Samsung HF1000 User manual

English...................................................................................1
Español................................................................................33

English
1
Contents
Getting started
Layout............................................................................................................3
Button functions.............................................................................................4
Charging the hands-free car kit .....................................................................5
Mount the hands-free car kit in your vehicle..................................................7
Using your hands-free car kit
Turning the hands-free car kit on or off..........................................................8
Using the voice prompt..................................................................................9
Pairing and connecting the hands-free car kit ............................................. 11
Pairing via the Active pairing feature ...........................................................15
Using call functions......................................................................................16
Appendix
Frequently asked questions.........................................................................20
Certication and Safety approvals ..............................................................22
UL certied travel adapter ...........................................................................23
STANDARD LIMITED WARRANTY ............................................................24
Specications ..............................................................................................31
English

2
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc. worldwide — Bluetooth QD ID:
B016384
More information about Bluetooth is available at www.bluetooth.com.
Safety precautions
Comply with the following precautions to avoid dangerous or illegal situations and ensure peak
performance of your device.
Avoid using mobile phones while driving and obey all regulations that restrict the use of mobile•
phones while driving. Use hands-free accessories to increase your safety when possible.
Do not install your device in any location that will interfere with normal operation of your vehicle.•
Keep your device and all accessories out of the reach of small children or animals. Small parts •
may cause choking or serious injury if swallowed.
Avoid exposing your device to very hot temperature (above 50 °C/122 °F).•
Do not allow your device to get wet — liquids can cause serious damage. Do not handle your •
device with wet hands. Water damage to your device can void your manufacturer’s warranty.
Allowing unqualied personnel to service your device may result in damage to your device and •
will void your warranty.
Avoid using your device’s light close to the eyes of children or animals.•

English
3
Getting started
This section explains what to remember for the proper use of your Bluetooth
hands-free car kit.
Layout
Speaker
Volume buttons
Sun visor clip
Charger Jack
Microphone
Talk button
Power switch
Indicator light

4
Make sure you have the following items with your hands-free car kit: Cigar lighter •
adapter, User manual.
The items supplied with your hands-free car kit may vary depending on your region.
•
Button functions
Button Function
Power
switch
Slide up to turn the hands-free car kit on.•
Slide down to turn the hands-free car kit off.•
Talk
Press to make or answer a call.•
Press to end a call.•
Press and hold to enter Pairing mode.•
Volume
Press to adjust the volume.•
Press and hold to turn on or off the multipoint feature.•
During a call, press and hold to turn the microphone •
on or off.

English
5
Charging the hands-free car kit
Your hands-free car kit has an internal battery. Before using the hands-free car kit
for the rst time, you must charge the battery.
If you charge the hands-free car kit at very cold or hot temperatures, •
it automatically stops charging.
You cannot use the functions of the hands-free car kit while charging.
•
1. Plug the small end of the cigar lighter adapter into the Charger Jack.

6
2. Plug the large end of the cigar lighter adapter into the accessory outlet in your
vehicle.
3. When the battery is fully charged (the indicator light turns blue), unplug the
cigar lighter adapter from the hands-free car kit.
You can also use the travel adapter to charge the hands-free car kit.•
About the low battery indicator•
When your battery is low, the indicator light will turn red. Recharge your battery
to continue using your hands-free car kit. If the battery level becomes too low,
the hands-free car kit will automatically power off. To turn it on, slide the Power
switch up again.
Checking the battery level
Press and hold the Talk button and the Volume down button at the same time.
Depending on the battery level, the indicator light ashes 5 times in one of the
following colors:
Battery level Indicator light color
Above 80% Blue
80 ~20% Violet

English
7
Battery level Indicator light color
Below 20% Red
Mount the hands-free car kit in your vehicle
Slide the hands-free car kit onto a sun visor in your vehicle as shown below.

8
Using your hands-free car kit
This section explains how to turn the hands-free car kit on, pair and connect to the
phone, and use various functions.
Activated functions and features may differ depending on the phone type.•
Some devices, especially those that are not tested or approved by Bluetooth SIG, •
may be incompatible with your hands-free car kit.
Turning the hands-free car kit on or off
To turn the hands-free car kit on, slide the Power switch up. The blue indicator •
light ashes 4 times.
To turn the hands-free car kit off, slide the Power switch down. The indicator •
light turns off after the blue indicator light changes to red.

English
9
Using the voice prompt
The voice prompt willl inform you about the current status of the hands-free car kit
and usage instructions.
Changing the language for the voice prompt
If you turn the hands-free car kit on for the rst time, you will hear the voice prompt
to change the language for the voice prompt. When you hear the voice prompt in
the language you want, press the Talk button.
To change the language for the voice prompt in Pairing mode, press and hold the
Talk button for 4 seconds.
Turning the voice prompt on or off
In Pairing mode, press and hold the Volume up and down buttons at the same
time. To enter Pairing mode, see page 12.

10
The following voice prompts are available according to your status:
Status Voice prompt
When you turn the hands-free car
kit on “Power on”
When you turn the hands-free car
kit off “Power off”
When you activate the language
selection option “Press call button to conrm”
When you select a language for the
voice prompt “Language name selected”
When the battery is low “Battery is low”
When you enter Paring mode or you
pair the hands-free car kit for the
rst time
“Ready to pair. Go to phone or
computer Bluetooth menu. PIN code
is 0000.”
When you connect the hands-free car
kit with a phone
“Phone1 connected” or “Phone2
connected”
When you disconnect the hands-free
car kit from a phone
“Phone1 disconnected” or “Phone2
disconnected”

English
11
Status Voice prompt
When an incoming call comes in “Incoming call Phone1”
When the second call comes in during
a call “Incoming call Phone2”
When you reject or end a call “Call terminated”
When you end the rst call and accept
the second call "Call terminated”
Pairing and connecting the hands-free car kit
Pairing will create a unique and encrypted wireless link between two Bluetooth
enabled devices, such as a Bluetooth phone and a Bluetooth hands-free car kit.
To use the hands-free car kit with other Bluetooth devices, the devices must be
paired. When trying to pair the two devices, keep the hands-free car kit and the
phone reasonably close together. After pairing, you can connect the two devices.

12
Pairing and connecting the hands-free car kit with a phone
1. Enter Pairing mode.
Turn on your hands-free car kit and press and hold the Talk button until the•
blue indicator light stays lit.
If you turn the hands-free car kit on for the rst time, it proceeds into Pairing •
mode immediately after the language for the voice prompt is selected.
2. Activate the Bluetooth feature on your phone and search for the hands-free car
kit (see your phone’s user manual).
3. Select the hands-free car kit (HF1000) from the list of devices found by your
phone.
4. Enter the Bluetooth PIN (0000, 4 zeros) to pair and connect the hands-free car
kit to your phone.
Your hands-free car kit supports the Simple Pairing feature which allows the
hands-free car kit to be paired with a phone without requesting a PIN. This feature is
available for phones that are compliant with Bluetooth version 2.1 or higher.
The hands-free car kit also can be paired via the Active pairing feature,
see page 15.

English
13
Connecting with two Bluetooth phones
With the Multi-point feature activated, your hands-free car kit can be connected
with two Bluetooth phones at the same time.
1. After connecting with the rst Bluetooth phone, press and hold the Talk button
until the blue indicator light stays lit.
2. Press and hold the Volume up button to activate the Multi-point feature.
3. Activate the Bluetooth feature on the second Bluetooth phone and search for
the hands-free car kit (see your phone’s user manual).
4. Select the hands-free car kit (HF1000) from the list of devices found by the
second Bluetooth phone.
5. Enter the Bluetooth PIN (0000, 4 zeros) to connect the hands-free car kit to the
phone.
6. Reconnect to the hands-free car kit from the rst Bluetooth phone.

14
You can set the hands-free car kit automatically to reconnect to the recently •
connected phones each time you turn it on.
To reconnect to the two most recently connected phones, activate the Multi-
-
point feature. Press and hold the Volume up button in Pairing mode until the
blue indicator light ashes twice.
To reconnect to only the most recently connected phone, deactivate the Multi-
-
point feature. Press and hold the Volume down button in Pairing mode until the
red indicator light ashes twice.
When the hands-free car kit connects to two Bluetooth phones, some phones may
•
not connect to the hands-free car kit as the second Bluetooth phone.
Disconnecting the hands-free car kit
To disconnect the hands-free car kit from your phone,
Turn off the hands-free car kit.•
Use the Bluetooth menu on your phone.•

English
15
Reconnecting the hands-free car kit
When the hands-free car kit is paired with a phone, it will attempt to automatically
reconnect each time you turn it on.
If the hands-free car kit does not automatically attempt to reconnect,
Press the Talk button.•
Use the Bluetooth menu on your phone.•
Pairing via the Active pairing feature
With the Active pairing feature, your hands-free car kit can automatically search for
a Bluetooth phone and try to make a connection with it.
This feature is available for mobile phones, but the phone’s Bluetooth visibility
option must be set to on.
1. Turn on the hands-free car kit.
2. Enter pairing mode, see page 11.
3. Press and hold the Talk button until the violet indicator light turns on.
The hands-free car kit will switch to Active Pairing mode, search a Bluetooth
phone within range, and attempt to pair with it.

16
Ensure the phone you wish to connect to is within range of the hands-free car kit. •
Place the hands-free car kit and phone close to each other to avoid pairing with
other devices.
The hands-free car kit will attempt Active pairing for up to 20 seconds.
•
The Bluetooth phone you want to connect with must not be paired with other•
devices. If the phone is already connected to another device, end the connection
and restart Active pairing feature.
This feature may be unavailable depending on the some PDAs.
•
Using call functions
Making a call
Redialing the last number
Press and hold the Talk button to redial the last number of the most recently
connected phone.
Press the Talk button twice to redial the last number of the other phone.

English
17
Dialing a number by voice
Press the Talk button to dial a number of the rst phone by voice, and say a name.
Available call functions may vary by the phone.
Answering a call
Press the Talk button to answer a call when you hear incoming call tones.
When two calls from the two connected phones come in, you can answer the call
of the rst phone.
Ending a call
Press the Talk button to end a call.
Rejecting a call
Press and hold the Talk button to reject a call when a call comes in.
When two calls from the two connected phones come in, you can reject the call of
the rst phone.

18
Using options during a call
You can use the following functions to control your call during a call.
Adjusting the volume
Press the Volume up or down button to adjust the volume.
Muting the microphone
Press and hold the Volume up or down button to turn the microphone off so that
the person with whom you are speaking cannot hear you. When the microphone
is turned off, the hands-free car kit beeps at regular intervals. Press and hold the
Volume up or down button again to turn the microphone back on.
Transferring a call from the phone to the hands-free car kit
Press the Talk button to transfer a call from the phone to the hands-free car kit.
Placing a call on hold
Press and hold the Talk button to place the current call on hold.
When the hands-free car kit is connected with two phones, this function is not
available.
