Samsung SDP-860 Assembly instructions

5
Samsung 860 Basic Operations
The Samsung SDP-860 provides basic controls on the base of the doc cam. Please note that you can also
access these features plus additional advanced functions via the remote control.
Control Panel Functions for Both the 860 Panel and Remote
1. INT/EXT – internal/external switching function
2. AF – Auto focus
3. MF/AWB – manual focus, white balance
4. ESC – return to live image at any point
5. BRIGHTNESS / ZOOM / FOCUS WHEEL
6. CAPTURE – Press to capture still images
or movies with audio to a
SD Memory Card
7. MODE – Switch to live image,
picture or video mode
8. FREEZE – Freeze live image or while
playing video switch to Full Screen
9. LAMP – turn the LED light on or off
Key Basic Functions for the Teacher
Power
Press the POWER button on the SDP-860 panel or
remote control to activate the unit. A blue status light
will illuminate around the Power button.
The initial boot-up screen will appear providing
information on the status of the following items:
1) Current digital presenter settings
2) Current screen capture settings
3) Operational status of the SD Memory card and
system.
Note – A SD Memory card is not required to use the 860
document camera. You can save images directly using the USB cable from the doc cam to your laptop if you
have the 860 software installed. More details on this will be presented later in this guide.
Remote Control
SDP-860 Panel
All manuals and user guides at all-guides.com
all-guides.com

6
INT/EXT (Internal/External)
Press INT/EXT button to toggle between doc cam (INT)and computer (EXT) modes.
Brightness / Zoom / Focus Wheel
Adjust the Brightness to the desired setting by using the UP/DOWN Buttons found on the control
panel or remote. The LED lamp can be turned on or off by pressing the LAMP button.
If glare occurs when viewing glossy materials, either turn off the lamp or use the included diffuser
sheet. Adjust the brightness as needed.
Press the LEFT/RIGHT Buttons found on the control panel to reduce
or enlarge the image to the desired size. The on screen display will indicate the
zoom range - Blue Gauge = optical zoom, Red Gauge = digital zoom.
The Optical zoom will automatically stop at 6x. Press the zoom button again to
continue with Digital zoom (up to 8x maximum). Auto focus will occur after
zooming has stopped in all modes.
Use the FREEZE button to “hold” any image on screen while you change your subject or to Freeze an
object in any position.
Tip:You can use the computer monitor as a live preview display when connected via the USB while
using the Freeze feature on the SDP-860. You can also adjust the default to Freeze both the live
image and the computer image by pressing the Menu button.
The LAMP is important because it is the quickest way to brighten your document or object. The
Samsung 860 by factory default has Automatic White Balance (AWB) built-in through an Auto
Tracking setting. This means that when you place a document, book or object on the white
presentation station, it will usually color balance the subject very quickly without the teacher
needing to make any adjustments.
Tip: If any color adjustments need to me made when displaying a new item, the simplest solution is to simply
turn the lamp off and then back on and this will cause the doc cam to white balance itself.
Not So Important
The MF (Manual Focus) /AWB (Auto White Balance) button can generally be ignored by most
teachers as they won’t need to manually focus as Auto Focus takes care of that and Auto White
Balance is also automatically set up for Auto Tracking from the factory.
