Samsung SPH-A310 User manual

CONFIDENTIAL
SPH-A310
Digital Dual-Band Phone
SAMSUNG ELECTRONICS CO, LTD
FCC Document for SPH-A310
User Manual

CONFIDENTIAL
SPH-A310
Digital Dual-Band Phone
9. User Manual

* Depending on the software installed or your service provider, some of the descriptions in
this manual may not match from your phone.
* Depending on your country, your phone and accessories may appear different from the
illustrations in this manual.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxA
English. 08/2008. Rev 1.0
A840.book Page 1 Wednesday, October 5, 2005 10:40 AM

SPH-A310
User’s Guide
For Draft Version
A840.book Page 2 Wednesday, October 5, 2005 10:40 AM

Dial Features
This section describes the Basic Features
of your Jitterbug™ Dial phone and how to use
them.
Topics Covered
• List of Key Features
• Closed View (Front and Back)
• Open View of Your Phone
• Your Display Screen
• Your Phone Settings
– Adjust Ringer Volume
– Speakerphone
– Emergency Callback
For more information or to see the latest products and services
visit us online at www.myjitterbug.com
The first cellular phone weighed 40 ounces.
Your Jitterbug Dial weighs only 4.5 ounces.
FACT

12 Dial Features
The following OPTIONAL SERVICES can be turned
on or off at your request:
Voice Dialing Speak a name exactly as it appears
in your Phone List and your Jitterbug will
connect you right away.
Phone List Updating Select simple or advanced
ways to change and save numbers.
Voicemail Makes it easy to retrieve any missed
messages (service fees and airtime may apply).
How to Guide Provides simple instruction on
navigating Jitterbu features.
For help with any of the above optional
features, please call the Jitterbug operator
for assistance anytime 24 hours a day.
Key Features
Your Jitterbug phone was designed to be easy
to use and helpful.
• Easy to use ,,buttons
• Soft ear cushion reduces outside noise so
sound is loud and clear.
• Bright screen with large easy to read text.
• Big, backlit buttons.
• Scrolling button for searching through your
Phone List.
Your Jitterbug includes the following standard
services:
Phone List Up to 50 of the numbers you call
most often stored right in your phone. Our
operators can even set up the Phone List for
you. See Section 5 (pg 47) for more details.
Call History An easy way to review your last ten
incoming, outgoing and missed calls.
Jitterbug Operator Greets you by name, makes
calls for you and assists when you need it most.
(per minute surcharge may apply).
Emergency call back service Just in case you ever
need it.

Jitterbug Menu Navigation
We designed Jitterbug with the easiest to use
menu system ever found on a cellular phone.
And you can do it all by with three simple
buttons located at the top of the keypad.
Press up or down to scroll quickly through a
list of features. Each menu option is asked in
the form of a question.
Press to choose the feature or item
displayed on your screen.
Press to continue to the next feature
or item.
Need Help?
User Guide
More Help?
User Guide
Yes
Yes
Every screen
asks a
question which
may be
answered by
pressing “Yes”
or “No”
Built-in
User Guide
available
More Help?
User Guide
Exit Help?
User Guide
Yes
“Yes” will
perform the
action and
“No” will select
the next fea-
ture
The arrow
keys (▼▲)
allow you
to choose
alternate
content, if
available
No
Yes
User Guide
Try it out yourself! Take a look at this built-in
guide for an easy, interactive tutorial about your
new Jitterbug.

SECTION 2
SECTION 2
C
Closed View of Your Phone (Front)
1. Internal Antenna Connects with the cellular
network so you can use your phone.
2. Display Window Shows time, day and date
(when your phone is on). Indicates when you have
an incoming call or message.
3. Volume Button Adjusts the ringer or the voice
volume during a call. (To silence the ringer
during an incoming call, tap the volume button.)
4. Accessory Connector Links accessories to
your phone.
5. Power Connector Connects the AC Power
Charger to your phone.
6. Light Alert The area around the volume button
will illuminate for various indications.
ON STEADY (Phone not plugged in) Phone
turned on.
CONSTANT FLASH (Phone not plugged in) Phone
needs recharging
SHORT FLASH (Phone not plugged in) Incoming
call or message
ON BRIEFLY (Phone plugged in) Charging has
begun
ON STEADY (Phone plugged in) Charging
complete
16 Dial Features Dial Features 17

Closed View of Your Phone (Back)
1. Battery Delivers power to make your
phone function.
2. Battery Latch Slides to open for battery
removal.
3. Lanyard Connector Makes it easy to attach a
hand-strap to carry your phone.
C
SECTION 2
SECTION 2
18 Dial Features Dial Features 19

Open View of Your Phone
1. Speaker Hear the caller and other phone sounds.
2. Display Screen Shows all the information you need
to operate your phone.
3. Up/Back Arrow Button Return to previous screen on
your Phone List or Call History
4. and Buttons Responds to questions or
commands on the screen.
5. Down/More Arrow Button Advance to next screen on
your Phone List or Call History list.
6. Accessory Connector Accessories such as a hands-free
car kit conncect into your phone here.
7. Power Connector AC Power Charger and Car Power
Charger connect here to recharge your phone.
8. Microphone Picks up the sound of your voice for
calls and voice calling.
9. Power Button Turns your phone on and off.
10. Softcell Ear Pad Fits comfortably around your ear
while reducing unwanted noise.
SECTION 2
SECTION 2
Dial Features 2120 Dial Features

4. Command Area Displays questions or
commands you can choose or bypass by
pressing or .
Remember to read the Command
Area line and respond by using the
or buttons.
Your Phone Settings
When you turn your phone on, it
automatically connects to the cellular service
to be ready for calls.
You can place and receive calls only when your
phone is on.
By calling Customer Service or the Jitterbug
operator, you can turn the
following settings on or off:
• Voice Dial
• Call History
• Built-In User Guide
If, for example, you turn on Voice Dial, that’s the
first feature you will see when you open your
phone.
Display Screen
This is what you may see on the screen while
using your Jitterbug.
1. Feature Area Identifies the feature you are using.
2. Additional Entries Indicates when entries are
available before or after the current page. Use
the Up/Down arrow buttons to scroll through
entries.
• “Back” Entries available before the current
page.
• “More” Entries available after the current
page.
3. Detail Area Displays individual entries from
your Phone List, phone call status and received
messages in adjustable type size (shorter
messages appear in larger type).
TIP
Call History(01/10)
Dr Jones
Show Details?
214-555-1793
Outgoing
more
back
1
2
3
4
Voice Dial
Yes to Use
Voice Dial?
SECTION 2
SECTION 2
22 Dial Features Dial Features 23

Speakerphone
Use the Speakerphone setting to conduct a call
without holding the phone to your ear (and allow
others to participate in your phone call).
Don’t hold the phone up to your ear
when it’s in Speakerphone mode.
The volume will be too loud and may
harm your ear.
You must be on a call to use this
setting.
Using the Speakerphone:
1. When you have made or answered a call, you
will see a "Connected to…” message on the
screen, as shown.
2. Press the Volume button Up repeatedly until you
see "Press Yes for SPKR Phone," as shown.
3. Press the button.
Exiting Speakerphone Mode:
While you’re on a call, press the volume button
Down to turn this feature off.
Your phone automatically exits the
Speakerphone setting when you end a call.
NOTE
ALERT
NOTE
Adjusting the ringer volume
1. Open your phone and confirm it’s turned on.
2. Press the Up/Down volume button on the
outside of the phone below the display window.
Each press will cycle through the below options.
• Ringer Volume Ring Max
• Ringer Volume High
• Ringer Volume Med
• Ringer Volume Low
• Ringer Volume Silent
The ringer and keypad can be silenced
by pressing the volume button Down
until “Silent” appears on the screen.
Your Jitterbug will now only vibrate to alert you
to incoming calls (This can come in handy at a
movie, a library or any other location where a
ringer may be a distraction.)
Adjusting the ear piece volume
When you’re on a call, press the Volume button
up or down until the sound reaches
a comfortable volume.
TIP
24 Dial Features Dial Features 25

You will know that you are in the Emergency
Callback mode when you open your phone and
see “Emergency Callback” on the screen.
Exiting “Emergency Callback” Mode:
You must remove your battery to exit the
emergency callback setting. See page 8 for
information about removing a battery.
Why do I have an Emergency Callback setting?
If you dial 9-1-1, your mobile phone line is kept
free so that the 911 operator can call you back or
stay on the line with you.
If you mistakenly call 9-1-1, end the
call as soon as possible by pressing
to Hang up or close your phone.
TIP
Every day in the U.S., more than 200,000 wireless
calls are made to 911.
FACT
Emergency Callback Mode
When you dial 9-1-1, your phone automatically
enters Emergency Callback mode for 30 minutes.
While in this mode, you cannot make
other calls.
Making an Emergency Call:
1. Dial the numbers 9-1-1. “Calling Emergency”
appears on the screen.
2. When the 911 operator answers,
“Connected to Emergency” appears
on the screen, as shown.
Ending an Emergency Call:
1. If the “No to Hang up” command is showing at
the bottom of the screen, press .
2. Your Emergency Callback setting is now
active. To reconnect to the 911 operator, press
the button.
Connected to
Emergency
No to Hang up
911
SECTION 2
Dial Features 27
SECTION 2
26 Dial Features

The Basics 29
SECTION 3
28 Dial Features
The Basics
This section explains how to use your phone’s
Calling and Answering features.
Topics Covered
• Answering a Call
• Ending a Call
• Ignoring a Call
• Placing a Call
– Dialing Manually
– Calling the Jitterbug Operator
INon-Phone List Numbers
IPhone List Numbers
For more information or to see the latest products and services
visit us online at www.myjitterbug.com
More than 196 million Americans subscribe to
a wireless service.
FACT
SECTION 2

2. A “Connected To...” message will appear on
the screen. The caller’s voice can be heard
through the earpiece.
Answering a call if the phone is closed:
1. Open the phone. The ring tone
will stop.
2. A “Connected To...” message will
appear on the screen. The caller’s
voice can be heard.
Ending a call:
1. During calls, the “No to Hang Up”
command appears at the bottom of
the screen.
2. To end a call, press the button
or close the phone.
Ignoring a call when the phone is closed:
When the phone is ringing you can press the
volume button to mute the ringer and ignore
the call.
If Voicemail is not active, callers will get a
message that you are not available.
When someone calls you
Your phone rings or vibrates (depending on
how you set the volume level) to indicate an
incoming call. Additionally there are other
indications of incoming calls:
If your phone is open:
• A phone number or name
appears if the caller’s name and
number are stored on your
Phone List.
• If the caller can’t be identified, you will see
one of the following messages:
• Call from unavailable number
• Call from restricted number
• No number
If your phone is closed:
• The volume button on the front
of your phone flashes.
• A phone number or name appears in the
display window, as shown.
Answering a call if the phone is open:
1. Press the button.
Amy
Answer?
909-555-2334
Calling from
Connected to
No to Hang Up
Betty
909-555-2334
Connected to
No to Hang Up
Amy
909-555-2334
Connected to
Hang up?
310-555-1234
Call from
817-555-2872

Placing a Call
Dialing Manually:
You can directly dial a number from any screen
on your phone.
1. Dial the full ten digit number using your
keypad.
2. Press the button when you see “Call?”
at the bottom of your screen.
3. If you make a mistake while entering the
number, pressing the key works like a
backspace or delete button.
A dial tone means service is available.
If it’s not, you’ll see “No Service.”
Always dial the full ten digit number
including area code (except 911) even
if it’s a local call.
TIP
NOTE
Ignoring a call when the phone is open:
You can send a caller directly to your Voicemail
by pressing the button when you see
“Answer?” at the bottom of the screen. This will
also give an unavailable message if you do not
have voicemail.
Your phone continues to ring until:
• You answer the call.
• The calling party ends the call.
• You mute the ringer.
• The call is sent to Voicemail.
Silencing a Call
Turn the ringer off by opening the phone and
pressing the volume button until “Silent”
appears on the screen. Your phone will
vibrate to alert you to incoming calls.
TIP

Using your Phone List to make a Call
Your Jitterbug Dial phone can store up to
50 numbers and contact names on your Phone
List. To place a call to a number on the list:
1. Press the button until a Phone List screen
appears.
2. Press the Up/Down arrow button to move back
and forward through your Phone List until you
find the number you want to call.
3. Press when you see the “Call?” question at
the bottom of your screen.
You can control the order of the
numbers on your Phone List from your
personal page at www.myjitterbug.com
NOTE
Calling via the Jitterbug Operator:
The Jitterbug Operator can connect you to
anyone on your Phone List or to any
number in the United States or Canada.
1. Press the “O” button.
2. Press the button when you see “Call?” at
the bottom of the screen. “Calling” will appear.
3. When the operator answers, “Connected” will
appear.
4. Tell the operator the name of the person or
service you want to call.
You can end any call or exit any screen
by closing, then re-opening your
phone.
Calling Non-Phone List Numbers
To call numbers that are not stored on your
Phone List or Call History list, you can dial the
number yourself or ask the operator to call for
you in the U.S. or Canada.
For security, you may be asked for a Personal ID
Number (PIN) if you have set one up at
www.myjitterbug.com.
TIP

Moving from Feature to Feature
on Your Phone
This section explains how to move in and out of
the features on your phone.
Topics Covered
• Accessing Features
• Examples of Feature Navigation
For more information or to see the latest products and services
visit us online at www.myjitterbug.com

Features on your Jitterbug are accessible in the
following order:
1. User Guide
2. Voice dialing
3. Phone List
4. Call History
5. Phone Info
Examples of the screens you’ll see when
navigating through features are included below.
Feature 1. Phone List with voicemail.
The following diagrams illustrate how to
navigate through features should they all be
activated. If a certain feature isn’t activated on
your phone, pressing “NO” will advance to the
next active feature.
Accessing Features
It’s easy to find what you want on your
Jitterbug Dial.
How to navigate using buttons:
1. Press the button to browse through the
feature choices on your phone.
2. Press the Up/Down arrow button to move
through the entries within a feature.
3. Press the button to select the action
displayed at the bottom of the screen.
Follow these steps as you look at the screen
images in the examples on the next page.
Feature Navigation
All Jitterbug phones include a pre-programmed
Phone List. (See Section 5 for details about your
Phone List.) Additional features, such as built in
User Guide, Voice Dialing, Voicemail, Call History,
and Phone Info, can be turned on or off by calling
1-800-733-6632.
Phone List (01/02)
Amy
Call?
909-555-2334
more
Smith
back
Voicemail
Check for
Listen?
messages
Saved
Phone List (02/02)
George
Call?
972-555-6149
back
more
Baker
Phone List (01/02)
Amy
Call?
909-555-2334
more
Smith
back

Feature 3. Phone List with Call History and other
optional services
Moving from Feature to Feature on Your Phone 41
SECTION 4
40 Moving from Feature to Feature on Your Phone
SECTION 4
Phone List (01/02)
Amy
Call?
909-555-2334
more
Smith
back
Phone List (02/02)
George
Call?
972-555-6149
back
more
Baker
All Recent(05/10)
Show Details?
972-555-3327
Incoming
Martha
more
back
Call History (02/02)
Voicemail
Check for
Listen?
messages
Saved
Phone List (01/02)
Amy
Call?
909-555-2334
more
Smith
back
Feature 2. Phone List with Voice Dialing
Voice Dial
Yes to Use
Voice Dial?
Phone List (01/02)
Amy
Call?
909-555-2334
more
Smith
back
Phone List (02/02)
George
Call?
972-555-6149
back
more
Baker
Voice Dial
Yes to Use
Voice Dial?
