Thank you for purchasing this Samsung product.
This manual is made with 100% recycled paper.
Duct Type Series
MA duct
DB68-05395A-00
EN ES FR PT
Air Conditioner
user & installation manual

2
Cool Summer Oer
On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool
comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest.
This summer, beat the heat with your own air conditioner.
Cost Ecient System
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an ecient heating
method in the winter with the advanced“Heat pump”system. This technology is up to 300% more ecient than electrical
heating, so you can further reduce its running cost. Now, meet year-round needs with one air conditioner.
Flexible installation
Duct type air conditioner is designed to be slimmer and oers dierent solutions for any shape room allowing for specic
air ow requirements. Also, the air intake can be set up on either the bottom or rear of the unit, so there is more exibility in
installation.
Features of your new air conditioner

ENGLISH
3
Safety precautions ................................................................................................................................................................................................................. 4
Checking before use .......................................................................................................................................................................................................... 10
Viewing the parts ................................................................................................................................................................................................................ 13
Cleaning and maintaining the air conditioner ...................................................................................................................................................... 14
Appendix ................................................................................................................................................................................................................................ 16
Contents
USING PARTS
INSTALLATION PARTS
Safety precautions ............................................................................................................................................................................................................. 18
Preparation for installation ............................................................................................................................................................................................ 19
Deciding on where to install the indoor unit ........................................................................................................................................................ 20
Indoor unit installation .................................................................................................................................................................................................... 24
Purging the unit .................................................................................................................................................................................................................. 25
Connecting the refrigerant pipe ................................................................................................................................................................................. 26
Cutting/Flaring the pipes ............................................................................................................................................................................................... 27
Performing leak test & insulation ............................................................................................................................................................................... 28
Drainpipe and drain hose installation ...................................................................................................................................................................... 29
Connecting the connection cord ............................................................................................................................................................................... 31
Adjusting air ow................................................................................................................................................................................................................. 32
Setting the indoor unit option code........................................................................................................................................................................... 33
Setting an indoor unit address and installation option ..................................................................................................................................... 34
Troubleshooting ................................................................................................................................................................................................................. 37

4
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that
you know how to safely and eciently operate the extensive features and functions of your
new appliance.
Because the following operating instructions cover various models, the characteristics of
your air conditioner may dier slightly from those described in this manual. If you have any
questions, call your nearest contact center or nd help and information online at www.
samsung.com.
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specications of the product or higher and use
the power line for this appliance only. In addition, do not use an extension line.
XExtending the power line may result in electric shock or fire.
XDo not use an electric transformer. It may result in electric shock or fire.
XIf the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualied technician or
service company.
XFailing to do so may result in electric shock, fire, explosion, problems with the
product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
XFailing to do so may result in electric shock or fire.
Fix the outdoor unit rmly so that the electric part of the outdoor unit is not exposed.
XFailing to do so may result in electric shock or fire.
USING PARTS

5
ENGLISH
FOR INSTALLATION
WARNING
Do not install this appliance near a heater, inammable material. Do not install
this appliance in a humid, oily or dusty location, in a location exposed to direct
sunlight and water (rain drops). Do not install this appliance in a location where
gas may leak.
XThis may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where it
could fall.
XIf the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas
pipe, plastic water pipe, or telephone line.
XFailure to do so may result in electric shock, fire, an explosion, or other problems with
the product.
XNever plug the power cord into a socket that is not grounded correctly and make
sure that it is in accordance with local and national codes.
FOR INSTALLATION
CAUTION
Install your appliance on a level and hard oor that can support its weight.
XFailing to do so may result in abnormal vibrations, noise, or problems with the
product.
Install the draining hose properly so that water is drained correctly.
XFailing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining hose so that
draining is performed correctly.
XThe water generated during the heating operation by the outdoor unit may overflow
and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or property
damage.

6
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power line.
Do not hook the power line over a metal object, place a heavy object on the power
line, insert the power line between objects, or push the power line into the space
behind the appliance.
XThis may result in electric shock or fire.
FOR POWER SUPPLY
CAUTION
When not using the air conditioner for a long period of time or during a thunder/
lightning storm, cut the power at the circuit breaker.
XFailing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is ooded, please contact your nearest service center.
XFailing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, unplug the
power plug immediately and contact your nearest service center.
XFailing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately
without touching the power line.
Do not touch the appliance or power line.
XDo not use a ventilating fan.
XA spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service center.
XFailing to do so may result in problems with the product, water leakage, electric
shock, or fire.
XA delivery service for the product is not provided. If you reinstall the product in
another location, additional construction expenses and an installation fee will be
charged.
XEspecially, when you wish to install the product in an unusual location such as in
an industrial area or near the seaside where it is exposed to the salt in the air, please
contact your nearest service center.
Safety precautions

7
ENGLISH
FOR USING
WARNING
Do not touch the circuit breaker with wet hands.
XThis may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
XThis may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to climb onto
the machine.
XThis may result in children seriously injuring themselves.
Do not turn the air conditioner o with the circuit breaker while it is operating.
XTurning the air conditioner off and then on again with the circuit breaker may cause a
spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the
reach of children, as packaging materials can be dangerous to children.
XIf a child places a bag over its head, it may result in suffocation.
Do not insert your ngers or foreign substances into the outlet when the air
conditioner is operating or the front panel is closing.
XTake special care that children do not injure themselves by inserting their fingers into
the product.
Do not touch the front panel with your hands or ngers during the heating
operation.
XThis may result in electric shock or burns.
Do not insert your ngers or foreign substances into the air inlet/outlet of the air
conditioner.
XTake special care that children do not injure themselves by inserting their fingers into
the product.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near inrm people.
XSince this may be dangerous due to a lack of oxygen, open a window at least once an
hour.

8
FOR USING
WARNING
If any foreign substance such as water has entered the appliance, cut the power by
unplugging the power plug and turning the circuit breaker o and then contact
your nearest service center.
XFailing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
XDo not use any fuse (such as cooper, steel wire, etc.)other than the standard fuse.
XFailing to do so may result in electric shock, fire, problems with the product, or injury.
FOR USING
CAUTION
Do not place objects or devices under the indoor unit.
XWater dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a
year.
XFailing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy eciency.
Do not stand on top of the appliance or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
XThis may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
XThis may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
XAs well as being harmful to humans, it may also result in electric shock, fire or
problems with the product.
Do not drink the water from the air conditioner.
XThe water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble the
remote controller.
Do not touch the pipes connected with the product.
XThis may result in burns or injury.
Safety precautions

9
ENGLISH
FOR USING
CAUTION
Do not use this air conditioner to preserve precision equipment, food, animals,
plants or cosmetics, or for any other unusual purposes.
XThis may result in property damage.
Avoid directly exposing humans, animals or plants from the air ow from the air
conditioner for long periods of time.
XThis may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use benzene,
thinner or alcohol to clean the appliance.
XThis may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the air conditioner from the
wall socket and wait until the fan stops.
XFailing to do so may result in electric shock or fire.
FOR CLEANING
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit
since it has sharp edges.
XTo avoid cutting your fingers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
XFor cleaning inside the appliance, contact your nearest service center.
XWhen cleaning the internal filter, refer to the descriptions in the‘Cleaning and
maintaining the air conditioner’section.
XFailure to do may result in damage, electric shock or fire.
State of California Proposition 65 Warning (US only)
t This product contains chemicals known to the State of California to cause cancer
and reproductive toxicity.
WARNING
