Samsung GT-B7320 User manual

Some of the contents in this manual may differ from your device depending on the software of the
device or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-24499A
English (SEA). 07/2009. Rev. 1.1

GT-B7320
user manual

ii
using this
manual
This user manual has been specially designed to
guide you through the functions and features of
your device. To get started quickly, refer to the
quick start guide.
Instructional icons
Before you start, familiarise yourself with the
icons you will see in this manual:
Warning—situations that could cause
injury to yourself or others
Caution—situations that could cause
damage to your device or other
equipment
Note—notes, usage tips, or additional
information
X Refer to—pages with related
information; for example:
X p. 12
(represents "see page 12")
→Followed by—the order of options or
menus you must select to perform a
step; for example: Press <Start> →
Messaging (represents Start, followed
by Messaging)

iii
using this manual
Copyrights and trademarks
Rights to all technologies and products that
comprise this device are the property of their
respective owners:
[] Square brackets—device keys;
for example: [ ] (represents the Power
key).
<> Angled brackets—softkeys that control
different functions at each screen; for
example: <Select> (represents the
Select softkey).
•This product includes
software licensed from MS,
an affiliate of the Microsoft
Corporation. Microsoft and software bearing
the Microsoft name are registered
trademarks of the Microsoft Corporation.
• Java™ is a trademark of Sun Microsystems,
Inc.
•Bluetooth
®is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: B014543
• Windows Media Player®is a registered
trademark of Microsoft Corporation.
•Wi-Fi
®, the Wi-Fi CERTIFIED logo, and the
Wi-Fi logo are registered trademarks of the
Wi-Fi Alliance.

iv
contents
safety and usage information .................. 2
Safety warnings .......................................... 2
Safety precautions ...................................... 4
Important usage information ....................... 7
quick start guide .................................... 12
Unpack ..................................................... 12
Phone layout ............................................ 13
Keys ......................................................... 14
Icons ........................................................ 15
Assemble and prepare your device ........... 16
Turn on your device on and off ................. 20
Work with applications .............................. 21
Use basic call functions ............................ 22
Send and view text messages .................. 23
Add and find contacts .............................. 24
Use basic camera functions ...................... 24
Listen to music ......................................... 26
Customise your device ............................. 27
communication ...................................... 29
Calls ......................................................... 29
Messaging ................................................ 30

v
contents
media ...................................................... 34
Camera .................................................... 34
Photo Slides ............................................. 38
Contents Manager .................................... 39
FM Radio .................................................. 41
Streaming Player ...................................... 42
Voice Notes .............................................. 42
personal productivity ............................. 43
Contacts ................................................... 43
Calendar ................................................... 44
Office Mobile ............................................ 45
Adobe
®
Reader LE .................................. 47
Team manager ......................................... 48
Tasks ........................................................ 49
web ......................................................... 50
Internet Explorer ....................................... 50
Windows Live ........................................... 51
Messenger ................................................ 52
RSS Reader .............................................. 53
connectivity ............................................ 55
Wi-Fi ......................................................... 55
Bluetooth .................................................. 56
USB ......................................................... 58
ActiveSync ............................................... 59
Internet Sharing ........................................ 61
Connections ............................................. 61
additional programs ............................... 63
Games ..................................................... 63
Java ......................................................... 63
World Clock .............................................. 64
Alarms ...................................................... 65
D-Day ....................................................... 65
Calculator ................................................. 65
Tip Calculator ........................................... 66
Smart Converter ....................................... 66
StopWatch ............................................... 67
Search ...................................................... 67
File Explorer .............................................. 68
Settings .................................................. 69
troubleshooting ........................................ a
index ......................................................... e

2
safety and
usage
information
Comply with the following precautions to avoid
dangerous or illegal situations and ensure peak
performance of your device.
Keep your device away from small
children and pets
Keep your device and all accessories out of the
reach of small children or animals. Small parts
may cause choking or serious injury if
swallowed.
Protect your hearing
Safety warnings
Listening to a headset at high
volumes can damage your hearing.
Use only the minimum volume setting
necessary to hear your conversation
or music.

3
safety and usage information
Install mobile devices and
equipment with caution
Ensure that any mobile devices or related
equipment installed in your vehicle are securely
mounted. Avoid placing your device and
accessories near or in an air bag deployment
area. Improperly installed wireless equipment
can cause serious injury when air bags inflate
rapidly.
Handle and dispose of batteries and
chargers with care
• Use only Samsung-approved batteries and
chargers specifically designed for your
device. Incompatible batteries and chargers
can cause serious injuries or damage to your
device.
• Never dispose of batteries or device in a fire.
Follow all local regulations when disposing of
used batteries or device.
• Never place batteries or devices on or in
heating devices, such as microwave ovens,
stoves, or radiators. Batteries may explode
when overheated.
• Never crush or puncture the battery. Avoid
exposing the battery to high external
pressure, which can lead to an internal short
circuit and overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches)
between mobile devices and pacemakers to
avoid potential interference, as recommended
by manufacturers and the independent
research group, Wireless Technology
Research. If you have any reason to suspect
that your device is interfering with a pacemaker
or other medical device, turn off the device
immediately and contact the manufacturer of
the pacemaker or medical device for guidance.

4
safety and usage information
Turn off the device in potentially
explosive environments
Do not use your device at refuelling points
(service stations) or near fuels or chemicals.
Turn off your device whenever directed by
warning signs or instructions. Your device could
cause explosions or fire in and around fuel or
chemical storage and transfer areas or blasting
areas. Do not store or carry flammable liquids,
gases, or explosive materials in the same
compartment as the device, its parts, or
accessories.
Reduce the risk of repetitive motion
injuries
While using your device, hold the device with a
relaxed grip, press the keys lightly, use special
features that reduce the number of keys you
have to press (such as templates and
predictive text), and take frequent breaks.
Drive safely at all times
Avoid using your device while driving and obey
all regulations that restrict the use of mobile
devices while driving. Use hands-free
accessories to increase your safety when
possible.
Follow all safety warnings and
regulations
Comply with any regulations that restrict the use
of a mobile device in a certain area.
Use only Samsung-approved
accessories
Using incompatible accessories may damage
your device or cause injury.
Safety precautions

5
safety and usage information
Turn off the device near medical
equipment
Your device can interfere with medical
equipment in hospitals or health care facilities.
Follow all regulations, posted warnings, and
directions from medical personnel.
Turn off the device or disable the
wireless functions when in an
aircraft
Your device can cause interference with aircraft
equipment. Follow all airline regulations and turn
off your device or switch to a mode that
disables the wireless functions when directed
by airline personnel.
Protect batteries and chargers from
damage
• Avoid exposing batteries to very cold or very
hot temperatures (below 0° C/32° F or
above 45° C/113° F). Extreme temperatures
can reduce the charging capacity and life of
your batteries.
• Prevent batteries from contacting metal
objects, as this can create a connection
between the + and - terminals of your
batteries and lead to temporary or
permanent battery damage.
• Never use a damaged charger or battery.
Handle your device carefully and
sensibly
• Do not allow your device to get wet—liquids
can cause serious damage. Do not handle
your device with wet hands. Water damage
to your device can void your manufacturer’s
warranty.

6
safety and usage information
• Avoid using or storing your device in dusty,
dirty areas to prevent damage to moving
parts.
• Your device is a complex electronic
device—protect it from impacts and rough
handling to avoid serious damage.
• Do not paint your device, as paint can clog
moving parts and prevent proper operation.
• If your device has a camera flash or light,
avoid using it close to the eyes of children or
animals.
• Your device may be damaged by exposure
to magnetic fields. Do not use carrying
cases or accessories with magnetic
closures or allow your device to come in
contact with magnetic fields for extended
periods of time.
Avoid interference with other
electronic devices
Your device emits radio frequency (RF) signals
that may interfere with unshielded or improperly
shielded electronic equipment, such as
pacemakers, hearing aids, medical devices,
and other electronic devices in homes or
vehicles. Consult the manufacturers of your
electronic devices to solve any interference
problems you experience.

7
safety and usage information
Use your device in the normal
position
Avoid contact with your device’s internal
antenna.
Allow only qualified personnel to
service your device
Allowing unqualified personnel to service your
device may result in damage to your device and
will void your warranty.
Ensure maximum battery and
charger life
• Avoid charging batteries for more than a
week, as overcharging may shorten battery
life.
• Over time, unused batteries will discharge
and must be recharged before use.
• Disconnect chargers from power sources
when not in use.
• Use batteries only for their intended
purpose.
Handle SIM cards and memory
cards with care
• Do not remove a card while the device is
transferring or accessing information, as this
could result in loss of data and/or damage to
the card or device.
• Protect cards from strong shocks, static
electricity, and electrical noise from other
devices.
• Frequent writing and erasing will shorten the
life span of memory cards.
• Do not touch gold-coloured contacts or
terminals with your fingers or metal objects. If
dirty, wipe the card with a soft cloth.
Important usage information

8
safety and usage information
Ensure access to emergency
services
Emergency calls from your device may not be
possible in some areas or circumstances.
Before travelling in remote or undeveloped
areas, plan an alternate method of contacting
emergency services personnel.
Specific Absorption Rate (SAR)
certification information
Your device conforms to European Union (EU)
standards that limit human exposure to radio
frequency (RF) energy emitted by radio and
telecommunications equipment. These
standards prevent the sale of mobile devices
that exceed a maximum exposure level (known
as the Specific Absorption Rate, or SAR) of 2.0
watts per kilogram.
During testing, the maximum SAR recorded for
this model was 0.637 watts per kilogram. In
normal use, the actual SAR is likely to be much
lower, as the device has been designed to emit
only the RF energy necessary to transmit a
signal to the nearest base station. By
automatically emitting lower levels when
possible, your device reduces your overall
exposure to RF energy.
The Declaration of Conformity at the back of
this manual demonstrates your device’s
compliance with the European Radio & Terminal
Telecommunications Equipment (R&TTE)
directive. For more information about the SAR
and related EU standards, visit the Samsung
mobile website.

9
safety and usage information
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
((Applicable in the European Union
and other European countries with
separate collection systems)
This marking on the product,
accessories or literature indicates
that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not
be disposed of with other household waste at
the end of their working life. To prevent possible
harm to the environment or human health from
uncontrolled waste disposal, please separate
these items from other types of waste and
recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the
retailer where they purchased this product, or
their local government office, for details of
where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier
and check the terms and conditions of the
purchase contract. This product and its
electronic accessories should not be mixed
with other commercial wastes for disposal.
This EEE is compliant with RoHS.

10
safety and usage information
Correct disposal of batteries in this
product
(Applicable in the European Union
and other European countries with
separate battery return systems)
This marking on the battery, manual
or packaging indicates that the
batteries in this product should not be disposed
of with other household waste at the end of
their working life.
Where marked, the chemical symbols Hg, Cd
or Pb indicate that the battery contains mercury,
cadmium or lead above the reference levels in
EC Directive 2006/66. If batteries are not
properly disposed of, these substances can
cause harm to human health or the
environment.
To protect natural resources and to promote
material reuse, please separate batteries from
other types of waste and recycle them through
your local, free battery return system.
Disclaimer
Some content and services accessible through
this device belong to third parties and are
protected by copyright, patent, trademark and/
or other intellectual property laws. Such content
and services are provided solely for your
personal noncommercial use. You may not use
any content or services in a manner that has
not been authorised by the content owner or
service provider. Without limiting the foregoing,
unless expressly authorised by the applicable
content owner or service provider, you may not
modify, copy, republish, upload, post, transmit,
translate, sell, create derivative works, exploit,
or distribute in any manner or medium any
content or services displayed through this
device.
“THIRD PARTY CONTENT AND SERVICES ARE
PROVIDED "AS IS." SAMSUNG DOES NOT
WARRANT CONTENT OR SERVICES SO
PROVIDED, EITHER EXPRESSLY OR
IMPLIEDLY, FOR ANY PURPOSE.

11
safety and usage information
SAMSUNG EXPRESSLY DISCLAIMS ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT
LIMITED TO, WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. SAMSUNG DOES
NOT GUARANTEE THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS
OF ANY CONTENT OR SERVICE MADE
AVAILABLE THROUGH THIS DEVICE AND
UNDER NO CIRCUMSTANCES, INCLUDING
NEGLIGENCE, SHALL SAMSUNG BE LIABLE,
WHETHER IN CONTRACT OR TORT, FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, ATTORNEY
FEES, EXPENSES, OR ANY OTHER
DAMAGES ARISING OUT OF, OR IN
CONNECTION WITH, ANY INFORMATION
CONTAINED IN, OR AS A RESULT OF THE
USE OF ANY CONTENT OR SERVICE BY YOU
OR ANY THIRD PARTY, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES."
Third party services may be terminated or
interrupted at any time, and Samsung makes
no representation or warranty that any content
or service will remain available for any period of
time. Content and services are transmitted by
third parties by means of networks and
transmission facilities over which Samsung has
no control. Without limiting the generality of this
disclaimer, Samsung expressly disclaims any
responsibility or liability for any interruption or
suspension of any content or service made
available through this device.
Samsung is neither responsible nor liable for
customer service related to the content and
services. Any question or request for service
relating to the content or services should be
made directly to the respective content and
service providers.

12
quick start guide
Unpack
Check your product box for the following items:
• Mobile device
•Headset
• Battery
• Travel adapter (charger)
•Usermanual
•PCdatacable
•CD-ROM
1
The items supplied with your device may vary
depending on the software and accessories
available in your region or offered by your
service provider. You can obtain additional
accessories from your local Samsung dealer.
1. The CD-ROM contains Microsoft ActiveSync software, add-on
software, and other applications.

13
quick start guide
Phone layout
The front of your device includes the following
keys and features:
The rear of your device includes the following
keys and features:
Power key
Volume key
Tal k key
Home/Task
Manager key
QWERTY
keyboard
Display
End/Device
lock key
Right softkey
Back/Delete key
4-way
navigation key
Left softkey
Confirm key
Mouthpiece
Front camera
lens for video
calls
Earpiece
Light sensor
Light Rear
camera lens
Battery cover
Multifunction
jack
Mirror
Internal antenna
Speaker

14
quick start guide
Keys
Key Function
Turn the device on and off (press
and hold); Open the Quick List
screen
Adjust the device’s volume; During
an incoming call, mute the call
ringer
Perform actions indicated at the
bottom of the display
Scroll through lists or menus; Move
the cursor up, down, left, or right
Confirm your selection or execute
the selected application
Open the dialling screen; Make or
answer a call
End a call; Return to the Home
screen; Lock the device (press and
hold)
Switch to the Home screen from a
application; Open Task Manager
(press and hold)
Return to the previous menu or
screen; Delete characters
~ Enter numbers, characters, and
symbols
Delete characters
Change case in a text input field
Confirm your selection; Start a new
line in a text input field
Use characters on the upper half of
the keys in a text input field
Open Windows Live Messenger
Open the symbol screen in a text
input field
Key Function

15
quick start guide
Icons
Learn about the icons that appear on your
display.
Insert a space in the text input
screen; Activate or deactivate the
silent profile from the Home screen
(press and hold)
Launch the web browser
Open Messaging; Open a new
message screen (press and hold)
Turn on the camera; In Camera
mode, take a photo or record a
video
Key Function
Icon Definition
Signal strength
Voice call in progress
Call on hold
GPRS network available
GPRS network connected or data call
in progress
EDGE network available
EDGE network connected or data call
in progress
Roaming in GPRS network
UMTS network available
HSDPA network connected or data
call in progress
