Installation Guide
ML-85G/85G plus
P/N. JC68-60945A
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ2

Contents
Installing the Toner Cartridge ..... .... .... .... .... . 1
Supplying Paper ..... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .2
Connecting Computer and Power Cables. ... . ... . ... .... ... . ..3
Installing Printer Driver and Printing . ... ... . ... ... . ... ... . ... ... 4
Before using
Driver
Setup Printing (Windows®95) . ............ 5
Installing Driver .............................................. 5
Setting as Default Printer ................................................7
Printing .........................................................................8
Uninstalling Drivers ........................................................9
Printing (Windows 3.x)............ 10
Installing Driver ............................................ 10
Setting as Default Printer .............................................. 12
Printing ........................................................................ 13
Uninstalling Drivers ...................................................... 14
Printing to a Network Printer ... 15
Setting up a Host PC .................................... 15
Setting up WPS Driver onto the Client PC ...................... 17
Client PC Sharing Setup ............................................... 18
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ4

1
Installing the Toner Cartridge
- Remove contents and packing material.
1 2 3
Place the cartridge on a
stable surface, then pull out
the tape attached to top of
cartridge, as shown.
•Place a protective sheet of paper
underneath the cartridge, in case of
toner leakage.
•Be careful not to tear the tape while
removing.
•Be careful not to spill toner
material when removing the
tape.
•Follow the above steps to install the
toner cartridge.
•Rock the toner cartridge to distribute
toner material evenly, as shown
below:
•Close the cover by pressing down
until it clicks.
Open the Top Cover by
pressing the release button. Insert the cartridge and close the cover.
Supplying the Paper
1 2 3
Remove the sealing tapes
and slide out the Paper
Cassette.
•Refer to page 4-1 in Operator’s Guide to
set the paper size.
•Insert the corner of the paper stack
under metal tab (A).
Place blank paper into the
Cassette. Push the Cassette back into place.
2
Note
A
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ6

From this point forward, you will be guided through driver
installation and printing documents.
The setup program is compatible with Windows 3.x and
Windows 95.
This Installation Guide describes only setup and printing
examples. To learn more details about the product, read
the Operator’s Guide supplied with the printer.
System Requirement
(Note that the ML-85G/85G plus printer does not support
switchbox connections.)
- IBM or compatible with 386 or higher processor
- Free disk space of at least 4Mb
- More than 8Mb RAM memory (16Mb recommended,
and note print speed will increase as system memory is
increased.)
Before Installation
Remove all other printer drivers before running Setup
program, or change the printer ports to ‘FILE’.
If not, printing operation may fail.
3
Connecting Computer
and Power Cables
- Be sure to remove power from both computer and printer.
1
Connect printer to computer.
•A printer cable is not included with the printer, and must be supplied by the
user.
•For best performance, use a good quality shielded cable with
IEEE 1284-compatible pin configuration (Centronics).
At temperatures below 50˚F (10˚C), apply
printer power at least an hour before
using.
•This will help maintain print quality.
• In winter time, it is recommended to keep
printer on (Power Save mode).
Installing Printer Driver and
Printing
4
2
Plug in the power cord.
• Note that this printer does not
have a power switch. It will
automatically shut off after a
period of non-use.
Note
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ8

5
Printing (Windows 95)
Installing driver
1 2
When Windows 95 senses the
printer and alerts you with the
message below, click OK.
Turn on printer and computer.
• If no message appears: Select Run under Start
menu and type a:\setup (or b:\setup) on the
command line, then press Enter.
Insert diskette #1 into the floppy
drive and click OK.
5 6
Setup resumes the
installation. When installation is complete, click Finish.
3 4
Type your name and company
•The information is the same as entered when
Windows 95 was installed. Change and/or
click Next if correct.
If the below message appears
during installation, insert next
diskette and click OK.
• Setup exits and Windows 95 restarts.
6
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ10

7 8
Printing (Windows 95)
Setting as default printer Printing (Windows 95) Printing
1 2
Select Printers under Settings
in Start menu. Double-click the ML-85G/85G plus icon.
3
Select Set As Default. A
check mark will confirm the
selection next time you open
the Printer menu.
1 2
Open the file you want to
print.
The following sample instructions show how to print
using Microsoft®Word.
Select Print in File menu.
3
Enter the number of copies
and pages to print, and
click OK.If printing fails, there may be a
problem with the
PC CMOS setup.
To solve this problem:
- Uninstall the previous printer
driver (see next page), then
re-install it. If set to output
only, printing may fail.
- Reboot your PC, run CMOS
setup, and set the LPT mode to
bi-directional.
Set as default printer.
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ12

9
Printing (Windows 3.x)
Installing driver
10
Windows 95
Uninstalling driver
1 2
Select ML-85G&85G plus
uninstaller.Click Yes.
3
Uninstaller removes printer
driver program, and restarts
Windows 95.
1 2
Insert diskette #1 into the
drive. Select Run from the Program Manager File menu.
4
Type your name and company
name, and click Next.
•The information is the same as entered when
Windows was installed. Chanhe and/or click
Next if correct.
3
Type a:\setup (or b:\setup) on
the command line, then
click OK.
Turn on printer and computer.
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ14

11 12
Printing (Windows 3.x)
Installing driver Printing (Windows 3.x) Setting as default printer
5 6
When the following message
appears, insert the next
diskette and click OK.
• Setup exits, and Windows restarts.
Setup resumes the
installation.
7
When installation is
complete, click Finish.
1 2
Double-click the Printers icon
in Control Panel. Select ML-85G/85G plus, click Set As Default Printer, then
Close.
Set as default
printer.
01ML-85G/85G 99.2.18 12:2 PM ∆‰¿Ã¡ˆ16

13 14
Printing (Windows 3.x)
Printing Windows 3.x Uninstalling driver
1 2
Open a file to print.
The following sample instructions show how to
print using the Microsoft®Word application.
Select Print from the
File menu.
If printing fails, reboot your PC,
and run CMOS setup to set the
LPT mode to bi-directional. If set
to output only, printing may fail.
Uninstall the previous printer driver
(see next page), then re-install it.
3
Enter the number of
copies and pages to print,
then click OK.
1 2
Open Program Manager and
double-click the ML-85G/85G
plus uninstaller.
Click Yes.
3
Uninstaller removes printer
driver program and restarts
Windows.
02ML-85G/85G 99.2.18 12:6 PM ∆‰¿Ã¡ˆ2

15
Printing on a network printer
Setting up a Host PC printer
1
Install the print driver before
setting up sharing.
See pages 5 through 14
for instructions on
installing drivers.
Click Start menu, select Control
Panel, and double-click the
Network icon.
5
Click the Sharing tab, check
Shared As, fill in the Shared
Name field, and click OK.
4
Select Properties in Printer
menu.
2 3
Click File and Print Sharing,
check box(es), then click OK.Click Start menu and select
Printers in Settings, then double-
click the ML-85G/85G plus.
Finish
16
02ML-85G/85G 99.2.18 12:6 PM ∆‰¿Ã¡ˆ4

17
Printing on a network printer
Installing driver onto a client PC
Printing on a network printer
Client PC Sharing setup
Before setting up sharing, printer driver should be installed.
See pages 5 through 14.
1 2
Click Start menu, select Control
Panel, then double-click Printer.Double-click ML-85G/85G plus, then choose Properties
from the Printer menu.
1 2
Click Add Port in Details
section. Click Browse, select your
printer’s name, then click OK.
18
Finish
