Samsung SCP-3430 User manual

SCP-3430/3430H
SCP-2430/2430H
• Powerful 43x optical zoom (3.2 ~ 138.5mm)
• High resolution of 600TV lines (Color)
• Min. illumination of 0.7Lux (SCP-3430H/3430)
0.2Lux (SCP-2430H/2430)
• VPS (SCP-3430H/3430), Intelligent video analytics (object appear/disappear)
• WDR backlight compensation (SCP-3430H/3430)
• Coax Control (CCVC)
SCP-3430/3430H/2430/2430H PTZ dome cameras are able to
capture quality images over expansive areas due to their 43x
optical zoom. These cameras offer clear and vivid images with
600TV lines color resolution and perform perfectly at low light
levels down to 0.7Lux/0.2Lux. The SCP-3430H/2430H cameras
come with a pre-fitted housing for extra convenience.
43x Zoom High Resolution WDR PTZ Dome Camera
43x Zoom
Industry's most powerful PTZ
www.samsungsecurityusa.com
12-2010

SCP-3430HN/2430HN SCP-3430HP/2430HP
VIDEO
Imaging Device 1/4" Ex-view HAD CCD (Double scan)
: SCP-3430H,
1/4" Super HAD CCD II : SCP-2430H
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Effective Pixels 768(H) x 494(V) 752(H) x 582(V)
Scanning System 2 : 1 Interlace
Synchronization Internal / Line lock
Frequency H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Horizontal Resolution Color : 600TV lines, B/W : 700TV lines
Min. Illumination
Color : [email protected] (50IRE), 0.001Lux (Sens-up, 512x) : SCP-3430H
[email protected] (50IRE), 0.0004Lux (Sens-up, 512x) : SCP-2430H
B/W : [email protected] (50IRE), 0.0002Lux (Sens-up, 512x) : SCP-3430H
[email protected] (50IRE), 0.00004Lux (Sens-up, 512x) : SCP-2430H
S / N Ratio 52dB (AGC off, Weight on)
Video Output CVBS : 1.0 Vp-p / 75Ωcomposite
LENS
Focal Length (Zoom Ratio)
3.2 ~ 138.5mm (Optical 43x)
Max. Aperture Ratio 1 : 1.65(Wide) ~ 3.7(Tele)
Angular Field of View H : 61.22°(Wide) ~ 1.47°(Tele) / V : 47.16°(Wide) ~ 1.1°(Tele)
Min. Object Distance 1m (3.28ft)
Focus Control Auto / Manual / One AF
Zoom Movement Speed
3.2sec (Wide to tele)
PAN / TILT
Pan Range 360° Endless
Pan Speed
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
Tilt Range -6° ~ 186°
Tilt Speed
Preset : 600°/sec, Manual : 0.01°/sec ~ 180°/sec (Proportional zoom ratio)
Preset 512
Preset Accuracy ±0.1°
OPERATIONAL
On Screen Display English, Japanese, Spanish, French,
Portuguese, Taiwanese, Korean
English, French, German, Spanish, Italian,
Chinese, Russian, Polish, Czech, Romanian,
Serbian, Swedish, Danish, Turkish, Portuguese
Camera Title Off / On (Displayed 54 characters)
Day & Night Day / Night / Auto / Ext
Backlight Compensation
Off / On (Area setting)
Wide Dynamic Range 128x (52dB)
: SCP-3430H 160x (52dB): SCP-3430H
Contrast Enhancement XDR (Off / Low / Mid / High)
Digital Noise Reduction Adaptive 3D+2D (Off / Low / Mid / High / User)
Digital Image Stabilization
Off / On
Motion Detection Off / Tracking / Detection
Privacy Masking Off / On (12 programmable zones with polygonal masking)
Sens-up (Frame Integration)
2x ~ 512x
Gain Control Off / On
White Balance ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
Electronic Shutter Speed
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
Digital Zoom Off / On (1x ~ 16x)
Digital Flip Off / On
Profile Standard / ITS / Backlight / Day & Night / Gaming / Custom
VPS Off / On
Intelligent Video Fixed / Moved
PIP Off / On
Schedule Day / Time
Alarm 8 In 3 Out
Communication Coaxial control (SPC-300 compatible), RS-485
Protocol Coax : CCVC
RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE
ENVIRONMENTAL
Operating Temperature / Humidity
-50°C ~ +50°C (-58°F ~ +122°F) / Up to 100% RH
Ingress Protection IP66
ELECTRICAL
Input Voltage / Current 24V AC ±10%
Power Consumption Max. 11W / 47W (Fan & heater on)
MECHANICAL
Color / Material Light gray / Aluminum, Plastic (Dome cover : Clear)
Dimensions (WxH) Ø228.0 x 256.0mm (Ø8.98" x 10.08")
Weight 3Kg (6.61 lb)
Ø228 (8.98”) Ø228 (8.98”)
256 (10.08”)
240 (9.45”)
Ø171 (6.73”)
Ø178 (7.01”)
219 (8.622”)
140 (5.51”)
Ø178 (7.01”)
Digital Image Stabilization
0.15 0.04
580TVL 3.6X
V/F Lens
3-Axis
52dB
3.7mm 3mm
12VDC
Driver Tx
12VDC
600TVL
0.04
Lux
3mm
43x Zoom High Resolution WDR PTZ Dome Camera
SCP-3430H/3430/2430H/2430
Specifications
I.E-1007
DISTRIBUTED BY
Dimensions
SCP-3430H//2430H SCP-3430//2430
Unit : mm (inch)
SCP-3430H/2430H
SCP-3430/2430
Accessories (optional):
SCX-300LM
SCX-300WM1
SCX-300CM
SCX-300HM1
not needed for
"H" models
+OR OR
SCX-300KMSCX-300PMSCX-300WM1
+OR
Design and specifications are subject to change without notice.
The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Road, Suite 700, Ridgefield Park, NJ 07660, UNITED STATES
Tol Free : 1-877-213-1222 Fax : [phone]
www.samsungsecurityusa.com
