Samsung SGH-A400 User manual

ELECTRONICS
SGH-A400
WAP Browser
User’s Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.: GH68-02251A
English. 07/2001. Rev. 1.0
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.

3
Contents
About the WAP Browser . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting Up the WAP Browser . . . . . . . . . . . . . . . . . . . . 5
Accessing the WAP Browser . . . . . . . . . . . . . . . . . . . . . 5
Configuring the WAP Browser . . . . . . . . . . . . . . . . . . . . 7
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Starting the WAP Browser . . . . . . . . . . . . . . . . . . . . . . 9
Exiting the WAP Browser . . . . . . . . . . . . . . . . . . . . . . . 9
Using the WAP Browser . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the Soft Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Navigating the WAP Browser . . . . . . . . . . . . . . . . . . . . 10
Entering Text, Numbers or Symbols . . . . . . . . . . . . . . . . 11
Using the WAP Browser Menus . . . . . . . . . . . . . . . . . . . 12
Using and Selecting Menu Options . . . . . . . . . . . . . . . . . 12
Reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mark Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
About Phone.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Advanced... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Show URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Homepage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Offline Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Restart UP.Browser . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
What is WAP?
WAP (Wireless Application Protocol) is the
gateway to a new world of mobile data. It
provides a universal standard, enabling you to
access Web-based interactive information
services and applications directly from your
mobile phone.

54
Setting Up the WAP
Browser
Before using the WAP Browser, you must set the
parameters for the proxy server used by your service
provider.
Accessing the WAP Browser
Toaccess the WAP Browser menu, proceed as follows.
1. When the idle screen is displayed, press the Menu
soft key to enter the menu facility.
About the WAP
Browser
Your phone comes equipped with a WAP (Wireless
Application Protocol) Browser, making it possible for you
to access the Wireless Web.
The WAP Browser allows you to:
• Access up-to-the-minute information via your phone
• View specially designed text versions of popular
Internet sites including Yahoo!®, CNN MobileSM and
the Weather Channel®
Browsing the Wireless Web using your phone is unlike
using your computer, in that site providers have:
• Selected only the critical aspects of their site for
wireless phone users
• Removed most graphics
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service indicator
icon ( ) appears on the display to inform you that you
are:
• Connected to the Wireless Web
• Will be billed accordingly (rates vary according to your
service option)
The WAP Browser ends the network connection after a
certain period of inactivity and automatically reconnects
as necessary. For this reason, you may find that you are
billed for several network connections within a single
session. This is normal and is designed to minimise your
bill.
<SERVICE PROVIDER>
12:57PM
Sat 05 Mar
Menu Name
2. Press the or key one or more times until the
WAP Browser menu option is displayed, and then
press the Select soft key. You can also press the
key directly.
Network
Services
WAP
Browser
Select 8

7
UUssiinnggYYoouurrWWAAPPBBrroowwsseerrSSeettttiinnggUUpptthheeWWAAPPBBrroowwsseerr
6
SSeettttiinnggUUpptthheeWWAAPPBBrroowwsseerr
Option Description (continued)
Settings Allows you to set up five proxy servers for
the WAP Browser.
Clear Clears the information stored in the cache
Cache (the phone’s temporary memory used to store
the most recently accessed Web pages).
Configuring the WAP Browser
To configure the WAP Browser, proceed as follows.
1. Within the WAP Browser menu, highlight Settings
using the
and keys, then press the Select soft
key.
2. Select a proxy server and enter the parameters
required. Contact your service provider for details.
Parameter Description
Profile Name Name of the HTTP proxy server.
Homepage Address of your startup homepage.
URL When the default homepage is
displayed, you can delete it using
the C key and enter your own
choice.
Security Data transmission mode: Secure
to protect your data against
unauthorised access; otherwise,
Non-Secure.
Option Description
Home Connects the phone to the network and
loads the homepage of the Wireless Web
service provider.
Favorite Allows you to store the URL addresses of
your favourite Web sites. You can access
this menu directly by pressing and holding
down the key while using the WAP
Browser.
To store a URL address, scroll to an empty
location and press the Options soft key.
Enter the address, then the name. After
saving a address, three sub-menus are
available. Select Goto URL to access the
site quickly, Edit to edit the selected
address and Erase to delete the selected
address.
http:// Allows you to enter manually the URL
address of the Web site that you wish to
access. You can access this menu directly
by pressing and holding down the key
while using the WAP Browser.
3. Press the or key one or more times to highlight
the required option and then press the Select soft
key.
WAP Browser
1 Home
2 Favorite
3 http://
Select 8.1

998
Getting Started
Starting the WAP Browser
Note: The first time you use the WAP Browser, you are
guided through a security setup procedure that
takes three to five minutes. Follow the on-screen
prompts to complete the procedure (only
necessary the first time you access the service).
To start the WAP Browser when the idle screen is
displayed, press the key or press the Menu soft key,
followed by the and keys.
A connection is established with your service provider
and the corresponding homepage is displayed.
The content of the WAP Browser startup homepage
depends on your Wireless Web service provider. To
scroll through the screen, use the
and keys.
Note: To access the startup homepage from any other
screen in the WAP Browser, use the Home option.
For more information on the WAP Browser
menus, refer to page 12.
Exiting the WAP Browser
To exit the browser at any time, simply press the
key.
Parameter Description (continued)
IP Address IP address required to connect
to the Internet.
Login Name PPP server login ID.
Password PPP server password.
Dial-up Number PPP server phone number.
Data Call Type Data call type: Analogue or
ISDN.
Note: The WAP Browser settings may vary,
depending on the service provider. Contact
your service provider for further information.
3. When you are satisfied with each parameter, press
the Select or OK soft key.
4. When you have finished configuring the WAP
Browser, press the key.
SSeettttiinnggUUpptthheeWWAAPPBBrroowwsseerr

1110
UUssiinnggtthheeWWAAPPBBrroowwsseerr
Entering Text, Numbers or Symbols
When you are prompted to enter text, the current text
entry mode is indicated on the screen. The following
modes are available.
Mode Description
alpha/ Allows you to enter letters in the alphabet.
ALPHA Press the corresponding key until the
required letter is displayed.
SYM 1 ~ 3 Allows you to enter various symbols and
punctuation marks. To view more symbols,
press the More soft key.
NUM Allows you to enter numbers.
word/ Allows you to enter words by pressing
WORD one key only per letter. Availability of this
mode depends on your service provider. To
access the WAP Browser menu or startup
homepage in this mode, press the key.
To... Then...
Change modes Press the right soft key one or
more times.
Enter a space Press the key.
Switch between Press the key.
upper and lower-case
characters
Edit text • Set the cursor to the right of the
character(s) to be corrected
• Press the Ckey one or more
times as required
• Enter the correct character(s)
Using the WAP
Browser
Using the Soft Keys
A bar containing browser commands is located at the
bottom of the WAP Browser display. The soft keys ( )
below the bar are used to execute these commands. The
two keys are called soft keys because their function
changes depending on the WAP Browser application in
use.
Navigating the WAP Browser
To... Then...
Scroll through and Press the
or key until
select browser items the symbol points to the
required item, and then press
the OK soft key to confirm the
selection.
Select a numbered Press the corresponding
item numeric key.
Return to the Press the Back soft key or
previous page the Ckey.
Return to the startup Select the Home menu option;
homepage for more information on this
option, refer to page 12.

1312
UUssiinnggtthheeWWAAPPBBrroowwsseerrMMeennuuss
Bookmarks
This option allows you to load a bookmarked Web page
directly.
Select the required page in the bookmark list using
the
and keys, and then press the OK soft key to
go to the selected page.
Note: To use the Bookmark feature, you must first set a
bookmark for the required page using the Mark
Site option below.
Mark Site
You can set a bookmark for most pages; they can then
be accessed directly from any Web page. Bookmarks
save you time by reducing the number of steps required
to access a given page.
Select this option for any page that you wish to consult
regularly.
About Phone.com
This option provides you with information about:
• Phone.Com, Inc.
• Your version of the WAP Browser
Using the WAP
Browser Menus
Using and Selecting Menu Options
Various menu options are available when you are using
the WAP Browser to navigate the Wireless Web.
To access a menu option, proceed as follows.
1. Press the key.
A menu is displayed.
2. Highlight the required menu option by pressing the
or key.
3. Select the option by pressing the OK soft key.
4. If necessary, select the secondary option using the
and keys, and press the OK soft key to confirm.
Note: The menus may vary, depending on your version
of the WAP Browser.
Reload
This option reloads the current page.
Home
This option takes you back at any time to the homepage
of the Wireless Web service provider.

15
UUssiinnggtthheeWWAAPPBBrroowwsseerrMMeennuuss
14
UUssiinnggtthheeWWAAPPBBrroowwsseerrMMeennuuss
Offline Services
Most applications are stored on a server that cannot be
accessed outside your wireless coverage area. However,
some applications can be stored in the cache of your
phone, enabling you to use them offline. You can
remove the associated site from the cache at any time.
Note: If you attempt to save more than 15 sites, a
message informs you that the first site in the list
will be deleted to create space for the new site.
To delete a site from the offline services list, proceed as
follows.
1. Select the site using the
and keys.
2. Press the Erase soft key.
Outbox
This advanced feature stores outgoing requests from the
browser so that they can be processed at a later date.
Restart UP.Browser
If the browser is not functioning correctly, select this
option to restart the browser without exiting it.
Encryption
This advanced feature is set automatically by the service
provider. You do not need to change it.
Advanced...
This option gives you access to the following advanced
features.
Show URL
This advanced feature displays the URL address of the
site to which you are currently connected. It also
enables you to declare the current site as the startup
homepage.
To... Then...
Declare the current Press the Set soft key and
page as your startup confirm your setting by
homepage pressing the OK soft key.
Cancel your setting Press the Cancel soft key.
Homepage
With this advanced feature, you can change the startup
homepage manually.
To... Then...
Declare the current Press the OK soft key.
page as your startup
homepage
Change the homepage Enter the required URL.
manually
For more information on entering text, numbers or
symbols, refer to page 11.
