Samsung GH15DS User manual

TFT-LCD MONITOR
GH15DS
Manual
SERVICE
TFT-LCD MONITOR CONTENTS
1. Precautions
2. Product Specifications
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Parts List
6. Electrical Parts List
7. Block Diagram
8. Wiring Diagram
9. Schematic Diagrams
10. Panel Description

1-1-1 Warnings
1. For continued safety, do not attempt to modify the
circuit board.
2. Disconnect the AC power and DC Power Jack
before servicing.
3. When the chassis is operating, semiconductor
heatsinks are potential shock hazards.
1-1-2 Servicing the LCD Monitor
1. When servicing the LCD Monitor, remove the static
charge by connecting a 10k ohm resistor in series
with an insulated wire (such as a test probe)
between the chassis and the anode lead.
(Disconnect the AC line cord from the AC outlet.)
2. It is essential that service technicians have an
accurate voltage meter available at all times. Check
the calibration of this meter periodically.
1-1-3 Fire and Shock Hazard
Before returning the monitor to the user, perform the
following safety checks:
1. Inspect each lead dress to make certain that the
leads are not pinched or that hardware is not
lodged between the chassis and other metal parts in
the monitor.
2. Inspect all protective devices such as nonmetallic
control knobs, insulating materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators, etc.
3. Leakage Current Hot Check (Figure 1-1):
WARNING: Do not use an isolation transformer
during this test.
Use a leakage current tester or a metering system
that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for
Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
Figure 1-1. Leakage Current Test Circuit
4. With the unit completely reassembled, plug the AC
line cord directly into a 120V AC outlet. With the
unit’s AC switch first in the ON position and then
OFF, measure the current between a known earth
ground (metal water pipe, conduit, etc.) and all
exposed metal parts, including: metal cabinets,
screwheads and control shafts. The current
measured should not exceed 0.5 milliamp. Reverse
the power-plug prongs in the AC outlet and repeat
the test.
1-1-4 Product Safety Notices
Some electrical and mechanical parts have special
safety-related characteristics which are often not
evident from visual inspection. The protection they give
may not be obtained by replacing them with
components rated for higher voltage, wattage, etc. Parts
that have special safety characteristics are identified by
on schematics and parts lists. A substitute
replacement that does not have the same safety
characteristics as the recommended replacement part
might create shock, fire and / or other hazards. Product
safety is under review continuously and new
instructions are issued whenever appropriate.
GH15DS 1-1
1 Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1 Safety Precautions
DEVICE
UNDER
TEST
TEST ALL
EXPOSED METAL
SURFACES
(READING SHOULD
NOT BE ABOVE 0.5mA)
LEAKAGE
CURRENT
TESTER
2-WIRE CORD
*ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED) EARTH
GROUND
!

1-2-1 General Servicing Precautions
1. Always unplug the unit’s AC power cord from the
AC power source and disconnect the DC Power
Jack before attempting to:
(a) remove or reinstall any component or assembly,
(b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic
capacitor.
2. Some components are raised above the printed
circuit board for safety. An insulation tube or tape
is sometimes used. The internal wiring is
sometimes clamped to prevent contact with
thermally hot components. Reinstall all such
elements to their original position.
3. After servicing, always check that the screws,
components and wiring have been correctly
reinstalled. Make sure that the area around the
serviced part has not been damaged.
1. Immediately before handling any semiconductor
components or assemblies, drain the electrostatic
charge from your body by touching a known earth
ground. Alternatively, wear a discharging wrist-
strap device. To avoid a shock hazard, be sure to
remove the wrist strap before applying power to
the monitor.
2. After removing an ESD-equipped assembly, place it
on a conductive surface such as aluminum foil to
prevent accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can
generate electrical charges sufficient to damage
ESDs.
4. Use only a grounded-tip soldering iron to solder or
desolder ESDs.
5. Use only an anti-static solder removal device. Some
solder removal devices not classified as “anti-static”
can generate electrical charges sufficient to damage
ESDs.
4. Check the insulation between the blades of the AC
plug and accessible conductive parts (examples:
metal panels, input terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the
power cord from the AC source and turn the power
switch ON. Connect an insulation resistance meter
(500 V) to the blades of the AC plug.
The insulation resistance between each blade of the
AC plug and accessible conductive parts (see
above) should be greater than 1 megohm.
6. Always connect a test instrument’s ground lead to
the instrument chassis ground before connecting
the positive lead; always remove the instrument’s
ground lead last.
6. Do not remove a replacement ESD from its
protective package until you are ready to install it.
Most replacement ESDs are packaged with leads
that are electrically shorted together by conductive
foam, aluminum foil or other conductive materials.
7. Immediately before removing the protective
material from the leads of a replacement ESD,
touch the protective material to the chassis or
circuit assembly into which the device will be
installed.
Caution: Be sure no power is applied to the
chassis or circuit and observe all
other safety precautions.
8. Minimize body motions when handling
unpackaged replacement ESDs. Motions such as
brushing clothes together, or lifting your foot from
a carpeted floor can generate enough static
electricity to damage an ESD.
1 Precautions
1-2 GH15DS
1-3 Electrostatically Sensitive Devices (ESD) Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated circuits and some field-
effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1-2 Servicing Precautions
WARNING: An electrolytic capacitor installed with the wrong polarity might explode.
Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions
section of this manual.
Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.

2 Product Specifications
2-1 Specifications
LCD Panel TFT-LCD panel, RGB vertical stripe, normaly white,15-Inch viewable,
0.297 mm pixel pitch
Scanning Frequency Horizontal : 30 kHz ~ 60 kHz
Vertical : 56 Hz ~ 75 Hz
Display Colors 16.2 Million colors
Maximum Resolution Horizontal : 1024 Pixels
Vertical : 768 Pixels
Input Video Signal VESA TMDS
Input Sync Signal Encoded by TMDS
Maximum Pixel Clock rate 80 MHz
Active Display Horizontal : 304 mm Vertical : 228 mm
AC power voltage & Frequency AC 90 ~ 260 Volts, 60/50 Hz ± 3 Hz
Power Consumption On : 30 W (max) / Saving : 3W (max) / Switch - off : 1W (max)
Dimensions
Unit (W x D x H)
With Simple Stand 15.4 x 15.1 x 6.8 Inches (391.4 x 383.6 x 173 mm)
Without Simple stand 15.4 x 11.5 x 2.5 Inches (391.4 x 292.8 x 64.0 mm)
With Pivot Stand 15.4 x 15.1 x 6.8 Inches (391.4 x 383.6 x 173 mm)
15.4 x 17.1 x 6.8 Inches (391.4 x 433.6 x 173 mm)
Without Pivot Stand 15.4 x 11.5 x 2.5 Inches (391.4 x 292.8 x 64.0 mm)
Weight (Net/Gross) 4.2 kg (9.3 lbs) / 5.2 kg (11.5 lbs)
Environmental Considerations Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %
Storage Temperature : -3.2°F ~ 140°F (-20°C ~ 60°C)
Humidity : 5 % ~ 95 %
•GH15DS comply with SWEDAC (MPR II) recommendations for reduced electromagnetic fields.
•Designs and specifications are subject to change without prior notice.
GH15DS 2-1
Item Description

Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
2 Product Specifications
2-2 GH15DS
2-2 DVI Signal Pin Assignments - Main Pin Field (GH15DS)
1 T.M.D.S. Data2- 9 T.M.D.S. Data1- 17 T.M.D.S. Data0-
2 T.M.D.S. Data2+ 10 T.M.D.S. Data1+ 18 T.M.D.S. Data0+
3 T.M.D.S. Data2 Return 11 T.M.D.S. Data1 Return 19 T.M.D.S. Data0 Return
4NC 12NC 20NC
5NC 13NC 21NC
6 DDC Clock 14 +5V Power 22 T.M.D.S. Clock Return
7 DDC Data 15 Ground (Self-Raster) 23 T.M.D.S. Clock+
8 NC 16 Hot Plug Detect (+5V) 24 T.M.D.S. Clock-

2 Product Specifications
GH15DS 2-3
2-3 Timing Chart
This section of the service manual describes the timing that the computer industry recognizes as standard
for computer-generated video signals.
Table 2-1. Timing Chart
2-3-1. GH15DS

2 Product Specifications
2-4 GH15DS
Table 2-2. Timing Chart

3-1-1 Removing the Stand
1. Remove 4 screws in the hinge area.
2. Disconnect Power Cord and Signal Cable.
3. Pry it off the back of the monitor.
3-1-2 Main Body Disassembly
1. Remove 2 screws on the two corner of the
Rear Cover.
2. Remove Rear Cover from the Front Cover.
3. Remove 4 screws on the Shield and remove
the shield.
4. Disconnect Inverter wire, Function PCB wire
and Interface wire.
Remove 3 screws on the Main PCB and
remove 2 screws on the D sub shield.
5. Remove 3 screws on the power PCB and
remove 2 screws on the Inverter PCB.
6. Remove the Main PCB Assembly.
7. Remove 3 screws on the Function PCB from
locking area of Function knob and remove
Function PCB.
3-1-3 Standard Stand Disassembly
1. Remove 2 screws from the Stand front.
2. Remove 7 screws from the Stand Bottom.
3. Remove Stand Rear from the Stand assembly.
4. Remove 5 screws from the Stand assembly.
5. Remove the Neck front from the Stand
assembly.
6. Remove 2 screws from the Stand assembly.
7. Remove Neck Rear from the Stand assembly.
8. Remove 4 screws from the Stand assembly.
GH15DS 3-1
3 Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the
GH15DS monitor.
WARNING: This monitor contains electrostatically sensitive devices. Use with caution when
handling these components.
3-1 Disassembly
Cautions:1. Disconnect the monitor from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

3 Disassembly and Reassembly
3-2 GH15DS
1. After confirm there is nothing
on the disk
Turn the LCD module over
and put it on a flat desk set to
the ground.
3-2 Replacement Order of Lamp Assemblies (GH15DS : Samsung Panel)
2. Push down the stopper and
slide the lamp unit.
3. Please take out the lamp
unit from the LCD
module.

3 Disassembly and Reassembly
GH15DS 3-3
4. Please fix the new lamp
units on the LCD module :
opposite process 2 and 3
* Replacement of lamp unit should be done at the power off state and recommanded clean
bench condition.
3-3 Reassembly
Reassembly procedures are in the reverse order of Disassembly procedures.

Memo
3 Disassembly and Reassembly
3-4 GH15DS

GH15DS 4-1
4 Troubleshooting
Notes: 1. Before troubleshooting, setup the PC’s display as below.
• Resolution: 1024 x 768
• H-frequency: 48 kHz
• V-frequency: 60 Hz
2. If no picture appears, make sure the power cord is correctly connected.
3. Check the following circuits.
• No raster appears: Main PCB
• 12V develop but no screen: Main PCB
• 12V does not develop: Main PCB
4. If you push and hold the EXIT button for more than 5 seconds, the monitor automatically turns back
to the factory preset(GH15DS).
4-1 Power
Does proper DC 12 V
appear at CN100? Check Power Adaptor.
Yes
No
Does proper DC 5 V appear at
output Pin of IC100? Check IC100 and related circuit.
Check IC101, IC102, IC601, IC401
and related circuit.
Yes
No
Yes
Does proper 3.3 V - signals
appear at output Pin of IC103? Check IC103 and related circuit.
No
Yes
Does proper 3.3 V - signals
appear at Pin 7 of CN100? Check CN100-7 and related circuit.
No
Yes
Does proper 3.3 V - signals
appear at R300? Check IC301 and related circuit.
No

4 Troubleshooting
4-2 GH15DS
4-2 Video
Power indicator is green?
Check IC301.
Check X301.
Yes
Yes
No
No
Yes
Do the input signals
appear at D201~D208?
No
Do the input signals appear at
pin 30, 31, 32 of IC401?
1 2
3 4 5
Check Pin 68 of IC301 and IC102.
Yes
Do the output signals appear
at pin 40 of IC401?
No
Check IC401.
Replace LCD panel.
6

4 Troubleshooting
GH15DS 4-3
WAVEFORMS
1
3
5
2
4
6
D201
IC401 #30
IC401 #32
D208
IC401 #31
IC401 #40

Memo
4 Troubleshooting
4-4 GH15DS

GH15DS 5-1
5 Exploded View and Parts List

5 Exploded View & Parts List
5-2 GH15DS
Memo

CIS BN44-00053A ADAPTOR DPA30L,150S,100-240VAC,47 - 63 HZ,12VDC/3.3VDC,2A/2A,-,30.6,AC-DC,-10~40C,-,-
CIS BN72-00209A SUPPORT-POWER GH15LS,ABS+PC,GR37,-,5V,-,-,- SNA
CIS BN75-00176B UNIT-SHIELD/DSUB GH15LS,-,SPTE T0.5,-,-,-,- SNA
CIS BN70-00204B SHIELD-D/SUB GH15DS,SPTE,-,T0.5,-,-,-
CIS BN71-00024A EARTH-PLATE GH17LS,SUS,T0.15,-,-,- SNA
CIS BN46-00008K MICOM-S/W,GOGH GH15DS,-,-,-,-,-,- SNA
CN100 3711-004853 CONNECTOR-HEADER BOX,7P,1R,2MM,ANGLE,SN,WHT SNA
CN201 3701-001173 CONNECTOR-DSUB 24P,3R,FEMALE,ANGLE,AUF
CN601 3711-001465 CONNECTOR-HEADER NOWALL,3P,1R,2.54mm,STRAIGHT,A SNA
DVI BN60-00001A SCREW-CHASSIS -,NI PLATING,-,11,HEX,HEX,-,UNC#4-40,NI PLT,- SNA
IC601 0903-001143 IC-MICROCONTROLLER
88P6232,8BITBit,SDIP,42P,600MIL,12MHz,ST,CMOS,PLASTIC,5V,-,-40to+85C,464BYTE,32K SNA
SOCK_IC601 3704-001071 SOCKET-IC 42P,DIP,SN,1.778mm
C102 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4
C103 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C104 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C105 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C106 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C107 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C108 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C112 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C113 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C114 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C115 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C201 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4
C202 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C301 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C302 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C303 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C304 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C307 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4
C308 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C309 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C310 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C311 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C312 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C313 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C314 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C315 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C316 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608
C317 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608
C318 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608
C319 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608
C320 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C321 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C322 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C323 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4
C325 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4
C326 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C327 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
GH15DS 6-1
Loc. No. Code No. Description Specification Remarks
6 Electrical Parts List
6-1 Main PCB Part

6 Electrical Parts List
6-2 GH15DS
C328 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C329 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C330 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C331 2402-000135 C-AL,SMD 22uF,20%,16V,GP,TP,5.3x5.3x5.4
C332 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C333 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C334 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C335 2203-000280 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1608
C336 2203-000280 C-CERAMIC,CHIP 0.01nF,0.5pF,50V,NP0,TP,1608
C402 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,-
C403 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,-
C404 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,-
C405 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,-
C413 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C414 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C415 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4
C600 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C601 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm
C602 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608
C603 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608
C604 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4
C605 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C606 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C610 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C611 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C612 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C613 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
C614 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608
CA301 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CA302 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CA303 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CA304 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CA305 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CA306 2503-001019 C-NETWORK 33PFX4,10%,50V,CHIP
CN101 3711-000556 CONNECTOR-HEADER BOX,12P,1R,1.25mm,SMD-A,SN SNA
CN402 3711-003161 CONNECTOR-HEADER BOX,20P,1R,1.25mm,ANGLE,SN SNA
CN600 3711-002049 CONNECTOR-HEADER BOX,6P,1R,1.25mm,SMD-A,SN SNA
D201 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D202 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D203 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D204 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D205 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D206 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D207 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D208 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D209 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
D210 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP
FT301 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1
FT302 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1
FT303 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1
FT402 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1
Loc. No. Code No. Description Specification Remarks

6 Electrical Parts List
GH15DS 6-3
FT407 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1
IC100 1203-001488 IC-POSI.FIXED REG. 7805,T0-252,3P,-,PLASTIC,4.8/5
IC103 1203-001293 IC-POSI.FIXED REG. 033,T0-252,3P,6.5MIL,PLASTIC,3
IC201 1103-000129 IC-EEPROM 24C02,256x8BIT,SOP,8P,150MIL,1
IC301 1003-001374 IC-LCD CONTROLLER GM3020,LQFP,128P,551MIL,SINGLE,-,-,PLASTIC,3.47V,0TO+70C,-,-,-
IC401 1205-001740 IC-TRANSMITTER
DS90C385,TSSOP,56P,240MIL,PLASTIC,4V,1.63W,-10 TO +70C,ST,FPD LINK-85MHZ(LVDS)
IC603 1103-000129 IC-EEPROM 24C02,256x8BIT,SOP,8P,150MIL,1
L100 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L101 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L102 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L201 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L303 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L304 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L401 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L402 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L602 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L603 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L604 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L605 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
L606 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
MP1.0 BN41-00093A PCB MAIN S/M150DS,FR4,2L,-,-,120*110*1.6,GH15D,-,-,-
Q101 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q102 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q103 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q600 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q601 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q602 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q603 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q605 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
Q606 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270
R100 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608
R101 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R102 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R103 2007-000102 R-CHIP 100Kohm,5%,1/16W,DA,TP,1608
R104 2007-000090 R-CHIP 10KOHM,5%,1/16W,DA,TP,1608
R105 2007-000102 R-CHIP 100Kohm,5%,1/16W,DA,TP,1608
R106 2007-000090 R-CHIP 10KOHM,5%,1/16W,DA,TP,1608
R107 2007-000102 R-CHIP 100Kohm,5%,1/16W,DA,TP,1608
R108 2007-000090 R-CHIP 10KOHM,5%,1/16W,DA,TP,1608
R109 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R110 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R111 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R112 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R113 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R114 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
R201 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608
R202 2007-000084 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1608
R203 2007-000084 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1608
R204 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608
R205 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608
R300 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608
Loc. No. Code No. Description Specification Remarks
