Samsung SDP-860 User manual

Before attempting to operate this product, Please read the instructions carefully.
www.samsungpresenter.com
USER’S MANUAL
SDP-860
DIGITAL PRESENTER
ENGLISH
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지2 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

󳥎 This high-resolution presentation system generates images on display devices such as PC
monitors and projectors.
󳥎 This user manual is for the SDP-860 product. Please read this manual and any
supplementary document(s) thoroughly before attempting to install and/or operate the
product.
󳥎 This manual and the software and hardware explained here are protected by copyright
law. All copy, reprint and translation to other languages of a part of or all of the contents of
this instruction manual without permission of Samsung Techwin Co., Ltd. are expressly
prohibited except for fair use within the scope of copyright law.
󳥎 The specifications of this product are subject to change and upgrade without prior notice.
2
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지3 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

The manufacturer of this product is not responsible for the sale of the product, nor
does the manufacturer delegate such responsibility to a third party. The product
warranty does not cover accidents, negligence, abuse, or improper use of the item in
whole or in any part. Additionally, the manufacturer does not provide warranty for any
additional part or piece that was not supplied by the manufacturer.
The product warranty period is for two years from the purchase date. However, the
warranty does not cover any of the following problems, and a nominal service fee will
be charged if:
󳢯 Malfunction due to user's negligence
󳢯 Dismantling or replacement by the user
󳢯 Product has been connected to power source that differs from that specified.
󳢯 Malfunction due to natural disasters (fire, flood, tsunami, etc.)
󳢯 To replace expendable components.
This warranty covers only the product supplied with the warranty.
After the warranty period has expired, a service fee will be charged for any inspection
and/or repair for the product. During the warranty period, a service fee will be charged
for repair and/or inspection for the product for any problems that are not covered by
the warranty.
This product is not an anti-theft or fire-prevention device; the manufacturer is not
responsible for any damage to property or personnel that may occur during its use.
This product must be installed by skilled and experienced personnel. Self-installation
by the user is prohibited. Self-installation by the user may result in fire, electrocution,
and/or product malfunctions. Please contact your local dealer for assistance with the
installation of the product.
Product Warranty and Limitations
3
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지4 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

1,300k-pixel High-Resolution & High-Definition Image
Generates real-time video images at 30 frames per second and at
1,300k pixels high-resolution for live presentations.
Super-Macro Capacity
With 6x optical and 8x digital zooms, this system achieves a
maximum of a 48x combined zoom for an excellent magnification
power equal to a microscope. When equipped with an adapter
lens, it also delivers super-close-up images.
Convenient Multimedia Options
The SDP-860 not only saves and plays still images and videos
(VGA/30 fps) but also supports audio mixing for more versatile
multimedia capabilities.
Page Detection & Auto Save
The SDP-860 not only detections motion of document but also
saves still image for use of various application.
2D/3D Dual Noise Reduction Technology
Equipped with our proprietary ISP chipset and 2D/3D dual noise
reduction technology, this presentation system depicts vivid colors
even in low light environments.
4
Product Features
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지5 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

5
Safety Precautions
Warning
Caution
6
6
Product Information
Package Contents
Part Names & Functions (Main Frame)
Front
Back (Rear Connection Terminals)
Side (Side Connection Terminals)
Part Names & Functions (Main Frame Control Board/Remote Controller)
Preparing Set
Settings Menus & Default Values
8
10
10
11
12
13
15
18
Miscellaneous (Appendix)
Troubleshooting
Replacing Remote Controller Batteries
Product Specifications
45
46
47
Installation
20
20
22
23
24
Connecting In/Output Devices
Connecting Output Devices
Connecting Peripheral Devices
Connecting Computer for External Input
Watching Video from External Devices
Operation
25
25
26
27
28
28
31
32
32
39
40
41
41
42
42
44
44
Table of Contents
Basic Operation (Functions)
Output Resolution Setup (DVI/VGA Output Mode)
Enlarging/Minimizing
Adjusting Focus
Adjusting Brightness
Adjusting the Image
Preset Setting
Basic Operation (Operation)
Capturing Image & Videos
Freeze Mode Setting & Operation
PC CTRL Mode Setting & Operation
OSD INFO. Mode Setting
ANTI FLK. Mode Setting
Page Detection Setting
Microscope Mode
System Reset
Checking System Version Information (VER. INFO)
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지6 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

To prevent possible user injury or damage to property, please read and follow all
information below.
6
Safety Precautions
Warning
Warning/Caution/Special Mark Messages
Caution
Safety Precautions
■Do not connect multiple power cords to a
single outlet.
󳢯It is often the cause of short-circuits that may
cause fire.
■Do not place vessels containing water on
the product.
󳢯Water leakage can cause serious malfunctions
in the product.
■Do not forcibly bend the power cord or
place a heavy object on the cord.
󳢯It may result in fire.
■Do not clean the product with water, paint
thinner, or other organic solvent.
󳢯To avoid product malfunctions and/or electric
shock, wipe with a dry cloth.
■Avoid installing the product in places with
high humidity.
󳢯It may result in electric shock and/or fire.
■Do not pull the power cord forcibly off the
outlet.
󳢯A broken cord may lead to fire and/or electric
shock.
■Do not disassemble, attempt to fix, or alter
the product yourself.
󳢯There is a risk of malfunction, shock, and other
dangers. this will invalidate the warranty.
■Do not touch the power plug with moisture
on your hands.
󳢯You may receive an electric shock injury.
■Do not insert the power plug to a loose
socket.
󳢯It may result in electric shock and/or fire.
■Avoid installing the product in places that
are vulnerable to impact.
■Avoid installing the product in places that
are exposed to powerful magnetic fields or
vibrations.
■Do not move the product while it is in
operation.
󳢯It may damage the product.
■Do not insert or allow foreign objects to
enter the product.
󳢯It may damage the product.
■Do not place heavy objects on the product.
󳢯It may damage the product.
■Allow good air circulation around the
product.
󳢯Keep the back panel at least 10cm away from
a wall and the front panel 5cm away from
other devices.
■Avoid installing the product in places that
are exposed to direct sunlight or heat
sources.
■Install on a flat, stable platform.
󳢯Failure to do so may result in product
malfunctions.
■Disconnect the power plug from the mains
outlet when the product is not in use for an
extended period of time, or during
electrical storms.
■When detecting a strange noise or smell
from the product, unplug the power cord
immediately and contact your nearest
service center for assistance.
This warning symbol indicates death, grave personal injury, and/or
damage to property as consequences for failure to comply.
This caution symbol indicates damage to the equipment, installed
programs, and/or contained data as consequences for failure to comply.
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지7 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

7
Product Features
Safety Precautions
Caution
Random replacement of built-in battery by other types of batteries may cause
explosion. The battery shall be replaced by the same battery. The used batteries shall be
disposed carefully because they can cause environment pollutions.
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
FCC Compliance Statement
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be
disposed of with other household waste at the end of their working life. Where marked, the chemical
symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm
to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of
waste and recycle them through your local, free battery return system.
Correct Disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems.)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지8 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

The picture of the contents may differ from actual products, and certain contents may
change if deemed necessary.
8
Package Contents
Product Information
Default Contents
User’s Manual Remote Controller Power Cable
Power Adapter DVI Cable VGA Cable
USB Cable USB Program
CD & Manual
Diffuser Sheet
(220x190)
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지9 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

9
Package Contents
Product Information
Caution
RS232C cables and adapter lenses from other brands may not be compatible with this
product.
Accessories
RS232C Cable SD Card Adapter Lens
Samsung Techwin cares for the environment at all product
manufacturing stages to preserve the environment, and is
taking a number of steps to provide customers with more
environmentally friendly products.
The Eco mark represents Samsung Techwin’s will to
create environmentally friendly products, and indicates
that the product satisfies the EU RoHS Directive.
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지10 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

10
Part Names & Functions (Main Frame)
Product Information
Front
1
2
3
4
5
6
78
1
2
3
4
5
6
7
8
Camera
LED Light
Main Support Column
Main Frame Control Board
Status LED
Remote Control Signal Receiver
Rear Connection Terminal
Side Connection Terminal
No. Name
P.13
P.11
P.12
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지11 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

11
Part Names & Functions (Main Frame)
Product Information
Back (Rear Connection Terminals)
1 2 3 4 5
1
2
3
4
Connect the power adapter cable.
Connect the video output terminal of a VGA output device.
When External Input is selected, video is displayed via this
VGA video output terminal.
Connect the RGB video output terminal of a PC monitor
or a projector.
Connect an LCD monitor or projector that supports DVI.
Connect to USB cable when transmitting image to a
PC by USB port
No. Terminal Function
5
P.23
P.20
P.20
P.21
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지12 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

12
Part Names & Functions (Main Frame)
Product Information
Side (Side Connection Terminals)
1 2 3 4
1
2
3
4
Connect Kensington Security Slot.
Connect an audio mixing mic for saving videos.
Connect a speaker or earphones for audio
output signals.
Insert an SD/SDHC card for saving or
importing videos and pictures.
Connect an RS-232C cable.
No. Terminal Function
RS-232C
RS-232C
5
5
P.21
P.22
P.22
P.22
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지13 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

13
Part Names & Functions (Main Frame Control Board/Remote Controller)
Product Information
Turn On/Off Power
Select Internal/External Video
( Mode) Auto Focus
( / LIST Mode) Page DOWN
(While Playing Video) Play Previous File
( Mode) MF/Auto Color Adjustment
( / LIST Mode) Page UP
(While Playing Video) Play Next File
Cancel Command
1
2
4
5
6
No. Button Function
Built-in Microphone
3
P.24
P.27
P.27
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지14 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

14
Part Names & Functions (Main Frame Control Board/Remote Controller)
Product Information
( Mode) Enlarge/Minimize Screen
( / LIST Mode) Move Left/Right
(While Playing Video) Rewind/Fast Forward
( Mode) Open Menu
( / LIST Mode) Execute Selected Menu
(While Playing Video) Play/Stop
( Mode) Capture Screen as Picture( ) / Video( )
File (SD Card Required)
7
8
9
10
No. Button Function
( Mode) Brighten/Darken Screen
( / LIST Mode) Move Up/Down
(While Playing Video) Adjust Volume
Switch to LIVE( ), Picture ( ), or Video ( )Mode
(Picture ( ) and Video ( ) Modes Require SD Card)
11
( Mode) Pause Screen
(While Playing Video) Switch to Full Screen
12
( Mode) Turn On/Off Light
( / LIST Mode) Delete Picture & Video
13
In LIVE Mode, Blue LED
In Still Image Mode, Blue LED
In Video Mode, Blue LED
In External Mode, Blue LED
Status LED
14
P.28
P.26
P.32
P.39
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지15 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

15
Preparing Set
Product Information
1. Face the lens straight down.
2. Adjust the main support to face the lens toward a document.
180。
55。
110。
180。
330。
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지16 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

16
Preparing Set
Product Information
3. Connect a VGA OUT, DVI, or USB cable and the power cord.
4. To turn on the power of the digital presenter, press the Power button on the digital
presenter’s control board or remote controller.
P.20
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지17 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

17
Preparing Set
Product Information
Displays the current digital presenter settings.
Displays the current screen-capture settings.
Displays the operational status of an SD card and the system.
※Pressing the Power button turns on the power LED light around the button
and set status LED in blue.
※Initial Screen
- SD (SDHC) CARD DETECTED: The SD card is inserted.
- SD (SDHC) CARD DOES NOT EXIST: No SD card is inserted.
- CAMERA SYSTEM INITIALIZING: In the process of initializing the system.
- SYSTEM FIRMWARE FILE EXISTS: System update files are available in an inserted
SD card.
- PLEASE WAIT FOR UPDATE PROCESS: In the process of updating the system.
- UPDATE PROCESS DONE!: The system is updated.
1
2
3
1
2
3
Caution
While the system is being updated, do not turn off the product or detach the SD
card. It may cause system errors.
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지18 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

18
Settings Menus & Default Values
Product Information
Setup Menu
Ⅰ
SXGA 1280x1024 4:3
UXGA 1600x1200 4:3 Up-Scaled
XGA 1024x768 4:3 Down-Scaled
720p 1280x720 16:9 Window Cut-out
1080p 1920x1080 16:9 Window Cut-out
720p 1280x720 16:9 Stretched
1080p 1920x1080 16:9 Stretched
TONE - Very LOW / LOW /
NORMAL / HIGH / Very High
COLOR -
LOW/MIDDLE/HIGH/B.W
SHARPNESS -
LOW/MIDDLE/HIGH
WB Mode
DNR
Rotation
IMG Mode
ATW(Tracking)/AWB
(One Push)/MANUAL
OFF/AUTO/MAX
0/180
TEXT
SXGA
ATW
AUTO
0
TEXT
CUSTOM
DVI/VGA OUTPUT
MODE
ADJUSTMENT
ⅡⅢ Ⅳ
Default
Value
/State
MACRO Mode
MICROSCOPE Mode
OFF/4x/8x
D-ZOOM
MAX
--
--
8x
ZOOM/FOCUS
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지19 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

19
Settings Menus & Default Values
Product Information
Setup Menu
Ⅰ
JPEG/BMP
PIC
Format
BEST/FINE/NORMAL
JPG
Quality
STANDARD/BEST
MOV
Quality
ON/OFFMic Mute
OFF/5MIN/10MIN/15MIN/20MIN/30MIN/
45MIN/1HOUR
Time
ELAPSE
Reset File
Number
PRESET1/PRESET2/PRESET3/PRESET4
Preset-
EXE
PRESET1/PRESET2/PRESET3/PRESET4
Preset-
SAV
OFF/PRESET1/PRESET2/PRESET3/PRESET4
Boot
Preset
DVI,VGA ONLY / ALL DISPLAY
FREEZE
ON/OFF
SYSTEM
RESET
JPEG
NORMAL
STANDARD
OFF
OFF
--
--
OFF
DVI/VGA
USB(HYBRID) / RS-232C ONLY
PC CTRL USB
(HYBRID)
SHOW ANYTIME/HIDE WHEN MOVIE REC
OSD
INFO.
SHOW
ANYTIME
OFF/ON
ANTI FLK. OFF
--
PAGE
DETECTION
--
-- --
--
USEFUL
TIP --
OFF
--Ver. INFO --
CAPTURE
SETTING
PRESET SETTING
MISCELLANEOUS
FUNCTION
ⅡⅢ Ⅳ
Default
Value
/State
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지20 G4-1G(Mac 2) C-2400 2438DPI 175LPI T

20
Connecting In/Output Devices
Installation
Connecting Output Devices
To use a normal or DVI monitor, you must connect the monitor to the digital presenter
using a monitor or DVI cable.
※Depending on the specifications of the SDP-860 D/A converter and the monitor A/D
converter, the color of RGB and DVI outputs may vary.
Connect to VGA Input Terminal
Monitor Cable
Digital Presenter
Monitor or Projector
Connect to DVI Input Terminal
DVI Cable
Digital Presenter
DVI Monitor or Projector
Connection
SDP-860-영문수정20100412 2010.4.28 9:30 AM 페이지21 G4-1G(Mac 2) C-2400 2438DPI 175LPI T
