Samsung QH43R User manual

© Samsung
Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited. Trademarks other than Samsung are property of their respective owners.
QH43R QH49R QH50R QH55R QH65R QH75R
The color and the appearance may differ depending on the product, and the content in the
manual is subject to change without prior notice to improve the performance.
Smart Signage User Manual (By Model)
This manual provides information about your Smart Signage including supported types and product specications per model.

Table of contents
Preparations
Checking the Components 3
Parts 4
Ports 5
Control menu 6
Before Installing the Product (Installation
Guide) 7
Tilting Angle and Rotation 7
Ventilation 7
Installing the Wall Mount 8
Preparing before installing Wall-Mount 8
Installing the Wall Mount 8
Wall Mount Kit Specifications (VESA) 9
Specifications
General 10
Preset Timing Modes 12
Appendix
License 13
2

3
Preparations
Chapter 01
"Contact the vendor where you
purchased the product if any
components are missing.
"The appearance of the components
may differfrom the images shown.
"A stand is not provided with the
product. To install a stand, you can
purchase one separately.
"The RS232C adapter can be used to
connect to another monitor using the
D-SUB (9-pin) type RS232C cable.
Checking the Components
Quick Setup Guide Warranty card
(Not available in some locations) Regulatory guide Power cord
Batteries (AAA x 2)
(Not available in some locations) Remote Control RS232C adapter HOLDER-CABLE
(Supported models: QH65R,
QH75R)
Wall Mount Adapter x 4

4
Parts
2.5 m 2.5 m
30°
30°
Power button
Power indicator
Remote sensor
4 m
Speaker
"The color and shape of parts may differ from what is shown. Specifications are subject to change without notice
to improve quality.
Parts Description
Remote sensor
Press a button on the remote control pointing at the sensor on the front of the product
to perform the corresponding function.
"Using other display devices in the same space as the remote control of this product
can cause the other display devices to be inadvertently controlled.
Power button Turns the product on or off.
Use the remote control within 2.5 m to 4 m from the sensor on the product at an angle of 30° from the left and
right.
"Store used batteries out of reach of children and recycle.
"Do not use a new and used battery together. Replace both batteries at the same time.
"Remove batteries when the remote control is not to be used for an extended period of time.
"To enhance the IR receiver performance, connect an external IR cable (sold separately) to the IR IN port.

5
Ports
"The color and shape of parts may differ from what is shown.
Specifications are subject to change without notice to improve quality.
Port Description
USB 1 ¨(1.0A)
Connect to a USB memory device.
"The USB ports on the product accept a maximum constant current of 1.0A.
If the maximum value is exceeded, USB ports may not work.
RJ45
Connects to MDC using a LAN cable. (10/100 Mbps)
"Use Cat7(*STP Type) cable for the connection.
*Shielded Twist Pair.
RS232C IN
Connects to MDC using an RS232C adapter.
DVI/MAGICINFO IN
DVI IN: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: Connects to a network box using DP-DVI cable to use Magicinfo.
HDMI IN 1 (ARC)
Connects to a source device using a HDMI cable or HDMI-DVI cable.
HDMI IN 2 (DAISY CHAIN IN)
•Connects to a source device using a HDMI cable or HDMI-DVI cable.
•Connects to another product using a HDMI cable.
DP IN (DAISY CHAIN IN)
Connects to a PC using a DP cable.
HDMI OUT (DAISY CHAIN OUT)
Connects to another product using a HDMI cable.
USB 2(0.5A)
Connect to a USB memory device.
"The USB ports on the product accept a maximum constant current of
0.5A. If the maximum value is exceeded, USB ports may not work.
DVI/HDMI AUDIO IN
Receives sound from a source device via an audio cable.
AUDIO OUT
Outputs sound to an audio device via an audio cable.
IR IN
Connects to an external IR cable that receives signals from the remote control.
RS232C OUT
Connects to multiple products using a serial cable.
"The serial cable is not provided with the product. Contact your vendor for
purchase.

6
Control menu
"The power button(
«
) is located on the bottom of the product.
"If you press the power button on the product when the product is
turned on, the control menu will be displayed.
Power Off Source
Press: Move Press & Hold: Select
Items Description
Power Off
Power off the product.
•With the control menu screen displayed, briefly press the power button to
move the cursor to Power Off , and then press and hold the power button to
turn off the product.
Source
Select the connected input source.
•With the control menu screen displayed, briefly press the power button to
move the cursor to Source , and then press and hold the power button to
display the input source screen.
•With the input source screen displayed, press and hold the power button to
switch to the desired input source.
"The power button can only be used for Power Off and Source.
"To exit from the control menu screen, wait for 3 seconds or more without pressing the power button.

7
Before Installing the Product (Installation
Guide)
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance
with the installation instructions.
•Ensure that an authorized installation company installs the wall mount.
•Otherwise, it may fall and cause personal injury.
•Make sure to install the specified wall mount.
Tilting Angle and Rotation
"Contact Samsung Customer Service Center for further details.
•The product can be tilted at a maximum angle of 15° from a perpendicular wall surface.
•To use the product in Portrait mode, rotate clockwise until the power indicator (Aor B) is
positioned as shown in the images below.
15°
AB
A
B
"Do not use this model installed on a ceiling, floor, or table.
Ventilation
"Contact Samsung Customer Service Center for further details.
Installation on a PerpendicularWall
AMinimum 40 mm
BAmbient temperature: Under 35 °C
"When installing the product on a perpendicularwall, allow at least
40 mm of space between the product and wall surface for ventilation
and ensure that the ambient temperature is kept below 35 °C.
A
B
Installation on an Indented Wall
AMinimum 40 mm
BMinimum 70 mm
CMinimum 50 mm
DMinimum 50 mm
EAmbient temperature: Under 35 °C
"When installing the product on an indented
wall, allow at least the space specified above
between the product and wall for ventilation
and ensure that the ambient temperature is
kept below 35 °C.
B
D
C
D
B
C
E
A

8
Installing the Wall Mount Preparing before installing Wall-Mount
Use the Wall Mount Adapter ( ) to install the wall mount.
Installing the Wall Mount
•The wall mount kit (sold separately) allows you to mount the product on the wall.
•The provided image is only for reference. For detailed information on installing the wall mount, see instructions
provided with the wall mount.
•We recommend you contact a technician for assistance when installing the wall mount bracket.
•Samsung is not responsible for any damage to the product or injury to yourself or others if you select to install
the wall mount on your own.

9
Wall Mount Kit Specications (VESA)
"Install your wall mount on a solid wall perpendicular to the floor. To
install the product on the otherwall area, contact the nearest agency.
If you install the product on a slanted wall, it may fall and result in
severe personal injury.
•Samsung wall mount kits contain a detailed installation manual and all parts necessary for assembly are
provided.
•Do not use screws that are longer than the standard length or do not comply with the VESA standard screw
specifications. Screws that are too long may cause damage to the inside of the product.
•Forwall mounts that do not comply with the VESA standard screw specifications, the length of the screws may
differ depending on the wall mount specifications.
•Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to
personal injury. Samsung is not liable for these kinds of accidents.
•Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is
used or the consumer fails to follow the product installation instructions.
•Do not mount the product at more than a 15 degree tilt.
•Always have at least two people mount the product on a wall.
•Standard dimensions forwall mount kits are shown in the table below.
Model Name VESA screw hole specs (A * B) in
millimeters Standard Screw Quantity
QH43R / QH49R / QH50R /
QH55R 200 × 200
M8 4
QH65R / QH75R 400 × 400
"Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric
shock.

10
Specications
Model Name QH43RQH49R
Panel
Size
43 CLASS (42.5 inches / 1 07.9 cm) 49 CLASS (48.5 inches / 123.2 cm)
Display area
941.184 mm (H) x 529.416 mm (V) 1073.78 mm (H) x 604.0 mm (V)
Model Name QH50RQH55R
Panel
Size
50 CLASS (49.5 inches / 125.7 cm) 55 CLASS (54.6 inches / 138.7 cm)
Display area
1095.84 mm (H) x 616.41 mm (V) 1209.6 mm (H) x 680.4 mm (V)
Model Name QH65RQH75R
Panel
Size
65 CLASS (64.5 inches / 163.9 cm) 75 CLASS (74.5 inches / 189.3 cm)
Display area
1428.48 mm (H) x 803.52 mm (V) 1650.24 mm (H) x 928.26 mm (V)
Chapter 02
General
