Samsung Messager Touch SCH-R631 User manual

Samsung Messager™ Touch
(SCH-R631)
PORTABLE TRI-BAND
MOBILE PHONE
User Manual
Please read this manual before operating your
phone, and keep it for future reference.
r631.book Page 1 Tuesday, July 20, 2010 12:31 PM

CKT_SCH-R631.02_English_UM_DF23_TE_072010_F3
Intellectual Property
All Intellectual Property, as defined below, owned by or which is
otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to,
accessories, parts, or software relating there to (the “Phone
System”), is proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or
unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of
authorship. You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover, you agree that you
will not (and will not attempt to) modify, prepare derivative works of,
reverse engineer, decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or ownership in the
Intellectual Property is transferred to you. All applicable rights of the
Intellectual Property shall remain with SAMSUNG and its suppliers.
Samsung Telecommunications America
(STA), LLC
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein Rd.
Richardson, TX 75082 Plano, TX 75074
Toll Free Tel: [phone].HELP (4357)
Internet Address: http://www.samsungusa.com
r631.book Page 2 Tuesday, July 20, 2010 12:31 PM

©2010 Samsung Telecommunications America, LLC is a registered
trademark of Samsung Electronics America, Inc. and its related
entities.
Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS
System (Automated Response System) at:
www.samsungtelecom.com/support
Printed in XXXXX.
Nuance®, VSuite™, XT9®Text Input, and the Nuance logo are
trademarks or registered trademarks of Nuance Communications,
Inc. or its affiliates in the United States and/or other countries.
Openwave®is a registered Trademark of Openwave, Inc.
RSA®is a registered Trademark RSA Security, Inc.
The Bluetooth®word mark, figure mark (stylized “B Design”), and
combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.
microSD™, microSDHC™, and the microSD logo are Trademarks of
the SD Card Association.
All other product or service names are the property of their respective
owners.
r631.book Page 3 Tuesday, July 20, 2010 12:31 PM

Disclaimer of Warranties; Exclusion of
Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON
THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES
NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO
THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR
QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS
CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT
PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR
IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR
USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR
BENEFITS.
r631.book Page 4 Tuesday, July 20, 2010 12:31 PM

1
Table of Contents
Section 1: Getting Started ........................................6
Understanding this User Manual ......................................... 6
Install the Battery ...............................................................7
Remove the Battery ............................................................9
Charging the Battery ..........................................................9
Activating Your Phone ...................................................... 11
Setting Up Your Voicemail ................................................12
Memory Card (Optional) .................................................... 12
Headset (Optional) ............................................................14
Section 2: Understanding Your Phone ...................15
Features of Your Phone .................................................... 15
Side Views of Your Phone ................................................. 16
Open View (Front) of Your Phone ......................................18
Closed Rear View of Your Phone .......................................20
Command Keys ................................................................21
Entering Text .................................................................... 23
Understanding the Display Screen ....................................24
Menu Navigation ..............................................................26
Your Phone’s Modes ........................................................ 27
Section 3: Call Functions ........................................32
Making a Call ...................................................................32
Answering a Call .............................................................. 36
Call Options Menu ............................................................39
Calls .................................................................................40
r631.book Page 1 Tuesday, July 20, 2010 12:31 PM

2
Section 4: Understanding Your Contacts ............... 43
Finding a Contact ..............................................................43
Adding a New Contact ......................................................44
Deleting a Contact ............................................................45
Editing a Contact ..............................................................45
Saving a Number After a Call ............................................46
Speed Dial ........................................................................47
Contact Groups .................................................................48
Memory Status .................................................................49
Section 5: Storefront .............................................. 50
Launching Storefront ........................................................50
Applications Shopping and Downloading ...........................50
Section 6: Messages .............................................. 51
Types of Messages ...........................................................51
Create and Send Text Messages .......................................51
Create and Send Picture Messages ...................................52
Create and Send Video Messages .....................................52
Receive Messages ............................................................53
Message Folders ..............................................................54
Messages .........................................................................54
Drafts ...............................................................................54
Voicemail ..........................................................................54
Erase Messages ...............................................................55
Managing Preset Messages ..............................................55
Message Settings .............................................................55
Section 7: Browser ................................................. 56
Browser ............................................................................56
r631.book Page 2 Tuesday, July 20, 2010 12:31 PM

3
Launching the Browser ....................................................56
Using the Browser ............................................................57
Using Links ...................................................................... 57
Section 8: Voice Service .........................................58
Voice Commands .............................................................58
Voice Settings .................................................................. 59
Section 9: Camera-Camcorder ...............................61
Taking Pictures and Videos ..............................................61
Screen Layouts ................................................................66
Saving Pictures and Videos .............................................. 69
Point, Click, and Send Pictures and Videos .......................70
Section 10: Multimedia ..........................................72
Camera ............................................................................72
Camcorder .......................................................................72
My Images ....................................................................... 72
My Videos ........................................................................72
Music Player ....................................................................73
My Ringtones ................................................................... 74
Ringback Tones ............................................................... 74
Communities ....................................................................74
Section 11: Tools ....................................................75
Calendar .......................................................................... 75
Alarm ...............................................................................75
Bluetooth .........................................................................75
Timer ...............................................................................77
Stop Watch ......................................................................77
World Clock ......................................................................77
r631.book Page 3 Tuesday, July 20, 2010 12:31 PM

4
Calculator .........................................................................78
Tip Calculator ...................................................................78
Memo Pad ........................................................................78
Converter ..........................................................................78
Device Search ..................................................................78
Section 12: Settings ............................................... 79
Location ...........................................................................79
Sound Settings .................................................................79
Display Settings ................................................................80
Touch Settings .................................................................80
Phone Settings .................................................................81
Call Settings .....................................................................82
Memory Manager .............................................................83
Phone Info ........................................................................83
Section 13: Health and Safety Information ........... 85
Health and Safety Information ...........................................85
Please Note the Following Information When
Using Your Handset ......................................................87
Samsung Mobile Products and Recycling ..........................88
UL Certified Travel Adapter ...............................................88
Consumer Information on Wireless Phones .......................89
Road Safety ....................................................................100
Responsible Listening .....................................................102
Operating Environment ...................................................105
Using Your Phone Near Other Electronic Devices .............106
FCC Hearing-Aid Compatibility (HAC) Regulations
for Wireless Devices ...................................................107
Potentially Explosive Environments .................................110
r631.book Page 4 Tuesday, July 20, 2010 12:31 PM

5
Emergency Calls ............................................................ 111
FCC Notice and Cautions ................................................ 112
Other Important Safety Information ................................. 113
Product Performance ..................................................... 114
Availability of Various Features/Ring Tones .....................116
Battery Standby and Talk Time .......................................116
Battery Precautions ........................................................ 116
Care and Maintenance ...................................................119
Section 14: Warranty Information ........................121
Standard Limited Warranty .............................................121
End User License Agreement for Software ......................126
Index ......................................................................135
r631.book Page 5 Tuesday, July 20, 2010 12:31 PM

6
Section 1: Getting Started
This section explains how to start using your Samsung Messager™
Touch.
Understanding this User Manual
The chapters of this manual generally follow the same order as the
menus and sub-menus in your phone.
Notes and Tips
Throughout this manual there is text that is set apart from the rest.
These are intended to point out important information, quick methods
for activating features, to define terms, and more. The definitions for
these methods are as follows:
• Notes : Explain alternative options within the current feature, menu, or sub-
menu.
• Tips : Provide quick or innovative methods for performing functions related
to the subject.
• Important : Points out important information about the current feature that
could affect performance, or even damage your phone.
Text Conventions
This manual provides condensed information about how to use your
phone. To make this possible, the following terms and icons appear in
r631.book Page 6 Tuesday, July 20, 2010 12:31 PM

Getting Started 7
place of often-used procedural steps:
Install the Battery
Note: Your phone comes packaged with a partially charged rechargeable standard
Li-Ion battery and travel adapter.
Important!: You must fully charge the battery the first time you use your phone,
otherwise you could damage the battery.
Battery Cover
Remove the battery cover to
access the battery.
䊳 To remove the battery
cover , if needed, lay the
phone face down and
insert a small coin into the
slot at the bottom of the
battery cover and gently
pry it away from the phone. Then, lift the cover away from the
phone (2).
select Touch a menu item or screen item to launch or save
a menu item or screen field of interest.
➔ Used in place of “select” in long “drill down”
procedure steps.
Example: “... Settings ➔ Call Settings ➔ Answer Options ...”

r631.book Page 7 Tuesday, July 20, 2010 12:31 PM

8
䊳 To replace the battery cover ,
align the top end of the
battery cover over the
battery (1) and press the
battery cover down into
place (2).
Install the Battery
䊳 Insert the top end of the battery, matching the gold contacts on
the battery to those on the inside of the phone (1), then press
lightly on the bottom end of the battery down into the phone
until it slips into place (2).
r631.book Page 8 Tuesday, July 20, 2010 12:31 PM

Getting Started 9
Remove the Battery
Before removing the battery, turn the phone off, if necessary. To turn
the phone off, press and hold the key.
䊳 Lift the bottom end of the battery up and away from the phone
(1) and slide the battery up and out of the phone (2).
Charging the Battery
Your phone is powered by a rechargeable standard Li-Ion battery.
Only use Samsung-approved charging devices and batteries.
Samsung accessories are designed to maximize battery life. Use of
other accessories may invalidate your warranty and may cause
damage.
Low battery indicator
The battery indicator in the upper-right corner of the display indicates
power level. Monitor the battery strength and ensure your battery is
adequately charged. If you continue to use your phone without
charging its battery, the phone will shut down.
r631.book Page 9 Tuesday, July 20, 2010 12:31 PM

10
•
Five bars indicate a full charge.
• An empty battery icon indicates a near empty battery.
• A blinking empty battery icon and a tone sounding indicate you have
two to three minutes before the battery is too low to operate the phone.
Use the Travel Adapter
The travel adapter included with your phone is a convenient, light-
weight charger that rapidly charges your phone from any 120/220
VAC outlet.
Important!: For connection to an electrical supply not located in North America,
you must use an adapter of the proper configuration for the power
outlet. Use of the wrong adapter could damage your phone and void
your warranty.
1. Plug the large end of the Travel Adapter into a standard 120
VAC or 220 VAC wall outlet.
2. Insert the small end of the
Travel Adapter into the
charger/accessory
connector on the side of
your phone. You must
unplug the adapter before
removing the battery from
the phone during charging
to avoid damage.
Correct
Incorrect
r631.book Page 10 Tuesday, July 20, 2010 12:31 PM

Getting Started 11
Activating Your Phone
Contact your Wireless Carrier and follow their instructions for
obtaining service, if necessary. We suggest that you read this guide
to fully understand the services your phone supports.
Turning Your Phone On
䊳 Press and hold the key until the display lights. the phone
searches for a network signal, and the time, date, and day
appear on the display.
If you are outside of your carrier’s coverage or roaming area, the No
Service icon ( ) appears at the top of the phone’s display. If you
cannot place or receive calls, try later when service is available, or at
another location.
Note: As with any other radio-transmitting device, do not touch the antenna while
using your phone as this can affect call quality and can cause the phone to
operate at a higher power level than is necessary.
Turn Your Phone Off
䊳 With the phone on, press and hold the key for two or
more seconds. Your phone powers off.
Note: If your phone is on and you press for less than one second, the phone
will not power off. This prevents your phone from being turned off
accidentally.
r631.book Page 11 Tuesday, July 20, 2010 12:31 PM

12
Setting Up Your Voicemail
Voicemail allows callers to leave voice messages, which can be
retrieved any time.
Note: Once your Voicemail account has been set up, you can use the Voicemail
folder (under the Message menu) to view details of voice messages in your
Voicemail box.
䊳 In Standby mode, press and hold the key, or dial your
mobile number to dial Voicemail. Follow the prompts in the
new user tutorial to set up your mail box.
Listen to Voicemail
䊳 In Standby mode, press and hold the key or dial your
mobile number to dial Voicemail. After connecting, you will
hear your voice greeting, and the prompt to enter your
password.
Memory Card (Optional)
Your phone has a Memory Card slot on its right side, behind the
battery cover. You can install a microSD™ card to provide additional
memory for storing files (such as, sound files and photos) in your
phone.
You can install a microSDTM card to provide additional memory for
storing files (such as, sound files and photos) in your phone.
r631.book Page 12 Tuesday, July 20, 2010 12:31 PM

Getting Started 13
Install a Memory Card
1. Open the microSD cover on the left hand side of the phone, as
shown.
2. Make sure that the gold contacts of the card are face up, as
shown, then carefully slide the memory card into the memory
card slot until you feel it click into place.
3. Replace the microSD cover.
Remove a Memory Card
1. Open the microSD cover on the right hand side of the phone.
2. Carefully press the memory card inward until you feel it
release.
3. Slowly release your pressure on the card. It will slide outward a
short distance.
Incorrect
Correct
r631.book Page 13 Tuesday, July 20, 2010 12:31 PM

14
4. Remove the memory card from the memory card slot.
5. If desired, install another memory card. (For more information,
refer to “Install a Memory Card” .)
6. Replace the microSD cover.
Headset (Optional)
Your phone includes a jack for attaching an optional Headset/
Headphones. You can use a Headset or Headphones to hear
telephone conversations.
䊳 Insert the Headset or Headphones into the Headset Connector
on the top of the phone.
r631.book Page 14 Tuesday, July 20, 2010 12:31 PM

Understanding Your Phone 15
Section 2: Understanding Your Phone
This section outlines some key features of your phone. It also
describes the screen format and the icons that will be displayed
when the phone is in use.
Features of Your Phone
Domestic and international voice and text messaging service
(available on participating networks).
• Full-screen Touch Screen [high-resolution (240 x320 pixels), color]
• Widget menu
• Messaging (Text, Picture, Video, and E-mail) with sliding QWERTY Keypad
• Built-in 2 Megapixel Digital wide screen Camera-Camcorder
• High speed data (3G-EVDO)
• Bluetooth
®
Stereo (v2.0) Wireless Technology (see Note)
• Global Positioning (GPS) Technology
• PIM Functions
• Voice and Touch Keypad Dial
• Music (MP3) Player and Video (MP4) Player
• Support for optional microSD™ and microSDHC™ cards up to 16 GB
• Voice Recognition
• Speakerphone
Note: The Messager Touch phone supports the wireless headset, handsfree, file
transfer, and object push profiles for Bluetooth®wireless technology.
r631.book Page 15 Tuesday, July 20, 2010 12:31 PM

16
Side Views of Your Phone
1. Volume Key — Lets you adjust the
ring volume in Standby mode, adjust
the voice volume during a call, or
mute the ringer during an incoming
call.
2. Memory Card Slot — Used to plug in
an optional microSD™ memory card
for additional multimedia file storage.
3. Music Player Key — Launches the
Music Player. (Requires a Memory
Card be installed. For more
information, refer to “Install a
Memory Card” on page 13.)
4. Send Key — Lets you place or receive a call. In Standby mode,
press the key once to access the Recent Calls log.
5. Clear Key — Deletes characters from the display when you are
in text entry mode. Press this key to return to the previous
menu or screen when navigating features on your phone.
6. Display — Indicates the status of your phone (including
numbers dialed, feature and function screens, status icons,
message indicators and contents, signal strength, and so on)
and shows all touch controls (hot buttons, keypads, and
menus).
r631.book Page 16 Tuesday, July 20, 2010 12:31 PM
