Samsung GT M7603 User manual

GSM TELEPHONE
Samsung M7603
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Disassembly and Assembly
Instructions
8. Block Diagrams
9. PCB Diagrams
10. Chart of Troubleshooting
11. Reference data
GSM TELEPHONE CONTENTS
efrcom efrcom

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2009. 05. Rev.1.0
ⓒ
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast &Africa mea.samsungportal.com
GSPN (Global Service Partner Network)

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-1
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View
QFR01
QME03
QLC01
QLB01
QCA01
QVK01
QSH01
QSP01
QCA00
QAR01
QKP01
QME01
QCA02
QCR04
QSP02
QCR91
QCR91
QBA01
QBA00
QRE01
QMP01
QVO01
QCW01
QRF03
QCK01
QIF01
QDC01
QSD01
QCK02

- This Document can not be used without Samsung's authorization -
5-2. Cellular phone Parts list : GT-M7603RKAINU
Design LOC Description SEC CODE
QAR01 AUDIO-RECEIVER 3009-001358
QBA01 INNER BATTERY PACK-960MAH,BLK,UNI,MAIN GH43-03216A
QBC00 PMO COVER-BATTERY GH72-52371B
QCA00 ASSY CAMERA-GT_M7600 3M GH96-03626A
QCA01 ASSY CAMERA-GT_M7600 CIF GH96-03607A
QCA02 KEY FPCB-GT_M7600 CAM KEY GH59-06916A
QCK01 PMO KEY-CAMERA GH72-52374A
QCK02 PMO KEY-HOLD GH72-52373A
QCR04 SCREW-MACHINE 6001-001479
QCR91 SCREW-MACHINE 6001-002260
QCW01 PMO WINDOW-CAMERA GH72-52381A
QDC01 NPR DECO-CAMERA GH71-08786A
QFR01 ASSY CASE-FRONT GH98-11796B
QIF01 PMO COVER-MICRO USB IF GH72-52368D
QKP01 ASSY KEYPAD-(BLACK/OPEN) GH98-12018A
QLB01 ASSY BRACKET-LCD GH98-11801A
QLC01 ASSY LCD-GT_M7600 GH96-03635A
QME01 KEY FPCB-GT_M7600 KEY PBA GH59-06914A
QME03 TOUCH/PANEL-GT_M7600 RK GH59-06964B
QMP01 ASSY PBA MAIN-GTM7603 GH92-05886A
QRE01 ASSY CASE-REAR GH98-11797D
QRF03 PMO COVER-EARPHONE GH72-52369D
QSD01 PMO COVER-SD GH72-52370D
QSH01 ASSY COVER-SHIELD CAN GH98-11800A
QSP01 MODULE-GT-M7600 SPK DOWN GH59-06946A
QSP02 MODULE-GT-M7600 SPK UP GH59-06963A
QVK01 KEY FPCB-GT_M7600 VOLUME KEY GH59-06927A
QVO01 PMO KEY-VOLUME GH72-52375D
QVO03 ASSY ACCE-HOLDER MEDIA FLO GH98-02026A

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-15
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
0403-001688 D600 DIODE-ZENER
0406-001267 ZD100 DIODE-TVS
0406-001267 ZD503 DIODE-TVS
0406-001267 ZD700 DIODE-TVS
0406-001267 ZD701 DIODE-TVS
0406-001267 ZD702 DIODE-TVS
0406-001267 ZD703 DIODE-TVS
0406-001267 ZD704 DIODE-TVS
0406-001286 ZD500 DIODE-TVS
0406-001286 ZD709 DIODE-TVS
0406-001330 U602 DIODE-TVS
0504-001151 U200 TR-DIGITAL
0504-001151 U201 TR-DIGITAL
0801-003013 U300 IC
0801-003065 U401 IC
1001-001394 U610 IC
1001-001394 U611 IC
1001-001394 U612 IC
1001-001481 U605 IC
1001-001494 U501 IC
1001-001586 U603 IC
1003-002047 U607 IC
1201-002470 U500 IC
1201-002581 F102 IC
1201-002775 PAM201 IC
1201-002821 PAM200 IC
1201-002830 PAM100 IC
1202-001068 U704 IC
1203-004570 U600 IC
1203-005250 U601 IC
1203-005367 U604 IC
1203-005396 U703 IC
1203-005448 U400 IC
1203-005503 U606 IC
1203-005522 U700 IC

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
1203-005690 U402 IC
1204-002924 U100 IC
1205-003297 U202 IC
1205-003498 UCD300 IC
1205-003517 U102 IC
1205-003611 U608 IC
1209-001831 U609 IC
1404-001224 VR300 THERMISTOR
1405-001196 V702 VARISTOR
1405-001196 V703 VARISTOR
1405-001196 V705 VARISTOR
1405-001196 V706 VARISTOR
2007-000138 R503 R-CHIP
2007-000138 R509 R-CHIP
2007-000138 R510 R-CHIP
2007-000144 R412 R-CHIP
2007-000145 R506 R-CHIP
2007-000148 R502 R-CHIP
2007-000162 R518 R-CHIP
2007-000168 R524 R-CHIP
2007-000170 R313 R-CHIP
2007-000173 R514 R-CHIP
2007-001285 R211 R-CHIP
2007-001285 R213 R-CHIP
2007-003015 R112 R-CHIP
2007-007310 R520 R-CHIP
2007-007488 R409 R-CHIP
2007-007741 R308 R-CHIP
2007-007943 R751 R-CHIP
2007-008043 R215 R-CHIP
2007-008045 R210 R-CHIP
2007-008045 R317 R-CHIP
2007-008045 R444 R-CHIP
2007-008045 R516 R-CHIP
2007-008045 R621 R-CHIP
2007-008045 R622 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2007-008045 R731 R-CHIP
2007-008045 R738 R-CHIP
2007-008045 R750 R-CHIP
2007-008046 R131 R-CHIP
2007-008046 R133 R-CHIP
2007-008046 R139 R-CHIP
2007-008047 R127 R-CHIP
2007-008047 R129 R-CHIP
2007-008047 R201 R-CHIP
2007-008047 R202 R-CHIP
2007-008049 R100 R-CHIP
2007-008049 R103 R-CHIP
2007-008049 R304 R-CHIP
2007-008052 R106 R-CHIP
2007-008052 R107 R-CHIP
2007-008052 R500 R-CHIP
2007-008052 R501 R-CHIP
2007-008052 R602 R-CHIP
2007-008052 R603 R-CHIP
2007-008055 R421 R-CHIP
2007-008055 R513 R-CHIP
2007-008055 R525 R-CHIP
2007-008055 R613 R-CHIP
2007-008055 R640 R-CHIP
2007-008135 R408 R-CHIP
2007-008403 R617 R-CHIP
2007-008419 R108 R-CHIP
2007-008419 R109 R-CHIP
2007-008419 R110 R-CHIP
2007-008419 R111 R-CHIP
2007-008419 R212 R-CHIP
2007-008419 R734 R-CHIP
2007-008419 R735 R-CHIP
2007-008419 R736 R-CHIP
2007-008419 R737 R-CHIP
2007-008420 R128 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-4
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2007-008420 R200 R-CHIP
2007-008478 R406 R-CHIP
2007-008478 R407 R-CHIP
2007-008478 R528 R-CHIP
2007-008478 R529 R-CHIP
2007-008483 R116 R-CHIP
2007-008483 R405 R-CHIP
2007-008483 R612 R-CHIP
2007-008483 R620 R-CHIP
2007-008483 R726 R-CHIP
2007-008483 R743 R-CHIP
2007-008486 R410 R-CHIP
2007-008486 R422 R-CHIP
2007-008486 R433 R-CHIP
2007-008516 R126 R-CHIP
2007-008516 R301 R-CHIP
2007-008516 R302 R-CHIP
2007-008516 R305 R-CHIP
2007-008516 R417 R-CHIP
2007-008516 R423 R-CHIP
2007-008516 R425 R-CHIP
2007-008516 R426 R-CHIP
2007-008516 R427 R-CHIP
2007-008516 R523 R-CHIP
2007-008516 R614 R-CHIP
2007-008516 R615 R-CHIP
2007-008516 R639 R-CHIP
2007-008516 R728 R-CHIP
2007-008516 R739 R-CHIP
2007-008531 R208 R-CHIP
2007-008531 R755 R-CHIP
2007-008544 R526 R-CHIP
2007-008544 R527 R-CHIP
2007-008548 R729 R-CHIP
2007-008548 R730 R-CHIP
2007-008582 R740 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-5
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2007-008587 R104 R-CHIP
2007-008588 R124 R-CHIP
2007-008588 R626 R-CHIP
2007-008588 R627 R-CHIP
2007-008588 R700 R-CHIP
2007-008588 R701 R-CHIP
2007-008588 R727 R-CHIP
2007-008806 R132 R-CHIP
2007-008806 R314 R-CHIP
2007-008806 R429 R-CHIP
2007-008808 R752 R-CHIP
2007-009084 R530 R-CHIP
2007-009084 R748 R-CHIP
2007-009084 R754 R-CHIP
2007-009111 R536 R-CHIP
2007-009115 R401 R-CHIP
2007-009115 R402 R-CHIP
2007-009115 R531 R-CHIP
2007-009115 R718 R-CHIP
2007-009115 R719 R-CHIP
2007-009155 R625 R-CHIP
2007-009155 R643 R-CHIP
2007-009155 R749 R-CHIP
2007-009157 R413 R-CHIP
2007-009157 R414 R-CHIP
2007-009157 R415 R-CHIP
2007-009157 R416 R-CHIP
2007-009201 R306 R-CHIP
2007-009233 R753 R-CHIP
2007-009361 R437 R-CHIP
2007-009420 R206 R-CHIP
2007-009793 R704 R-CHIP
2007-009793 R747 R-CHIP
2007-009838 R411 R-CHIP
2007-009879 R505 R-CHIP
2203-000233 C434 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-6
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-000254 C118 C-CERAMIC,CHIP
2203-000254 C127 C-CERAMIC,CHIP
2203-000386 C115 C-CERAMIC,CHIP
2203-000438 C100 C-CERAMIC,CHIP
2203-000696 C200 C-CERAMIC,CHIP
2203-000725 C610 C-CERAMIC,CHIP
2203-000812 C541 C-CERAMIC,CHIP
2203-000812 C563 C-CERAMIC,CHIP
2203-000854 C542 C-CERAMIC,CHIP
2203-002487 C616 C-CERAMIC,CHIP
2203-002668 C124 C-CERAMIC,CHIP
2203-002677 C101 C-CERAMIC,CHIP
2203-002709 C552 C-CERAMIC,CHIP
2203-003019 C524 C-CERAMIC,CHIP
2203-005288 C119 C-CERAMIC,CHIP
2203-005446 C205 C-CERAMIC,CHIP
2203-005682 C110 C-CERAMIC,CHIP
2203-005682 C134 C-CERAMIC,CHIP
2203-005682 C135 C-CERAMIC,CHIP
2203-005682 C136 C-CERAMIC,CHIP
2203-005682 C204 C-CERAMIC,CHIP
2203-005682 C207 C-CERAMIC,CHIP
2203-005682 C245 C-CERAMIC,CHIP
2203-005682 C260 C-CERAMIC,CHIP
2203-005682 C288 C-CERAMIC,CHIP
2203-005682 C309 C-CERAMIC,CHIP
2203-005682 C411 C-CERAMIC,CHIP
2203-005682 C445 C-CERAMIC,CHIP
2203-005682 C455 C-CERAMIC,CHIP
2203-005682 C618 C-CERAMIC,CHIP
2203-005682 C725 C-CERAMIC,CHIP
2203-005682 C726 C-CERAMIC,CHIP
2203-005682 C732 C-CERAMIC,CHIP
2203-005682 C733 C-CERAMIC,CHIP
2203-005717 C294 C-CERAMIC,CHIP
2203-005717 C704 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-7
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-005719 C130 C-CERAMIC,CHIP
2203-005719 C297 C-CERAMIC,CHIP
2203-005719 C298 C-CERAMIC,CHIP
2203-005719 C459 C-CERAMIC,CHIP
2203-005725 C236 C-CERAMIC,CHIP
2203-005725 C250 C-CERAMIC,CHIP
2203-005725 C258 C-CERAMIC,CHIP
2203-005725 C259 C-CERAMIC,CHIP
2203-005725 C261 C-CERAMIC,CHIP
2203-005725 C262 C-CERAMIC,CHIP
2203-005725 C264 C-CERAMIC,CHIP
2203-005725 C265 C-CERAMIC,CHIP
2203-005725 C267 C-CERAMIC,CHIP
2203-005725 C270 C-CERAMIC,CHIP
2203-005725 C281 C-CERAMIC,CHIP
2203-005725 C290 C-CERAMIC,CHIP
2203-005725 C292 C-CERAMIC,CHIP
2203-005727 C139 C-CERAMIC,CHIP
2203-005727 C296 C-CERAMIC,CHIP
2203-005729 C148 C-CERAMIC,CHIP
2203-005729 C218 C-CERAMIC,CHIP
2203-005729 C408 C-CERAMIC,CHIP
2203-005729 C409 C-CERAMIC,CHIP
2203-005732 C221 C-CERAMIC,CHIP
2203-005732 C222 C-CERAMIC,CHIP
2203-005736 C227 C-CERAMIC,CHIP
2203-005736 C231 C-CERAMIC,CHIP
2203-005736 C233 C-CERAMIC,CHIP
2203-005736 C235 C-CERAMIC,CHIP
2203-005736 C237 C-CERAMIC,CHIP
2203-005736 C247 C-CERAMIC,CHIP
2203-005736 C249 C-CERAMIC,CHIP
2203-005736 C257 C-CERAMIC,CHIP
2203-005736 C268 C-CERAMIC,CHIP
2203-005736 C280 C-CERAMIC,CHIP
2203-005736 C282 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-8
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-005736 C412 C-CERAMIC,CHIP
2203-005736 C429 C-CERAMIC,CHIP
2203-005736 C731 C-CERAMIC,CHIP
2203-005739 C278 C-CERAMIC,CHIP
2203-005789 C220 C-CERAMIC,CHIP
2203-005792 C126 C-CERAMIC,CHIP
2203-005806 C215 C-CERAMIC,CHIP
2203-005806 C230 C-CERAMIC,CHIP
2203-005806 C255 C-CERAMIC,CHIP
2203-005806 C334 C-CERAMIC,CHIP
2203-005806 C342 C-CERAMIC,CHIP
2203-005806 C360 C-CERAMIC,CHIP
2203-005806 C535 C-CERAMIC,CHIP
2203-005806 C536 C-CERAMIC,CHIP
2203-005993 C531 C-CERAMIC,CHIP
2203-006048 C544 C-CERAMIC,CHIP
2203-006090 C246 C-CERAMIC,CHIP
2203-006090 C521 C-CERAMIC,CHIP
2203-006120 C228 C-CERAMIC,CHIP
2203-006123 C147 C-CERAMIC,CHIP
2203-006194 C251 C-CERAMIC,CHIP
2203-006194 C266 C-CERAMIC,CHIP
2203-006194 C279 C-CERAMIC,CHIP
2203-006194 C283 C-CERAMIC,CHIP
2203-006194 C303 C-CERAMIC,CHIP
2203-006194 C304 C-CERAMIC,CHIP
2203-006194 C324 C-CERAMIC,CHIP
2203-006194 C325 C-CERAMIC,CHIP
2203-006194 C327 C-CERAMIC,CHIP
2203-006194 C328 C-CERAMIC,CHIP
2203-006194 C331 C-CERAMIC,CHIP
2203-006194 C340 C-CERAMIC,CHIP
2203-006194 C344 C-CERAMIC,CHIP
2203-006194 C345 C-CERAMIC,CHIP
2203-006194 C350 C-CERAMIC,CHIP
2203-006194 C724 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-9
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-006260 C103 C-CERAMIC,CHIP
2203-006260 C105 C-CERAMIC,CHIP
2203-006305 C142 C-CERAMIC,CHIP
2203-006305 C553 C-CERAMIC,CHIP
2203-006305 C554 C-CERAMIC,CHIP
2203-006324 C528 C-CERAMIC,CHIP
2203-006324 C611 C-CERAMIC,CHIP
2203-006348 C435 C-CERAMIC,CHIP
2203-006348 C462 C-CERAMIC,CHIP
2203-006399 C460 C-CERAMIC,CHIP
2203-006423 C106 C-CERAMIC,CHIP
2203-006423 C107 C-CERAMIC,CHIP
2203-006423 C108 C-CERAMIC,CHIP
2203-006423 C238 C-CERAMIC,CHIP
2203-006423 C242 C-CERAMIC,CHIP
2203-006423 C253 C-CERAMIC,CHIP
2203-006423 C254 C-CERAMIC,CHIP
2203-006423 C256 C-CERAMIC,CHIP
2203-006423 C263 C-CERAMIC,CHIP
2203-006423 C269 C-CERAMIC,CHIP
2203-006423 C274 C-CERAMIC,CHIP
2203-006423 C276 C-CERAMIC,CHIP
2203-006423 C277 C-CERAMIC,CHIP
2203-006423 C285 C-CERAMIC,CHIP
2203-006423 C289 C-CERAMIC,CHIP
2203-006423 C291 C-CERAMIC,CHIP
2203-006423 C306 C-CERAMIC,CHIP
2203-006423 C308 C-CERAMIC,CHIP
2203-006423 C312 C-CERAMIC,CHIP
2203-006423 C313 C-CERAMIC,CHIP
2203-006423 C314 C-CERAMIC,CHIP
2203-006423 C317 C-CERAMIC,CHIP
2203-006423 C341 C-CERAMIC,CHIP
2203-006423 C353 C-CERAMIC,CHIP
2203-006423 C354 C-CERAMIC,CHIP
2203-006423 C356 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-10
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-006423 C400 C-CERAMIC,CHIP
2203-006423 C403 C-CERAMIC,CHIP
2203-006423 C424 C-CERAMIC,CHIP
2203-006423 C428 C-CERAMIC,CHIP
2203-006423 C447 C-CERAMIC,CHIP
2203-006423 C457 C-CERAMIC,CHIP
2203-006423 C500 C-CERAMIC,CHIP
2203-006423 C504 C-CERAMIC,CHIP
2203-006423 C507 C-CERAMIC,CHIP
2203-006423 C510 C-CERAMIC,CHIP
2203-006423 C513 C-CERAMIC,CHIP
2203-006423 C516 C-CERAMIC,CHIP
2203-006423 C520 C-CERAMIC,CHIP
2203-006423 C522 C-CERAMIC,CHIP
2203-006423 C526 C-CERAMIC,CHIP
2203-006423 C537 C-CERAMIC,CHIP
2203-006423 C609 C-CERAMIC,CHIP
2203-006423 C612 C-CERAMIC,CHIP
2203-006423 C722 C-CERAMIC,CHIP
2203-006462 C310 C-CERAMIC,CHIP
2203-006556 C272 C-CERAMIC,CHIP
2203-006556 C359 C-CERAMIC,CHIP
2203-006556 C444 C-CERAMIC,CHIP
2203-006562 C414 C-CERAMIC,CHIP
2203-006562 C415 C-CERAMIC,CHIP
2203-006562 C416 C-CERAMIC,CHIP
2203-006562 C418 C-CERAMIC,CHIP
2203-006562 C419 C-CERAMIC,CHIP
2203-006562 C420 C-CERAMIC,CHIP
2203-006562 C421 C-CERAMIC,CHIP
2203-006562 C422 C-CERAMIC,CHIP
2203-006562 C425 C-CERAMIC,CHIP
2203-006562 C440 C-CERAMIC,CHIP
2203-006562 C441 C-CERAMIC,CHIP
2203-006562 C443 C-CERAMIC,CHIP
2203-006562 C461 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-11
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-006562 C534 C-CERAMIC,CHIP
2203-006562 C603 C-CERAMIC,CHIP
2203-006562 C604 C-CERAMIC,CHIP
2203-006562 C605 C-CERAMIC,CHIP
2203-006562 C606 C-CERAMIC,CHIP
2203-006562 C607 C-CERAMIC,CHIP
2203-006562 C608 C-CERAMIC,CHIP
2203-006562 C613 C-CERAMIC,CHIP
2203-006562 C614 C-CERAMIC,CHIP
2203-006562 C615 C-CERAMIC,CHIP
2203-006562 C705 C-CERAMIC,CHIP
2203-006562 C708 C-CERAMIC,CHIP
2203-006562 C716 C-CERAMIC,CHIP
2203-006562 C719 C-CERAMIC,CHIP
2203-006562 C729 C-CERAMIC,CHIP
2203-006562 C730 C-CERAMIC,CHIP
2203-006668 C211 C-CERAMIC,CHIP
2203-006668 C212 C-CERAMIC,CHIP
2203-006668 C307 C-CERAMIC,CHIP
2203-006674 C140 C-CERAMIC,CHIP
2203-006681 C116 C-CERAMIC,CHIP
2203-006681 C515 C-CERAMIC,CHIP
2203-006681 C519 C-CERAMIC,CHIP
2203-006681 C529 C-CERAMIC,CHIP
2203-006681 C530 C-CERAMIC,CHIP
2203-006681 C532 C-CERAMIC,CHIP
2203-006681 C533 C-CERAMIC,CHIP
2203-006707 C111 C-CERAMIC,CHIP
2203-006707 C112 C-CERAMIC,CHIP
2203-006707 C113 C-CERAMIC,CHIP
2203-006707 C114 C-CERAMIC,CHIP
2203-006712 C210 C-CERAMIC,CHIP
2203-006712 C243 C-CERAMIC,CHIP
2203-006824 C213 C-CERAMIC,CHIP
2203-006824 C229 C-CERAMIC,CHIP
2203-006824 C273 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-12
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2203-006824 C275 C-CERAMIC,CHIP
2203-006824 C430 C-CERAMIC,CHIP
2203-006824 C431 C-CERAMIC,CHIP
2203-006824 C432 C-CERAMIC,CHIP
2203-006824 C701 C-CERAMIC,CHIP
2203-006824 C703 C-CERAMIC,CHIP
2203-006824 C706 C-CERAMIC,CHIP
2203-006838 C109 C-CERAMIC,CHIP
2203-006838 C710 C-CERAMIC,CHIP
2203-006838 C712 C-CERAMIC,CHIP
2203-006839 C464 C-CERAMIC,CHIP
2203-006839 C545 C-CERAMIC,CHIP
2203-006839 C564 C-CERAMIC,CHIP
2203-006841 C463 C-CERAMIC,CHIP
2203-006872 C117 C-CERAMIC,CHIP
2203-006872 C121 C-CERAMIC,CHIP
2203-006872 C305 C-CERAMIC,CHIP
2203-006872 C426 C-CERAMIC,CHIP
2203-006872 C427 C-CERAMIC,CHIP
2203-006872 C433 C-CERAMIC,CHIP
2203-006872 C501 C-CERAMIC,CHIP
2203-006872 C523 C-CERAMIC,CHIP
2203-006872 C602 C-CERAMIC,CHIP
2203-006872 C715 C-CERAMIC,CHIP
2203-006890 C330 C-CERAMIC,CHIP
2203-006890 C358 C-CERAMIC,CHIP
2203-006890 C401 C-CERAMIC,CHIP
2203-006890 C437 C-CERAMIC,CHIP
2203-006890 C502 C-CERAMIC,CHIP
2203-006890 C509 C-CERAMIC,CHIP
2203-007143 C717 C-CERAMIC,CHIP
2203-007143 C718 C-CERAMIC,CHIP
2203-007210 C423 C-CERAMIC,CHIP
2203-007235 C413 C-CERAMIC,CHIP
2203-007270 C465 C-CERAMIC,CHIP
2203-007270 C619 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-13
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2404-001381 TA500 C-TA,CHIP
2404-001414 TA504 C-TA,CHIP
2404-001414 TA505 C-TA,CHIP
2404-001465 TA502 C-TA,CHIP
2404-001465 TA503 C-TA,CHIP
2404-001474 TA601 C-TA,CHIP
2404-001496 TA100 C-TA,CHIP
2703-001990 L118 INDUCTOR-SMD
2703-002176 L125 INDUCTOR-SMD
2703-002176 L201 INDUCTOR-SMD
2703-002199 L200 INDUCTOR-SMD
2703-002203 L127 INDUCTOR-SMD
2703-002204 L208 INDUCTOR-SMD
2703-002205 L202 INDUCTOR-SMD
2703-002205 L204 INDUCTOR-SMD
2703-002208 L116 INDUCTOR-SMD
2703-002268 L115 INDUCTOR-SMD
2703-002365 L123 INDUCTOR-SMD
2703-002649 L214 INDUCTOR-SMD
2703-002714 L502 INDUCTOR-SMD
2703-002714 L503 INDUCTOR-SMD
2703-002793 L112 INDUCTOR-SMD
2703-002793 L114 INDUCTOR-SMD
2703-002793 L120 INDUCTOR-SMD
2703-002798 L124 INDUCTOR-SMD
2703-002798 L205 INDUCTOR-SMD
2703-002798 L210 INDUCTOR-SMD
2703-002858 L119 INDUCTOR-SMD
2703-002900 L103 INDUCTOR-SMD
2703-002900 L105 INDUCTOR-SMD
2703-002900 L107 INDUCTOR-SMD
2703-002900 L109 INDUCTOR-SMD
2703-002903 L209 INDUCTOR-SMD
2703-002906 L217 INDUCTOR-SMD
2703-002917 L216 INDUCTOR-SMD
2703-002918 L222 INDUCTOR-SMD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-14
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2703-002919 L219 INDUCTOR-SMD
2703-002919 L220 INDUCTOR-SMD
2703-002953 L224 INDUCTOR-SMD
2703-002958 L110 INDUCTOR-SMD
2703-003001 L404 INDUCTOR-SMD
2703-003003 L223 INDUCTOR-SMD
2703-003004 L102 INDUCTOR-SMD
2703-003260 L401 INDUCTOR-SMD
2703-003260 L402 INDUCTOR-SMD
2703-003347 L601 INDUCTOR-SMD
2703-003476 L509 INDUCTOR-SMD
2703-003502 L400 INDUCTOR-SMD
2801-004339 OSC400 CRYSTAL-UNIT
2801-004573 OSC500 CRYSTAL-UNIT
2801-004589 OSC100 CRYSTAL-UNIT
2809-001277 OSC200 OSCILLATOR-VCTCXO
2901-001409 F700 FILTER-EMI SMD
2901-001409 F701 FILTER-EMI SMD
2901-001409 F702 FILTER-EMI SMD
2901-001409 F703 FILTER-EMI SMD
2901-001409 F704 FILTER-EMI SMD
2901-001469 F705 FILTER-EMI SMD
2901-001469 F706 FILTER-EMI SMD
2904-001759 F101 FILTER-SAW
2904-001785 F202 FILTER-SAW
2904-001789 F204 FILTER-SAW
2904-001864 F205 FILTER-SAW
2909-001283 F100 FILTER-DUPLEXER
2910-000034 F203 FILTER
2910-000058 F201 FILTER
2911-000128 U101 FILTER
3301-001534 L500 CORE-FERRITE BEAD
3301-001534 L501 CORE-FERRITE BEAD
3301-001534 L504 CORE-FERRITE BEAD
3301-001534 L505 CORE-FERRITE BEAD
3301-001912 L100 CORE-FERRITE BEAD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-15
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
3301-001917 L506 CORE-FERRITE BEAD
3301-001917 L507 CORE-FERRITE BEAD
3301-001917 L508 CORE-FERRITE BEAD
3301-001917 L510 CORE-FERRITE BEAD
3301-001971 L706 CORE-FERRITE BEAD
3301-001971 L707 CORE-FERRITE BEAD
3408-001109 SLIDE_KEY SWITCH
3705-001503 RFS100 CONNECTOR-COAXIAL
3709-001465 SIM400 CONNECTOR-CARD EDGE
3711-005981 CN702 CONNECTOR-HEADER
3711-006084 BTC400 CONNECTOR-HEADER
3711-006615 CN703 CONNECTOR-HEADER
3711-006615 CN704 CONNECTOR-HEADER
3711-006615 CN705 CONNECTOR-HEADER
3711-006865 CN701 CONNECTOR-HEADER
3711-006865 HDC700 CONNECTOR-HEADER
4302-001180 BAT400 BATTERY CONTACT
4709-001721 F200 RF-MODULE
GH13-00066A U502 RF-MODULE
GH71-08426A ANT100 NPR-CONTACT ANT
GH71-08426A ANT101 NPR-CONTACT ANT
GH71-08426A ANT103 NPR-CONTACT ANT
3722-002840 IFC600 CONNECTOR-HEADER
2703-003679 L700 INDUCTOR-SMD
2703-003679 L701 INDUCTOR-SMD
1108-000237 UME301 MEMORY
Please consult the GSPN website (Samsung Portal) for the most recent version of the product's
part list.

SAMSUNG Proprietary-Contents may change without notice
9. Flow Chart of Troubleshooting
This Document can not be used without Samsung's authorization
9-1
9-1. Power On
'Power On 'does not work
Yes
Check the current consumption
Yes
Current consumption
>= 100mA Download again
No
Change the Battery
Check the Battery Voltage
>=3.3V
Yes
No
Check the TP_PSHOLD
is high?
Yes
Check the ON_SW Voltage Level
No
Check the PMIC
output voltage
(C421, C427, C430, C431,
C432, C433)
Check the Pin 3of
OSC200 Produces clock
signal
No
Check the U400
check the OSC200
Yes
END
Yes
No
Yes
Check the initial operation
Yes
