ENGLISH
Centralized Controller
MCM-A200, A200U
MCM-A201, A201U
INSTALLATION MANUAL
MANUAL DE INSTALACIÓN
MANUEL D’INSTALLATION
MANUALE D’INSTALLZIONE
MANUAL DE INSTALAÇÃO
INSTALLATIONS-HANDBUCH
E°XEIPI¢IO E°KATA™TA™H™
àçëíêìäñàü èé ìëíÄçéÇäÖ
ESPAÑOL
FRANÇAIS
ITALIANO
PORTUGUÊS
DEUTSCH
E§§HNIKA
RUSSIAN
System Air Conditioner
Aire acondicionado sistemático
Climatiseur numérique multifonctionnel
Sistema Aria Condizionata
Sistema Ar Condicionado
Klimaanlage System
™‡ÛÙËÌ· ∫ÏÈÌ·ÙÈÛÌÔ‡
ëËÒÚÂÏÌ˚ ÇÓÁ‰Û¯Ì˚ äÓ̉ˈËÓÌÂ
E S F I P D G R A DB98-12722A(2)

Safety Precautions
◆Please read this installation manual carefully before
installing this product and be sure to check whether
the centralized controller is installed correctly.
◆Do not attempt to install or repair this product by
yourself.
◆This product contains no user-serviceable parts.
So always consult an authorized service personnel
for repairs.
◆When moving, consult an authorized service
personnel for disconnection and reinstallation of the
centralized controller.
◆Ensure that the wall is strong enough to support the
weight of the centralized controller.
◆The centralized controller must be installed by an
installation specialist according to the national
electrical standards.
◆When you want to stop using this product, consult an
authorized installation center.
WARNING
CAUTION
◆Do not install this product in places where it will come
into contact with volatile substances such as machine
oil, benzene, gasoline or naphtha.
◆Do not install this product in places where it will come
into contact with combustible gases such as sulfuric
gas, hydrogen gas, methane gas, etc.
◆Avoid using spray products such as insecticides near
this product.
◆Do not clean this product with substances such as
benzene or acid/alkali solvents.
◆Install this product in a location that is not exposed to
direct sunlight and has a temperature between
0°C (32°F) and 39°C (102°F).
◆Do not spill liquid of any kind into the centralized
controller.
◆When installing the electric wires, do not pull or bend
the wire excessively because it may be disconnected.
◆Do not press the buttons on the centralized connector
with a sharp object.
◆Do not connect the power cable to the control cable
terminal.
◆If the centralized controller is installed in places like a
hospital, take care that the centralized controller does
not interfere or affect other electrical equipments or
devices.
E-2
This installation manual explains how to install the centralized controller which is
connected to the indoor unit. When installing the optional accessories, see an
appropriate installation manual.

E-3
ENGLISH
Centralized Controller Installation
◆If you would like to install the centralized controller, you must install the
optional transmitter in the outdoor unit.
NN
NNoo oott ttee ee
Accessories
Centralized
controller (1) Cable-tie (2) Cable clamp (5) M4x16 tapped screw (7) Owner’s instructions(1) Installation manual (1)
Outdoor unit 1
Transmitter 1
Transmitter 2
Transmitter 3
Centralized
controller
Indoor unit 1 Indoor unit 2 Indoor unit 3
Outdoor unit 2
Indoor unit 4
Wired remote
controller
Indoor unit 5 Indoor unit 6
Wiring Diagram
◆Each outdoor unit connected to the same centralized controller must have its own
transmitter.
◆Connect the R1, R2 and F1, F2 terminals to the corresponding indoor unit terminals.
If the R1, R2 and F1, F2 terminals in the centralized controller is not connected to the R1,
R2 and F1, F2 terminals in the indoor unit, the centralized controller will not work properly.

Centralized Controller Installation(cont.)
Transmitter Installation
Transmitter 1
Transmitter 2
CN01
(BLUE)
CN12
(BLUE)
CN02
(RED)
Transmitter 3
AC power supply
Rear of the
centralized
controller
Outdoor unit PCB
Red Blue
Transmitter rotary
switch
Turn the arrow of the rotary switch on the transmitter to
the appropriate position. Transmitters controlled with
the same centralized controller must have different
addresses.
Assigning the Address
E-4

Setting up Option Switches
In order to use the centralized controller, adjust the K2 DIP
switch(SW03) in the indoor unit PCB to the "OFF" position.
When the user only wants to use the centralized controller
◆The number of buttons on the centralized
controller is decided by the RMC address of the
indoor units. Refer to the table below.
NN
NNoo oott ttee ee
◆Individual control
means that the centralized controller controls
only 1 indoor unit. In this case, you should assign
the RMC address to the indoor unit.
◆Group control
means that the centralized controller controls
more than 2 indoor units. In this case, you should
assign the RMC address to each indoor unit to
be controlled by the centralized controller.
However the wireless remote controller cannot
be used.
NN
NNoo oott ttee ee
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
9
A
B
C
D
E
F
Button No.
RMC
Address
Button No.
RMC
Address
K1 K2 K3 K4
RMC SW01
SW03
E-5
ENGLISH

Centralized Controller Installation(cont.)
In order to use the centralized controller, adjust the K2 DIP
switch(SW03) in the indoor unit PCB to the "OFF" position.
1
When the user wants to use the centralized controller
and the remote controller at the same time.
◆ The number of buttons on the centralized
controller is decided by the RMC address of
the indoor units. Refer to the table below.
NN
NNoo oott ttee ee
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
9
A
B
C
D
E
F
Button No.
RMC
Address
Button No.
RMC
Address
E-6

In order to use the wired remote controller, adjust the K1 DIP
switch(SW03) in the indoor unit PCB to the "OFF" position.
For further information, refer to the table below.
2
Assign an address to the wired remote controller by
turning the arrow of the rotary switch.
3
CC
CCAA AAUU UUTT TTII IIOO OONN NN
◆ An indoor unit that is connected to a specific wired
remote controller cannot be grouped together with
indoor units connected to a different wired remote
controller.
◆ Indoor units that can be group-controlled using the
wired remote controller can also be group-controlled
with the centralized controller.
If an indoor unit’s RMC address is ‘0’, the
indoor unit will be operated by the address ‘0’
when using the wired remote controller, and
the address ‘0’when using the centralized
controller.
EE
EExx xxaa aamm mmpp ppll llee ee
◆The address of the wired remote controller
and the RMC address of the indoor units
should be the same.
NN
NNoo oott ttee ee
ON
OFF
Not using the
wired remote
controller
Not using the
centralized
controller
Using the
wired remote
controller
Using the
centralized
controller
--
--
Switch
K1 K2 K4K3
RMC SW01
K1 K2 K3 K4
SW03
E-7
ENGLISH

Centralized Controller Installation(cont.)
E-8
When installing 1 centralized controller, 4 outdoor units and 12 indoor units.
◆6 indoor units connected to the number 1 and 2 outdoor unit can be controlled with the
"individual control" remote controller and the centralized controller.
◆3 indoor units connected to the number 3 outdoor unit can be controlled as a group with the
"group control" remote controller and centralized controller.
◆Among the indoor units connected to the number 4 outdoor unit, 2 indoor units are controlled by
a wired remote controller and a centralized controller. However, the remaining indoor unit can
only be controlled with an "individual control" wired remote controller. It cannot be controlled by
a centralized controller.
Installation of the Centralized Controller & Wired Remote Controller
00 RMC RMC RMC
RMC RMC RMC
RMC
RMC RMC RMC
RMC RMC
1 1 2 2
0 3 1 4 2 5
0 6 1 6 2 6
0 7 1 8 2 9
01 2
345
6
7 8 9
Outdoor unit 1
Outdoor unit 2
Outdoor unit 3
Outdoor unit 4
Transmitter 1
Transmitter 2
Transmitter 3
Transmitter 4
Centralized
controller SW03 switch in indoor unit
SW03 switch in indoor unit
SW03 switch in indoor unit
SW03 switch in indoor unit SW03 switch in indoor unit

E-9
ENGLISH
Different Levels of the Centralized Controller
OFF
ON
OFF
Level 0
Level 1
Level 2
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
Among the various controllers, such
as the centralized controller,
wired/wireless controller and the
indoor unit button, the air conditioner
will only be able to operate with the
most recently used controller
The wired/wireless controller can only
be used when the centralized
controller is powered on.
The air conditioner can only be
operated with the centralized
controller.
ONLevel 3 ON OFF OFF
Switch
No. 1 2 3 4 Meaning
DIP switch
Rotary switch
MCM-A200/A200U
Operating mode
switch
DIP switch
Rotary switch
MCM-A201/A201U
Operating mode
switch
◆Adjust the DIP switch in the centralized controller PCB and set a
level. This will enable the user to control the indoor units connected
to the centralized controller according to the set level.
◆If the "All ON" button of the
centralized controller is pressed
once, the operating lamp turns on,
the indoor unit falls into a standby
state, and the indoor unit can be
turned ON/OFF using the wired/
wireless remote controller and the
indoor unit button. (The indoor
units cannot be operated with the
"All ON/OFF" button)
◆If the "All ON" button of the
centralized controller is pressed
twice, the operating lamp turns off,
and it is not possible to control the
indoor unit with a wired/wireless
remote controller or an indoor unit
button.
◆The LEVEL of the centralized controller is ‘0’when
all the switches are in the "OFF" position.
◆The power is reset when the ADDRESS of the
centralized controller is changed.
◆When attempting to change the LEVEL of the
centralized controller, reset the main system's
power or turn off and then on the power of all the
indoor units using the "All ON/OFF" button.
NN
NNoo oott ttee ee

E-10
Level 0
Level 1
Level 2
The wired remote controller
does not have priority over
the centralized controller.
When using the wired/
wireless remote controller,
the air conditioner will run in
the mode selected when the
unit was last used.
The wired/wireless remote
controller can be used when
the centralized controller is
powered on.
The air conditioner can only
be operated with the
centralized controller.
(The wired/wireless remote
controller cannot be used.)
The wired remote controller
has priority over the
centralized controller.
When using the centralized
controller and the wired
remote controller, the air
conditioner will run in the
mode selected when the
unit was last used. (The
wireless remote controller
cannot be used.)
The wired remote controller
is the only controller that
can be used when the
centralized controller is
powered on. (The wireless
remote controller cannot be
used.)
The air conditioner can only
be operated with the
centralized controller.
(The wired/wireless remote
controller cannot be used.)
Wired Remote
Controller
Centralized
controller
Master Mode
(No.4 DIP Switch “OFF”)Slave Mode (No.4 DIP Switch “ON”)
◆If the wired remote controller and the centralized controller
is used at the same time, refer to the table below.
Centralized Controller Installation(cont.)
◆Refer to the wired remote controller section of the
Installation Manual for information about the
MASTER MODE and SLAVE MODE.
NN
NNoo oott ttee ee

E-11
ENGLISH
Memo

ELECTRONICS
THIS AIR CONDITIONER IS MANUFACTURED BY:
ESTE AIRE ACONDICIONADO HA SIDO FABRICADO POR:
CE CLIMATISEUR EST FABRIQUE PAR:
QUESTO CONDIZIONATORE D’ARIA È PRODOTTO DA:
ESTE APARELHO DE AR CONDICIONADO É FABRICADO POR:
DIESE KLIMAANLAGE IST FABRIZIERT VON:
AYTH H ™Y™KEYH KATA™KEYA™THKE A¶O:
ùíéí äéçÑàñàéçÖê àáÉéíéÇãÖç îàêåéâ:
