Samsung GT-N7100 User manual

GSM TELEPHONE
GT-N7100
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
GSM TELEPHONE CONTENTS

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2012. 09. Rev.1.0
ⓒ

2. Specification
2-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2-1. GSM General Specification
GSM850 EGSM 900 DCS1800 PCS1900 WCDMA
2100
WCDMA
1900
WCDMA
900
WCMDA
850
Freq.
Band[MHz]
Uplink/
Downlink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
1922~1977
2112~2167
1852~1907
1932~1987
880~915
925~960
824~849
869~894
ARFCN
range 128~251 0~124 &
975~1023 512~885 512~810
UL:
9612~9888
DL:
10562~1083
8
UL:
9262~9538
DL:
9662~9938
UL:
2712~2863
DL:
2937~3088
UL:
4132~4233
DL:
4357~4458
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 80MHz 45MHz 45MHz
Mod. Bit
rate/
Bit Period
270.833kbp
s
3.692us
270.833kbp
s
3.692us
270.833kbp
s
3.692us
270.833kbp
s
3.692us
3.84Mcps 3.84Mcps 3.84Mcps 3.84Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
FrameLengt
h:
10ms
Slotlength:
0.667ms
FrameLengt
h:
10ms
Slotlength:
0.667ms
FrameLengt
h:
10ms
Slotlength:
0.667ms
FrameLengt
h:
10ms
Slotlength:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPS
K
QPSKHQPS
K
QPSKHQPS
K
QPSKHQPS
K
MS Power 33dBm~5dB
m
33dBm~5dB
m
30dBm~0dB
m
30dBm~0dB
m
24dBm~
-50dBm
24dBm~
-50dBm
24dBm~
-50dBm
24dBm~
-50dBm
Power
Class
5pcl ~
19pcl 5pcl ~19
pcl 0pcl ~15 pcl 0pcl ~15 pcl 3(max+24dB
m)
3(max+24dB
m)
3(max+24dB
m)
3(max+24dB
m)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm -106.7dBm -106.7dBm
TDMA Mux 8 8 8 8 8888
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-2
2-2. GSM Tx Power Class
TX Power
control
level
GSM850
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
EGSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control
level
PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

3. Operation Instruction and Installation
3-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Main Function
•Android OS: JB
•HSPA+ 21Mbps /HSUPA 5.76Mbps
•8
MP AF with LED Flash
•5.5
Super AMOLED MIPI (C-Type)
•A-GPS /BT v4.0 USB v2.0 /WiFi (802.11 a/b/g/n)
•Recording definition: 1080p / Playback at 1080p resolution
•Sensors: Acceleration, Electromagnetic, Gyro, RGB, Proximity, Barometer
•Additional :
-1.6
GHz Quad Core CPU

6. Level 6Repair
6-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
6-1. S/W installation
6-1-1. Required items in order to install S/W
Installation program: Downloader Program (Odin3 v3.04.exe)
GT-N7100 Mobile Phone
Data Cable
JIG BOX (GH99-36900B)
RF TEST CABLE (GH39-00985A)
OCTA LCD (GH97-13630A)
JIG Cable (GH81-10631A)
Adapter (GH99-38251A)
Serial Cable
Mobile device specific S/W: Binary files
※Settings
Connect ANYWAY JIG BOX
with JIG CABLE (Phone to JIG)
or PC to Phone Using Data Cable

Level 6Repair
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
6-2
6-1-2. S/W Installation Program (Downloader program)
Open up the S/W Installation Program by executing the "Odin3 v3.04.exe"
1.Enable the check mark by click on the following options,
-Check Re-Partition, Auto Reboot, and F. Reset Time
-Check PIT
-Check PDA, PHONE, and CSC Files
2.Enter into Download Mode
-Enter into Download Mode by pressing Volume Down button, Home Key and
ON/OFF Button simultaneously. And then, press Volume UP button in Warning Page to
enter the Download Mode.

Level 6Repair
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
6-3
3.Connect the device to PC via Data Cable.
Make sure that the one of communication port [ID:COM] box is highlighted in
light blue. The device is now connected with the PC and ready to download the
binary file into the device.
4.Start downloading binary file into the device by clicking Start Button on the screen.
the green colored "PASS!" sign will appear on the upper-left box if the binary file
has been successfully downloaded into the device.
Vol Down Power Key
Home Key

Level 6Repair
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
6-4
5. Disconnect the device from the Data cable.
6.Once the device boots up, you can check the version of the binary file or name
by pressing the following code in sequence;
*#1234#
You can perform full reset by pressing the following code in sequence;
*2767*3855#

9. Reference Abbreviate
9-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Reference Abbreviate
―AAC: AdvancedAudioCoding.
―AVC: AdvancedVideoCoding.
―BER: BitErrorRate
―BPSK: BinaryPhaseShiftKeying
―CA: ConditionalAccess
―CDM: CodeDivisionMultiplexing
―C/I: CarriertoInterference
―DMB: DigitalMultimediaBroadcasting
―두:EuropeanStandard
―ES: ElementaryStream
―ETSI: EuropeanTelecommunicationsStandardsInstitute
―MPEG: MovingPictureExpertsGroup
―PN: Pseudo-randomNoise
―PS: PilotSymbol
―QPSK: QuadraturePhaseShiftKeying
―RS: Reed-Solomon
―SI: ServiceInformation
―TDM: TimeDivisionMultiplexing
―TS: TransportStream

1. Safety Precautions
1-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of
the low margin of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use asoldering iron with apower rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replac
ement parts may not function properly.

Safety Precautions
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
1-2
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discha
rge and can be easily damaged by it. We recommend protecting these components with cond
uctive anti-static bags when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are
properly connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

4. Exploded View and Parts List
4-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4-1. Cellular phone Exploded View
QRE01
QCR105
QBC01
QFR01
QFR02
QCR12
QJK01
QCA02
QCA01
QCR72
QMP01
QME02
QLC01
QKP02
QKP01
QME04
QMO01
QSP01
QCB01
QBA01
QST01
QCK01
QVO01
QME01

5. MAIN Electrical Parts List
5-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Design LOC SEC CODE Description
D501 0403-001688 USFZ5.6V-RTK/H
ZD501,ZD604 0406-001267 RCLAMP0521P
U506 0406-001369 RCLAMP3654P.TCT
ZD500 0406-001390 PESD24VS1UL
ZD602,ZD603,ZD605,ZD606,ZD
607,ZD608,ZD609,ZD700 0406-001459 RD1301B
ZD702,ZD703,ZD704 0406-001506 UCLAMP0541Z
ZD705 0406-001506 UCLAMP0541Z
D500 0406-001526 PTVS26VS1UR
U501 0504-001176 EMD5T2R
Q021,Q200,Q600 0505-002384 PMR280UN
LED500 0601-003079 SPFCW04301BLS0D0T0
U302 0801-003024 TC7SG32AFS
U605 0801-003437 NL17SG32P5T5G
U204 0903-001837 AT32UC3L0128-D1HR
U707 1001-001394 NLAS5123MNR2G
U604 1001-001650 DG2750DN-T1-E4
F101 1001-001715 XM2400SB-DL1201
U603 1003-002337 AN30259A
U808 1003-002431 NLSX5014MUTAG
U803,U807 1003-002469 FXMA2102UMX
U210 1201-003378 SFMG2S0D001
U103 1201-003400 RF6261B
U606,U700 1202-001120 NCX2200GM
U600,U701,U702,U703 1203-004819 RP103K281D-TR
U801 1203-004925 RP103K301D-TR
U104 1203-006801 RF6590
U806 1203-006874 RP154L006A-E2
U710 1203-007142 AAT2146MIJS-0.6-T1
U708 1203-007294 RP114K331D-TR
U505 1203-007321 MAX77693EWQ+T
U502,U504 1203-007323 MAX14607EWL+T
U805 1203-007324 RP114K121D-TR
U102 1203-007333 RF6561A
U7041203-007408 TPS65632A
U500 1203-007657 MAX77686GEWE+T

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-2
Design LOC SEC CODE Description
U602 1204-003328 ES305B
U709 1204-003364 S5C73M3X01-Y040
U226 1204-003365 SI4705-D50-GM
U400 1205-003611 TPS22922YFPR
U800 1205-004233 SII9244BO
U601 1205-004509 WM1811AECS
UCP300 1205-004511 PMB9811C
U503 1205-004513 SIP32408DNP-T1-GE4
U101 1205-004515 PMB5712A2
U802 1205-004643 W9001
U228 1205-004646 PN65OEV
U232 1205-004649 BCM4752IUB2G
U200 1209-002124 AK8963C
U230 1209-002149 LSM330DLC
U231 1209-002167 BMP182
U809 1301-002097 ICE40LP1K-CM36
V100 1404-001726 NCP03XH223E05RL
TH300,TH400,TH401 1404-001728 NCP03WB473J05RL
V601,V602,V603,V700,V701 1405-001183 AVLC5S01033
V600 1405-001296 IECS0505C040FR
R214 2007-000141 RC1005J222CS
R104 2007-003010 RC1005J200CS
R307,R762 2007-007107 RC1005F1003CS
R623 2007-007134 RC1005F393CS
R477 2007-007136 RC1005F472CS
R444 2007-007142 RC1005F103CS
R651 2007-007573 RK73H1ETP3303F
R515,R731,R732,R804 2007-007741 M5534204B10E0R
R761 2007-007798 RC1005F0100CS
R416,R652 2007-007942 RC-1005F105CS
R218,R329,R817,R818,R823,R
824,R825,R838 2007-008045 ERJ1GEJ101C
R209,R811,R812 2007-008048 ERJ1GENJ201X
R211,R212,R456,R457,R458,R
706,R816,R819,R820,R826,R82
7,R828,R829,R833,R834
2007-008052 ERJ1GENJ472X
R207,R412,R413,R414,R415,R
461,R464,R513,R602,R605,R60
6,R712,R805,R808,R809
2007-008055 ERJ1GENJ104X

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-3
Design LOC SEC CODE Description
R221 2007-008117 ERJ2RKF2701X
R527 2007-008403 RC1005F364CS
R451,R452,R803 2007-008419 ERJ1GEJ102C
R512,R639,R650,R708 2007-008420 RMC-1/20-330JPA
R437,R438,R445,R446 2007-008478 RMC1/20152JPA
R201,R202,R203,R204,R205,R
528,R529,R530,R531 2007-008483 RMC1/20473JPA
R500,R504,R523 2007-008486 ERJ1GEJ204C
R319,R402,R403,R406,R408,R
409,R410,R422,R423,R455,R46
3,R465,R475,R516,R532,R600,
R630,R635,R638,R660,R704,R
800,R806,R810,R814,R832,R83
5,R836,R837
2007-008516 ERJ1GEJ103C
R105,R206,R321,R471 2007-008531 MCR006MZPJ0100
R213,R216,R217,R227,R228,R
305,R306,R330,R331,R332,R72
1,R722,R729,R730
2007-008588 MCR006YZPJ222
R735 2007-008736 RC1005F150CS
R509,R525,R526 2007-008774 ERJ1GEJ2R2C
R503 2007-008798 MCR006YZPJ153
R435,R436,R468,R469 2007-008800 MCR006MZPF2002
R112 2007-008806 RC0603J510CS
R219,R220,R223,R421,R424,R
501,R502,R616,R617,R710,R71
1,R801
2007-009084 MCR006YZPJ105
R334 2007-009155 MCR006YZPJ474
R417,R418,R419,R420,R443,R
728,R736,R763 2007-009157 MCR006YZPF1003
R815,R831 2007-009158 MCR006MZPF1503
R308,R309,R310,R311,R312,R
313,R314,R315 2007-009171 MCR006YZPJ513
R317 2007-009171 MCR006YZPJ513
R764 2007-009201 MCR006YZPJ300
R640,R641 2007-009208 MCR006YZPJ160
L208,R610 2007-009212 MCR006YZPF1001
R505 2007-009314 MCR006MZPJ334
R304 2007-009315 RC0603J4R7CS
R425,R426,R427,R428,R429,R
430,R431,R432,R433,R434,R44
7,R448,R453,R454,R459,R460
2007-009408 ERJ1GEF222C
R619,R620 2007-009408 ERJ1GEF222C

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-4
Design LOC SEC CODE Description
R102,R103 2007-009801 MCR006YZPF1000
R511,R707 2007-009866 MCR006YZPF2003
R441,R442,R466,R467 2007-009920 RC0603F241CS
R462 2007-009964 MCR01MZP5F44R2
R612 2007-009969 MCR006YZPF1201
R507 2007-010202 RC0603F473CS
R318 2007-010233 RC1005F4021CS
C120 2203-000254 GRP155R71C103K
C204 2203-000330 GRP1555C1H120J
C215 2203-000438 GRP155R71H102K
C586 2203-000725 GRP155R71H392KA01E
C581 2203-001101 GRP155R71E682KA01E
C585 2203-001239 GRP1555C1H820JD01E
C216 2203-002668 C1005CG1H0R5BT
C138,C160,C162,C199,C572,C
649 2203-005682 GRP0335C1E330JD01E
C816,C821,L120,L122 2203-005683 GRP0335C1E8R0DD01E
C118 2203-005719 GRP0335C1E390JD01E
C210,C297,C299,C506,C507,C
703,C704 2203-005725 GRP0335C1E220JD01E
C169,C248,C249,C628,C632 2203-005726 GRM0335C1E560J
C219,C227,C580 2203-005727 CL03C120JA3GNNC
C223,C629,C633,C653 2203-005729 CL03C150JAGC
C442,C443,C655,C656 2203-005731 GRM0335C1E180J
C143,C239,C246,C563,C646,C
647 2203-005734 GRM0335C1E820JD01D
C139,C202,C212,C760 2203-005736 GRP0335C1E101JD01E
C107 2203-005789 ECJZEC1E0R5B
C129,C195 2203-005792 CL03C1R5CA3GNNC
C131,C236,C264,C738 2203-005806 GRP033R71C102KD01E
C110,C312,C453,C803 2203-006048 GRM155R71A104K
C207,C263 2203-006123 GRM0335C1E5R6CD01D
C801,C807,C810,C812 2203-006141 GRM188R61C105K
C333 2203-006190 GRM155R60J224KE01E
C137,C295,C336,C338,C601,C
603,C605 2203-006194 GRP033R70J103KA01E
C117,C132 2203-006260 GRM155R61A224KE19E

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-5
Design LOC SEC CODE Description
C218,C237,C238 2203-006305 CM03CG100J25AH
C213 2203-006318 GRP0335C1E1R2CD01
C817 2203-006324 GRM188R61A225KE19D
C128 2203-006379 GRP033R70J472KA01
C168 2203-006410 CL03C1R8CA3GNNC
C134,C148,C180,C181,C182,C
183,C184,C189,
C190,C191,C203,C217,C220,C
224,C225,C226,
C228,C231,C232,C234,C250,C
253,C255,C293,C301,C302,C30
6,C309,C310,C314,C316,C317,
C318,C319,C322,C323,C325,C
326,C327,C330,C331,C332,C33
4,C335,C339,C340,C346,C400,
C403,C407,C413,C422,C439,C
441,C448,C501,C502,C505,C56
6,C579,C612,C614,C651,C652,
C660,C756,C804,C805,C806,C
814,C818,C822,C823,C829,C83
0,C831,C832,C833,C834,C835,
C836
2203-006423 GRM33X5R104K6.3
C241,C244 2203-006556 GRM0335C1E470JD01D
C173,C174,C221,C222,C621,C
622,C714, 2203-006562 CV05X5R105K10AH
C240,C243,C414,C416,C420 2203-006642 GRM033R71E331KA01D
C185,C186,C187,C192 2203-006647 GRM033R60J473KE19D
C449,C731 2203-006668 GRM033R61A222K
C130,C133,C590 2203-006815 GRM033R70J682K
C178,C179 2203-006824 CV105X5R475K10AT
C149,C150,C209,C247,C252,C
558,C561,C570,C734 2203-006839 CL03A104KP3NNNC

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-6
Design LOC SEC CODE Description
C230 2203-006844 CV05X5R474K10AH
C114,C116,C175,C188,C298,C
342,C406,C412,C424,C430,C43
7,C438,C440,C526,C529,C530,
C534,C538,C539,C544,C545,C
639,C641,C642,C730,C737,C74
0,C746,C749,C800,C802,C811,
2203-006872 GRM155R60J225ME15D
C103,C157,C158,C194 2203-006896 GRM033R71E121KA01D
C100,C101,C568 2203-006979 CL03B103KP3NNNC
C450,C452 2203-006994 CL03B332KP3NNNC
C726 2203-007133 CL21A106KOCLRNC
C140 2203-007194 CL03C6R8BA3GNNC
C176,C300,C305,C307,C311,C
315,C320,C324,C328,C329,C34
1,C347,C503
2203-007210 CV03X5R224K06AH
C431,C547,C548,C549,C550,C
551 2203-007240 CL10A226MQ8NRNE
C343,C345,C718,C719 2203-007269 CL21A226MPCLRNC
C710,C713 2203-007270 CL10A106KP8NNNC
C172,C177,C211,C401,C404,C
408,C421,C434,C521,C523,C52
4,C525,C542,C543,C546,C552,
C615,C616,C619,C627,C758,C
759
2203-007317 CV05X5R475M06AH
C251,C423,C427 2203-007385 CL05A106MR5NRNC
C815 2203-007391 CL03A474KQ3NNNH
C144,C313 2203-007393 CL05A475KP5NRNC
C200,C229,C233,C235,C291,C
292,C296,C321,C402,C405,C40
9,C410,C411,C415,C417,C418,
C419,C425,C426,C428,C429,C
432,C433,C435,C436,C444,C44
5,C446,C447,C519,C527,C528,
C531,C532,C533,C535,C536,C
537,C540,C541,C565,C567,C57
1,C576,C583,C600,C602,C604,
C606,C607,C610,C613,C617,C
618,C644,C650,C654,C706,C70
7,C708,C720,C721,C722,C723,
C724,C725,C752,C753,C808,C
809,C813,C819,C820,C824,C82
5,C826,C827,C828
2203-007449 CL03A105MQ3CSNH
C562,C573,C587,C589 2203-007456 CL05A105KA5NQNC
C254 2203-007474 CL05A106MQ5NUNC
C337 2203-007775 CV05X5R475M10AH
C559 2203-007781 CL10A226MP8NUNE

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-7
Design LOC SEC CODE Description
C555,C556 2203-007795 CL05A106MP5NUNC
C147,C257,C258,C553,C574,C
575,C623,C625,C626,C634,C63
7,C638,C640,C643,C711,C712,
C751
2203-007796 CL03A105MP3NSNC
C736,C745,C750 2203-008095 CL03A224KP3NNNC
C735,C739,C741,C743,C744,C
748 2203-008097 CL03A104KA3NNNC
R224,R225 2203-008192 CL05A106MP5NUNZ
C256,C588,C757 2203-008243 CL03A103KA3NNNC
C508,C611 2203-008525 CL10A475KP9NHBC
C716 2203-008526 CL21A106KOCL3RC
C111,C112,C167,C303,C304,C
308,C513,C514,C515,C516,C51
7,C715
2203-008527 CL05A106MP8NUB8
C560,C564 2203-008528 CL10A226MPMNUBE
C122,C165,C206,C509,C510,C
511,C512,C518,C520,C522,C55
4
2203-008529 CL05A475MP7NRBC
TA500,TA501 2404-001506 TCTP1A476M8R-D
TA600 2404-001561 298D336X06R3M2T
TA100 2409-001127 TEPSLJ1A225M8R
C500 2409-001243 CPH3225A/PAS3225P
L515 2703-001231 LK1608-100K-T
L514,L516,L710 2703-002309 CIH05T82NJNC
L124,L127 2703-002596 LQW15AN15NH00D
L118 2703-002958 CIH03T56NJNC
L102 2703-003004 LLV0603-F47NJ
L207 2703-003476 LQG15HSR27J02D
L713 2703-003685 CIG21L4R7MNE
L500,L507,L508,L509 2703-003687 CIG21L1R0MNE
L123,L125,L126 2703-003755 MIPSZ2012D4R7-SS
L302,L303 2703-003869 LQM2HPN3R3MGCL
L704,L707 2703-003897 1239AS-H-4R7N
L105 2703-003911 CIG22H1R0MNE
L111,L119,L129 2703-004000 LQP03TN47NJ02D
L131,L142,L143 2703-004035 LQP03TN3N3B02D
L106 2703-004039 LQW15CN18NJ00D
