Samsung SCD-2082 Installation guide

ENGLISH
ITALIANO ČESKY
SCD-2082 Quick Manual
SCD-2082 Guida rapida SCD-2082 Rychly návod
High Resolution Varifocal
Dome Camera
Quick Manual
SCD-2082
MAIN SETUP
1.LENS DC
2.EXPOSURE
5.BACKLIGHT OFF
6.SSNR3 ON
7.DAY/NIGHT AUTO
8.SPECIAL
9.EXIT SAVE
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
BRIGHTNESS / SHUTTER / AGC / SENS-UP / RETURN
ATW / OUTDOOR / INDOOR / MANUAL / AWCSET
ON / OFF
AUTO / COLOR / B/W
SAVE / NOT SAVE / RESET
❶Pan Base : Control panning angle of camera.
❷Rotate Base : Control rotating angle of camera.
❸
x3.6 Vari-focal Lens Module : 2.8 ~ 10.0mm (F1.2).
➍
Video Output Terminal to Monitor
➎
Function Setup switch : Display the menu on the screen and move the cursor to four directions to
confirm status or after changing a selected item.
➏
Video Output Jack : Video signals are output through this port.Connect this port to the Video IN
port of a monitor.
➐
Power input terminal : Connect the power as specified for each model here.
➑
Dome Cover
➒
Shield Case
➋➍ ➊
➐
➑
➎
➒
➏
CONFIG PRINCIPALE
1.OTTICA DC
2.ESPOSIZIONE
4.BIL BIANCO ATW
5.CONTROLUCE OFF
6.SSNR3 ON
7.GIORNO/NOTT AUTO
8.SPECIALE
9.USCITA SAVE
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
LUMINOSITÀ / OTTURATORE / AGC / SENS-UP / RITORNO
ATW / ESTERNO / INTERNO /MANUALE/ AWCSET
ON / OFF
AUTO / COLORE / B/N
SAVE / NOT SAVE / RESET
❶Supporto Pan : Controllo angolo di rotazione orizzontale (pan) della videocamera.
❷Supporto girevole : Controllo angolo di rotazione della videocamera.
❸
Sistema varifocale x3.6 : 2.8 ~ 10.0mm(F1.2).
➍
Terminale uscita video al Monitor
➎
Pulsante Impostazione funzioni : Visualizza il menù e permette di scorrere il cursore in quattro
direzioni per confermare o modi la voce selezionata.
➏
Jack Video in uscita : Porta in uscita per il segnale video. Collegare la porta alla porta video in entrata
di un monitor.
➐
Terminale alimentazione : Collegare l’alimentazione secondo le indicazioni del modello utilizzato.
➑
Custodia a cupola
➒
Custodia di protezione
HLAVNÍ NASTAVENÍ
1.OBJEKTIV DC
2.EXPOZICE
5.PODSVÍCENÍ VYP
6.SSNR3 ZAP
7.DEN/NOC AUTO
8.SPECIÁL
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
JAS / CLONA / AGC / SENS-UP / RETURN
ATW / VENKU / UVNITŘ / RUČNÍ / AWCSET
ZAP / VYP
AUTO / BARVA / ČB
ULOŽIT / NEUKLÁDAT / RESETOVAT
❶Základna otočení : Kontroluje úhel otočení kamery.
❷Základna rotace : Kontroluje rotační úhel kamery.
x3,6 varifokální čočka : 2.8 ~ 10.0mm(F1.2).
➍
Výstup obrazu do monitoru
➎
Tlačítko nastavení funkce : Na obrazovce zobrazí nabídku a přesune kurzor do čtyř směrů k
potvrzení či po změně vybrané položky.
➏
Připojení výstupu obrazu : Skrze tento výstup vychází signál obrazu. Tento výstup připojte ke VSTUPU
obrazu monitoru.
➐
Terminál vstupu napájení : Připojte napájení,jak je to uvedeno pro každý model.
➑
Kryt kopule
➒
Kryt
ESPAÑOLDEUTSCH
SCD-2082 Kurzanleitung SCD-2082 Manual Rápido
FRANÇAIS
SCD-2082 manuel de référence rapide
EINST HAUPTMENÜ
1.LENS DC
2.BELICHTUNG
4.WEIβAB ATW
5.GEGENLICHT AUS
6.SSNR3 EIN
7.TAG/NACHT AUTO
8.SPEZIAL
9.BEENDEN SAVE
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
HELLIGKEIT / SHUTTER / AGC / SENS-UP / ZURÜCK
ATW / AUßEN / INNEN / MANUELL / AWCSET
EIN / AUS
AUTO / COLOR / S/W
❶Supporto Pan : Für die Steuerung des Schwenkwinkels der Kamera.
❷Drehbasis : Für die Steuerung des Drehwinkels der Kamera
❸
x3.6 Objektiv mit variabler Brennweite : 2.8 ~ 10.0mm (F1.2).
➍
Videoausgang für Anschluss von Monitor
➎
Funktion-Setup-Schalter : Anzeigen des Bildschirmmenüs und Bewegen des Cursors in vier
Richtungen zur Statusbestä oder nach Änderung eines Elements.
➏
Video-Out-Anschlussbuchse : Über diesen Port werden Videosignale ausgegeben.Diesen Port mit
dem Port “Video IN” an einem Monitor verbinden.
➐
Netzeingang : Schließen Sie die für das jeweilige Modell angegebene Stromversorgung hier an.
➑
Domekuppel
➒
Abschirmkappe
CONFIG PRINCIPAL
1.LENTE DC
2.EXPOSIC
4.BAL BLAN ATW
5.CONTRALUZ OFF
6.SSNR3 ON
7.DIA/NOCHE AUTO
8.ESPEC
9.SALIR SAVE
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
BRILLO / SHUTTER / AGC / SENS-UP / VOLVER
ATW / EXTER / INTER / MANUAL / AWCSET
ON / OFF
AUTO / COLOR / N/B
SAVE / NOT SAVE / RESET
❶Base de Paneo : Controla el ángulo de paneo de la cámara.
❷Base de rotación : Commande de l’angle de rotation de la caméra.
❸
Módulo del Lente Varifocal x3,6 : 2.8 ~ 10.0mm (F1.2).
➍
Terminal de Salida de Video al Monitor
➎
Botón de Configuración de Funciones : Muestra el menú en la pantalla y desplaza el cursor en las
cuatro direcciones para confirma estado o el cambio de un elemento seleccionado.
➏
Puerto de Salida de Video : Permite la salida de las señales de video. Conecte este puerto al puerto
de entrada de un monitor.
➐
Terminal de entrada de alimentación : Conecte aquí la alimentación apropiada para cada modelo.
➑
Cubierta del Domo
➒
Tapa Protectora
CONFIG PRINCIPALE
1.LENS DC
2.EXPOSITION
4.BAL BLC ATW
5.CONTRE-JOUR ARRET
6.SSNR3
MARCHE
7.JOUR/NUIT AUTO
8.SPECIAL
9.QUITTER SAVE
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
Ķ
DC
LUMINOSITE / OBTURATEUR / AGC / SENS-UP / RETOUR
ATW / EXTER / INTER /MANUEL/ AWC SET
MARCHE / ARRET
AUTO / COULEUR / N/B
❶Base panoramique : Commande de l’angle panoramique de la caméra.
❷Base de rotation : Permet de commanderl’angle de rotation de la caméra.
❸
Module de lentille avec zoomx3.6 : 2.8 ~ 10.0mm (F1.2).
➍
Terminal de sortie vidéo vers lemoniteur
➎
Commutateur de configuration desfonctions: Affiche le menu sur l’écran et déplace le curseur
dans les quatre directions, pour confirmer,ou après une modification d’un élément sélectionné.
➏
Prisede sortie vidéo : Les signaux vidéo sont émis via ce port. Raccordez ce port au portd’entrée
(IN) d’un moniteur.
➐
Terminal d’entrée d’alimentation : Raccordez l’alimentation selon la manière spécifiée ici pour
chaque modèle.
➑
Couvercledu dôme
➒
Boîtier de protection
