Samsung SCH-F699 User manual

SCH-F699
user manual

ii
using this
manual
This user manual has been specially designed to
guide you through the functions and features of your
mobile phone. To get started quickly,
refer to “introducing your mobile phone,”
“assembling and preparing your mobile phone,”
and “using basic functions.”
Instructional icons
Before you start, familiarise yourself with the icons
you will see in this manual:
Warning —situations that could cause
injury to yourself or others
Caution —situations that could cause
damage to your phone or other
equipment
Note —notes, usage tips, or additional
information
X Refer to —pages with related information;
for example: X p.12 (represents “see
page 12”)

using this manual
iii
Copyright information
Rights to all technologies and products that
comprise this device are the property of their
respective owners:
Bluetooth®is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: B015183.
→
Followed by —the order of options or
menus you must select to perform a step;
for example: In menu mode, select
Messages → Create new message
(represents Messages, followed by
Create new message)
[] Square brackets —phone keys; for
example: [ ] (represents the Power/
Menu exit key)
<> Angled brackets —softkeys that control
different functions at each screen; for
example: <Menu> (represents the Menu
softkey)

iv
contents
safety and usage information .................. 2
Safety warnings ..........................................2
Safety precautions ......................................4
Important usage information .......................7
introducing your mobile phone ............... 9
Unpack .......................................................9
Phone layout .............................................10
Keys .........................................................11
Display ......................................................12
Icons .........................................................12
assembling and preparing your mobile
phone ...................................................... 14
Install the UIM card and the battery ........... 14
Charge the battery .................................... 16
Insert a memory card (optional) .................17

contents
v
using basic functions ............................ 18
Turn your phone on and off ....................... 18
Access menus .......................................... 19
Customise your phone .............................. 19
Use basic call functions ............................ 20
Send and view messages ......................... 22
Add and find contacts ............................... 23
Use basic camera functions ...................... 24
Listen to music .........................................25
Use Air services ........................................ 27
using advanced functions ..................... 28
Use advanced call functions .....................28
Use advanced phonebook functions ......... 29
Use advanced messaging functions .......... 31
Use advanced camera functions ............... 32
Use advanced music functions ................. 34
using tools and applications ................. 37
Use the Bluetooth wireless feature ............ 37
Activate and send an SOS message ......... 38
Activate the mobile tracker ........................ 39
Record and play voice memos .................. 42
Edit images ............................................... 43
Play a game .............................................. 44
View world clocks ..................................... 44
Set and use alarms ................................... 44
Create a timetable .................................... 45
Use the calculator ..................................... 46
Convert measurements ............................. 46
Use the stopwatch .................................... 46
Set a countdown timer ............................. 47
Create a text memo .................................. 47
Manage your calendar .............................. 47
troubleshooting ........................................ a

2
safety and
usage
information
Comply with the following precautions to avoid
dangerous or illegal situations and ensure peak
performance of your mobile phone.
Keep your phone away from small
children and pets
Keep your phone and all accessories out of the
reach of small children or animals. Small parts may
cause choking or serious injury if swallowed.
Protect your hearing
Safety warnings
Listening to a headset at high volumes
can damage your hearing. Use only the
minimum volume setting necessary to
hear your conversation or music.

safety and usage information
3
Install mobile phones and equipment
with caution
Ensure that any mobile phones or related equipment
installed in your vehicle are securely mounted. Avoid
placing your phone and accessories near or in an air
bag deployment area. Improperly installed wireless
equipment can cause serious injury when air bags
inflate rapidly.
Handle and dispose of batteries and
chargers with care
• Use only Samsung-approved batteries and
chargers specifically designed for your phone.
Incompatible batteries and chargers can cause
serious injuries or damage to your phone.
• Never dispose of batteries or phones in a fire.
Follow all local regulations when disposing used
batteries or phones.
• Never place batteries or phones on or in heating
devices, such as microwave ovens, stoves, or
radiators. Batteries may explode when
overheated.
• Never crush or puncture the battery. Avoid
exposing the battery to high external pressure,
which can lead to an internal short circuit and
overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between
mobile phones and pacemakers to avoid potential
interference, as recommended by manufacturers
and the independent research group, Wireless
Technology Research. If you have any reason to
suspect that your phone is interfering with a
pacemaker or other medical device, turn off the
phone immediately and contact the manufacturer of
the pacemaker or medical device for guidance.

4
safety and usage information
Turn off the phone in potentially
explosive environments
Do not use your phone at refuelling points (service
stations) or near fuels or chemicals. Turn off your
phone whenever directed by warning signs or
instructions. Your phone could cause explosions or
fire in and around fuel or chemical storage and
transfer areas or blasting areas. Do not store or carry
flammable liquids, gases, or explosive materials in
the same compartment as the phone, its parts, or
accessories.
Reduce the risk of repetitive motion
injuries
While using your phone, hold the phone with a
relaxed grip, press the buttons lightly, use special
features that reduce the number of buttons you have
to press (such as templates and predictive text), and
take frequent breaks.
Drive safely at all times
Avoid using your phone while driving and obey all
regulations that restrict the use of mobile phones
while driving. Use hands-free accessories to
increase your safety when possible.
Follow all safety warnings and
regulations
Comply with any regulations that restrict the use of a
mobile phone in a certain area.
Use only Samsung-approved
accessories
Using incompatible accessories may damage your
phone or cause injury.
Safety precautions

safety and usage information
5
Turn off the phone near medical
equipment
Your phone can interfere with medical equipment in
hospitals or health care facilities. Follow all
regulations, posted warnings, and directions from
medical personnel.
Turn off the phone or disable the
wireless functions when in an aircraft
Your phone can cause interference with aircraft
equipment. Follow all airline regulations and turn off
your phone or switch to a mode that disables the
wireless functions when directed by airline
personnel.
Protect batteries and chargers from
damage
• Avoid exposing batteries to very cold or very hot
temperatures (below 0° C/32° F or above
45° C/113° F). Extreme temperatures can reduce
the charging capacity and life of your batteries.
• Prevent batteries from contacting metal objects,
as this can create a connection between the +
and - terminals of your batteries and lead to
temporary or permanent battery damage.
• Never use a damaged charger or battery.
Handle your phone carefully and
sensibly
• Do not disassemble your phone due to a risk of
electric shock.

6
safety and usage information
• Do not allow your phone to get wet—liquids can
cause serious damage. Do not handle your
phone with wet hands. Water damage to your
phone can void your manufacturer’s warranty.
• Avoid using or storing your phone in dusty, dirty
areas to prevent damage to moving parts.
• Your phone is a complex electronic device—
protect it from impacts and rough handling to
avoid serious damage.
• Do not paint your phone, as paint can clog
moving parts and prevent proper operation.
• If your phone has a camera flash or light, avoid
using it close to the eyes of children or animals.
• Your phone may be damaged by exposure to
magnetic fields. Do not use carrying cases or
accessories with magnetic closures or allow your
phone to come in contact with magnetic fields for
extended periods of time.
Avoid interference with other electronic
devices
Your phone emits radio frequency (RF) signals that
may interfere with unshielded or improperly shielded
electronic equipment, such as pacemakers, hearing
aids, medical devices, and other electronic devices
in homes or vehicles. Consult the manufacturers of
your electronic devices to solve any interference
problems you experience.

safety and usage information
7
Use your phone in the normal position
Avoid contact with your phone’s internal antenna.
Allow only qualified personnel to service
your phone
Allowing unqualified personnel to service your phone
may result in damage to your phone and will void
your warranty.
Ensure maximum battery and charger
life
• Avoid charging batteries for more than a week, as
overcharging may shorten battery life.
• Over time, unused batteries will discharge and
must be recharged before use.
• Disconnect chargers from power sources when
not in use.
• Use batteries only for their intended purpose.
Handle UIM cards and memory cards
with care
• Do not remove a card while the phone is
transferring or accessing information, as this
could result in loss of data and/or damage to the
card or phone.
• Protect cards from strong shocks, static
electricity, and electrical noise from other devices.
• Frequent writing and erasing will shorten the life
span of memory cards.
• Do not touch gold-coloured contacts or terminals
with your fingers or metal objects. If dirty, wipe the
card with a soft cloth.
Important usage information

8
safety and usage information
Ensure access to emergency services
Emergency calls from your phone may not be
possible in some areas or circumstances. Before
travelling in remote or undeveloped areas, plan an
alternate method of contacting emergency services
personnel.
Specific Absorption Rate (SAR)
certification information
Your phone conforms to U.S. Federal
Communications Commission (FCC) standards that
limit human exposure to radio frequency (RF) energy
emitted by radio and telecommunications
equipment. These standards prevent the sale of
mobile phones that exceed a maximum exposure
level (known as the Specific Absorption Rate, or
SAR) of 1.6 watts per kilogram of body tissue.
In normal use, the actual SAR is likely to be much
lower, as the phone has been designed to emit only
the RF energy necessary to transmit a signal to the
nearest base station. By automatically emitting lower
levels when possible, your phone reduces your
overall exposure to RF energy.
The FCC has granted an Equipment Authorisation
for this model phone based on the compliance of all
reported SAR levels with the FCC RF exposure
guidelines. The authorization can be found on the
FCC Office of Engineering and Technology website
at http://www.fcc.gov/oet/ea.

9
introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, display, and icons.
Unpack
Check your product box for the following items:
• Mobile phone
• Battery
• Travel adapter (charger)
•Usermanual
The items supplied with your phone may vary
depending on the software and accessories
available in your region or offered by your
service provider. You can obtain additional
accessories from your local Samsung dealer.

10
introducing your mobile phone
Phone layout
The front of your phone includes the following keys
and features:
The rear of your phone includes the following keys
and features:
Earpiece
Right softkey
Power/Menu
exit key
Mouthpiece
Left softkey
Dial key
4-way
navigation key
Display
Confirm key
Multifuncion
jack
Alphanumeric
keys Special function
keys
Volume key
Closing the phone automatically locks the
exposed keys to prevent you from accidentally
pressing them. To unlock these keys, press
< Unlock > → < OK >.
Memory card slot Battery cover
Mirror Camera lens
Camera key
Internal
antenna

introducing your mobile phone
11
Keys
Key Function
Softkeys Perform actions indicated at the
bottom of the display
4-way
navigation
In Idle mode, access user-defined
menus; In Menu mode, scroll
through menu options
Confirm
In Idle mode, access Menu
mode; In Menu mode, select the
highlighted menu option or
confirm an input
Dial
Make or answer a call; In Idle
mode, retrieve recently dialled,
missed, or received numbers
Power/Menu
exit
Turn the phone on and off (press
and hold); End a call; In Menu
mode, cancel input and return to
Idle mode
Alpha-
numeric
Enter numbers, letters and
special characters; In Idle mode,
press and hold [0] to enter an
international call prefix
Special
function
Enter special characters or
perform special functions; In Idle
mode, press and hold [ ] for the
silent profile
Volume
Adjust the phone’s volume; In Idle
mode, press and hold for the
outdoor profile
Camera
Turn on the camera (press and
hold); In Camera mode, take a
photo or record a video
Key Function

12
introducing your mobile phone
Display
Your phone’s display consists of three areas:
Icons
Learn about the icons that appear on your display.
Icon line
Displays various icons
Text and graphic area
Displays messages,
instructions, and information
you enter
Softkey line
Displays the current actions
assigned to each softkey
Select Back
Icon Definition
Signal strength
Roaming (outside of normal service area)
Call in progress
SOS message feature activated
1X network connected
Bluetooth activated
New text message (SMS)
New multimedia message (MMS)
Alarm activated
Memory card inserted

introducing your mobile phone
13
Normal profile activated
Silent profile activated
Battery power level
Current time
Icon Definition

14
assembling and
preparing your
mobile phone
Get started by assembling and setting up
your mobile phone for its first use.
Install the UIM card and the battery
When you subscribe to a cellular service, you will
receive a User Identity Module, or UIM, card with
subscription details, such as your personal
identification number (PIN) and optional services.
To install the UIM card and battery,
1. Remove the battery cover.
If the phone is on, press and hold [ ] to turn
it off.

assembling and preparing your mobile phone
15
2. Insert the UIM card. 3. Insert the battery.
4. Replace the battery cover.
• Place the card in the phone with the gold-
coloured contacts facing down.
• You can only use voice call and text message
functions with the regular UIM card. To use
full network services, insert an OMH card
(Ruby marked RUIM card).

16
assembling and preparing your mobile phone
Charge the battery
Before using the phone for the first time, you must
charge the battery.
1. Open the cover to the multifunction jack on the
side of the phone.
2. Plug the small end of the travel adapter into the
multifunction jack.
3. Plug the large end of the travel adapter into a
power outlet.
4. When the battery is fully charged (the icon is
no longer moving), unplug the travel adapter from
the power outlet.
5. Unplug the travel adapter from the phone.
6. Close the cover to the multifunction jack.
Improperly connecting the travel adapter can
cause serious damage to the phone. Any
damages by misuse are not covered by the
warranty.
With the triangle
facing up
About the low battery indicator
When your battery is low, the phone will emit a
warning tone and a low battery message. The
battery icon will also be empty and blinking. If
the battery level becomes too low, the phone
will automatically power off. Recharge your
battery to continue using your phone.
