Samsung SGH T809 User manual

UVEJ5_1.1_WCt809_101705_F8
SGH-T809
PORTABLE Quad-Band
TELEPHONE
User Guide
Please read this manual before operating your
phone, and keep it for future reference.

Intellectual Property
All Intellectual Property, as defined below, owned by or which is
otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to,
accessories, parts, or software relating there to (the “Phone
System”),isproprietarytoSamsungandprotectedunderfederal
laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or
unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other
works of authorship. You may not infringe or otherwise violate
the rights secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble,
or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to
you. All applicable rights of the Intellectual Property shall
remain with SAMSUNG and its suppliers.
Samsung Telecommunications America (STA),
Inc.
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein St.
Richardson, TX 75082 Plano, TX 75074
Tel: [phone] Toll Free Tel: [phone].HELP (4357)
Internet Address: http://www.samsungusa.com
©2005 Samsung Telecommunications America, Inc. is a
registered trademark of Samsung Electronics America, Inc. and
its related entities.

Printed in Korea.
GH68-07931A
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered Trademark RSA Security, Inc.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH
THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS
IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR
ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP
OF THE PRODUCT OR THE COMPONENTS CONTAINED
THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR
CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TO THE PRODUCT. IN ADDITION, SAMSUNG SHALLNOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE OR USE OF THE PRODUCT OR
ARISING FROM THE BREACH OF THE EXPRESS WARRANTY,
INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR
BENEFITS.

Table of Contents 1
Table of Contents
Table of Contents
Section 1: Getting Started . . . . . . . . . . . . . . . . . . 5
Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . 10
Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . . . . . . . 10
Section 2: Understanding Your Phone . . . . . . . 13
Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . 14
View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Get More Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Section 3: Call Functions . . . . . . . . . . . . . . . . . . 21
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adjusting the Call Volume . . . . . . . . . . . . . . . . . . . . . . . . 24
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Selecting Functions and Options . . . . . . . . . . . . . . . . . . . 29
Section 4: Menu Navigation . . . . . . . . . . . . . . . 37
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Menu Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Section 5: Entering Text . . . . . . . . . . . . . . . . . . 45
Changing the Text Input Mode . . . . . . . . . . . . . . . . . . . . . 46
Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using T9 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Using Number Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Section 6: Understanding Your Phonebook . . . 53
Storing a Number in the SIM Card . . . . . . . . . . . . . . . . . . 54
Storing a Number in the Phone’s Memory . . . . . . . . . . . . 55

Table of Contents
2
Finding a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . .57
Dialing a Number from Phonebook . . . . . . . . . . . . . . . . . .59
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Editing a Caller Group . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Dialing a Number from the SIM Card . . . . . . . . . . . . . . . .62
Copying all SIM Phonebook Entries . . . . . . . . . . . . . . . . . .62
Deleting all of the Phonebook Entries . . . . . . . . . . . . . . . .63
My Name Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Finding My Own Phone Number . . . . . . . . . . . . . . . . . . . .64
FDN List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Section 7: Messages . . . . . . . . . . . . . . . . . . . . . .69
Voice Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Text Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Picture Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Sentbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Delete All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Broadcast Messages (SIM Dependent) . . . . . . . . . . . . . . .91
Instant Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Section 8: Changing Your Settings . . . . . . . . . .95
Time & Date Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Network Services Settings . . . . . . . . . . . . . . . . . . . . . . .106

Table of Contents 3
Table of Contents
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Reset Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Section 9: Fun & Apps . . . . . . . . . . . . . . . . . . . 117
File Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
MP3 Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Image Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Organizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Section 10: Camera and Camcorder . . . . . . . . 141
Using the Camera and Camcorder . . . . . . . . . . . . . . . . . 142
Take and Send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Record Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
My Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
My Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
My Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
My Journal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Section 11: t-zones . . . . . . . . . . . . . . . . . . . . . 155
t-zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Section 12: Health and Safety Information . . . 161
Health and Safety Information . . . . . . . . . . . . . . . . . . . . 162
Consumer Information on Wireless Phones . . . . . . . . . . 164
Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . 176
Using Your Phone Near Other Electronic Devices . . . . . . 176
Potentially Explosive Environments . . . . . . . . . . . . . . . . 179
Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . 181
Other Important Safety Information . . . . . . . . . . . . . . . . 182
Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Availability of Various Features/Ring Tones . . . . . . . . . . 184

Table of Contents
4
Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . .185
Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . .185
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . .187
Section 13: Warranty Information . . . . . . . . . .189
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . .190
Intellectual Property Statement . . . . . . . . . . . . . . . . . . . .196
Samsung Telecommunications America (STA), Inc. . . . . .197
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199

Section 1: Getting Started 5
Section 1
Section 1: Getting Started
Topics Covered
• Activating Your Phone
• Switching the Phone On or Off
• Setting Up Your Voicemail
This section allows you to start using your phone by
activating your service and setting up your voice mail.

6
Section 1
Activating Your Phone
When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, any optional
services available, and many others.
Installing the SIM Card
Important! The plug-in SIM card and its contacts can be easily damaged
by scratching or bending, so be careful when handling, inserting, or
removing the card.
Keep all SIM cards out of reach of small children.
If necessary, switch off the phone by holding down the
key until the power-off image displays.
1. Remove the back cover. To do so, slide the back cover off
in the direction of the arrow (1).
2. Lift the back cover away, as shown (2).

Section 1: Getting Started 7
Activating Your Phone
Section 1
3. Remove the battery. Grasp the bottom of the battery (1)
and lift up. Pull the battery out and away (2).
4. Slide the SIM card into the SIM card socket so that the
card locks into place. Make sure the gold contacts of the
card face into the phone.
Note: When you need to remove the SIM card, slide it, as shown, and take
it out of the socket.

8
Section 1
5. Place the battery so that the 3 brass tabs on the end
align with the 3 brass prongs at the bottom of the battery
compartment (1). Press the battery down until it clicks
into place (2).
6. Replace the back cover. Make sure that the battery is
properly installed before switching on the phone.
Charging a Battery
Your phone is powered by a rechargeable Li-ion battery.
A travel adapter comes with your phone for charging the
battery. Use only approved batteries and chargers. Ask
your local Samsung dealer for further details.
You can use the phone while the battery is charging, but
this causes the phone to charge more slowly.
Note: You must fully charge the battery before using your phone for the
first time. A discharged battery recharges fully in approximately 200
minutes.
1. With the battery in position in the phone, plug the
connector of the travel adapter into the jack at the
bottom of the phone.

Section 1: Getting Started 9
Activating Your Phone
Section 1
2. Plug the adapter into a standard AC wall outlet.
3. When charging is finished, unplug the adapter from the
power outlet and disconnect it from the phone.
Note: You must unplug the adapter before you remove the battery from the
phone during charging; otherwise, the phone could be damaged.
Low Battery Indicator
When the battery is weak and only a few minutes of talk
time remain, a warning tone sounds and the “Battery
low” message repeats at regular intervals on the display.

10
Section 1
When this happens, your phone turns off the backlight to
conserve the remaining battery power.
When the battery level becomes too low, the phone
automatically turns off.
Switching the Phone On or Off
1. Slide the phone open.
2. Press and hold the key until the phone switches on.
3. If the phone asks for a PIN, enter the PIN and press the
OK soft key or the key. For further details, see "PIN
check" on page 111.
The phone searches for your network and after finding it,
the Idle screen appears. Now, you can make or receive
calls.
Note: The display language is preset to English at the factory. To change
the language, use the Language menu. For further details, see "Language"
on page 97.
4. When you wish to switch off the phone, press and hold
the key until the power-off image displays.
Setting Up Your Voice Mail
For new users, follow the instructions below to set up
voicemail:
1. Open your phone to access the keypad.
2. In Idle mode, press and hold the key on the keypad.
3. Follow the tutorial to create a password, a greeting, and
your name.

Section 1: Getting Started 11
Setting Up Your Voice Mail
Section 1
Note: These steps may be different depending on your network.
Accessing Your Voice Mail
You can access your Voice Mail by pressing the key on
the keypad or by going to the menu. To access Voice Mail
using the menu:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Highlight Messages and press the Select soft key or the
key.
3. Highlight Voice mail and press the Select soft key or
the key.
4. Highlight Call voice mail and press the Select soft key
or the key. Your phone dials the specified voice mail
number.
5. When connected, follow the voice prompts from the
voice mail center.
Changing the Voice Mail Number
Your SIM card gives you the default service numberof the
voice mail center. However, should you need to change
the number, use the following procedures:
1. In Idle mode, press the Menu soft key to access the
Menu mode.
2. Highlight Messages and press the Select soft key or the
key.
3. Highlight Voice mail and press the Select soft key or the
key.

12
Section 1
4. Highlight Voice server number and press the Select
soft key or the key. Highlight Empty and press the
Options soft key.
5. Highlight Edit and press the Select soft key or the
key. Or, you may highlight Delete to delete the number.
6. Edit the name if desired, and then press the Down
Navigation key to edit the number.
7. Press the Options soft key, highlight the Save option,
and press the Select soft key or the key.
8. Press the key to return to Idle mode.

Section 2: Understanding Your Phone 13
Section 2
Section 2: Understanding Your Phone
Topics Covered
• Features of Your Phone
• View of Your Phone
•Keys
• Display Layout
•GetMoreHelp
This section outlines some key features of your phone. It
also displays the screen and the icons that are displayed
when the phone is in use.

14
Section 2
Features of Your Phone
Your phone is lightweight, easy-to-use and offers many
significant features. The following list outlines a few
of the features included in your phone.
• Bluetooth Technology
• Instant Messaging capability
• Multimedia capability
• Fun & Apps feature provides file manager, MP3 player, games,
image editor, alarms, calendar, calculator, world time, unit
conversion, timer, and stopwatch.
View of Your Phone
The following illustrations show the main elements of
your phone:

Section 2: Understanding Your Phone 15
Keys
Section 2
Keys
The following list correlates to the illustrations.
1. During a call, adjusts the earpiece volume.
In Idle mode with the phone open, adjusts the ring
volume. With the phone closed, turns on the external
display when held down.
2. Performs the functions indicated by the screen text on
the bottom line of the display.
3. Makes or answers a call.
In Idle mode, recalls the last number dialed or received
when held down.
4. In Idle mode, accesses voice mail when held down.
5. The headset jack is used for the hands-free headset.
6. Enters special characters. Performs various functions.
7. External speakers allow you to hear sounds and music.
8. The microphone used during phone calls and voice note
recordings.
9. Enters numbers, letters, and some special characters.
10. TransFlash memory card slot. This expansion slot allows
you to insert a TransFlash memory card to add
additional memory and storage capacity.
11. The Cancel key deletes characters from the display.
In Menu mode, it returns you to the previous menu level.

16
Section 2
12. Ends a call. Also switches the phone on and off when
held down.
In Menu mode, cancels your input and returns the phone
to Idle mode.
13. In Idle mode, launches the WAP (Wireless Application
Protocol) browser.
In Menu mode, selects the highlighted menu options.
When the Left soft key shows Options, it is the
short-cut key to select the first option in the options list.
14. In Menu mode, scrolls through the menus and
Phonebook.
In Idle mode:
䢇Down key: allows you to access the Phonebook Search
menu directly.
䢇Up key: allows you to access the Camera or Camcorder
feature directly.
䢇Left key: allows you to access Text messaging directly.
䢇Right key: allows you to access the Voice notes feature
directly.
When entering text, moves the cursor to the left or right,
depending on which side you press.
15. Display area where text and graphics are displayed.
16. Used to listen to audio from your phone.
17. The built-in digital camera/camcorder has video capture
capabilities.
