Samsung SVP-6000N/P User manual

Before attempting to operate this product,
please read the instructions carefully.
SVP-6000N/P
HIGH RESOLUTION
VIDEO PRESENTER
User’s Manual
SVP-6000N/P
HIGH RESOLUTION
VIDEO PRESENTER
User’s Manual

page1
English French German Italian Spanish
Special features
By adopting 12X super optic angle zoom lens that it is
possible to shoot material in the size of a film to B4.
Thank you for purchasing this product.
This product is a high resolution video presenter that can project all kinds of
data on a PC monitor, a TV, or a projector with simple manipulations.
12X zoom lens
(canbeusedforthematerialswithsizesfromB4tofilm)
Adopted 1.5 million pixel CCD
By adopting 1/2 inch PS type CCD, high resolution
and excellent color reappearance are realized.
Can control USB and RS-232
By using USB, it is possible to view or store the
image in a PC and control the functions of the
this set. Also it is possible to control the this set
by using RS-232C port.
Output modes from SXGA to VGA
(supportsFULL/SCROLL modes)
It supports various output modes from SXGA
to VGA that it can be connected to all kinds of
projectors.
Remote control is a standard feature
Remote control is supplied as a standard feature
for the product so that it can be manipulated
from a distance. Thus it is very convenient during a
conference.
TV output mode
By adopting TV output mode, monitoring and
conference data can be recorded through VTR.

page2
English French German Italian Spanish
Contents
Product features and structure
Uses 3
Accessories 3
Names and functions of each part 4
Front side 4
Main control panel 5
Terminals at the back 6
Remote control 10
Notes on operations 15
Storage after use 15
Trouble shooting 16
Fuse replacement 16
Battery replacement 16
Specifications 17
Set preparation 12
Basic connecting methods 9
To view an image projected on the video presenter
through a PC monitor or a projector 9
To view an image on a TV screen or a monitor while
listening to the sound from a microphone 9
To view the VGA output of an external device
through a PC monitor or a projector 10
To connect to a PC for USB communication 10
To connect to a PC for RS-232C communication 11
To connect with a mouse 11
Basic operations 12
Methods of using various buttons for the screen
contro
l13
Operation methods
Before requesting service

Detailed information in a report, form, table,
etc. as well as a three dimensional object,
such as a model, can be projected on a
screen clearly that all the participants can
focus on the same topic during a conference.
Thusit is veryhelpful for aneffective progress ofa conference.
page3
English French German Italian Spanish
Uses of video presenter/Supplied accessories
Conference
It is possible to present various visual data
including slides and X-ray film etc. at a
medical conference or a doctors' association
inthe order offile.
Medicine and science areas
By connecting to a large projector, it can
produce dynamic images at a new product
demonstration,an exhibition, oran event.
Demonstration or exhibition
It can be used as an audiovisual tool for
printed materials, such as text books, as well
as audiovisual materials, educational
materials, and especially for students' art
works.
Education
It is useful in design area where visualization
is necessary. It is possible to project catalogs
and slides, thus the effect of a job can be
checkedeasily.
Advertisement and design areas
By using USB, the next generation interface,
it is possible to view or store the image in a
PC with higher speed and control the
functions of the this set.Also it is prssible to
controlthe this setby using RS-232C.
PC interface function(USB/RS-232C)
User’s Manual Audio/Video cables S-video cable Remote control
Power cable Dust cover Adaptor lens and Lens cap PS/2 mouse
PC monitor cable USB cable BGVu program Mouse Pad
Diskette Program
Manual
Supplied accessories

page4
English French German Italian Spanish
Names and functions of each part
Front side
Lens
Canrotate to thefront and back.
Remote control signal
receiver Main control panel
(seenext page) Document plate (built-inlower lamp) Lamp unit (upperlamp )
Main support Main lock button
Pressto move themain support.

page5
English French German Italian Spanish
Names and functions of each part
Main control panel
The buttons on the main control panel can be found in the
remote control. These buttons perform the same functions

Power
Usethis to turnthe power onor off.

Freeze
Usethis to freezethe image

Lamp
Usethis to turnthe upper orlower lamp onor off.

Nega/Posi
Positive:for regular picturesor positive films
Negative:for negative films

Red/Blue control
Usethis to controlthe color manually

Iris
Usethis to controlthe brightness ofthe image byusing the iris.

Volume
Usethis to controlthe volume ofthe microphone.

Zoom
Usethis to controlthe size ofan object projectedon the screen.

Focus
Usethis to adjustthe focus

Control key
Use this to move the image on the screen to up and down, right
andleft in theSCROLL mode.

FULL/SCROLL
FULL:use this todisplay the wholeimage
SCROLL:use this todisplay only apart of theimage
(applicableto XGA, SVGA,and VGA modesonly)

INT/EXT
Usethis to selectinternal or externalimage
INT:to view theimage on thisproduct.
EXT: to view the VGA output from another device on a PC monitor
ora projector byconnecting it tothis product.

Mode
Use this to select the desired resolution for the video output
device(PCmonitor, projector) connectedto this product.
SXGA(1280 x 1024),XGA (1024 x768)
SVGA(800 x 600),VGA (640 x480)
(whenthe power ison, the initialsetting is inSXGA mode)

Tone
Usethis to controlthe tone ofthe image.

AWC
Usethis to controlthe color automatically


     
      

page6
English French German Italian Spanish
Names and functions of each part
Terminals at the back

Power input terminal

VGA video input

VGA video output
Usethis to connectthe power cable(100 - 240V,free volt method)

S-video output
Thisis the videooutput terminal connectingto a TVthat has S-videoinput terminal.

USB: computer connection terminal
Usethis to connectUSB cable whentransmitting image byUSB port.

TV output
Connectthis to theTV input terminal.
Connectthis to viewthe image projectedon the TVscreen.
Evenwhen the externalinput is selected,only the imageon the mainunit is displayedon
TVoutput terminal.
Connectthis to theVGA output terminalof another VGAoutput device.
Whenexternal input isselected, the imageis shown throughthe VGA outterminal.
Connectthis to theRGB input terminalof a PCmonitor or aprojector.

Audio output (left/right)
Connectthis to theaudio output terminalof a TVor a VCRor speakers.
Thesound from anexternal AV deviceor microphone isheard through this.

Audio input
Connectthis to theaudio output terminalof a PC.
Connectthis to listento the soundfrom another AVdevice.

Mouse
ConnectPS/2 mouse tothis when theuser wants touse the mousepointer.

RS-232C: computer connection terminal
Usethis to connectRS-232C cable.

Microphone
Usethis to connectthe microphone tothe main unit.
    
    

page7
English French German Italian Spanish
Names and functions of each part
Remote Control
POWER button
Usethistoturnthe power onor off
INT/EXT button
Usethis to selectinternal image orexternal image
-INT: to viewan image projectedon this product
-EXT: to viewanother VGA outputthough a PCmonitor or a
projectorby connecting it tothis product.
FOCUS F button
Usethis to focuson area faraway
VOLUME +, - buttons
Usethis to increaseor decrease the
volumelevel of themicrophone.
FOCUS N button
Usethistofocusonareanear
W button
Usethis to reducethe image on
thescreen
IRIS+button
Usethis to brightenthe image
IRIS-button
Usethis to dimthe image
Control key buttons
(←, →, ↑, ↓)
Usethis to movethe image upand down,
rightand left inthe scroll mode.
B ADJ. +, -button
Usethis to controlthe blue hue
T button
Usethis to enlargethe image onthe screen
NEGA/POSI button
-POSI: use thisto view regularor positive films
-NEGA: use thisto view negativefilms
LIGHT button
Usethis to turnthe upper orlower light
onor off
R ADJ. +, -button
Usethis to controlthe red hue
AWC button
Usethis to adjustthe color automatically
F/S button
FULL:Use this todisplay the wholeimage on the screen
SCROLL:Use this todisplay a partof the whole image
onthe screen.
TONE button
Whenadjusting the outputtone of thisproduct.
(selectthe appropriate toneaccording to thetype of
originalmaterial)
FREEZE button
Usethis to freezethe screen
Resolution mode selection buttons
(SXGA, XGA, SVGA, VGA)
Usethis to adjustthe resolution ofthe VGA outputdevice
connectedto the videopresenter
(Select the maximum resolution the output device supports)

page8
English French German Italian Spanish
Set preparation
Press the main lock button
and raise the main support
Turn the lens area to face
downward
Connect the power cable to the main unit
and the outlet.
Remove the lens cap
Raise the lamp unit until it is convenient for use,
and set it to the center of the document plate.
For230V
For120V

page9
English French German Italian Spanish
Basic connecting methods
To view an image projected on the video presenter
through a PC monitor or a projector
• Set the resolution mode of the main unit to the maximum resolution of the external device connected.
To view an image on a TV screen or a monitor
while listening to the sound from a microphone
• The resolution of the TV output is much lower than the VGA output,
so please use it for monitoring or recording.
• Microphone is not supplied. Use one purchased from an audio shop.
• When a microphone is used, the image and sound are produced simultaneously through the projector.
Thus it can be very useful for a demonstration or an exhibition.
Connectto the VGAinput terminal
PCmonitor,
projector,etc.
TV,monitor, projector, etc.
Yellew
Yellew
Connectto the audio
inputterminal Connect to thevideo inputterminal
White
White
Red
Red
VideoPresenter
VideoPresenter

page10
English French German Italian Spanish
Basic connecting methods
•
When it is properly connected, put the BGVu program installation diskette supplied with this product into
the PC and install USB driver and PC operation program. For installation method, refer to the program
manual supplied with the program.
•Can't viewthe image inputfrom an externaldevice on aPC through USB
To connect to a PC for USB communication
To view the VGA output of an external device
through a PC monitor or a projector.
VideoPresenter
VideoPresenter
Connectto the
VGAinput terminal
Connectto the
VGAoutput terminal
ExternalVGA output device
(PCetc.)
USBcable
Connectto the USBport
ofthe PC
PCmonitor,
projector,etc.

page11
English French German Italian Spanish
Basic connecting methods
To connect to a PC for RS-232C communication
• RS-232 operation program is not supplied.
• It supports mouse pointer function and enables effective presentation. Also, various colors and shapes
of mouse pointer are available.
To connect with a mouse
VideoPresenter
VideoPresenter
RS-232Ccable
Connectto the serialport
(9pinor 25pin)
PCmonitor,
projector,etc.
Connectto the VGAinput terminal

page12
English French German Italian Spanish
Basic operations
Please check
. Is the power connected properly?
. Is the desired device (PC monitor, Projector, etc.) connected to the output terminal correctly?
•The power buttonon the mainunit can bepressed
Press the power button
Place the material on the document plate and adjust the size of the image
with the zoom button. For better result, use the [T] to maximize the image
and focus, and then use the [W] button to obtain the size wanted.
•When connecting toa PC monitoretc., select the maximumresolution mode
supported.
•Select RGB modeif it isconnected to aprojector.
•If it isconnected to aTV, select the inputmode as theexternal input.
Set the resolution mode
•Notes for better result
• Glossy material could cause irregular reflection, so take
precautions.
• When using a material that is vertically long, use [T] and
fill up the screen for better result.
• For a material with more words, select the text mode of the
[TONE] button, and for a material with more pictures,
select the image mode for better result.

page13
English French German Italian Spanish
Basic operations
•Whenever the button is pressed, the
identification of INT or EXT alternates on the
screen.
•INT: to view an image through this product.
•EXT: to viewthe image andsound from an
externalVGA output devicethrough a PC
monitoror a projectorconnected to this videopresenter
INT/EXT
Ifthe <INT/EXT> buttonis pressed when another VGA output deviceis not
connected,NO SYNC signappears.
Methods of using various buttons for the screen control
•POSI •NEGA
•When this buttonis pressed, alternates
betweenthe POSI modeand NEGA mode.
•POSI: to viewregular material ora picture
•NEGA:to view afilm
NEGA/POSI
• When the power is supplied, use the light
button to turn the upper or lower lamp on or
off.
•Select the upperor lower lampaccording to
thematerial to beprojected.
LIGHT
•Manual focus control: press [Focus F]
or[Focus N] toadjust
•Ifthe user wantto adjust moreaccurately,
pressthe [T] buttonto the maximum
close-upthen bring theimage into focus
andthen adjust tothe desired screen
sizeby pressing the[W] button.
FOCUS F/N
•When [AWC] button is pressed,
the color is adjusted automatically.
At this time, project the camera lens on a
white piece of paper and press the [AWC]
button, then the color control is more
accurate.
•If more minute control is desired, adjust by using the [R/B ADJ. +, - ]
buttons.
•Press the [R/BADJ. +, -] button toadjust color whenthe film isused.
AWC
•Controls the volume level of the microphone
whenit is used.
VOLUME
The color level chosen wll be displayed.
•When this buttonis pressed, theimage
freezes.It is aconvenient feature when
replacinga material ora picture.
•Press the [FREEZE]button one moretime
torelease the freezemode.(VGA video
outputonly)
FREEZE
•Use this to control the tone of the output
imageof this product.
•When the [TONE] button is pressed,
alternates between the Image Mode and
Text mode.Image mode: for a material with
many pictures or colors Text mode: for a
materialmostly with words
TONE

page14
English French German Italian Spanish
Basic operations
•To adjust the brightness, press the [Iris +/-]
buttonson the maincontrol panel orthe [Iris
+/-]buttons on theremote control.
[Iris+]: when thesubject is toodark.
[Iris-]:when the subjectis too bright.
IRIS +/-
Methods of using various buttons for the screen control
•Press the [Zoom W/T] buttons on the main
controlpanel or the[W/T] buttons on the
remotecontrol to selectappropriate image
size
[ZoomW]:to reduce thesize of thesubject
[ZoomT]:to increase thesize of thesubject
ZOOM W/T
•This is used to select the resolution required
bythe VGA outputdevice connected tothe
videopresenter so thatthe image datadon't
getchanged.
-SXGA (1280 x1024) - XGA(1024 x 768)
-SVGA (800 x600) - VGA(640 x 480)
•Ifthe output modeis not correct,it could lowerthe resolution or
theremight be novalid output, Besure to selectthe correct resolutionfor
theVGA output device.
Resolution selection
•FULL mode: When trying to compress the
entire image taken and project it on the
screen.
•SCROLL mode: use this to display a part of
the whole image (This is in operation only
when the resolution is in XGA, or SVGA, or
VGAmode)
F/S
• Use this to select the desired area by moving
the image up and down and right and left in
thescroll mode.
Control key
•Wide • Tele
When an adaptor lens is necessary
•Attach the adaptor lens only in the camera mode
(possiblefocal length: 1m~°ƒ)
•Remove the adaptor lens to view a material or a
document or a film placed on the document plate.
(Possiblefocal length: 230mm- 320mm)
•Beyond the possible focal length mentioned above, it
might be out of focus. So pay attention to the
distance between the object to be viewed and the
mainunit and whetherthe adaptor lensis attached.

page15
English French German Italian Spanish
Notes on operations / Storage after use
Donot place heavyobjects. Do not drop.
Wipewith dry andsoft cloth Do notuse in thehumid or wetarea Use of benzene or thinner can damage the
product.
Coverthe product whennot in use.
Turnthe power offand unplug the
productfrom the outletwhen it is
leftunused for along period oftime.
Storage after use
Press the main lock button and fold the
lensso that ittouches the documentplate.
2
Fold the upper lamp so that it touches the
documentplate successively.
3
Turnthe lens tomake
itparallel to themain support
1
Pleasenote that anyslides, pictures,
documentsthat are protectedunder
thecopy right lawcan't be reproduced
withoutpermission.

page16
English French German Italian Spanish
Trouble shooting / Fuse and battery replacement
No image appears
-Check if the resolution of the output device corresponds to that of the video
presenter.(for example, when the maximum resolution of a projector is XGA and if
thevideo presenter isset to SXGA, then no image appears.)
-Check if theinput selection of the output devic is appropriate.
-Check if theiris control is adequate
-Check if theVGA cable is connected to the VGAoutput terminal correctly.
-Check if thereis any problem with the fuse
If there are problems,
please contact the store
you purchased the product
or our distributor nearest
you.
Remote control is not working
-Check the batteryof the remotecontrol.
Replaceit with anew one.
No image from a slide film or
a negative film
-Check if thelower lamp is turned on
-Adjust the lensto face the film directly
-Check if theNEGA/POSI button is selected properly
No communication
between the PC and USB.
-Make sure the operating system is Windows 98. It doesn’t
workon Windows 95.
-For other detailed information, please refer to the program
manualsupplied with theproduct.
The image is out of focus
-Check if theadaptor lens isattached properly forthe purpose.
(Besure to attachthe adaptor lensin the cameramode)
-Check if thedistance from theobject is tooshort.
The light is not turned on right away after
the [LIGHT] button is pressed
It is a normal phenomenon occurring because the protection circuit is in operation to protect
thelamp
Openthe battery compartmentlid
atthe back ofthe remote control
•Battery type:AAA type1.5V
•Fuse type:2A, 250V
Takeout the fuseholder
1
Takeout the fuseand replace it
2Putthe fuse holderback
3
Insertthe batteries so
thattheir with anew one
Closethe lid
Sparefuse
fuse
Fuse replacement
Battery replacement
3
2
1

page17
English French German Italian Spanish
Specifications
• Specifications
Items Specifications
Lens
Shootingrange
Zoom
Focus
Iris
Upperlamp
Lowerlamp
Pick-upDevice/Effective pixel
Framerate
Syncsystem
VGAOutput
VideoOutput
WhiteBalance
Positive/Negative
Freeze
Inputterminals
Outputterminals
Mousepointer
Applicationsoftware
USB
RS-232C
Operating
temperature
andhumidity
Powersource/power
consumption
Dimensionsand weight
Accessories
F2.8 - 3.3, f =6.4 - 73.6, 12x power zoom
MAX:384 x 272mm, MIN:50 x 40mm
Powered
Powered
Auto(with fine level adjustment)
Attach to the side arm of the main unit
Light box (built-in main unit)
1/2” 1.5 million pixel PS CCD / 1360 (H) x 1024 (V)
7.5 frame / sec.
Internal sync
1280 x1024 (SXGA) RGB COLOR, 1024 x 768 (XGA) RGB COLOR
800 x 600 (SVGA) RGB COLOR, 640 x 480 (VGA) RGB COLOR
H. Sync : 15. 734KHz
V. Sync : 59. 94Hz
Subcarrier : 3. 579545MHz
Resolution : 400TVL (H), 350TVL (V)
H. Sync : 15. 625KHz
V. Sync : 50Hz
Subcarrier : 4.43361875MHz
Resolution : 400TVL (H), 400TVL (V)
C-Video VBS 1.0Vp-p / 75Ω(unbalance)
S-Video Y:1.0Vp-p / 75Ω(unbalance)
C:0.286Vp-p / 75Ω(unbalance)
Manual/Auto(one touch type)
Selectable
built-in ( VGA video output only )
Microphone:1, VGA:1, Audio:1, Mouse:1,
VIDEO:1, Audio:1, VGA:1, USB:1, RS-232C:1, S-Video:1
Adopted
TWAIN Driver & Viewer ( for WIN98 )
built-in
SET control
5˚C~35˚C, 30%~90%
AC100V - 240V Free voltage, 50/60Hz, 60W
Weight:11.5kg
In store : 533 (W) x 145 (H) x 558 (D)
In use : 676 (W) x 537 (H) x 558 (D)
Remote control, PS/2 Mouse, Cables
Lighting
Optical
Video
Other
PC connection
•Designof mainframe andspecifications subject tochange without noticeto enhance thequality of production.
SVP-6000N
(NTSC)
SVP-6000P
(PAL)
SVP
SAMSUNG
SAMSUNG
