Samsung SIR-4260V User manual

Design and specifications are subject to change without notice.
I.E-0911
DISTRIBUTED BY
The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
High Resolution IR LED Vandal-Resistant Dome Camera
SIR-4260V
Digital Image Stabilization
0
52dB
COAX
3.6X
IR LED
IR MODE
SAMSUNG TECHWIN CO., LTD.
145-3, Sangdaewon 1-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do Korea 462-703
Tel : [phone]~8 Fax : [phone]
www.samsungcctv.com
SAMSUNG TECHWIN AMERICA Inc.
1480 Charles Willard St, Carson, CA 90746, UNITED STATES
Tol Free : [phone] Fax : [phone]
www.samsungcctvusa.com
SAMSUNG TECHWIN EUROPE CO., LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS
Tel : [phone] Fax : [phone]
TIANJIN SAMSUNG TECHWIN OPTO-ELECTRONICS CO., LTD.
No.11 Wei 6 Street. Micro-Electronic Industrial Park
Jingang Road, Tianjin, P.R. CHINA 300385
Tel : [phone] Fax : [phone]
Specifications
ELECTRICAL
Input Voltage
Power Consumption
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N (Y signal)
Video Output
LENS
Zoom Ratio
Focal Length
Max. Aperture Ratio
Min. Object Distance
Angular Field of View
Focus
Iris Control
PAN / TILT / ROTATE
Pan Range
Tilt Range
Rotate Range
OPERATIONAL
On Screen Display
Camera Title
Day & Night
SSDR
Backlight Compensation
Motion Detection
Digital Image Stabilization
Privacy Masking
2D+3D Noise Filter (SSNRIII)
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Communication
ENVIRONMENTAL
Operating Temperature / Humidity
Storage Temperature / Humidity
MECHANICAL
Dimension (WxH)
Weight
IR LED
IR Distance
Ingress Protection
Certifications
SIR-4260VN SIR-4260VP
Dual (12V DC/ 24V AC)
Max. 5.5W (LED On), Max. 15W (Heater On, Option)
1/3" Super HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H :15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines (Min.) / B/W : 700TV lines (Min.)
Color : 0.15Lux ([email protected]), 0.0003Lux (Sens-up, 512X)
B/W : 0Lux (LED on)
52dB
CVBS : 1.0Vp-p / 75
3.6X (Manual)
2.8 ~ 10mm (F1.2)
1 : 1.2(Wide) ~ 2.8(Tele)
0.2m (0.66ft)
H : 94.4°(Wide) ~ 28°(Tele) / V : 69.2°(Wide) ~ 21°(Tele)
Auto / Manual / One-push
Auto / Manual
0° ~ 340°
0° ~ 146°
0° ~ 340°
Korea, English, Japan, English, French, German, Spanish, Italian,
Spanish, French, Portuguese Chinese, Russian, Polish, Czech
On / Off (Displayed 15 characters)
Auto (ICR) / Color / B/W
On / Off (Level adjustable)
BLC / HLC / Off
On / Off
On / Off
On / Off (8 Programmable zones)
On / Off
Auto / Off (Selectable limit ~ 256X )
Low / High / Off
ATW / AWC / Manual / Indoor / Outdoor
Fixed (1/60 / Flickerless) Fixed (1/50 / Flickerless)
On / Off
Coaxial (Protocol : Pelco Coaxitron), RS-485
-10°C ~ +50°C / 20% ~ 80% RH
-20°C ~ +60°C / 20% ~ 95% RH
Ø148 x 126mm (Ø5.83" x 4.96")
1.3Kg (2.87 lb)
10EA
30m (98.4ft)
IP66
FCC (Class A), UL/cUL listed CE (Class A)
Dimensions
Accessories
Unit : mm (inch)
148 (5.83")
126 (4.96")
85 (3.35")
83.5 (3.29")
46
(1.81")
85 (3.35")
STB-319VPW STB-249VPW STB-225VW STB-275VW STB-250VCW
Pendant Mount Wall Mount Corner Mount
SIR-4260V
• IR vandal-resistant dome camera with a horizontal resolution of 600 TV lines
• Visibility of 30m (high performance black IR LED)
• 3.6X varifocal lens (2.8 ~ 10mm)
• Dustproof and waterproof (IP66)
• OSD menu access via coaxial telemetry
www.samsungcctv.com
High Resolution IR LED Vandal-Resistant Dome Camera
Ultra Low Light Levels of 0 Lux!
Shine Through
the Darkness
REVISED 11-2009

High Resolution IR LED Vandal-Resistant Dome Camera ISIR-4260V
Featuring DSP,
Superb Color Image Quality
at 600TV lines Resolution!
Thanks to the Samsung Techwin DSP W-Vchipset, the SIR-
4260V boasts stable and precise image processing, delivering
high-quality images with a color resolution of 600TV lines.
0Lux, No Additional Illumination required
With built-in high performance black IR LEDs, which are up to
four times brighter than normal ones, the SIR-4260V can
capture even tiny movements up to 30 meters in complete
darkness of 0Lux.
0
Indoor Visibility of 30m!
Conventional Camera
SIR-4260V
Conventional Camera SIR-4260V
EIAJ TEST CHART
600TV lines
The SIR-4260V is a high resolution IR LED camera that can capture images within 30
meters in extremely low or no lighting using its built-in black IR LED lamps. In addition,
it boasts excellent performance in monitoring inside factories, warehouses and
stores. The rugged dome exterior sports superior physical shock resistance against
accidents and vandals.
High Resolution Black IR LED
Vandal-Resistant Dome Camera SIR-4260V
Easier to Install
With the use of the same accessories as the existing
vandal-resistant dome cameras, the SIR-4260V is
easier to install.
SSDR (Samsung Super Dynamic Range)
Under backlit conditions, where there is a clear
distinction between bright and dark areas, the SIR-
4260V selectively brightens dark sections, ensuring
virtually homogeneous brightness across the image.
SSNRIII (Samsung Super Noise Reduction)
The SIR-4260V ensures clear and sharp images in
low lighting by eliminating “image noise” with its
high performance W-VDSP chips.
Various Digital Features
Backlight Compensation (HLC, SSDR)
: The camera displays clear images captured under backlit conditions.
Multiple Language OSD
: You can select a language you want, such as English, French,
Spanish and Italian.
Motion Detection
: The camera detects moving objects without exterior sensors.
Supporting COAX Communications
: Coaxial control enables OSD control.
Versatile Varifocal Lens
: The built-in 3.6X, 2.8-to-10-millimeter varifocal lens enables
flexible adjustments of viewing angles.
Samsung Techwin's Proprietary Technology
DSP for High Resolution Monitoring
W-V, an embodiment of Samsung Techwin's commitment to techno-
logical development, is a fifth-generation DSP chipset that enables
high resolution of 600TV lines. Samsung Techwin packs quite a bit of
technology into the small chip to deliver unmatched cost-effectiveness.
The chip features SSNRIII “image noise” elimination using upgraded
2D/3D filtering to ensure clear images in the darkness, day & night,
SSDR, HLC highlight backlight compensation, image stabilization,
multiple language OSD and other high-end features.
Clear Images of Close Objects
in IR Mode
In IR mode, the SIR-4260V suppresses image blur
with an IR LED lamp in B/W mode, ensuring clear
images when shooting close objects.
IR MODE
Conventional Camera
SIR-4260V
Conventional Camera SIR-4260V Conventional Camera SIR-4260V
