Samsung SM-S766C User manual

SM-S766C
SMARTPHONE
User Manual
Please read this manual before operating your device
and keep it for future reference.

i
Legal Notices TF_SM-S766C_Eng_UM_NK2_TN_120514_F4
Legal Notices
Warning: This product contains chemicals known to the
State of California to cause cancer and reproductive toxicity.
Intellectual Property
All Intellectual Property, as defined below, owned by
or which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is
proprietary to Samsung and protected under federal laws,
state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions
(patentable or unpatentable), patents, trade secrets,
copyrights, software, computer programs, and related
documentation and other works of authorship. You may
not infringe or otherwise violate the rights secured by the
Intellectual Property. Moreover, you agree that you will
not (and will not attempt to) modify, prepare derivative
works of, reverse engineer, decompile, disassemble,
or otherwise attempt to create source code from the
software. No title to or ownership in the Intellectual

ii
Legal Notices
Property is transferred to you. All applicable rights of the
Intellectual Property shall remain with SAMSUNG and its
suppliers.
Open Source Software
Some software components of this product incorporate
source code covered under GNU General Public
License (GPL), GNU Lesser GeneralPublic License
(LGPL), OpenSSL License, BSD License and other
open source licenses. Toobtain the source code
covered under the opensource licenses, please visit:
http://opensource.samsung.com.
Disclaimer of Warranties; Exclusion of
Liability
EXCEPT AS SET FORTH IN THE EXPRESS
WARRANTY CONTAINED ON THE WARRANTY PAGE
ENCLOSED WITH THE PRODUCT, THE PURCHASER
TAKES THE PRODUCT “AS IS”, AND SAMSUNG
MAKES NO EXPRESS OR IMPLIED WARRANTY
OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT, INCLUDING BUT NOT LIMITED TO
THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE
OR USE; THE DESIGN, CONDITION OR QUALITY

iii
Legal Notices
OF THE PRODUCT; THE PERFORMANCE OF THE
PRODUCT; THE WORKMANSHIP OF THE PRODUCT
OR THE COMPONENTS CONTAINED THEREIN;
OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION
OR CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG
SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY
KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE
ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR
EDITING OF REGISTRY SETTINGS, OR YOUR
MODIFICATION OF OPERATING SYSTEM SOFTWARE.

iv
Legal Notices
USING CUSTOM OPERATING SYSTEM SOFTWARE
MAY CAUSE YOUR DEVICE AND APPLICATIONS TO
WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT
USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH
AS CUSTOM OS.
SAFE™(Samsung For Enterprise)
SAFE™: “SAFE™” (Samsung for Enterprise) is a mark
for a Samsung device which has been tested against
Samsung’s own internal criteria for interoperability with
certain third party security-related solutions for MDM
and VPN. The testing includes field testing with local
network connection and menu tree testing which tests
functionality of the solutions in conjunction with the
Samsung device. During the testing, the device is tested
with the security solutions to see if the solutions work
with the device as described by the third party security
solution providers. The testing, for example, includes
field testing with local network connection and menu
tree testing which tests functionality of the solutions
in conjunction with the Samsung device. For more
information about Samsung’s SAFE™program, please
refer to www.samsung.com/us/safe.

v
Legal Notices
Disclaimer of Warranties: EXCEPT AS OTHERWISE
PROVIDED IN THEIR STANDARD END USER LICENSE
AND WARRANTY, TO THE FULL EXTENT PERMITTED
BY LAW SAMSUNG ELECTRONICS CO., LTD.,
SAMSUNG TELECOMMUNICATIONS AMERICA,
LLC, AND THEIR AFFILIATES (COLLECTIVELY
REFERRED TO HEREIN AS THE “SAMSUNG
ENTITIES”) EXPRESSLY DISCLAIM ANY AND ALL
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, INTEROPERABILITY OR NON-
INFRINGEMENT, WITH RESPECT TO INFORMATION
TECHNOLOGY SECURITY PROTECTION, SAFE™
DEVICES AND APPLICATIONS TESTED WITH SAFE™
DEVICES. IN NO EVENT SHALL THE SAMSUNG
ENTITIES BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL
DAMAGES OF ANY KIND WHATSOEVER WITH
RESPECT TO INFORMATION TECHNOLOGY SECURITY
PROTECTION, SAFE™DEVICES OR APPLICATIONS
TESTED WITH SAFE™DEVICES. In addition, information
technology security protection will be affected by
features or functionality associated with, among other
things the e-mail platform, master data management, and
virtual private network solutions selected by the software
provider, solution provider or user. Choice of an e-mail,
master data management, and virtual private network
solution is at the sole discretion of the software provider,

vi
Legal Notices
solution provider or user and any associated effect on
information technology security protection is solely the
responsibility of the software provider, solution provider
or user. For complete statement of limited warranty,
please refer to www.samsung.com/us/safe, available on
the web and where Samsung smartphones and mobile
devices are sold. [091714]
Samsung Telecommunications
America (STA), LLC
Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082
1-800-SAMSUNG (726-7864)
1-888-987-HELP (4357)
Internet Address: www.samsung.com
©2014 Samsung Telecommunications America, LLC.
Samsung, Galaxy, Galaxy Note, S Pen, Multiwindow,
and SHealth are registered trademarks of
SamsungElectronics Co., Ltd.

vii
Legal Notices
Do you have questions about your Samsung
Mobile Phone?
For 24 hour information and assistance, we offer a new
FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
The actual available capacity of the internal memory is
less than the specified capacity because the operating
system and default applications occupy part of the
memory. The available capacity may change when you
upgrade the device.
Nuance®, VSuite™, T9®Text Input, and the Nuance logo
are trademarks or registered trademarks of Nuance
Communications, Inc., or its affiliates in the United States
and/or other countries.
ACCESS®and NetFront™are trademarks or registered
trademarks of ACCESS Co., Ltd. in Japan and other
countries.
The Bluetooth®word mark, figure mark (stylized “B
Design”), and combination mark (Bluetooth word mark
and “B Design”) are registered trademarks and are
wholly owned by the Bluetooth SIG.

viii
Legal Notices
microSD™and the microSD logo are Trademarks of the
SD Card Association.
Openwave®is a registered Trademark of Openwave,Inc.
Google, the Google logo, Android, the Android logo,
Google Play, Gmail, Google Mail, Google Maps, Google
Music, Google Hangouts, Picasa, Play Newsstand,
YouTube, and other marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the WirelessFidelity
Alliance, Inc.
Online Legal Information
The online version of the Health/Safety and Warranty
guide for your device can be found at:
English
www.samsung.com/us/Legal/Phone-HSGuide
Spanish
www.samsung.com/us/Legal/Phone-HSGuide-SP
The online version of the End User Licensing
Agreement for your device can be found online at:
www.samsung.com/us/Legal/SamsungLegal-EULA1.

ixTable of Contents
Getting Started.....................................................................1
Front View............................................................................. 2
Back View............................................................................. 4
Assemble Your Device ....................................................... 6
Set Up Your Device...........................................................13
Set Up Accounts ...............................................................15
Know Your Device ...........................................................17
Home Screen .....................................................................18
Status Bar ...........................................................................25
Navigation and Motions ...................................................29
Notification Panel ..............................................................31
Entering Text.......................................................................34
Calling.......................................................................................37
Making and Answering Calls .......................................... 38
Applications......................................................................... 48
Apps Screen ......................................................................49
Google Applications .........................................................55
Other Applications ............................................................60
Calculator............................................................................ 62
Calendar .............................................................................64
Table of Contents

xTable of Contents
Camera and Video............................................................66
Clock ...................................................................................72
Contacts..............................................................................75
Email....................................................................................86
Gallery .................................................................................89
Internet ................................................................................94
Memo ..................................................................................99
Messages .........................................................................101
Music Player.....................................................................110
My Files.............................................................................112
Video .................................................................................114
Voice Recorder................................................................116
Settings..................................................................................118
Wi-Fi and Wi-Fi Direct .....................................................120
Bluetooth...........................................................................127
Data Usage ......................................................................132
Airplane Mode .................................................................134
Mobile Networks..............................................................135
Virtual Private Networks (VPN) .....................................136
Lock Screen .....................................................................138
Display Settings...............................................................141
Sound Settings ................................................................146
Home Screen Mode........................................................152
Call Settings .....................................................................153
Blocking Mode.................................................................155
Hands-Free Mode ...........................................................157
Power Saving ...................................................................158

xiTable of Contents
Accessibility .....................................................................160
Language and Input Settings........................................164
Motions..............................................................................169
Accounts...........................................................................170
Backup and Reset ..........................................................174
Location Services............................................................176
Security .............................................................................178
Application Manager.......................................................182
Battery...............................................................................187
Storage..............................................................................188
Date and Time Settings..................................................193
About Your Device ..........................................................194

Learn about your mobile device
hardware, assembly procedures,
and how to get started using your
new device.
Getting Started

2Front ViewGetting Started
Front View
Power/Lock
key
Menu key Back key
Home
key
Volume
Earpiece Headset jack
Proximity sensor
Front
camera

3Front ViewGetting Started
• Back key: Tap to return to the previous screen, or to
close a dialog box, menu, or keyboard.
• Earpiece: Listen to a call.
• Front camera: Take self-portraits and record videos
of yourself.
• Headset jack: Connect an optional headset
(notincluded).
• Home key: Tap to return to the Home screen.
• Menu key: Tap to display a menu of options.
• Power/Lock key: Press and hold to turn the device
on or off. Press to lock or wake up the screen. Press
and hold to turn the device off or restart it, or for
quick access to Airplane Mode, Emergency Mode,
and to Mute, Vibrate, and Sound modes.
• Proximity sensor: Detects the presence of objects
near the device.
• Volume: Press to adjust the volume of your device’s
sounds and audio.

4Back ViewGetting Started
Back View
Microphone
Speaker
USB charger/Accessory port
Microphone
Back
camera

5Back ViewGetting Started
• Back camera: Take pictures and record videos.
• Microphone: Records audio and detects voice
commands.
• Speaker: Plays music and other sounds.
• USB charger/Accessory port: Connect the Charger/
USB cable (included), and other optional accessories
(not included).

6Assemble Your DeviceGetting Started
Assemble Your Device
Prior to use, it is necessary to install
the optional memory card (not
included), andthe battery.
Remove the Back Cover
1. Remove the back cover using the slot on the side of
your device.
2. Lift the cover up and to the bottom of the device.

7Assemble Your DeviceGetting Started
Warning: Do not bend or twist the back cover excessively.
Doing so may damage the cover.
Install a Memory Card
You can install an optional microSD or microSDHC
memory card (not included) to expand available memory
space.
Note: A memory card can be installed at any time; it is not
necessary to install it prior to using the device.
For more information on installing a memory card, see
Install a Memory Card.

8Assemble Your DeviceGetting Started
Install the Battery
1. Insert the battery into the opening on the back of
the device, making sure the connectors align.
2. Gently press down to secure the battery.
