or infirm persons should be always supervised when they use the air conditioner.
• Max current is measured according to IEC standard for safety.
• Current is measured according to ISO standard for energy efficiency.

6
2-1 The Feature of Product
u2-step cooling
2-step cooling function will quickly cool the room to reach the desired temperature and then
it will adjust the fan speed and ai ow direction automatically to help you stay comfortable and
refreshed.
uFast cooling
If you want the strong and cool air, just select Fast function! It will get you the strongest air!
uComfort cooling
If you want the comfortable and refreshing air, Comfort function will spread the cool air indirectly
to you, so that you can stay comfortable.
uSingle User
Use the Single User function when you’re along at home. Aside from energy savings from the
inverter technology, the Single User Mode will further minimize your energy consumption and
reduce your electricity bill by adjusting the maximum operating capacity of the compressor.
uEasy Filter
Thereisnogrilletoremovebeforeseparatingthelterfromtheairconditioner!Therefore,lter
canbecleanedeasilyandmorefrequently.Constantltercleaningwillpreventdustfromenter-
ingtheproductoraccumulatingonthelter.
ugood’sleep function
good’sleep function will allow you to have deep, good night’sleep by adjusting the temperature,
fanspeedandairowdirection.
uSmart Install
When the installation is done, your product will examine itself through trial operation to check if
it was installed properly.
uEasy Installation
It’s so easy to install! You can easily hang the product on the wall and connect the pipes
and wires by opening the cover on the bottom of the product. Now you won’t have to tilt
the product to connect the pipe and the wires!
2. Product Specications

7
2-2 Product specication
Model AR09RXFPEWQ/EU AR12RXFPEWQ/EU AR18RXFPEWQ/EU AR24RXFPEWQ/EU
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool W 2750 3500 5000 6500
T3 Cool W - - - -
Heat W 3200 3500 6000 7400
Power
Input
T1 Cool W 820 1220 1390 1950
T3 Cool W - - - -
Heat W 850 940 1745 2350
Current
T1 Cool A 4.0 5.6 6.4 8.8
T3 Cool A - - - -
Heat - 4.0 4.3 7.9 10.5
Efciency
EER W/W 3.35 2.87 3.6 3.33
- - - - -
COP W/W 3.76 3.72 3.44 3.15
Dehumidifying l/hr. 0.8 0.8 0.8 0.8
Platform IDU - MALDIVES 1 MALDIVES 1 MALDIVES 3 MALDIVES 3
ODU - N-V2MD N-V2MD Q-480 Q-480
Evap
Main - Φ7,2R*10S*605mm,
H1.3, N.G.S, 1by2
Φ7,2R*8S*635mm,H1.3,
N.G.S, 1by2
Φ7,2R*10S*850mm,
H1.3, N.G.S, 5by5
Φ7,2R*10S*850mm,
H1.2, N.G.S, 5by5
Sub -Φ7,2R*4S*575mm,H1.3,
N.G.S : (4-1-5)
Φ7,2R*6S*635mm,H1.3,
N.G.S : (F03-2-1-1)
Φ7,2R*5(6)S*830mm,
H1.3, N.G.S : (4-3-3)
Φ7,2R*5(6)S*830mm,
H1.3, N.G.S : (4-3-4)
Cond Main - Φ7W,2R*20(21)
S*639/611mm,Corru-
gate1.5, N.G.S, 4by4by2
Φ7W,2R*20(21)
S*639/611mm,Corru-
gate1.5, N.G.S, 4by4by2
Φ7W,2R*28S*906.8mm,
Corrugate1.5, N.G.S,
4by4by1
Φ7W,2R*28S*906.8mm,
Corrugate1.5, N.G.S,
4by4by1
Sub -----
Comp Model - UB9AK1090FJR UB9AK1090FJR UB9TK3150FE4 UB9TK2150FE4
OLP - - - - -
Motor In Code - DB31-00636C DB31-00636C DB31-00609A DB31-00609A
Name - - - - -
Motor Out Code - DB31-00642C DB31-00642C DB31-00642D DB31-00658D
Name - - - - -
Expansion Φ*L -EEVΦ1.4 EEVΦ1.4 EEVΦ1.4 EEVΦ1.4
Refrigerant type - R-32 R-32 R-32 R-32
charge g 700 g 700 g 1150 g 750 g
SVC Valve Liquid / Gas - 6.35/9.52 6.35/9.52 6.35/12.7 6.35/15.88
Tube Dis. / Suc. - 9.52/9.52 9.52/9.52 7.94/12.7 9.52/12.7
Drain hose D*L mm 20*550 20*550 20*550 20*550
4-WAY V/V - 1 HP 1 HP 2HP 2 HP
Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1 220-240/50/1 220-240/50/1
Climate Class - T1 T1 T1 T1
Noise IDU UT,T dB 56 59 58 63
ODU dB 63 65 65 69
Net Size
(W*D*H)
IDU mm 820*280*215 820*280*215 1065*298*230 1065*298*230
ODU 660*475*242 660*475*242 880*638*310 880*638*310
Weight IDU kg 8 8 11.6 11.6
ODU 22.8 22.8 40.2 44.2
Operation
range
Cooling IDU 16˚C~32˚C 16˚C~32˚C 16˚C~32˚C 16˚C~32˚C
ODU -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C -10 °C to 46 °C
Heating IDU 27 °C or less 27 °C or less 27 °C or less 27 °C or less
ODU -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C -15 °C to 24 °C

8
2-3 The comparative specication of product
Model DEVELOPMENT MODEL
AR09RXPXBWK/EU AR12RXPXBWK/EU
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 8 8
Outdoor Unit 22.8 22.8
Net Dimension Indoor Unit 820*280*215 820*280*215
Outdoor Unit 660*475*242 660*475*242
Noise Indoor Unit 56 59
Outdoor Unit 63 65
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 3 LED 3 LED
Model DEVELOPMENT MODEL
AR18RXFPEWQ/EU AR24RXFPEWQ/EU
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 11.6 11.6
Outdoor Unit 40.2 44.2
Net Dimension Indoor Unit 1065*298*230 1065*298*230
Outdoor Unit 880*638*310 880*638*310
Noise Indoor Unit 58 63
Outdoor Unit 65 69
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 3 LED 3 LED

9
2-4 Accessoray and option specications
Item Descriptions Code No. Q’ty Remark
ASSY-PLATE HANGER
DB90-04558A
(M1) 1
Indoor unit case
DB90-06524A
(M3) 1
ASSY WIRELESS REMOCON DB93-15882Q 1
BATTERY 4301-000121 2
MANUAL USERS DB68-08176A 1
MANUAL INSTALL DB68-08177A 1
Rubber Leg DB67-01533A 4
Outdoor unit case
Drain plug DB67-20011A 1

10
3-1 Test Mode
u
How to Approach Test Mode
You can approach the test mode by pressing the on/off
switch of indoor unit for 5 seconds.
u
Test mode operation option
After installing the air conditioner, check whether each subordinate is normally operated or not by
operating the test mode.
• When an Error occurs, display the Error Mode.
• Operation Mode : Cool mode. operate the cool mode by operating the compressor by force
without the compressor ON/OFF according to the set temperature/indoor temperature. (Do not
follow the antifreeze control)
• Up-down louver : Up-down swing mode
• Indoor Fan : Turbo
Note
• Because the heat mode operate the cool mode by force not related to the set temperature
/ indoor temperature, check whether each subordinate is operated normally or not after
completing installation and must turn off the power of the air conditioner.
3. Alignment and Adjustments

11
3-2 Display Error and Check Method
3-2-1 Indoor Display Error and Check Mathod
ERROR MODE
DESCRIPTION
7-SEG LED1 LED2 LED3
Operation Timer Option
E101 , E102 Communication error
(Indoor <-> Outdoor)
E121 ROOM TH sensor error
E122, E123 INDOOR MID, INDOOR IN PIPE-TH
sensor error
E154 Fan error (Indoor)
E162 EEPROM error
E163 Option error
FROM E200 Outdoor error display
E203 Time out comm. (Inv Micom <-> Main Micom)
E422 / E554 EEV or valve close error-Self diagnosis/ Gas
Leak error
E458 Outdoor and Fan error
E461 Comp.starting error
E463 No display about the outdoor condition
E464 IPM over current (O.C) error
E465 Com V_limit/I_limit error
E500 Heatsink overheat or IPM overheat
:LAMP ON : LAMP OFF : LAMP BLINK
*Note*
If the set doesn’t work (No power), check the thermal fuse of terminal block OPEN or
SHORT with Multimeter.
*MeasurethethermalfusehousingPIN#1~2:OPEN(disconnection)->defectiveproduct

12
3-2 Display Error and Check Method
3-2-2 Outdoor Display Error and Check Mathod
ERROR MODE DESCRIPTION
7-SEG YEL GRN RED
-Power off /VDD NG
-Power on reset (1sec)
-Normal operation
-Abnormal communication
(Indoor <-> Outdoor)
-
E464 IPM over current (O.C) error
E461 Comp. strating error
E470 EEPROM data error (no data)
E466 DC-Link voltage under / Over error
E484 PFC over load error
E483 Over voltage protection error
E221 OUT-TH (Outdoor temperature) sensor error
E416 DIS-TH (Discharge temperature) Over error
E251 DIS-TH (Discharge temperature) sensor error
E468 Current sensor error
E474 Heatsink sensor error
E485 Input current sensor error
E465 Comp. V_limit/ I_limit error
E500 Heatsinkover temperature error
E231 CON-TH (Cond temperature) sensor error
E203 Time out Comp. (Inv Micom <->Main Micom)
E458 Fan error
E471
EEPROM data error (Main Micom <-> INV Micom)
E467 Comp. wire missing error
E440 Prohibit operation condition error (Heating)
E441 Prohibit operation condition error (Cooling)
E469 DC-Link voltage sensor
E488 AC Input voltage sensor
E462 AC Input I_limit trip error
E554 Gas leak error
E422 EEV or valve close error-self diagnosis
E462 Outdoor OLP over temperature error
-Test operation at Cooling mode
-Test operation at Heating mode
:LAMP ON : LAMP OFF : LAMP BLINK

13
3-3 Setting Option Setup Method
Step 2
Enter the Options Setup mode and select your options asscording to the following procedure.
Ex) Option No. :
Step 1
Enter the Option Setup mode.
1. Tack out the batteries of remote control.
2. Press the temperaturebutton simultaneously and insert the battery again.
3. Make sure the remote control display shown as
Setting option SEG1
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Cool mode.
5
4
3
2
1
MethodDisplay
Setting option SEG2
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG3
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG4
Press the button the display panel to .
Press the button repeatedly to select .
⋯

14
6
7
8
9
10
11
12
13
14
Method Display
Press the button to set Dry mode.
Setting option SEG5
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG6
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG7
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG8
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG9
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG10
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Fan mode.
Press the button to set Heat mode.

15
15
16
17
18
19
20
21
22
23
MethodDisplay
Setting option SEG16
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG15
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG14
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG13
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG11
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG12
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Auto mode.
Press the button to set Cool mode.
Press the button to set Dry mode.

16
24
25
26
27
28
29
설정방 법표시 부
Press the button to set Fan mode.
Press the button to set Heat mode.
Setting option SEG17
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG18
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG19
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG20
Press the button the display panel to .
Press the button repeatedly to select .
⋯

17
24
25
26
27
28
29
설정방 법표시 부
Press the button to set Fan mode.
Press the button to set Heat mode.
Setting option SEG17
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG18
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG19
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG20
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Option code :
Model Option code
AR09RXFPEWQ/EU 014005-176228-271B20-372584
AR12RXFPEWQ/EU 014005-15628A-272323-371784
AR18RXFPEWQ/EU 014005-15625C-27323C-372784
AR24RXFPEWQ/EU 014005-16629D-27414A-371584

18
u Necessary Tools
Item Remark
+SCREW DRIVER
Q’ty 1 ea.
To assembly and disassembly the screw
MONKEY SPANNER
Q’ty 1 ea.
To assembly and disassembly the Fan motor and
Compressor
- SCREW DRIVER
Q’ty 1 ea.
To assembly and disassembly the screw
4. Disassembly and Reassembly

19
4-1. Indoor Unit
NO. Parts Procedure Remark
1 PANEL-FRONT 1) Stop the driving of air conditioner
and shut off main power supply.
2) Open the FRONT-GRILLE and pull
out from the PANEL-FRONT.
3) Detach COVER-TERMINAL from
the PANELFRONT.(use + Screw
Driver)
4) Loosen connector wire(white) and
detach the temperature sensor wire.
5) To detach the FRONT-PANEL the
main frame, unfasten 2 screw at the
bottom.(use + Screw Driver)
6) Take off the FRONT-
PANEL,lifting up the bottom.

20
NO. Parts Procedure Remark
2 TRAY DRAIN 1) Loosen stepping motor wire and
detach the hook of main frame.
2) To detach TRAY-DRAIN from the
main frame, pull the bottom of the
TRAY-DRAIN towards you.
3
CONTROL IN 1) Unfasten the earth screw.(use
+ Screw Driver)
2) Detach COVER-CONTROL
from the CASECONTROL.
3) Detach the temperature sen-
sor.
4) Loosen MOTOR Wire.
