SAMSUNG TFT-LCD
MODEL : LTY[Z]460HB01
SAMSUNG TFT
SAMSUNG TFT- -LCD LCD
MODEL
MODEL : LTY[Z]460HB01 : LTY[Z]460HB01
SL Development Team, LCD Business
Samsung Electronics Co . , LTD.

2/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
Contents
Revision History -------------------------------------------------------------------------------------------- (3)
General Description --------------------------------------------------------------------------------------- (4)
General Information --------------------------------------------------------------------------------------- (4)
1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)
2. Optical Characteristics --------------------------------------------------------------------------------- (6)
3. Electrical Characteristics ------------------------------------------------------------------------------- (9)
3.1 TFT LCD Module
3.2 Back Light Unit
4. Block Diagram ------------------------------------------------------------------------------------------- (11)
5. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)
5.1 Input Signal & Power
5.2 Balance Board
5.3 LVDS Interface
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color
6. Interface Timing ---------------------------------------------------------------------------------------- (20)
6.1 Timing Parameters (DE only mode)
6.2 Timing Diagrams of interface Signal (DE only mode)
6.3 Power ON/OFF Sequence
7. Outline Dimension -------------------------------------------------------------------------------------- (23)
8. EMI Specification --------------------------------------------------------------------------------------- (25)
9. Spread Spectrum Specification
10. UL Approval
11. Reliability Test ----------------------------------------------------------------------------------------- (26)
12. Packing ------------------------------------------------------------------------------------------------ (27)
13. Marking & Others ------------------------------------------------------------------------------------- (28)
14. General Precaution ---------------------------------------------------------------------------------- (29)
14.1 Handling
14.2 Storage
14.3 Operation
14.4 Operation Condition Guide
14.5 Others

3/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
* Revision History
First Issued-000
Sep.
07,
2007
SummaryPage
Rev.
No
Date

4/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
LTY[Z]460HB01 is a color active matrix liquid crystal display (LCD) that uses amorphous
silicon TFT(Thin Film Transistor) as switching components. This model is composed of a
TFT LCD panel, a driver circuit and a back light unit. The resolution of a 46.0“ is 1920 x
1080 and this model can display up to 1.07 billion colors with wide viewing angle of 89°or
higher in all directions. This panel is intended to support applications to provide a excellent
performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV, Display
terminals for AV application products, and High Definition TV (HDTV).
RoHS compliance (Pb-free)
1.07(True-10Bit) Color Support
High contrast ratio, high aperture ratio, fast response time
SPVA (Super Patterned Vertical Align) mode
Wide viewing angle (±89°)
High speed response
Full HD(1920 x 1080 pixels) resolution (16:9)
Low Power consumption
24 High color gamut CCFTs (Cold Cathode Fluorescent Tube)
DE(Data Enable) mode
Mini-LVDS (Mini Low Voltage Differential Signaling) interface
Features
General Description
Description
General Information
57.1(DMAX)
mm0.53025(H) x 0.17675(W)*3Pixel Pitch
g16000(Max)Weight
±1.0mm
mm
1083.0(HTYP) x 627.0(VTYP)
Module Size
mm1018.08(H) x 572.67(V)Active Display Area
Refer to Page 6
Note
DSLR(3H)Surface Treatment
cd/m2
550Luminance of White
Normally BlackDisplay Mode
RGB vertical stripePixel Arrangement
pixel1920 x 1080Number of Pixels
colors1.07 billion(True-10Bit)Display Colors
UnitSpecificationItems

5/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
Note (1) Ta= 25 ±2 °C
(2) Temperature and relative humidity range are shown in the figure below.
a. 93.8 % RH Max. (Ta ≤40 °C)
b. Maximum wet-bulb temperature at 40 °C or less. (Ta ≤40 °C)
c. No condensation
(3) Polarizer will not be damaged in this range, even though abnormal visual problems occur
in TSUR range.
(4) 11ms, sine wave, one time for ±X, ±Y, ±Z axis
(5) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.
Fig. Temperature and Relative humidity range
30-
±Z axis
±XY axis
(2)
℃
500TOPR Operating Temperature
40
(1)V13GND-0.5VDD Power Supply Voltage
(5)G1.5-VNOP
Vibration ( non - operating )
(4)G
-
SNOP
Shock ( non - operating )
(3)
℃
650TSUR
Panel surface temperature
(2)
℃
65-20TSTG
Storage temperature
NoteUnitMax.Min.SymbolItem

6/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
2. Optical Characteristics
The optical characteristics should be measured in a dark room or equivalent.
Measuring equipment : TOPCON BM-7,SPECTRORADIOMETER SR-3
(Ta = 25 ±2°C, VDD=12V, fv= 60Hz, fDCLK=148.5MHz, Dim = 90%)
-2.2-
γ
Gamma
-8-
Normal
θL,R=0
θU,D=0
Viewing
Angle
TgG-to-G
(7)
SR-3
%-90--Color Gamut
Ver.
Hor.
(4)
SR-3
%23--Buni
Brightness Uniformity
(9 Points)
-8979θD
-8979θU
-8979θR(8)
SR-3
Degree
-8979
C/R≥10
θL
Viewing
Angle
(7)
SR-3
K-(11800)*--Color Temperature
White
Blue
Green
Red
Falling
Rising
(0.274)*Wy
(0.274)*Wx
(0.059)*By
(0.148)*Bx
(0.662)*Gy
(0.211)*Gx
(0.324)*Ry
(7),(8)
SR-3
TYP.
+0.03
(0.651)*
TYP.
-0.03
Rx
Color
Chromaticity
(CIE 1931)
(6)
SR-3
cd/m2
-550450YL
Luminance of White
(Center of screen)
106-Tf (5)
BM-7
msec
1610-Tr
Response
Time
(3)
SR-3
-1700(1000)*C/R
Contrast Ratio
(Center of screen)
NoteUnitMax.Typ.Min.ConditionSymbolItem
Note (1) Test Equipment Setup
The measurement should be executed in a stable, windless and dark room between
40min and 60min after lighting the back light at the given temperature for stabilization
of the back light. This should be measured in the center of screen.
Single lamp current @ IL= 6.5mArms(typ.), Dim = 90%
Environment condition : Ta = 25 ±2 °C
* marked Items will be decided after taking data of early mass production.

7/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
2°BM-7
1°SR-3
FieldPhoto detector Photo detector
LCD Panel
TFT - LCD Module
The center of the screen
SR-3 : 50㎝
BM-7 : 50㎝
Field
Note (2) Definition of test point
①②③
⑥
⑨⑧
⑤④
⑦Active Area
Test Point
Note (3) Definition of Contrast Ratio (C/R)
: Ratio of gray max (Gmax) & gray min (Gmin) at the center point ⑤of the panel
CR G
G
/max
min
=
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black
320 960 1600
900
540
180

8/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
Note (4) Definition of 9 points brightness uniformity
Note (5) Definition of Response time : Sum of Tr, Tf
Buni BB
B
=∗ − 100 (max min)
max
Bmax : Maximum brightness
Bmin : Minimum brightness
Display data
Optical Instruments
Response
TIME
TRTF
10%
90%
White (data off)
0%
Black (data off) White (data on)
100%
Note (6) Definition of Luminance of White : Luminance of white at center point ⑤
Note (7) Definition of Color Chromaticity (CIE 1931)
Color coordinate of Red, Green, Blue & White at center point ⑤
Note (8) Definition of Viewing Angle
: Viewing angle range (C/R ≥10)

9/ 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
3. Electrical Characteristics
3.1 TFT LCD Module
The connector for display data & timing signal should be connected.
Ta = 25°C±2 °C
(4)A3--IRUSH Rush Current
MHz155148.5130fDCLK
Main Frequency
kHz7567.550fH
Hsync Frequency
Hz636047fV
Vsync Frequency
mA-1000-(c) Mosaic
mA13001200-(b) White (2),(3)
mA-800-
IDD
(a) Black
Current
of Power
Supply
(1)V131211VDD
Voltage of Power Supply
NoteUnitMax.Typ.Min.SymbolItem
Note (1) The ripple voltage should be controlled under 10% of VDD.
(2) fV=60Hz, fDCLK = 148.5MHz, VDD = 12.0V, DC Current.
(3) Power dissipation check pattern (LCD Module only)
a) Black Pattern b) White Pattern c) Mosaic
(4) Measurement Conditions
Rush Current IRUSH can be measured when TRUSH. is 1ms.
TRUSH=1ms
100%
GND
90%
10%
VDD

10 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
3.2 Back Light Unit
The back light unit contains 24 CCFTs ( Cold Cathode Fluorescent Tube ).
The characteristics of lamps are shown in the following tables. Ta=25 ±2°C
(1)Hour--30,000HrOperating Life Time
NoteUnitMax.Typ.Min.SymbolItem
Note (1) It is defined as the time to take until the brightness reduces to 50% of its original value.
[Operating condition : Ta = 25±2℃, IL=6.5mArms(typ.), For single lamp only. ]
LCD
Module
Socket
Balance
Board
HOT 1
HOT 2
HOT 23
HOT 24
Balance
Board
HOT 24
HOT 23
HOT 2
HOT 1
Socket

11 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
4. Block Diagram
CONTROL PCB
CONTROL
DATA
VIN(12.0V)
AVDD
Von/Voff
VCOM
ΥVoltage
VCC(1.8V)
SOURCE
PCB
FPC
DATA Dr.IC
(720CH)X4
DATA Dr.IC
(720CH)X4
DATA Dr.IC
(720CH)X4
DATA Dr.IC
(720CH)X4
460HT PANEL
1920 x 1080 x RGB
GATE Dr. IC
(540CH)X4
GATE Dr. IC
(540CH)X4
SOURCE
PCB
FPC
USER CONNECTOR
USER CONNECTOR
VCOM-GEN
R-STRING +FB
VCOM-GEN
R-STRING +FB
SSC
SSC
DCC MEMORY
DCC MEMORY
GAMMA GEN
GAMMA GEN
T-Con
LVDS + mini
LVDS
T-Con
LVDS + mini
LVDS
GATE Dr. IC
(540CH)X4
GATE Dr. IC
(540CH)X4
VCC(3.3V)
DC/DC CONVERTER
DC/DC CONVERTER
DC/DC CONVERTER
DC/DC CONVERTER
Von/off GEN
Von/off GEN

12 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5. Input Terminal Pin Assignment
5.1. Input Signal & Power Connector : FI_R51S_HF ( JAE )
■ACC SEL - HIGH : ACC OFF LOW/OPEN : ACC ON
■B-INT : I2C BUS RELEASE
USER CAN ACCESS EEPROMH
SDA/SCL LINE BECOME HI-ZL/OPEN
DCC Select Bit
SEC Internal Use Only
N.C.
Odd LVDS Signal +
Odd LVDS Signal -
Even LVDS Signal +
Even LVDS Signal -
T-Con Ready Check
DCC Look-up
Table Select
N.C.
ACC On/Off
Bus Release
I2C SDA
I2C SCL
GND
Even LVDS Signal +
Even LVDS Signal -
GND
Even LVDS Clock+
Even LVDS Clock-
GND
Even LVDS Signal +
Even LVDS Signal -
Even LVDS Signal +
Even LVDS Signal -
Even LVDS Signal +
Description
Even LVDS Signal -
GND
Odd LVDS Signal +
Odd LVDS Signal -
GND
Odd LVDS CLK +
Odd LVDS CLK -
GND
Odd LVDS Signal +
Odd LVDS Signal -
Odd LVDS Signal +
Odd LVDS Signal -
Odd LVDS Signal +
Odd LVDS Signal -
GND
GND
GND
N.C.
VDD
VDD
VDD
VDD
VDD
Description
LUT SEL249GND24
T-Con Ready50RE[0]N25
DCC SEL46RO[3]P21
LUT SEL047RO[4]N22
LUT SEL148RO[4]P23
ACC SEL44GND19
N.C45RO[3]N20
RE[4]P38RO[1]P13
GND39RO[2]N14
SCL40RO[2]P15
SDA41GND16
SEL151
B-INT43ROCLK+18
N.C42ROCLK-17
RE[4]N37RO[1]N12
RE[3]P36RO[0]P11
RE[3]N35RO[0]N10
GND34GND9
RECLK+33GND8
RECLK-32GND7
GND31N.C.6
RE[2]P30Power5
RE[2]N29Power4
RE[1]P28Power3
RE[1]N27Power2
RE[0]P26
Power1
SignalPIN No.SignalPIN No.

13 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
■DCC SELECTION
■DCC Look Up Table Selection
50Hz*50%
-
50Hz*175%
-
60Hz*50%
-
60Hz*175%
1
0
1
0
1
0
1
0
47
1
1
0
0
1
1
0
0
4849
1
1
1
1
0
0
0
-0
Select
bit
DescriptionPin N.O.
■TCON Ready
Error OperationHigh ÆLow
Normal OperationLow ÆHigh
DescriptionOperation
H
L/OPEN
DCC 1.5 Off
DCC 1.5 On
Select Bit

14 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
Note(1) Pin number starts from Right side
Pin No. 1 Pin No. 51
▼PCB
a. All GND pins should be connected together and also be connected to the LCD’s
metal chassis.
b. All power input pins should be connected together.
c. All NC pins should be separated from other signal or power.
Fig. Connector diagram
#1
connect name
#51
#1 #51

15 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5.2. Balance Board
5.2.1 Recommended Operation Condition
Vrms--4200HVSTRIKE
Striking
Voltage (1)
Bright Control
%
100-20DPWM
Dim Duty
Ratio
Hz170160150FDIM
Dimming
Frequency
Switching
Frequency
kHz625553FOP
Inverter
Frequency
Max.Typ.Min. RemarkNoteUnit
Recommendation
SymbolItem
Note Asymmetric ratio of Total Input Current must be less than 10 % ( | IP–I
-P | / ( Irms@T < 0.1)
Crest factor must be from 90 % to 110 % ( 0.9 < IP/ Irms@T/2 X √2< 1.1)
(1) Striking Voltage( HVSTRIKE ) based on CCFL spec. for ambient temperature.
Soft rising time must be
- at starting time Tsoft > 300msec
- at PWM dimming condition Trise < 100usec

16 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5.2.2 Balance Board Input Pin Configuration
1. HV Input Connector : MD51SU-2P-13V(Hirose)
Power Supply for CCFLHV22
Power Supply for CCFLHV11
REMARKSYMBOLPIN NO.
2. Feed Back Interface : KN30-7P-1.25H(Hirose)
Lamp DetectionLD4,5,6,7
GNDGND3
Feed BackFB2
12VVcc1
REMARKSYMBOLPIN NO.
3. HV Input Connector : BM03-XASS-TF(LF)(SN)(JST)
Power Supply for CCFLHV13
NCNC2
Power Supply for CCFLHV11
REMARKSYMBOLPIN NO.
4. HV Input Connector : BM04B-XASS-TF(LF)(SN)(JST)
NCNC4
Power Supply for CCFLHV23
NCNC2
Power Supply for CCFLHV21
REMARKSYMBOLPIN NO.

17 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5.2.3 Feedback I/O Specification
Low
(LD)
High
(Normal)
1--
@Vcc = 12 [V]V
--Vcc-1
VLD
Lamp
Detection
at Recommended
Load Condition
mA20--IOC
Input current
Of Vcc
LampV151211VCC
Supply Voltage
Max.Typ.Min. REMARKSUNIT
Recommendation
SYMBOLITEM
5. Left Right Interface Connector : KN30-10P-1.25H (Hirose)
7,8,9,10
5,6
3,4
1,2
RightLeft
JIN Coil LoopLOOP4,3,2,1
Protect InterfacePROT6,5,
12VVCC8,7
GroundGND10,9
REMARKSYMBOLPIN NO.

18 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5.3 LVDS Interface
RESERVED
B1
B0
G1
G0
R1
R0
RESERVED
B3
B2
G3
G2
R3
R2
DEN
VSYNC
HSYNC
B9
B8
B7
B6
B5
B4
G9
G8
G7
G6
G5
G4
R9
R8
R7
R6
R5
R4
Even Data
RESERVEDTxIN/RxOUT34
B1TxIN/RxOUT33
B0TxIN/RxOUT32
G1TxIN/RxOUT31
G0TxIN/RxOUT30
R1TxIN/RxOUT29
R0TxIN/RxOUT28
TxOUT/RxIN4
RESERVEDTxIN/RxOUT23
B3TxIN/RxOUT17
B2TxIN/RxOUT16
G3TxIN/RxOUT11
G2TxIN/RxOUT10
R3TxIN/RxOUT5
R2TxIN/RxOUT27
TxOUT/RxIN3
DENTxIN/RxOUT26
VSYNCTxIN/RxOUT25
HSYNCTxIN/RxOUT24
B9TxIN/RxOUT22
B8TxIN/RxOUT21
B7TxIN/RxOUT20
B6TxIN/RxOUT19
TxOUT/RxIN2
B5TxIN/RxOUT18
B4TxIN/RxOUT15
G9TxIN/RxOUT14
G8TxIN/RxOUT13
G7TxIN/RxOUT12
G6TxIN/RxOUT9
G5TxIN/RxOUT8
TxOUT/RxIN1
G4TxIN/RxOUT7
R9TxIN/RxOUT6
R8TxIN/RxOUT4
R7TxIN/RxOUT3
R6TxIN/RxOUT2
R5TxIN/RxOUT1
R4TxIN/RxOUT0
TxOUT/RxIN0
Odd DataLVDS pin

19 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color
Note) Definition of Gray :
Rn : Red Gray, Gn : Green Gray, Bn : Blue Gray (n = Gray level)
Input Signal : 0 = Low level voltage, 1 = High level voltage
COLOR DISPLAY
DATA SIGNAL GRAY
SCALE
LEVEL
RED GREEN BLUE
R
0
R
1
R
2
R
3
R
4
R
5
R
6
R
7
R
8
R
9
G
0
G
1
G
2
G
3
G
4
G
5
G
6
G
7
G
8
G
9
B
0
B
1
B
2
B
3
B
4
B
5
B
6
B
7
B
8
B
9
BASIC
COLOR
BLACK 000000000000000000000000000000 -
BLUE 000000000000000000001111111111 -
GREEN 000000000011111111110000000000 -
CYAN 000000000011111111111111111111
RED 111111111100000000000000000000 -
MAGENTA 111111111100000000001111111111 -
YELLOW 111111111111111111110000000000 -
WHITE 111111111111111111111111111111 -
GRAY
SCALE
OF
RED
BLACK 000000000000000000000000000000 R0
DARK
↑
↓
LIGHT
100000000000000000000000000000 R1
010000000000000000000000000000 R2
::::::::::::::::::::::::::::::R3~R1020
::::::::::::::::::::::::::::::
1 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1021
0 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1022
RED 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1023
GRAY
SCALE
OF
GREEN
BLACK 000000000000000000000000000000 G0
DARK
↑
↓
LIGHT
000000000010000000000000000000 G1
000000000001000000000000000000 G2
::::::::::::::::::::::::::::::
G3~G1020
::::::::::::::::::::::::::::::
000000000010111111110000000000 G1021
000000000001111111110000000000 G1022
GREEN 000000000011111111110000000000 G1023
GRAY
SCALE
OF
BLUE
BLACK 000000000000000000000000000000 B0
DARK
↑
↓
LIGHT
000000000000000000001000000000 B1
000000000000000000000100000000 B2
::::::::::::::::::::::::::::::B3~B1020
::::::::::::::::::::::::::::::
000000000000000000001011111111 B1021
000000000000000000000111111111 B1022
BLUE 000000000000000000001111111111 B1023

20 / 31Page05-000-S-070907Doc. NoLTY[Z]460HB01MODEL
6. Interface Timing
6.1 Timing Parameters ( DE only mode )
-clocks245022002154TH
Horizontal
Total
-clocks-1920-THD
Active
Display
Period
Horizontal
Display Term
-Lines148011251100TVB
Vertical
Total
-lines-1080-TVD
Active
Display
Period
Vertical
Display Term
-Hz636047FV Vsync
-KHz7567.550FH Hsync
-MHz155148.51301/TC
Frequency
Clock
NOTEUnitMAX.TYP.MIN.SYMBOLITEMSIGNAL
Note) This product is DE only mode. The input of Hsync & Vsync signal does
not have an effect on normal operation.
(1) Test Point : TTL control signal and CLK at LVDS Tx input terminal in system
(2) Internal VDD = 3.3V
