Samsung DB10E-TPOE User manual

User Manual
The color and the appearance may dier depending on the product, and
the specications are subject to change without prior notice to improve the
performance..
DB10E-T
DB10E-POE
DB10E-TPOE

Table of contents
Before Using the Product
Copyright 6
Safety Precautions 7
Symbols 7
Cleaning 7
Storage 8
Electricity and Safety 8
Installation 9
Operation 11
Preparations
Checking the Components 14
Components 14
Parts 15
Control Panel 15
Reverse Side 16
Anti-theft Lock 17
Spacer logo 17
Remote Control 18
Before Installing the Product (Installation
Guide) 20
Ventilation 20
Using the STAND-BAR 21
Installing the Wall Mount 22
Installing the Wall Mount Kit 22
Wall Mount Kit Specifications (VESA) 22
Remote Control (RS232C) 23
Cable Connection 23
Connection 26
Control Codes 27
Using a touchscreen monitor
Touchscreen monitor 36
Read below before using the product 36
Requirements 37
Connecting the touchscreen monitor 38
Connecting to a PC 38
Connecting to a laptop or tablet PC 39
Configuring the touchscreen
monitor settings 40
Calibrating a monitor 40
Calibration 41
Controlling the screen 43
Touchscreen gestures 43
Notes 44
Connecting and Using a Source
Device
Before Connecting 46
Pre-connection Checkpoints 46
Connecting to a PC 46
Connection using an HDMI Cable 46
Connection using an HDMI-DVI Cable 47
Connecting to a Video Device 47
Connection Using an HDMI-DVI Cable 47
Connection Using an HDMI Cable 48
Connecting the LAN Cable 48
Changing the Input source 49
Source 49
Using MDC
MDC Program Installation/Uninstallation 50
Installation 50
Uninstallation 50
Connecting to MDC 51
Using MDC via Ethernet 51
Home feature
Player 52
Approving a connected device from the server 53
Network Channel 57
Local Channel 57
PublishedContent 57
Published Channel 57
Network File 57
My Templates 57
2

Table of contents
Available features in the Player page 58
Player page Settings menu 59
When Content is Running 61
File Formats Compatible with Player 63
File Formats Compatible with Videowall 68
Schedule 70
Available features in the Schedule page 70
Template 72
Clone Product 75
ID Settings 76
Device ID 76
PC Connection Cable 76
Screen Saver 77
Network Status 77
Video Wall 78
Video Wall 78
On/Off Timer 80
On Timer 80
Off Timer 81
Holiday Management 81
Ticker 82
More settings 82
URL Launcher 83
Screen Adjustment
Picture Mode 84
Backlight / Contrast / Brightness /
Sharpness / Color / Tint (G/R) 85
Color Temperature 86
White Balance 87
2 Point 87
10 Point 87
Gamma 88
Calibrated Value 88
Advanced Settings 89
Dynamic Contrast 90
Black Tone 90
Flesh Tone 90
RGB Only Mode 90
Color Space 90
Motion Lighting 90
Picture Options 91
Color Tone 92
Digital Clean View 92
MPEG Noise Filter 92
HDMI Black Level 93
Film Mode 93
Dynamic Backlight 93
Picture Size 94
Picture Size 94
Position 95
Zoom/Position 95
Picture Off 96
Reset Picture 96
OnScreen Display
Display Orientation 97
Onscreen Menu Orientation 97
Source Content Orientation 97
Aspect Ratio 97
Screen Protection 98
Auto Protection Time 98
Screen Burn Protection 98
Message Display 101
Source Info 101
No Signal Message 101
MDC Message 101
Download Status Message 101
Menu Language 102
Reset OnScreen Display 102
Sound Adjustment
Sound Mode 103
Sound Effect 104
Dialog Clarity 104
3

Table of contents
Equalizer 104
Dolby Digital Comp 105
Speaker Settings 105
Sound Output 105
Auto Volume 106
Reset Sound 106
Network
Network Status 107
Network Settings 107
Network Type 107
Network Settings (Wired) 108
Network Setting (Wireless) 110
WPS(PBC) 112
Wi-Fi Direct 113
Multimedia Device Settings 113
Screen Mirroring 114
Screen Mirroring 114
Server Network Settings 114
Connect to Server 114
MagicInfo Mode 114
Server Access 114
FTP Mode 114
Device Name 115
System
Accessibility 116
Menu Transparency 116
High Contrast 116
Enlarge 116
Setup 117
Initial settings (System) 117
Touch Control 119
Touch Control Lock 119
Admin Menu Lock 119
Device to Control 119
Time 120
Clock Set 120
DST 120
Sleep Timer 120
Power On Delay 120
Auto Source Switching 121
Auto Source Switching 121
Primary Source Recovery 121
Primary Source 121
Secondary Source 121
Power Control 122
Auto Power On 122
Max. Power Saving 122
Standby Control 122
Power Button 122
Network Standby 122
Eco Solution 123
Energy Saving 123
Screen Lamp Schedule 123
No Signal Power Off 123
Auto Power Off 123
Temperature Control 124
Device Manager 125
Keyboard Settings 125
Mouse Settings 126
Play via 127
Change PIN 127
Security 128
Safety Lock 128
Button Lock 128
USB Auto Play Lock 128
General 129
Smart Security 129
BD Wise 130
Anynet+ (HDMI-CEC) 131
HDMI Hot Plug 135
DivX® Video On Demand 135
Game Mode 135
Reset System 136
4

Table of contents
Support
Software Update 137
Update now 137
Auto Update 137
Contact Samsung 137
Go to Home 137
Reset All 137
Playing photos, videos and music
(Media Play)
Read the following before using
media play with a USB device 138
Using a USB device 140
Playing media content from a PC/mobile device 141
Features provided in the
media content list page 142
Menu items in the media content list page 143
Available buttons and features during photo
playback 144
Available buttons and features during video
playback 145
Available buttons and features
during music playback 146
Supported Subtitle and
Media play file formats 147
Subtitle 147
Supported image resolutions 147
Supported music file formats 148
Supported Video Formats 148
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 150
Testing the Product 150
Checking the Resolution and Frequency 150
Check the followings. 151
Specifications
General 156
Preset Timing Modes 157
Appendix
Responsibility for the Pay Service (Cost to
Customers) 160
Not a product defect 160
A Product damage caused by customer's fault 160
Others 160
Optimum Picture Quality and
Afterimage Burn-in Prevention 161
Optimum Picture Quality 161
Prevention of Afterimage Burn-in 161
License 163
Terminology 164
5

6
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
©2016 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
Chapter 01

7
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Cleaning
―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―Take the following steps when cleaning.
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Power off the product and computer.
2
Disconnect the power cord from the product.
―Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
!
3
Wipe the product with a clean, soft and dry cloth.
•Do not use detergents that contain alcohol, solvent or
surface-active agents.
•Do not spray water or detergent directly on the product.
4
Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.

8
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-
colored stains on the product.
―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•An electric shock or fire may result.
Do not use multiple products with a single power socket.
•Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
!
Insert the power plug all the way in so it is not loose.
•An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket (type 1 insulated
devices only).
•An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•A fire or electric shock may result.
!
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•A fire may result.

9
Caution
Do not disconnect the power cord while the product is being used.
•The product may become damaged by an electric shock.
!
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•A fire or electric shock may result.
!
Keep the power socket where the power cord is connected unobstructed.
•The power cord must be disconnected to cut off power to the product
when an issue occurs.
•Note that the product is not completely powered down by using only
the power button on the remote.
!
Hold the plug when disconnecting the power cord from the power socket.
•An electric shock or fire may result.
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•A fire may result.
!
Have a technician install the wall-mount hanger.
•Installation by an unqualified person can result in an injury.
•Only use approved cabinets.
!
Keep the plastic packaging out of the reach of children.
•Children may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•The product may fall and become damaged and/or cause an injury.
•Using the product in an area with excess vibration may damage the
product or cause a fire.
!
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•A fire or electric shock may result.

10
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
•The product may fall and injure children.
•As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not
install the product in a kitchen or near a kitchen counter.
Caution
!!!
Do not drop the product while moving.
•Product failure or personal injury may result.
Do not set down the product on its front.
•The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•The product may fall and become damaged and/or cause an injury.
•Install the product only on cabinets or shelves of the right size.
!
Set down the product gently.
•Product failure or personal injury may result.
SAMSUNG
!
Installing the product in an unusual place (a place exposed to a lot of fine
dust, chemical substances, extreme temperatures or a significant presence
of moisture, or a place where the product will operate continuously for an
extended period of time) may seriously affect its performance.
•Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.
