Samsung SPHA820 User manual

SPH-A820
User’s Guide
Draft
(2005. 1. 27)

Intellectual Property
All Intellectual Property, as defined below, owned by or
which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is
proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions.
Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade
secrets, copyrights, software, computer programs, and
related documentation and other works of authorship.
You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify,
prepare derivative works of, reverse engineer,
decompile, disassemble, or otherwise attempt to create
source code from the software. No title to or ownership
in the Intellectual Property is transferred to you. All
applicable rights of the Intellectual Property shall
remain with SAMSUNG and its suppliers.
Samsung Telecommunications
America (STA), Inc.
Headquarters:
1301 East Lookout Drive Suite 150 Richardson,
TX 75082
Tel: [phone]
Customer Care Center:
1601 E. Plano Parkway, Suite 150 Plano, TX 75074
Toll Free Tel: [phone].HELP (4357)
Fax: [phone]
Internet Address: http://www.samsungusa.com
©2004 Samsung Telecommunications America, Inc. is a
registered trademark of Samsung Electronics America,
Inc. and its related entities.
Licensed by Qualcomm Incorporated under one or more of
the following patents: U.S. Patent No. 4, 901, 307; 5, 056,
109; 5, 099, 204; 5,101, 501; 5, 103, 459; 5, 107, 225;
5, 109, 390.
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered TrademarSk RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED ON THE WARRANTY PAGE ENCLOSED
WITH THE PRODUCT, THE PURCHASER TAKES THE
PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS
OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT
NOT LIMITED TO THE MERCHANTABILITY OF THE
PRODUCT OR ITS FITNESS FOR ANY PARTICULAR
PURPOSE OR USE; THE DESIGN, CONDITION OR
QUALITY OF THE PRODUCT; THE PERFORMANCE OF
THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT
OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION
OR CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG
SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY
KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF
ANTICIPATED PROFITS OR BENEFITS.

Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.

Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press [ ].
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 19.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
Contents
Unpack 3
Make sure you have each item
Your phone 3
Buttons, features, and locations
Get started 4
First steps to operate your phone
Menu functions 8
All menu options listed
Solve problems 17
Help and personal needs
Health and safety information 19

3
Unpack
Make sure you have each item
You can obtain the following accessories
for your phone from your local Samsung
dealer.
Phone Travel Adapter
Battery User’s Manual
• Standard battery • Extended battery
• Battery charger • Leather case
• Headset • Data link cable
• Car charger/
adapter •Travel chager/ adapte
• Portable hands free kit
Your phone
Buttons, features, and locations
Left soft key
Volume keys
Dial key
Special
function keys
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
Menu access/
Confirm key
Cancel/
Correct key
Headset jack
External
speaker
External
display
Speaker
key
Service
LED
Ready link key

4
Get started
First steps to operate your phone
Install and charge the phone
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Install the battery:
To remove the battery,
slide the battery catch
toward the top of the
phone and hold it.
Plug the adapter into
the phone.
Plug the adapter into a standard AC wall outlet.
1 2
3
When the phone is completely charged (the
battery icon stops blinking), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
4
5

5
Get started
Power on or off Keys and display
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [] to turn on
the phone.
3. If necessary, enter the PIN and
press < OK >
Power off 1. Open the phone.
2. Press and hold [] .
Key(s) Description
Perform the function indicated on the bottom
line of the display.
In Idle mode, access menu options directly.
In Menu mode, scroll through the menu
options.
In Idle mode, enters Menu mode.
In Menu mode, selects the highlighted menu
option.
Sends or answers a call.
In Idle mode, retrieves the last number
dialled, missed, or received.
Deletes characters from the display.
In Menu mode, returns to the previous menu
level.

6
Get started
Key(s) Description
Ends a call. Hold down to switch the phone
on and off.
In Menu mode, cancels input and returns the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1] down to access your
voicemail.
Enter special characters.
Use for some special functions.
(on the left)
Accesses the Ready link list.
Makes and answers a R-Link call.
(on the left)
Adjusts the phone volume.
In Idle mode, with the phone open, adjusts
the keypad tone volume. With the phone
closed, hold down to turn on the backlight.
In Menu mode, scrolls through the menu
options.
(on the right)
Turns on the external speaker during a call.
In Idle mode, retrieves the last number
dialed, received, or missed.
Holde down to start the voice recognition.

7
Overview of menu functions
To access Menu mode, press [ ] in Idle mode.
1 Voice memo
1 Record
2 Review
2 Messaging
1 Send message
2 Text
3 Voice SMS
4 Email
5 Voicemail
6 Settings
3 Tools
1 Today
2 Scheduler
3 Task list
4 Memo pad
5 World time
6 Alarm clock
7 Calculator
8 Countdown
9 Set time
4 Voice service
1 Launch VSuite
2 Settings
5 Call history
1 Outgoing calls
2 Incoming calls
3 Missed calls
4 Erase history
6 Web
7 Settings
1 Display
2 Sounds
3 PCS vision
4 Ready link
5 Security
6 Roaming
7 Launch pad
8 Others
9 Phone info
8 Downloads
9 Contacts
1 Find
2 Add new entry
3 My phone #
4 Group setting
5 Services

8
Menu functions
All menu options listed
Voice memo
Use this menu to record voice memos and review the
voice memos you have recorded.
To access this menu, press [ ] in Idle mode and
select
Voice memo .
Record
In this menu, you can record a voice memo. A voice
memo can be up to one minute long.
Review
Use this menu to review the voice memos you have
recorded.
Messaging
Use the Messaging menu to send and receive short
text messages to and from other mobile phones. In
addition, your phone supports the Enhanced
Messaging Service (EMS), which enables you to
include simple pictures, melodies, and animated
images in your messages. You can also use the voice
mail feature.
To access this menu, press[ ] in Idle mode and
select
Messaging .
Send message
You can create and send new text messages including
voice SMS messages and e-mails.
Text
You can view the messages you have received, sent,
or saved separately in this message box. When you
access each message box, a list of messages displays.

Menu functions
9
Voice SMS
Use this menu to view the voice SMS messages you
have received in the message box.
Email
Use this menu to view the e-mails you have received
in the message box.
Voicemail
Use this menu to dial to the voice mail server and
access your voice mails. You can also delete voice
mails you have received.
Settings
You can change the various settings for using the
message feature.
In this menu, you can:
• select the message notification settings.
• change the message sending settings.
• use the message template.
• edit your signature.
• change the message alert settings.
• set the phone to save outgoing messages after
sending them in the Outbox.
• set the phone to erase the oldest message in order
to free up memory space to receive a new
message when the memory is full.
• set the voice SMS options.
You must enter the voice server number before you
can access your voice mails. Your service provider
can give the voice server number.

10
Menu functions
Tools
The Tools menu provides you various convenient
features like a calendar, task list, memo pad, D-day
counter, alarm, and calculator.
To access this menu, press [ ] in Idle mode and
select
Tools .
Today
You can schedule up to 9 events for the current day,
indicating each event’s starting and ending time. You
can even have your phone’s calendar alert you before
an event commences. Events scheduled for future
dates automatically appear on your Today events
schedule on that day.
Scheduler
This menu allows you to view the current month, as
well as past or future months in calendar format.
On the calendar, the current day is indicated by a
colored box and the selected day is highlighted. Days
with scheduled events are indicated by blue box on the
calendar day.
Task list
This feature allows you to enter a list of tasks you
need to be done and assign both a priority and a
deadline to them.
Memo pad
This feature allows you to make and view memos of
important things you need to remember.
World time
You can use this menu to find out what time it is in
another part of the world.
Select the city corresponding to your time zone by
pressing the Navigation keys once or repeatedly. The
local time and date display.
To apply the DST (Daylight Savings Time) setting on,
press <
Options >, select DST setting , and then On .

Menu functions
11
Alarm clock
This menu allows you to set an alarm to ring at a
specific time.
Calculator
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
Countdown
This menu helps you know how many time it takes for
you to do something or how many days until a specific
event occurs.
Set time
Use this menu to change the time and date to be
displayed on your phone.
Voice service
Use the Voice service menu to use the voice dial
feature.
To access this menu, press [ ]
in Idle mode and
select Voice service .
Launch VSuite
In this menu, you can use the voice dial feature by
saying one of names you have saved in Contacts.
In this menu, you can:
• register phone numbers to your phone to dial them
by voice command.
• record voice memos and review the recorded ones.
• check the status of your phone and phone number.
Settings
This menu allows you to customize the settings for
using the voice dial feature.
You can:

12
Menu functions
• set the phone to adapt digits for digit dialing.
• set the phone’s sensitivity about your commands
and the names in Contacts.
•settheChoicelist.
• set the sound settings in each command.
• set how to launch the voice dial feature in Idle
mode.
Call history
Use this menu to view the calls you have dialled,
received, or missed.
To access this menu, press [ ] in Idle mode and
select
Call history .
Outgoing calls
If Caller Line Identification is available, your phone
keeps a list of the 20 most recent outgoing calls that
you have made. Contact your service provider for the
availability.
Incoming calls
This menu lets you view up to 20 of the most recent
calls you have received if you are a subscribe to the
Caller Line Identification service. Contact your service
provider for further details about this service. When
you access this menu, a list of the incoming calls
displays.
Missed calls
The phone stores up to 20 of the most recent numbers
you have failed to answer. When you access this
menu, a list of the missed calls displays.
Erase history
In this menu, you can erase the entries stored in each
of three call logs; outgoing, incoming, and missed
calls. You can also erase all of the call logs at one time.

Menu functions
13
Web
Your phone comes equipped with a WAP browser
which makes it possible for you to access the wireless
web. Using the WAP browser, you can access updated
information and a wide variety media contents.
To access this menu, press [ ] in Idle mode and
select
Web .
Settings
Many different features of your phone can be
customized to suit your preferences.
To access this menu, press [ ] in Idle mode and
select
Settings .
Display
This menu enables you to customize various settings
for display and the lights.
In this menu, you can:
• change the idle screen image.
• change the menu display style.
• set the caller ID image for incoming calls.
• set a greeting message to be displayed.
• specify the length of time the backlight of the
display or keypad turns on.
You can also select
whether or not the phone use the backlight.
• adjust the brightness of the main and front display.
• select whether or not the service light is on.
Sounds
This menu enables you to customize various settings
for sounds.
In this menu, you can:
• adjust the ringer volume for calls, messages, and
alarms.
• set the unique ringer melodies for incoming calls,
alarm melodies, scheduler alert, or roaming alert.
• customize additional tones for the phone.
• select the key tone type and adjust the key tone
volume and length.

14
Menu functions
• set the sound settings for using downloaded
applications.
PCS vision
This menu enables you to set whether or not the
phone connects to the wireless web when you access
the associated menus.
Ready link
Use this menu to customize settings for the Ready link
feature.
Security
Your phone provides you with various security options,
including a user-programmable lock code and special
number features.
To access the
Security menu, you must enter the 4-
digit lock code. It is preset to “0000” at the factory.
In this menu, you can:
• lock your phone and serivces so that other people
cannot use your phone and the additional services.
• change your current lock code to a new one.
• store emergency numbers.
• erase your Contacts entries and downloaded items.
• reset your phone.
Roaming
Roaming is a feature, which is only relevant in areas
where there are at least two cellular service providers
having valid roaming agreements. Roaming allows you
to register your phone on one of the networks, but use
the facilities of the other if your own network is not
available.
In this menu, you can:
• select a roaming mode.
• set the phone to remind you when you are making
or receiving a roaming call.
Launch pad
You can set the Navigation keys as shortcut keys to
access specific menus directly in Idle mode.

Menu functions
15
Others
In this menu, you can:
• set digits, such as area codes and network feature
activation codes, to the beginning of a phone
number before dialling it.
• activate the contact match feature.
• restrict outgoing calls.
• set how to answer incoming calls.
• turn the automatic redealing or answering features
on or off.
• select one of several languages for the display
text.
• activate or deactivate Airplane mode, the location
feature, Headset mode, or Key Guard mode.
Phone info
In this menu, you can:
• view your phone number.
• view information of the icons to be displayed on
the screen.
• view the software and hardware versions of your
phone.
• view details about your phone system.
Downloads
This menu allows you to download various multimedia
files, such as games, ringers, screen savers, and
applications, from the wireless web.
Select
Get new to connect to the website preset by
your service provider and download new items.
To access this menu, press [ ]
in Idle mode and
select Downloads .

16
Menu functions
Contacts
You can store phone numbers in your phone.
To access this menu, press [ ] in Idle mode and
select
Contacts .
Find
This menu allows you to find an entry using a person’s
name, entry number, or group name in your Contacts.
Add new entry
This menu allows you to add a new entry to your
Contacts. A name can contain up to 6 numbers in
different categories; Home, Work, Mobile, Paper, Fax,
and No label.
My phone #
Use this feature to check your own phone numbers.
Group setting
In this menu, you can change the default group names
and ringer melodies.
Services
In this menu, you can dial the service centers preset
by your service provider to get more information. For
details, contact your service provider.
