Built for Reliability and Low-Cost Simplicity
M4530NX I M4530ND
Samsung A4 Mono Laser Printer

Elevate business with high-volume, hassle-free printing
In today’s driven marketplace, businesses must continuously
rethink and innovate their strategies to maintain a competitive
edge. Efficiency and manageability are top of mind for businesses
of all sizes, as they seek to improve their performance and their
bottom line.
Business tools, particularly printers, have emerged as a key area of
focus for improving cost efficiencies and performance. Businesses
need reliable, low-maintenance print solutions with the capacity to
handle even the most demanding print jobs. Plus, these printers
must deliver advanced functionality, such as manageability, rich
security and mobile printing, while still holding down costs.
Samsung’s flagship A4 mono laser printer
ProXpress M4530NX / M4530ND powers business with
reliable, secure performance while lowering total cost of
ownership (TCO). Its robust, hassle-free design solves common
document-handling and upkeep hassles with low maintenance
and easy manageability – musts for today’s small-to-medium
sized work groups.
Samsung ProXpress:
M4530NX
(45 ppm)
M4530ND
(45 ppm)

Store more print jobs
An impressive 320 GB standard hard disk drive (HDD)2gives you
all the space you need and more to store print jobs for pull printing.
Wirelessly print from anywhere and then, from any networked printer,
“pull” or release the print job from your virtual queue at any time.
ProXpress M4530 Series’ 320 GB of storage ensures your print job
will be safely stored and ready to pull when you are.
Boost print performance with more speed, quality and storage
Fast, high-volume print processing with zero fuss
ProXpress M4530 Series prints at fast speeds of up to 45 pages
per minute (ppm). The 1 GHz dual-core CPU provides the power
and capacity to accomplish print and copy jobs of any size or
complexity. Businesses can work smoothly and operate at a much
more efcient level with high-performance speed printing. Plus, the
1 GB standard memory1drives productivity levels with high-volume
printing and the power to handle more print jobs at once.
De-Screening
Edge Enhancement
Negative Sharpening
De-ICE
(Integrated Cavity Eect)
Reliable performance when it counts
ProXpress M4530 boasts a durable build, specially designed to cope
with the pressures of business. With a high monthly duty cycle of up
to 200,000 sheets, businesses can rest assured that ProXpress can
keep up with their print demands. And thanks to the unique anti-jam
friction roller system, M4530 signicantly reduces the occurrence
of multiple sheet pickups, misfeeds and paper jams keeping
workgroups working.
11 GHz dual-core CPU is available on M4530NX model only.
512 MHz dual-core CPU is available on M4530ND model only.
2320 GB standard HDD is available on M4530NX model only.
Storage is not available on M4530ND model.
Get sharper-quality print output
Samsung’s unique Rendering Engine for Clean Page (ReCP)
technology delivers professional-quality output with sharp text and
clean images, ensuring a perfect-looking printout every time. And
with a superior resolution of 1,200 x 1,200 effective dpi, both your
printouts and company will always look polished.

Efcient consumables for high-yield productivity
Businesses can handle heavy printing volumes while reducing
labour costs with ProXpress M4530 Series’ ultra-high-yield toner
cartridges and drums. Flexible options range from toners that yield
40,000 standard black and white pages, while drums yield 100,000
standard black and white pages. These long-life consumables
ensure businesses get the most out of their resources, resulting
in lower TCO.
Toner and paper savings at your ngertips
Lower toner and paper usage are just a touch away with the One
Touch Eco Button. With a push of a button, businesses can activate
instant savings with 2-up printing (two pages on the same side) and
duplex printing (printing on both sides). The savings continue with the
option to skip blank pages using the Toner Saving Mode. All these
eco settings can be easily adjusted using Easy Printer Manager.
Award-winning Samsung Eco Driver extends cost savings with
eco options that reduce toner and paper use by up to 20 percent,
while easing energy consumption. Preview and edit quality, text and
images before printing, and even monitor paper, toner and energy
usage to economise your printing.
Cut costs with fewer replacements
By separating the toner and drum cartridge, Samsung has enabled
users to reduce TCO even further by replacing the drum unit only
when required, rather than with every new toner cartridge. Add to
this the extra-high capacity toner cartridge, and you have a truly
economical ofce printing solution.
Drive productivity while lowering TCO
Toner Cartridge
(40,000 pages)
Drum
(100,000 pages)
One Touch
7,000 pages
20,000 pages
40,000 pages

Print easily, yet safely, on the go with robust document security
Intuitive cloud-based mobility and security
Samsung Cloud Print™ (SCP) enables intuitive connectivity
between mobile devices and printers, enabling you to effortlessly
create, share, edit and print documents from anywhere.
Seamlessly manage document ow from creation to print while
on the go. Plus, embedded security solutions offer safe access
to business-critical data.
1Touchscreen panel is available on M4530NX model only.
Seamless manageability with a secure platform
XOA Web platform supports an array of server-based productivity
solutions to meet your specic business needs. Without the need for
complicated hardware specications, your business can seamlessly
run your custom or independent software vendor (ISV) solutions
on this web-based platform for peak business performance.
Plus, your business can safeguard corporate condentiality
with security-enhanced functions.
Productivity
Solutions
Server
Fleet
Management
Output
Management
Mobility Document
Distribution
Management
AP
Web Server
Firmware
Mobilise your printing with a tap
The Samsung Wireless and Near-Field Communication (NFC) option
supports convenient mobile printing and intuitive keypad functionality
for secure print release:
.User authentication: Authorise printing to a Samsung printer
directly from your mobile device.
.Secure printing: Use your mobile device to authorise secure
release of documents held in the printer’s memory for retrieval.
.Easy wireless setup: Congure print functions from your mobile
device without complicated activation steps.
.Device cloning: Create a multi-device network environment from
virtually anywhere using your mobile device.
Easy, secure touch-to-print functionality
The simple-to-use 4.3” touchscreen1or 4-line LCD control panel
and built-in numeric keypad offer convenient access to a wide array
of features and settings. And with the numeric keypad, users can
safeguard personal and condential documents by entering a PIN
to release print jobs.
All-in-one
Wireless &
NFC Option
User
Authentication
Secure Printing
Easy to Set Up
& Manage

Optional Paper Tray
(550 sheets,
Supports up to 4 EA)
Short Stand
4.3” Touch Screen Panel 4-line LCD + Numeric Keypad
2 GB
Memory
(DDR)
Congurations & Options
Congurable devices for optimised performance
Businesses of varying sizes and industries can meet their specic needs with ProXpress M4530ND / M4530NX’s unique conguration capabilities.
Factory-provided modules serve as a basis upon which differing components are chosen along with a wide array of optional components, including,
but not limited to, a wireless and NFC option and various stand sizes.
Wireless & NFC Option*
M4530NX M4530ND
320 GB HDD
(M4530ND only)
• IEEE 802.11 b/g/n
• NFC (Active Type)
Select from a range of options to create a tailor-made MLP

M4530NX I M4530ND
Samsung A4 Mono Laser Printer
Technical details
M4530NX M4530ND
General
Functions Standard
Print
Value Added
4.3” Touch-Screen LCD / XOA Web XOA Web
Processor
Dual Core 1GHz (C4N + A1000 )
Memory Standard
1 GB 512 MB
Max
2 GB
Interface Standard
Hi-Speed USB 2.0 Device (1EA), Host (2EA ), Ethernet 10/100/1000 Base TX
Optional
IEEE 802.11 b/g/n, NFC active
Power Consumption
less than 16 W (Ready) / 850 W (Normal operation) / 850 W (Max/Peak) / 1.5W (Sleep) / 0.45 W (Power off) / 2.45 KWh/week (TEC)
Noise Level
Less than 54 dBA (Printing) / Less than 30 dBA (Standby)
Dimension (WxDxH)
433 x 459.5 x 408.8 mm (17” x 18.1” x 16.1” ) 433 x 459.5 x 390.7 mm (17” x 18.1” x 15.4” )
Weight
22.0 kg (48.5 lb)
Max. Monthly Duty Cycle
200,000 Pages
Storage Standard
320 GB N/A
Optional
N/A 320 GB HDD
Operational Panel
4.3” Touch Screen LCD 4 Line LCD
Print
Speed (Mono)
45 ppm in A4 (47 ppm in Letter)
First Print Out Time (Mono)
6.5 sec (From ready)
Resolution
Up to 1,200 x 1,200 dpi Effective Output (600 x 600 x 2 bit)
Emulation
PCL5e / PCL6 / PostScript3 / PDF Direct V1.7 / XPS / TIFF / URF / PWG
Duplex Print
Built-in
Client OS
Support
Windows
XP (32 / 64bit) / Vista (32 / 64bit) / 2003 Server (32 / 64bit) / 2008 Server (32 / 64bit) / Win7 (32 / 64bit) / 2008 Server R2 (64bit) / Win8 (32 / 64bit) /
Win8.1 (32 / 64bit) / 2012 Server (64bit) / 2012 Server R2 (64bit)
Linux
RedHat Enterprise Linux WS 5, 6 / Fedora 12, 13, 14, 15, 16, 17, 18, 19, 20 / openSuSE 11.2, 11.3, 11.4, 12.1, 12.2, 12.3 /
Ubuntu 10.04, 10.10, 11.04, 11.10, 12.04, 12.10, 13.04, 13.10, 14.04 / SuSE Linux Enterprise Desktop 10, 11 / Debian 6, 7 / Mint 13, 14, 15, 16
UNIX
Sun Solaris 9,10,11 (x86, SPARC) / HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC, Itanium) / IBM AIX 5.1, 5.2, 5.3, 5.4, 6.1, .7.1 (PowerPC)
Mac OS
X 10.5 - 10.9
Direct Print Support
Yes
Print Features
Automatic Double Sided Print / Direct Print / Secure Print
Solutions
SyncThru™ Admin / SecuThru™ Lite* / Usage Tracker
Paper
Handling
Input
Capacity
Standard
550 Sheets Cassette Tray (@75gsm) / (520 Sheets @80gsm)
Multipurpose
100 Sheet MP Tray (@80gsm)
Other Options
550 Sheet SCF (@75gsm) x 4
Maximum
2,850 Sheet Cassette Tray (550 Std + 100 MP + 4 x 550 SCF)
Standard
Cassette
Tray
Capacity
550 Sheets (@75 gsm)
Media size
A4 / A5 / A6 / Letter / Legal / Ocio / Folio / JIS B5 / ISO B5 / Executive / Statement / PostCard 4x6 / Envelope Monarch / Envelope No 9 /
Envelope No 10 / Envelope DL / Envelope C5 / Envelope C6 / Custom
Media type
Plain / Thin / Bond / Punched / Pre-Printed / Recycled / Envelope / Label / CardStock / Letterhead / Thick / Cotton / Coloured / Archive
Media weight
Supported Weight: 60 - 163 g/m2 (16 - 43 lb), Thin Paper (60 - 69 g/m2) / Plain Paper (70 - 90 g/m2) / Thick Paper (91 - 120 g/m2) /
Bond Paper (105 - 120 g/m2) / Cardstock (121 - 163 g/m2)
Multipurpose
Tray
Capacity
100 Sheets
Media size
Min : 76.2 mm x 127 mm (3”x5”) / Max : 216 mm x 356 mm (8.5”x14.0”)
Media type
Plain / Thin / Bond / Pre-printed / Recycled / Envelope / Label / Cardstock / Thick / Cotton / Coloured / Archive / Thicker
Media weight
Supported Weight: 60 - 220 g/m2 (16 ~ 59 lb), Thin Paper (60 - 69 g/m2) / Plain Paper (70 - 90 g/m2) / Thick Paper (90 - 120 g/m2) /
Bond Paper (105 - 120 g/m2) / Cardstock (121 - 163 g/m2) / Thicker Paper (164 - 220 g/m2)
Other
Options
Capacity
550 Sheets @ 75 g/m2
Media size
A4 / A5 / A6 / Letter / Legal / Ocio / Folio / JIS B5 / ISO B5 / Executive / Statement / PostCard 4x6 / Envelope B5 /
Envelope Monarch / Envelope COM-10 / Envelope DL / Envelope C5 / Envelope C6 / Custom
Media type
Plain Paper / Thin Paper / Bond / Punched / Pre-Printed / Recycled / Envelope / Label / CardStock / Letterhead / Thick / Coloured / Archive
Media weight
Supported Weight: 60 - 163 g/m2 (16 - 43 lb), Thin Paper (60 - 70 g/m2) / Plain Paper (70 - 90 g/m2) / Thick Paper (91 - 105 g/m2) /
Bond Paper (105 - 120 g/m2) / Cardstock (121 - 163 g/m2)
Output Capacity
500 Sheets Face Down
Supplies
Toner (Black)
Yield
Standard: 7,000 Pages* / High Yield: 20,000 Pages* / Extra High Yield: 40,000 Pages* / *Declared Cartridge Yield in Accordance With ISO/IEC 19752
Model Code
MLT-D304S / MLT-D304L / MLT-D304E
Drum Unit
Yield
100,000 Pages (* based on simplex 3 average letter/A4-size pages per print job and ~ 5% coverage)
Model Code
MLT-R304
Option
Second Cassette Tray (SL-SCF4500), Stand (SL-DSK001S),
Memory Upgrade Kit (SL-MEM001), Wireless LAN (SL-NWE001X (Wireless + NFC ))
Second Cassette Tray (SL-SCF4500), Stand (SL-DSK001S),
Memory Upgrade Kit (SL-MEM001), Wireless LAN (SL-NWE001X (Wireless + NFC))
HDD Kit (SL-HDK4001)

LEGAL AND ADDITIONAL INFORMATION
In modern society, keeping up with technology is critical to the
success of any business or the productivity of any individual.
The choice of technology can be the difference between survival
and leadership.
As the workplace becomes more digitised and the workforce
becomes more mobile, printer and copier devices must also adapt
and evolve.
Printer technology and satisfaction lack the electronics innovation
most employees expect. Nor has there been any major entrant to
help shake change.
Until now.
Samsung is applying its ingenuity to develop breakthrough printing
solutions that ignite productivity. Only Samsung has the electronics
expertise to design and build a printer that ts the way society
works today.
Printing for the modern world has arrived.
Samsung is printing innovation.
For more information
visit www.samsung.com/uk/businessprinters
Real value. True performance.
Always make the right impression
by using genuine Samsung supplies.
About Samsung Electronics Co., Ltd.
Samsung Electronics Co., Ltd. is a global leader in technology, opening
new possibilities for people everywhere. Through relentless innovation
and discovery, we are transforming the worlds of TVs, smartphones,
tablets, PCs, printers, cameras, home appliances, printers, LTE
systems, medical devices, semiconductors and LED solutions. We
employ 286,000 people across 80 countries with annual sales of US
$216.7 billion. To discover more, please visit www.samsung.com.
Copyright © 2016 Samsung Electronics Co., Ltd. All rights reserved. Samsung, Business Core, SecuThru, and
SmarThru are either trademarks or registered trademarks of Samsung Electronics Co., Ltd. Specications and
designs are subject to change without notice. Non-metric weights and measurements are approximate. All
data was deemed correct at time of creation. Samsung is not liable for errors or omissions. All brand, product,
service names and logos are trademarks and/or registered trademarks of their respective owners and are hereby
recognised and acknowledged.
Bonjour is trademark of Apple Inc., registered in the U.S. and other countries. IEEE is a registered trademark of
the Institute of Electrical and Electronic Engineers, Inc.
1Mobile devices need to support NFC technology.
Samsung Electronics Co., Ltd.
Samsung Electronics (UK) Ltd, Samsung House 1000, Hillswood Drive, Chertsey, Surrey, KT16 0PS
www.samsung.com
