Samsung XA010J User manual

1
Outdoor P10 Product User Manual
Model Name: XA010J
Model Code:
Version Number: A03
Date: 26-Apr-2019
LH100XAJSAC/**

2
Table of contents
1. Safety........................................................................................................................ 4
1.1 Warning& Symbols........................................................................................ 4
1.2 Safety Guidelines...........................................................................................5
1.3 Installation instructions..................................................................................6
2. Open Package.........................................................................................................7
2.1 Front view........................................................................................................7
2.2 Side view......................................................................................................... 8
2.3 Placing cabinet............................................................................................... 9
3.XAJ10 Product introduction..................................................................................10
3.1 Product Specification.................................................................................. 10
3.2 Product Appearance....................................................................................12
3.3 Product design............................................................................................. 14
3.4 Product main components......................................................................... 16
4. LED display screen components........................................................................18
5. Parts List And Parts BOM List............................................................................ 20
5.1 Accessories list............................................................................................ 20
5.2 Spares list..................................................................................................... 21
5.3 Parts BOM List............................................................................................. 22
5.4 Service BOM List......................................................................................... 23
6. Trouble shooting list............................................................................................. 26
6.1 Display screen problem.............................................................................. 26
6.2 Cabinet problem.......................................................................................... 29
6.3 Module problem........................................................................................... 31
7. Installation Guides................................................................................................ 34
7.1 Mechanical requirements and installation............................................... 34
8. Connection of the LED screen............................................................................41
8.1 Connection for equipments........................................................................ 41
8.3 Connection for power cables..................................................................... 43
8.4 Connection for data cables........................................................................ 44
9. Control system setting......................................................................................... 46
9.1 Software setup............................................................................................. 46
9.2 NovaLCT-Mars Main interface...................................................................47
9.3 Main Menu.................................................................................................... 48
9.4 Tool Bar......................................................................................................... 50
9.5 Screen Config.............................................................................................. 51
9.6 Advanced color configuration.................................................................... 55
9.7 Adjust the brightness, Gamma and Current Gain.................................. 61
9.8 Display Control.............................................................................................73
9.9 Check Hardware Info.................................................................................. 74
9.10 Brightness/Color Calibration....................................................................75
9.11 Monitor the System................................................................................... 95
10. Servicing............................................................................................................ 104

3
10.1 Cleaning....................................................................................................104
10.2 Calibration................................................................................................ 105
10.3 Replacement steps................................................................................. 106
11. Appendix.............................................................................................................119

4
1. Safety
1.1 Warning& Symbols
Grounding
The combination of multiple cabinets in an installation results in increased levels of
leakage current. In order to avoid risk of electric shock due to high leakage current, proper
grounding of the installation is required.
Defeating the purpose of the grounding type plug will expose you to the risk of electric
shock.
Grounding symbols
Electric safety
Do not open equipment with below symbols. To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable parts inside. Qualified service personnel is
required for serving.
High voltage symbols
High voltage symbols
The lighting flash with an arrowhead within a triangle is intended to tell the user that parts
inside this product may cause a risk of electrical shock to persons.

5
1.2 Safety Guidelines
Personal protection
Ensure you understand and follow all the safety guidelines, installation instruction, warnings
and symbols.
Mind yourself while working with heavy loads and high voltage.
Contact with high voltage may cause death or serious injury. Always disconnect power to the
display cabinet or cabinets prior to servicing.
All personnel at the LED Video Board installation site are required to have personal
protection equipment (PPE) such as hard hats, safety glasses, gloves, harnesses, and other
appropriate safety equipment.
Equipment protection
This installation must be performed by authorized and qualified technical personnel only.
Accredited safety officers must ensure the safety of the site, construction, assembly,
connection, use, dismantling, transport etc.
Assembly parts are designed for use only with Samsung displays.
LEDs use specific materials and manufacturing processing in order to achieve unique
advantages.Do not modify and/or replicate any components.
Ground the LED display screen before connecting the power source.Contacting displays
that are not earth-grounded may cause death or serious injury.
Do not use the LED display screen ground lugs for installation equipment such as welding
equipment.
Structural & mounting components should be kept dry, clean, lubricated (only if
recommended), coated properly, and maintained in a manner consistent with part design.
LED products must be installed and operated in a manner to reply on its design and
inspection a routine basis for security, wear, deformation, corrosion and any other
circumstances that may affect the load handling capability of the part.
We recommend inspections at regular intervals for all installations and increasing in
frequency for more critical installations. A part is damaged which may cause a decrease in
load capability. The part must be removed for service or replaced immediately.
Always follow LED display screen installation instruction.
Contact the support technical person if user has any question regarding the safety of an
application. The manufacturer assumes no liability for incorrect, inadequate, irresponsible or
unsafe assembly of systems.

6
1.3 Installation instructions
Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not block ventilation openings. Please install in accordance with the manufactures
instructions.
Avoid installation near heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat. We suggest the user install some
equipment to reduce the heat if any.
Do not break the safety purpose of polarized or grounding type plugs/sockets. If the
provided sockets/plugs are damaged then replacement of the detective parts must be
undertaken immediately.
Protect the power/data cords from being taken off or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus. Replace
damaged power/data cords immediately.
Only use attachments/accessories specified or provided by the manufacturer.
Use with caution during lifting/moving or transporting to avoid damage by possible crash.
After receiving the LED display screen, please uncover all the boxes and cases, count and
check all things compare with the packing list. If there is any problem such as missing or
damaged part, contact the manufacture immediately.
Installation guide details are shown in charter 7&8.

7
2. Open Package
2.1 Front view
Step 1: Open the top wooden cover
Step 2: Open the side wooden cover
Step 3: Take the cabinets out from the wooden box.

8
2.2 Side view
Step 1: Open the top wooden cover
Step 2: Open the side wooden cover
Step 3: Take the cabinets out from the wooden box.

9
2.3 Placing cabinet
After taking the cabinets out from the wooden box, when you place the cabinet on the
ground, please put the back side on the ground first, then carefully put it standing on
the ground as shown above to make sure the modules will not be damaged.

10
3.XAJ10 Product introduction
3.1 Product Specification
NO.
Parameter
Specification
1
Attribute
Outdoor P10
2
Model Name (VD Common)
XA010J
3
Basic Model Name)
LH100XAJSAC
4
Pixel Pitch (mm)
10
5
LED vendor
Nationstar
6
LED package type
SMD3535
7
LED package part name
RS-3535MWAR
8
LED Lifetime Hr
( 24Hr, Luminace 50% down)
100,000
9
Size of LED color bin combination
R: 5nm, G:4nm, B:4nm
10
Number of LED color bin combination
1ea, upto 2ea
11
Driver IC vendor
MBI
12
Driver IC part name
MBI5051B
13
T-CON vendor
Novastar
14
T-CON part name
MCTRL600/MRV560/MON300
15
SMPS vendor
Mean Well
16
SMPS part name
HSP-300-4.2 4.2V/60A
17
Module Dimentions, LxH (mm)
320x320
18
Cabinet Dimensions, LxH (mm)
1280x1280x144
19
Cabinet Dimensions
With Waterproof cover ,LxH (mm)
1280x1280x177
20
Cabinet Weight (per ㎡)
38.5kg
21
Cabinet Weight (per cabinet)
63kg
22
Cabinet Construction
Aluminum
23
Package Method
2pcs in 1wooden case
24
Package Dimension ,LxHxD(mm)
1380x1500x514

11
25
Package Weight(per wooden box)
42kg
26
Package Total Weight (Per wooden
Box)
168kg
27
Brightness (cd/m²) Before Calibration
>7000
28
Brightness (cd/m²) After Calibration
>6300
29
Contrast Ratio(C/R)
3000：1
30
Front Mask for C/R
Louver/Mask
31
Viewing angle - Horizontal (o)
140
32
Viewing angle - Vertical (o)
80
33
Bit-depth(bit)
14
34
Refresh rate(hz) (typical)
≧2000
35
Scan rate (lines)
2
36
Power consumption - Max
≦670W/㎡
37
Power consumption - Typical
≦240W/㎡
38
Power
AC100-120V/ 220-240V,47-63Hz
39
Monitoring Function
LOD,Module data,Temperature,Huminity,
Power voltage,Fan and so on
40
Working Temperature (℃)
-30°C to 50°C
41
Operation Humidity
10% to 90%
42
Storage Temperature
-30°C to 60°C
43
Storage Humidity
10% to 90%
44
Color Temperature
45
- Default
6500K±500K
46
-Adjustable range
2800~16000K
47
Cooling
Fan(4pcs)
48
IP Rating
IP65 front/IP45 rear
49
Accessory in Box
Module mask, screws, power cables,
signal cable,Connecting Plate, door keys.
50
EMC Class
Class A
51
Certification
52
Service
Front and Back service

12
3.2 Product Appearance

13

14
3.3 Product design
Decomposition chart

15
Assembly drawing

16
3.4 Product main components
Module
Power Supply
Receiving Card
Monitoring Card

17
Fan
Hub board
Power-data cables（16pcs）
DC power cables (8PCS)and Flat cables (16 pcs)

18
4. LED display screen components
LED display screen connection
Sending box(Model Name: LSFNS, Model Code: VG-LSFNS/ZX)
Power LED and Switch:
Power on or power off the sending box, the LED show the status of sending box.
Power supply:
AC power input, offer power for sending box.
Power LED on back:
Show the status of sending card.
Audio:
Audio input, connect to the audio source, receiving the audio signal
USB:
Control port, connect to the computer, receiving control signal
DVI input:
DVI video input, connect to the video source, receiving the video signal
HDMI input:
HDMI video input, connect to the video source, receiving the video signal
Ethernet port:
Signal output ports, connect to the display, pass signal
Cascade:
Cascade control in and out, connect to another sending box
Light Sensor interface:
Connect to the light sensor, support brightness adjustment automatically.

19
Function of sending box:
1. HDMI/DVI input;
2. HDMI/external audio input;
3. 12bit/10bit/8bit HD video source；
4. Resolution supported: 2048x1152, 1920x1200, 2560x960;
5. Resolution supported: 1440x900;
6. 1 light sensor interface;
7. Cascading supported;
8. 18bit gray scale processing and presentation;
9. Video format:RGB, YCrCb4:2:2, YCrCb4:4:4;
10. Standard 1U housing; independent power supply;
1U chassis, Size: 482.6mm(width)*44.45mm(height)*250mm(depth).dd Weight: 4.15Kg
Net weight: 2.7Kg
Computer
Note: Usually the sending box and he PC should be running in control room.
LED display screen

20
5. Parts List And Parts BOM List
5.1 Accessories list
Sending box U Disk 3 core plug DVI cable
BN81-15303A BN81-15333A BN81-15312A BN81-15310A
R2S8-22-1721 2S8-22-2038 R2J8-22-0125 R2L3-27-0104
USB cable AC power input cable Signal input cable AC power cascade cable
BN81-15311A Different code by different project
R2L3-27-0105 Different code by different project 3D2-22-8582
Signal cascade cable Connect plate M10 Bowls Key for power box
R3D3-23-1931 R2J8-42-10000 R2W8-22-0466 R2W8-29-3277
Remark: The final quantity is subject to each order.
