Samsung ProXpress M4030 Series User manual

MonoLaserPrinter
ProXpressM4030series
SL-M4030ND
(Ver1.00)
SERVICEMANUAL
MonoLaserPrinterContents
1.Precautions
2.ProductSpecicationsandDescription
3.DisassemblyandReassembly
4.Troubleshooting
5.SystemDiagram
6.ReferenceInformation
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precautions......................................................................................................................................1−1
1.1.Safetywarning........................................................................................................................1−1
1.2.Cautionforsafety....................................................................................................................1−2
1.2.1.Toxicmaterial.............................................................................................................1−2
1.2.2.Electricshockandresafetyprecautions.........................................................................1−2
1.2.3.Handlingprecautions...................................................................................................1−4
1.2.4.AssemblyandDisassemblyprecautions...........................................................................1−4
1.2.5.Disregardingthiswarningmaycausebodilyinjury............................................................1−5
1.3.ESDprecautions......................................................................................................................1−6
2.ProductSpecicationsandDescription..................................................................................................2−1
2.1.ProductOverview....................................................................................................................2−1
2.2.Specications..........................................................................................................................2−2
2.2.1.General.....................................................................................................................2−2
2.2.2.Printspecication........................................................................................................2−4
2.2.3.PaperHandlingspecication..........................................................................................2−5
2.2.4.SoftwareandSolution..................................................................................................2−7
2.2.5.Supplies.....................................................................................................................2−8
2.2.6.MaintenancePart.........................................................................................................2−8
2.2.7.Option.......................................................................................................................2−9
2.3.SystemConguration...............................................................................................................2−10
2.4.FeedingSystem.......................................................................................................................2−14
2.4.1.FeedingSystemOverview.............................................................................................2−14
2.4.2.Cassette.....................................................................................................................2−17
2.4.3.Pick-UpUnit..............................................................................................................2−18
2.4.4.MPF(Multi-PurposeFeeder)Unit...................................................................................2−18
2.5.ImageCreation........................................................................................................................2−19
2.5.1.Printingprocessoverview.............................................................................................2−19
2.5.2.TonerCartridge...........................................................................................................2−20
2.6.Fuserunit...............................................................................................................................2−21
2.7.LaserScanningUnit(LSU)........................................................................................................2−22
2.7.1.LaserScanningUnitOverview.......................................................................................2−22
2.7.2.LaserScanningOpticalpath..........................................................................................2−23
2.8.DriveSystem..........................................................................................................................2−24
2.8.1.DriveMotors..............................................................................................................2−24
2.8.2.MainDriveUnit..........................................................................................................2−25
2.8.3.ExitDriveUnit...........................................................................................................2−26
2.8.4.TrayLiftingDriveUnit.................................................................................................2−27
2.9.HardwareConguration............................................................................................................2−28
iCopyright©1995-2017SAMSUNG.Allrightsreserved.

Contents
2.9.1.Mainboard.................................................................................................................2−30
2.9.2.OPE..........................................................................................................................2−31
2.9.3.SO-DIMMPBA..........................................................................................................2−33
2.9.4.CRUMPBA...............................................................................................................2−33
2.9.5.SCFboard..................................................................................................................2−34
2.9.6.NFCOptionalBoard(SL-NWE001X).............................................................................2−35
2.9.7.SMPSboard...............................................................................................................2−36
2.9.8.HVPSboard...............................................................................................................2−38
2.9.9.ElectricalPartsLocation...............................................................................................2−40
3.DisassemblyandReassembly..............................................................................................................3−1
3.1.Precautionswhenreplacingparts................................................................................................3−1
3.1.1.Precautionswhenassemblinganddisassembling...............................................................3−1
3.1.2.PrecautionswhenhandlingPBA.....................................................................................3−1
3.1.3.ReleasingPlasticLatches..............................................................................................3−2
3.2.Replacingthemaintenancepart..................................................................................................3−3
3.2.1.FuserUnit..................................................................................................................3−3
3.2.2.TransferRoller............................................................................................................3−5
3.2.3.SeparationRoller.........................................................................................................3−6
3.2.4.Pick-upRollerandForwardRoller..................................................................................3−7
3.2.5.SCFSeparationRoller..................................................................................................3−8
3.2.6.SCFPick-upRollerandForwardRoller...........................................................................3−9
3.3.ReplacingthemainSVCpart.....................................................................................................3−10
3.3.1.RightCover................................................................................................................3−10
3.3.2.LeftCover..................................................................................................................3−11
3.3.3.RearCover.................................................................................................................3−12
3.3.4.MainBoard................................................................................................................3−13
3.3.5.HVPSBoard...............................................................................................................3−14
3.3.6.SMPSBoard...............................................................................................................3−15
3.3.7.DuplexMotor.............................................................................................................3−16
3.3.8.FuserDriveUnit.........................................................................................................3−17
3.3.9.MainDriveUnit..........................................................................................................3−18
3.3.10.CST-LiftingDriveUnit.................................................................................................3−19
3.3.11.PaperSizeSensor........................................................................................................3−20
3.3.12.OPEBoard.................................................................................................................3−21
3.3.13.LSU..........................................................................................................................3−22
3.3.14.ExitUnit....................................................................................................................3−23
3.3.15.Bin-FullSensor...........................................................................................................3−24
3.3.16.MPUnit....................................................................................................................3−25
3.3.17.MPRoller..................................................................................................................3−27
3.3.18.SecondCassetteFeeder(OptionalTray)...........................................................................3−28
Copyright©1995-2017SAMSUNG.Allrightsreserved.ii

Contents
3.3.18.1.PBA-SCF....................................................................................................3−28
3.3.18.2.LiftUnit......................................................................................................3−29
3.3.18.3.Clutch.........................................................................................................3−30
3.3.18.4.DriveUnit...................................................................................................3−31
4.Troubleshooting................................................................................................................................4−1
4.1.Controlpanel..........................................................................................................................4−1
4.2.UnderstandingtheLEDs...........................................................................................................4−2
4.3.UpdatingFirmware..................................................................................................................4−3
4.3.1.UpdatethermwarebyusingtheUSBport......................................................................4−3
4.3.2.UpdatingfromtheNetwork..........................................................................................4−4
4.4.Clearingpaperjams..................................................................................................................4−8
4.5.Usefulmanagementtools..........................................................................................................4−22
4.5.1.SyncThru™WebService..............................................................................................4−22
4.5.2.SamsungEasyPrinterManager......................................................................................4−25
4.6.ServiceMode..........................................................................................................................4−27
4.7.Troubleshooting......................................................................................................................4−32
4.7.1.Procedureofcheckingthesymptoms...............................................................................4−32
4.7.2.ErrorCodeandTroubleshooting.....................................................................................4−33
4.7.2.1.11–2Txx(PaperMismatcherror)......................................................................4−37
4.7.2.2.Ax-xxxx(Motor_Fan_Sensorerror)..................................................................4−38
4.7.2.3.Cx-xxxx(TonerCartridgeerror).......................................................................4−41
4.7.2.4.H1-xxxx(OptionalCassetteerror)....................................................................4−44
4.7.2.5.Mx-xxxx(Jam_Paperhandlingerror)................................................................4−55
4.7.2.6.Sx-xxxx(Systemerror)..................................................................................4−62
4.7.2.7.U1-xxxx(Fusererror)....................................................................................4−67
4.7.2.8.U2-xxxxtype(LSU)errorcode........................................................................4−68
4.7.3.Imagequalityproblem..................................................................................................4−69
4.7.4.Othererrors................................................................................................................4−83
5.SystemDiagram................................................................................................................................5−1
5.1.BlockDiagram........................................................................................................................5−1
5.2.ConnectionDiagram.................................................................................................................5−2
6.ReferenceInformation........................................................................................................................6−1
6.1.ToolforTroubleshooting...........................................................................................................6−1
6.2.Glossary.................................................................................................................................6−2
6.3.TheSamplePatternfortheTest..................................................................................................6−8
6.4.ModelNameandCode.............................................................................................................6−9
6.5.DocumentRevisionList............................................................................................................6−10
iiiCopyright©1995-2017SAMSUNG.Allrightsreserved.

1.Precautions
1.Precautions
Inordertopreventaccidentsanddamagestotheequipmentpleasereadtheprecautionslistedbelowcarefullybefore
servicingtheproductandfollowthemclosely.
1.1.Safetywarning
1)Onlytobeservicedbyafactorytrainedservicetechnician.
Highvoltagesandlasersinsidethisproductaredangerous.Thisproductshouldonlybeservicedbyafactorytrained
servicetechnician.
2)UseonlySamsungreplacementparts.
Therearenouserserviceablepartsinsidetheproduct.Donotmakeanyunauthorizedchangesoradditionstothe
productasthesecouldcausetheproducttomalfunctionsandcreateanelectricshocksorrehazards.
3)LaserSafetyStatement
TheprinteriscertiedintheU.S.toconformtotherequirementsofDHHS21CFR,chapter1SubchapterJfor
ClassI(1)laserproducts,andelsewhereiscertiedasaClassIlaserproductconformingtotherequirementsof
IEC/EN60825-1:2014.ClassIlaserproductsarenotconsideredtobehazardous.Thelasersystemandprinterare
designedsothereisneveranyhumanaccesstolaserradiationaboveaClassIlevelduringnormaloperation,user
maintenanceorprescribedservicecondition.
•Wavelength:800nm
•Beamdivergence
-Parallel:11degrees
-Perpendicular:35degrees
•Maximumpowerofenergyoutput:12mW
WARNING
NeveroperateorservicetheproductwiththeprotectivecoverremovedfromLaser/Scannerassembly.Thereected
beam,althoughinvisible,candamageyoureyes.
Whenusingthisproduct,thesebasicsafetyprecautionsshouldalwaysbefollowedtoreduceriskofre,electric
shock,andpersonalinjury.
4)Lithiumbatterynotreplaceablebyuser
Copyright©1995-2017SAMSUNG.Allrightsreserved.1-1

1.Precautions
1.2.Cautionforsafety
1.2.1.Toxicmaterial
Thisproductcontainstoxicmaterialsthatcouldcauseillnessifingested.
1)Pleasekeepimagingunitandtonercartridgeawayfromchildren.Thetonerpowdercontainedintheimagingunitand
tonercartridgemaybeharmful,andifswallowed,youshouldcontactadoctor.
1.2.2.Electricshockandresafetyprecautions
Failuretofollowthefollowinginstructionscouldcauseelectricshockorpotentiallycauseare.
1)Useonlythecorrectvoltage,failuretodosocoulddamagetheproductandpotentiallycauseareorelectricshock.
2)Useonlythepowercablesuppliedwiththeproduct.Useofanincorrectlyspeciedcablecouldcausethecableto
overheatandpotentiallycauseare.
3)Donotoverloadthepowersocket,thiscouldleadtooverheatingofthecablesinsidethewallandcouldleadtoare.
4)Donotallowwaterorotherliquidstospillintotheproduct,thiscancauseelectricshock.Donotallowpaperclips,pins
orotherforeignobjectstofallintotheproduct,thesecouldcauseashortcircuitleadingtoanelectricshockorrehazard.
5)Nevertouchtheplugsoneitherendofthepowercablewithwethands,thiscancauseelectricshock.Whenservicing
theproduct,removethepowerplugfromthewallsocket.
6)Usecautionwheninsertingorremovingthepowercord.Whenremovingthepowercord,gripitrmlyandpull.The
powercordmustbeinsertedcompletely,otherwiseapoorcontactcouldcauseoverheatingleadingtoare.
7)Takecareofthepowercable.Donotallowittobecometwisted,bentsharplyaroundcornersorpowercablemaybe
damaged.Donotplaceobjectsontopofthepowercable.Ifthepowercableisdamageditcouldoverheatandcausea
re.Exposedcablescouldcauseanelectricshock.Replacethedamagedpowercableimmediately,donotreuseor
repairthedamagedcable.Somechemicalscanattackthecoatingonthepowercable,weakeningthecoverorexposing
cablescausingreandshockrisks.
1-2Copyright©1995-2017SAMSUNG.Allrightsreserved.

1.Precautions
8)Ensurethatthepowersocketsandplugsarenotcrackedorbrokeninanyway.Anysuchdefectsshouldberepaired
immediately.Takecarenottocutordamagethepowercableorplugswhenmovingthemachine.
9)Usecautionduringthunderorlightningstorms.Samsungrecommendsthatthismachinebedisconnectedfromthe
powersourcewhensuchweatherconditionsareexpected.Donottouchthemachineorthepowercordifitisstill
connectedtothewallsocketintheseweatherconditions.
10)Avoiddampordustyareas,installtheproductinacleanwellventilatedlocation.Donotpositionthemachineneara
humidierorinfrontofanairconditioner.Moistureanddustbuiltupinsidethemachinecanleadtooverheatingand
causeareorcausepartstorust.
11)Donotpositiontheproductindirectsunlight.Thiswillcausethetemperatureinsidetheproducttorisepossiblyleading
totheproductfailingtoworkproperlyandinextremeconditionscouldleadtoare.
12)Donotinsertanymetalobjectsintothemachinethroughtheventilatorfanorotherpartofthecasing,itcouldmake
contactwithahighvoltageconductorinsidethemachineandcauseanelectricshock.
13)WhenreplacingtheSMPSboard,pleasewait5minutesafterunpluggingthepowercord,thenreplaceit.You
cangetashockbytheelectricdischarge.
Copyright©1995-2017SAMSUNG.Allrightsreserved.1-3

1.Precautions
1.2.3.Handlingprecautions
Thefollowinginstructionsareforyourownpersonalsafetytoavoidinjuryandsoasnottodamagetheproduct.
1)Ensuretheproductisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcause
theproducttotiporfall.
2)Theproductcontainsmanyrollers,gearsandfans.Takegreatcaretoensurethatyoudonotcatchyourngers,hairor
clothinginanyoftheserotatingdevices.
3)Donotplaceanysmallmetalobjects,containersofwater,chemicalsorotherliquidsclosetotheproductwhichifspilled
couldgetintothemachineandcausedamageorashockorrehazard.
4)Donotinstallthemachineinareaswithhighdustormoisturelevels,besideonopenwindoworclosetoahumidieror
heater.Damagecouldbecausedtotheproductinsuchareas.
5)Donotplacecandles,burningcigarettes,etcontheproduct,Thesecouldcauseare.
6)Ensurethatthemachineisinstalledandusedinproperareatomeetthetemperatureandhumidityspecications.
•IfthemachineisstoredatbelowzeroCelsiusforalongtime,donotusethemachineinstantlyaftermovement.It
canmalfunction.Takecareofthemachinestorage.IfthemachineisstoredatbelowzeroCelsiusforalongtime,
keepthemachineatroomtemperatureandinstallit.
1.2.4.AssemblyandDisassemblyprecautions
1)ReplacepartscarefullyandalwaysuseSamsungparts.Takecaretonotetheexactlocationofpartsandalsocable
routingbeforedismantlinganypartofthemachine.Ensureallpartsandcablesarereplacedcorrectly.Pleasecarryout
thefollowingproceduresbeforedismantlingtheproductorreplacinganyparts.
2)Ensurethatpowerisdisconnectedbeforeservicingorreplacinganyelectricalparts.
3)Disconnectinterfacecablesandpowercables.
4)Onlyuseapprovedspareparts.Ensurethatpartnumber,productname,anyvoltage,currentortemperaturerating
arecorrect.
5)Whenremovingorre-ttinganypartsdonotuseexcessiveforce,especiallywhenttingscrewsintoplastic.
6)Takecarenottodropanysmallpartsintothemachine.
7)HandlingoftheOPCDrum
•TheOPCDrumcanbeirreparablydamagedifitexposedtolight.TakecarenottoexposetheOPCDrumeither
todirectsunlightortouorescentorincandescentroomlighting.Exposureforaslittleas5minutescandamage
thesurfaceofthephotoconductivepropertiesandwillresultinprintqualitydegradation.Takeextracarewhen
servicingtheproduct.RemovetheOPCDrumandstoreitinablackbagorotherlightproofcontainer.Take
carewhenworkingwiththeCovers(especiallythetopcover)openaslightisadmittedtotheOPCareaandcan
damagetheOPCDrum.
•TakecarenottoscratchthegreensurfaceofOPCDrumUnit.IfthegreensurfaceoftheDrumCartridgeis
scratchedortouchedtheprintqualitywillbecompromised.
1-4Copyright©1995-2017SAMSUNG.Allrightsreserved.

1.Precautions
1.2.5.Disregardingthiswarningmaycausebodilyinjury
1)Becarefulwiththehightemperaturepart.
Thefuserunitworksatahightemperature.Usecautionwhenworkingontheprinter.Waitforthefuserunitto
cooldownbeforedisassembly.
2)Donotputngersorhairintotherotatingparts.
Whenoperatingaprinter,donotputhandorhairintotherotatingparts(Paperfeedingentrance,motor,fan,etc.).
Ifdo,youcangetharm.
3)Whenyoumovetheprinter,usesafeliftingandhandlingtechniques.
Thisprinterisheavy.Usetheliftinghandleslocatedoneachsideofthemachine.Backinjurycouldbecausedif
youdonotliftcarefully.
4)Ensuretheprinterisinstalledsafely.
Ensuretheprinterisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcausethe
printertotiporfallpossiblycausingpersonalinjuryordamagingtheprinter.
5)Donotinstalltheprinteronaslopingorunstablesurface.Afterinstallation,doublecheckthattheprinterisstable.
Copyright©1995-2017SAMSUNG.Allrightsreserved.1-5

1.Precautions
1.3.ESDprecautions
Certainsemiconductordevicescanbeeasilydamagedbystaticelectricity.Suchcomponentsarecommonlycalled
“ElectrostaticallySensitive(ES)Devices”orESDs.ExamplesoftypicalESDsare:integratedcircuits,someeldeffect
transistors,andsemiconductor“chip”components.Thetechniquesoutlinedbelowshouldbefollowedtohelpreducethe
incidenceofcomponentdamagecausedbystaticelectricity.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
1)Immediatelybeforehandlingasemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,employacommerciallyavailable
wriststrapdevice,whichshouldberemovedforyourpersonalsafetyreasonspriortoapplyingpowertotheunit
undertest.
2)AfterremovinganelectricalassemblyequippedwithESDs,placetheassemblyonaconductivesurface,suchas
aluminumorcopperfoil,orconductivefoam,topreventelectrostaticchargebuildupinthevicinityoftheassembly.
3)UseonlyagroundedtipsolderingirontosolderordesolderESDs.
4)Useonlyan“anti-static”solderremovaldevice.Somesolderremovaldevicesnotclassiedas“anti-static”can
generateelectricalchargessufcienttodamageESDs.
5)DonotuseFreon-propelledchemicals.Whensprayed,thesecangenerateelectricalchargessufcienttodamageESDs.
6)DonotremoveareplacementESDfromitsprotectivepackaginguntilimmediatelybeforeinstallingit.Most
replacementESDsarepackagedwithallleadsshortedtogetherbyconductivefoam,aluminumfoil,oracomparable
conductivematerial.
7)ImmediatelybeforeremovingtheprotectiveshortingmaterialfromtheleadsofareplacementESD,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
8)MaintaincontinuouselectricalcontactbetweentheESDandtheassemblyintowhichitwillbeinstalled,until
completelypluggedorsolderedintothecircuit.
9)MinimizebodilymotionswhenhandlingunpackagedreplacementESDs.Normalmotions,suchasthebrushingtogether
ofclothingfabricandliftingone’sfootfromacarpetedoor,cangeneratestaticelectricitysufcienttodamageanESD.
1-6Copyright©1995-2017SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.ProductSpecicationsandDescription
2.1.ProductOverview
1)Speed
•Upto40ppminA4(42ppminLetter)
2)Processor
•DualCore1GHz
3)Memory(Std/Max)
•256MB/2GB
4)Interfaces
•High-SpeedUSB2.0
•10/100/1000BaseTXEthernet
•4LineLCD
5)Tonercartridgeyield
•Initial:6,000pages
•Standard:10,000pages
•Highyield:20,000pages
Copyright©1995-2017SAMSUNG.Allrightsreserved.2-1

2.ProductSpecicationsandDescription
2.2.Specications
ProductSpecicationsaresubjecttochangewithoutnotice.
NOTE
Thespecicationinthismanualisthereferenceinformationforserviceengineer.Donotusethisspecicationforsales.
2.2.1.General
ItemSpecication
ProcessorCPUDualCore1GHz(C4N+A1000)
OperationalPanel4LineLCD
LED7EA(PowerKey/ECO/Status/Navigation) UserInterface
Key/Button18EA(3x4Numerickey,Power,ECO,Menu,OK,Start,Stop)
Standard256MB
MemoryMax.(Option)2GB
USB(Device)Hi-SpeedUSB2.0
USB(Host)Hi-SpeedUSB2.0
USB(EDI)Yes
WiredLANStd(Ethernet10/100/1000BaseTX)
WirelessLANOption(IEEE802.11b/g/n)
NFCOption(Active)
Interface
RJ11ConnectorYes
FromSleepLessthan16sec
WarmupTimePowerOffLessthan35sec
Operating10to30°C(50to86°F)
TemperatureStorage-20to40°C(-4to104°F)
Operating20to80%RH
HumidityStorage10to90%RH
StandbyLessthan30dB(A)
NoiseLevelPrintModeLessthan53dB(A)
ReadyLessthan50W
Normaloperation700W
Max/Peak1100W
Sleep1.21W
PowerOff0.1W
PowerConsumption
TEC1.9KWh/week
Dimension(WxDxH)421.4x405.9x351mm(16.6x16x13.8inches)
WeightMachinewithsupplies16.6kg(36.6lb)
2-2Copyright©1995-2017SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
ItemSpecication
RecommendedMonthly
PrintingV olume(AMPV)
1,500-14,000pages
Reliability&ServiceMax.MonthlyPrint
V olume
120,000pages
Copyright©1995-2017SAMSUNG.Allrightsreserved.2-3

2.ProductSpecicationsandDescription
2.2.2.Printspecication
ItemSpecication
SimplexUpto40ppminA4(42ppminLetter) PrintSpeed
DuplexUpto20ipminA4(20ipminLetter)
ReadyModeAsfastas7sec FPOT
SleepModeLessthan18.5sec
Optical(Standard)1200x600dpi Resolution
EnhancedUpto1,200x1,200dpieffectiveoutput(1,200x600x2bit)
PrinterLanguagesPCL5e/PCL6/PostScript3/PDFDirectV1.7/XPS/TIFF/URF
/PWG
PCL96ScalableFonts(IncludeOCR-A/OCR-B)/1Bitmap Font
Postscript3136ScalableFonts
WindowsWindowXP(32/64bit)/Vista(32/64bit)/2003Server(32/64bit)/
2008Server(32/64bit)/Win7(32/64bit)/2008ServerR2(64bit)/
Win8(32/64bit)/Win8.1(32bit/64bit)/2012Server(64bit)/2012
ServerR2(64bit)
Linux•RedHatEnterpriseLinux5,6,7
•Fedora13,14,15,16,17,18,19,20,21
•openSUSE11.3,11.4,12.1,12.2,12.3,13.1,13.2
•Ubuntu10.04,10.10,11.04,11.10,12.04,12.10,13.04,13.10,
14.04,14.10
•SUSELinuxEnterpriseDesktop11,12
•Debian6,7
•Mint13,14,15,16,17
UNIX•SunSolaris9,10,11(x86,SPARC)
•HP-UX11.0,11iv1,11iv2,11iv3(PA-RISC,Itanium)
•IBMAIX5.1,5.2,5.3,5.4,6.1,.7.1(PowerPC)
ClientOSSupport
MacOSMacOS:X10.6-10.10
BasicStandardTCP/IP(Raw),IPassign(DHCP ,BOOTP ,AutoIP),
HTTP,HTTPs,IPP,IPPs,WSD,SNMPv1/v2c/v3,SetIP,SLP ,DNS,
DDNS,Bongjour,WINS,LPD/LPR,ThinPrint,GoogleCloudPrint,
SMTP,SMTPs,UPnP ,LDAP,Kerberos,SMB,IPSec,802.1x
NetworkProtocol
Advanced(Wi-Fisupport:Opensystem,SharedKey,WPAPersonal,WPA2
Personal(PSK),WPAEnterprise,WPA2Enterprise,WEP64,
WEP128,TKIP,AES)
2-4Copyright©1995-2017SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.3.PaperHandlingspecication
ItemSpecication
StandardCapacity•550sheetCassetteTray@75g/m²
•100sheetMultiPurposeTray@75g/m²
Max.Capacity2850sheet(550standardcassette+100MP+4x550SCF)
Capacity550sheet@75g/m²(520sheet@80g/m²)
Mediasizes
A4/A5/A6/Letter/Legal/Ocio/Folio/JISB5/ISOB5/
Executive/Statement/PostCard4x6/EnvelopeMonarch/Envelope
No9/EnvelopeNo10/EnvelopeDL/EnvelopeC5/Envelope
C6/Custom
MediatypesPlain/Thin/Bond/Punched/Pre-Printed/Recycled/Envelope
/Label/CardStock/Letterhead/Thick/Colored/Archive/Cotton
Mediaweight
SupportedWeight:60to163g/m²(16~43lb)
•ThinPaper(60~69g/m²)
•PlainPaper(70~90g/m²)
•ThickPaper(91~105g/m²)
•BondPaper(105~120g/m²)
•Cardstock(106~163g/m²)
StandardCassetteTray
Sensing
•H/WInstallDetect:Yes
•PaperEmpty:Yes
•Paperlowleveldetect:Yes
•PaperTypeDetect:No
•PaperSizeDetect:Yes
Capacity•PlainPaper:100sheets@75g/m²
•Envelope:10sheets
MediasizesMin:76.2mmx127mm(3"x5")
Max:216mmx356mm(8.5"x14.0")
Mediatype
Plain/Thin/Bond/Pre-printed/Recycled/Envelope/Label/
Cardstock/Thick/Cotton/Colored/Archive/Thicker/Punched/
Letterhead
Mediaweight
SupportedWeight:60-220g/m²(16~59lb)
•ThinPaper(60-69g/m²)
•PlainPaper(70-90g/m²)
•ThickPaper(91-105g/m²)
•BondPaper(105-120g/m²)
•Cardstock(106-163g/m²)
•ThickerPaper(164-220g/m²)
Multi-purposetray
SensingPaperEmpty
Copyright©1995-2017SAMSUNG.Allrightsreserved.2-5

2.ProductSpecicationsandDescription
ItemSpecication
Capacity550sheet@75g/m²(520sheet@80g/m²)
Mediasizes
A4/A5/Letter/Legal/Ocio/Folio/JISB5/ISOB5/Executive
/Statement/EnvelopeNo9/EnvelopeNo10/EnvelopeDL/
EnvelopeC5/Custom
MediatypesPlain/Thin/Bond/Punched/Pre-Printed/Recycled/Envelope
/Label/CardStock/Letterhead/Thick/Colored/Archive/Cotton
Mediaweight
SupportedWeight:60-163g/m²(16-43lb)
•ThinPaper(60-69g/m²)
•PlainPaper(70-90g/m²)
•ThickPaper(91-105g/m²)
•BondPaper(105-120g/m²)
•Cardstock:(106-163g/m²)
OptionalCassetteTray
Sensing
•H/WInstallDetect:Yes
•PaperEmpty:Yes
•Paperlowleveldetect:Yes
•PaperTypeDetect:No
•PaperSizeDetect:Yes
CapacityFace-Down:250sheets@80g/m²
OutputStackingOutputFullsensingYes
Max.Size216x356mm(8.5"x14")
Min.Size76.2x127mm(3"x5") Printingsize
Margin(T/B/L/R)T/B/L/R:1mm
SupportBuilt-in
MediasizesA4/Letter/Ocio/Folio/Legal/JISB5/ISOB5/Executive/
Statement/A5
MediatypesPlain/Thin/Thick/Recycled/Bond/Pre-printed/Cotton/Colored
DuplexPrinting
Mediaweight60~120g/m²(16-32lb)
2-6Copyright©1995-2017SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.4.SoftwareandSolution
ItemSpecication
AnywebPrintN/A
EasyPrinterManagerWindows/Mac
EasyColorManagerN/A
EasyDocumentCreatorN/A
NetPCFaxN/A
DirectPrintingUtilityWindows
EasyDeployment
Manager
Windows
EasyEcoDriverWindows
Application
UniversalPrinterDriverWindows/Mac
GCP(GoogleCloudPrint)Yes
MobilePrintingAirPrintYes
DeviceManagementSyncThru
OutputManagementCounThru
DocumentManagement
andDistribution
SmarThruWorkFlow
SecuritySecuThru
Solution
MobilityAny#
Authentication(Local)Yes
Authentication(Network)Y es(Kerberos/SMB/LDAP)
IPAddressFilteringIPv4Filtering/IPv6Filtering/MACFiltering
HDDOverwrite
(Standard)
N/A
HDDOverwrite(Max.
Overwrites)
N/A
SecurePrintYes
EncryptedSecurePrintN/A
EncryptedPDFMode
(EncryptedScanning)
N/A
IPSecYes
Security
SmartCard
Authentication
N/A
Copyright©1995-2017SAMSUNG.Allrightsreserved.2-7

2.ProductSpecicationsandDescription
2.2.5.Supplies
ItemsModelNameLife
Initial-Approx.6,000pages
StandardMLT-D201SApprox.10,000pages TonerCartridge
HighYieldMLT-D201LApprox.20,000pages
NOTE
DeclaredyieldvalueinaccordancewithISO/IEC19752.Thenumberofpagesmaybeaffectedbyoperatingenvironment,
printinginterval,graphics,mediatypeandmediasize.
Dependingontheoptions,percentageofimageareaandjobmodeused,thetonercartridge’slifespanmaydiffer.
2.2.6.MaintenancePart
Someofthemachine’spartshaveshorterlifespanthanmachine’slife.
Toensurethatthemachineproducesgoodcopiesandtoextenditsservicelife,itisrecommendedthatthesemaintenance
partsatspecicintervalsbereplacedasinstructed.
ItemPartCodeLife
Pickup/Forwardroller
(forTray1)
JC93-00540B200,000pages
Separationroller
(forTray1)
JC93-00540B100,000pages
MPPickup/ForwardrollerJC90-01540A100,000pages
MPSeparationrollerJC73-00328A100,000pages
TransferrollerJC66-02842A100,000pages
FuserUnit•JC91-01023A(110V)
•JC91-01024A(220V)
90,000pages
Pickup/Forwardroller
(forOptionalTray)
JC97-02259A200,000pages
Separationroller
(forOptionalTray)
JC97-02259A100,000pages
NOTE
•Dependingontheprintpatternsandjobmodeused,thelifespanmaydiffer.
•RefertoChapter3.2.2forreplacingthemaintenanceparts.
2-8Copyright©1995-2017SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.7.Option
OptionList
ItemModelRemark
Optionaltrays(Tray2,Tray3,Tray4)SL-SCF4000550Sheets(Plainpaper75g/m²(20lb
bond))
StandSL-DSK065S-
MemorymoduleSL-MEM0012GB
Wireless/NFCkitSL-NWE001XWireless+NFC
Copyright©1995-2017SAMSUNG.Allrightsreserved.2-9

2.ProductSpecicationsandDescription
2.3.SystemConguration
1)FrontView
1Controlpanel
2Coverforoptionalmemory*
3Frontcover
4Paperlevelindicator
5Optionaltrays**
6Tray1
7Multi-purposetray
8Outputtray
9Paperwidthguidesonamulti-purposetray
10Tonercartridge
11Outputsupport
12USBmemoryport
*Openthiscovertoinstalltheoptionalmemoryandoptionaltray.
**Installtheoptionaltrayifitisnecessary.
2-10Copyright©1995-2017SAMSUNG.Allrightsreserved.
