SVR‐6400QuickStart
Guide














ThepurposeofthisquickguideistohelpyouconfiguretheNVRmodelSVR‐6400.

General

Theunithasthree1GBxnetworkcards(Figure1)
1xforaMonitor
1xforaSource(receivingIPstreams)
1xconnectingtoanexternalstoragedevise(NAS).

TheSNRsetupisdividedintotwosections:
1. BasicconfigurationviathefrontLCDpane(Figure2);
2. Fullconfigurationviainternalwebserver(MonitorPortIPAddress).



FrontLCDpanel

Figure1.Figure2.









BasicConfiguration

AddpowertotheunitusingthePowerbuttonontherearpanel(Figure1),Usethedownarrowonthefront
paneltofindandselecttheNetworkSetupmenu(Figure3)thenclickENTER.

Figure3.Figure4.











NowselectOption1.MonitoringPort(Figure4)
thenclickENTER

NowselectOption1.UseStaticIP(Figure5)thenclickENTER
Figure5.Figure6.











SettheIPaddressandSubnetMaskfortheMonitorport(Figure6),usethisIPaddresstoconnectviaWeb
Server.

Fullconfiguration

OncetheMonitorIPaddressisset,openInternetExplorerandopenanIPsessionoverhttp(port80)as
detailedbelow,UserandPasswordarethedefaults(USER:admin,PWD:11111111).(Figure7)
Figure7.



















SelecttheCONFIGTABandthenTIMESETUPtosetuptheTIMEconfigurationasinFigure8andclickAPPLY.
Figure8.























SelecttheCONFIGTABandthenNETWORKSETUPtoconfiguretheIPaddressfortheSourceETHPORTbefore
theStorageETHPORTIPaddressalltheparametersasshowninFigure9thenclickAPPLY.

Figure9.





















SelectCAMERASETUPTABundertheCONFIGTAB.Addanewcameratothesystemasshownintheexample
inFigure10andclickAPPLY.

Figure10.





SelecttheRECORDSETUPTABintheCONFIGTABandsetuptheparametersasshownintheexamplein
Figure11andclickAPPLY.






















Figure11.


Withtheunitnowrecording,itispossibletoseeLIVEpicturesfromthecamerasusingtheMonitoringMenu
andrecordedvideousingthePlaybackMenu.

